Nissan NV Passenger Van (2018 year). Manual - part 10

Rear door

Turning the key toward the left

䊊

of the

vehicle locks the rear doors.

Turning the key to the right

䊊

of the vehicle

unlocks the rear doors.

Power (with vehicle security
system) (if so equipped)

The power door lock system with vehicle
security system allows you to lock all doors
at the same time.

Front and sliding doors

Turning the key toward the front

䊊

of the

vehicle locks all the doors.

Turning the key one time toward the rear

䊊

of the vehicle unlocks that door. From that
position, returning the key to neutral

䊊

(where the key can only be removed and
inserted) and turning it toward the rear
again within 5 seconds unlocks all doors

䊊

Rear door

Turning the key toward the left

䊊

of the

vehicle locks all the doors.

Turning the key one time toward the right

䊊

of the vehicle unlocks that door. From that
position, returning the key to neutral

䊊

(where the key can only be removed and
inserted) and turning it toward the right
again within 5 seconds unlocks all doors

䊊

LPD2671

LPD0483

LPD2670

3-4

Pre-driving checks and adjustments

LOCKING WITH INSIDE LOCK KNOB

To lock the door without the key, move the
inside lock knob to the lock position

䊊

then close the door.

To unlock the door without the key, move the
inside lock knob to the unlock position

䊊

To lock the door without the key, move the
inside lock knob to the lock position

䊊

then close the door.

To unlock the door without the key, move the
inside lock knob to the unlock position

䊊

To lock the door without the key, move the
inside lock knob to the lock position

䊊

then close the door.

To unlock the door without the key, move the
inside lock knob to the unlock position

䊊

To open the door from the inside, pull the
inside door handle toward you.

Inside lock – front doors

LPD2000

Inside lock – sliding door

LPD2003

Inside lock – back door

LPD2001

Pre-driving checks and adjustments

3-5

LOCKING WITH POWER DOOR
LOCK SWITCH

To lock all the doors without a key, push the
door lock switch (driver’s or front passen-
ger’s side) to the lock position

䊊

. When

locking the door this way, be certain not to
leave the key inside the vehicle.

To unlock all the doors without a key, push
the door lock switch (driver’s or front pas-
senger’s side) to the unlock position

䊊

Lockout protection

When the power door lock switch (driver’s
or front passenger’s side) is moved to the
lock position with the key in the ignition
switch while any door is open, all doors will
lock and then unlock automatically. This
helps to prevent the keys from being acci-
dently locked inside the vehicle.

OPERATING THE SLIDING DOOR

The sliding door can be opened from the
inside or the outside.

To open the sliding door from the inside,
pull the release lever

䊊

down and pull the

handle

䊊

toward the rear of the vehicle

until the door clicks. This will lock the door
into an open position.

To close the sliding door from the inside
pull the release lever

䊊

down. The door will

release from the open position. Slide the
door forward to close.

Driver’s and passenger’s side

WPD0381

Right side only

LPD2002

3-6

Pre-driving checks and adjustments

To open a sliding door from the outside, pull
out the outside handle and slide the door
toward the rear of the vehicle until the door
clicks. The door will lock into an open posi-
tion.

To close the sliding door from the outside,
pull the outside handle again. The door will
release from the open position and slide
closed.

BACK DOORS

CAUTION

Do not operate the 243° release lever
until the door has been fully opened.
Doing so can result in damage to the
vehicle

and/or

malfunction

the

mechanism.

Open the back doors by performing the
following:

1. From the outside of the vehicle, pull the

door handle on the right side door to-
ward you and open door until it stops.

2. Lift the lever

䊊

on the side of the left

back door and pull the door to open
until the door stops

䊊

LPD2051

Pre-driving checks and adjustments

3-7

The back doors open approximately 243°
to allow access to the rear of the vehicle.

3. To open either door to the wide open

position

䊊

pull the release lever

䊊

to-

ward the back door and release the
check link arm

䊊

4. Open the door slowly until the mag-

netic door stopper connects to the
stop pad on the outside of the vehicle.
Do not use the stopper as a step.

5. To close the doors from the outside,

close the left door until it latches, then
close the right door until it latches.

AUTOMATIC DOOR LOCKS
(if so equipped)

∙ All doors lock automatically when the

vehicle

speed

reaches

mph

(24 km/h).

∙ All doors unlock automatically when the

transmission is placed in the P (Park)
position, when the ignition is turned to
the OFF position, or when the key is re-
moved from the ignition.

CHILD SAFETY SLIDING DOOR LOCK

The child safety lock helps prevent the slid-
ing door from being opened accidentally,
especially when small children are in the
vehicle.

The child safety lock lever is located on the
edge of the sliding door.

When the lever is in the unlock position, the
door can be opened from the outside or
the inside.

When the lever is in the LOCK position,
the door can be opened only from the
outside.

LPD2009

LPD2050

3-8

Pre-driving checks and adjustments

WARNING

∙ Radio waves could adversely affect

electric medical equipment. Those
who use a pacemaker should contact
the

electric

medical

equipment

manufacturer for the possible influ-
ences before use.

∙ The remote keyless entry key fob

transmits radio waves when the but-
tons are pressed. The FAA advises ra-
dio waves may affect aircraft naviga-
tion and communication systems. Do
not operate the remote keyless entry
key fob while on an airplane. Make
sure the buttons are not operated un-
intentionally when the unit is stored
for a flight.

It is possible to lock/unlock all doors, turn
the interior light on, and activate the panic
alarm by using the key fob from outside the
vehicle.

Some settings for the key fob, such as horn
beep, can be adjusted. For additional infor-
mation, refer to “Silencing the horn beep
feature” in this section.

Be sure to remove the key from the ve-
hicle before locking the doors.

The key fob can operate at a distance of
approximately 33 ft (10 m) from the vehicle.
The effective distance depends upon the
conditions around the vehicle.

As many as five key fobs can be used with
one vehicle. For information concerning
the purchase and use of additional key
fobs, it is recommended that you visit a
NISSAN dealer.

The key fob will not function when:

∙ The battery is discharged.

∙ The distance between the vehicle and

the key fob is over 33 ft (10 m).

The panic alarm will not activate when
the key is in the ignition switch.

CAUTION

Listed below are conditions or occur-
rences which will damage the key fob:

∙ Do not allow the key fob, which con-

tains electrical components, to come
into contact with water or salt water.
This could affect the system function.

∙ Do not drop the key fob.

∙ Do not strike the key fob sharply

against another object.

∙ Do not change or modify the key fob.

∙ Wetting may damage the key fob. If

the key fob gets wet, immediately
wipe until it is completely dry.

∙ Do not place the key fob for an ex-

tended period in an area where tem-
peratures exceed 140°F (60°C)

∙ Do not attach the key fob with a key

holder that contains a magnet.

∙ Do not place the key fob near equip-

ment that produces a magnetic field,
such as a TV, audio equipment and
personal computers.

If a key fob is lost or stolen, NISSAN rec-
ommends erasing the ID code of that
key fob. This will prevent the key fob
from unauthorized use to unlock the
vehicle. For information regarding the
erasing procedure, it is recommended
that you visit a NISSAN dealer.

REMOTE KEYLESS ENTRY SYSTEM

Pre-driving checks and adjustments

3-9

HOW TO USE REMOTE KEYLESS
ENTRY SYSTEM

Locking doors

1. Close all windows.

2. Remove the key from the ignition

switch.

3. Close the hood and all doors.

4. Press the

button on the key fob.

All the doors lock. The hazard warning
lights flash twice and the horn beeps
once to indicate all doors are locked.

∙ When the

button is pressed

with all doors locked, the hazard warn-
ing lights flash twice and the horn
beeps once as a reminder that the
doors are already locked.

∙ If a door is open and you press

the

button, the doors will lock

but the horn will not beep and the haz-
ard warning lights will not flash.

The horn may or may not beep. For addi-
tional information, refer to “Silencing the
horn beep feature” in this section.

Unlocking doors

Press the

button on the key fob once.

∙ Only the driver’s door unlocks.

∙ The hazard warning lights flash once if

all doors are completely closed with the
ignition switch in any position except
the ON position.

∙ The interior lights turn on and the light

timer activates for a period of time
when the interior light switch is in the
center position with the ignition switch
in any position except the ON position.

LPD0209

LPD0210

3-10

Pre-driving checks and adjustments

Press the

button on the key fob again

within 5 seconds.

∙ All doors unlock.

∙ The hazard warning lights flash once if

all doors are completely closed.

The interior lights can be turned off without
waiting by inserting the key into the ignition
switch and placing it in the ON or START
position, locking the doors with the key fob
or pushing the interior light switch to the
OFF position.

Auto relock (if so equipped)

When the

button on the key fob is

pressed, all doors will lock automatically
within 1 minute unless one of the following
operations is performed:

∙ Any door is opened.

∙ A key is inserted into the ignition switch

and the switch is cycled from OFF to ON.

Using the panic alarm

If you are near your vehicle and feel threat-
ened, you may activate the panic alarm to
call attention by pressing and holding
the

button on the key fob for longer

than 0.5 seconds.
The panic alarm and headlights will stay on
for a period of time.

The panic alarm stops when:

∙ It has run for a period of time.

∙ Any button is pressed on the key fob.

Using the interior lights

Press the

button on the key fob once

to turn on the interior lights.
For additional information, refer to “Interior
lights” in the “Instruments and controls”
section of this manual.

LPD2497

Pre-driving checks and adjustments

3-11

Silencing the horn beep feature

If desired, the horn beep feature can be
deactivated using the key fob.

To deactivate: Press and hold the
and

buttons for at least 2 seconds.

The hazard warning lights will flash three
times to confirm that the horn beep fea-
ture has been deactivated.

To activate: Press and hold the
and

buttons for at least 2 seconds

once more.

The hazard warning lights will flash once
and the horn will sound once to confirm
that the horn beep feature has been reac-
tivated.

Deactivating the horn beep feature does
not silence the horn if the alarm is trig-
gered.

LPD0262

3-12

Pre-driving checks and adjustments

1. Pull the hood lock release handle

䊊

located below the driver side instru-
ment panel. The hood will spring up
slightly.

2. Push the lever

䊊

at the front of the

hood to the side as illustrated with your
fingertips and raise the hood.

When closing the hood, lower it slowly and
make sure it locks into place.

WARNING

∙ Make sure the hood is completely

closed and latched before driving.
Failure to do so could cause the hood
to fly open and result in an accident.

∙ If you see steam or smoke coming

from the engine compartment, to
avoid injury do not open the hood.

OPENING THE FUEL-FILLER DOOR

Pull on the finger tab to open.

LPD2006

LPD2005

HOOD

FUEL-FILLER DOOR

Pre-driving checks and adjustments

3-13

FUEL-FILLER CAP

WARNING

∙ Gasoline is extremely flammable and

highly explosive under certain condi-
tions. You could be burned or seri-
ously injured if it is misused or mis-
handled. Always stop the engine and
do not smoke or allow open flames or
sparks

near

the

vehicle

when

refueling.

∙ Do not attempt to top off the fuel tank

after the fuel pump nozzle shuts off
automatically.

Continued

refueling

may cause fuel overflow, resulting in
fuel spray and possibly a fire.

∙ Use only an original equipment type

fuel-filler cap as a replacement. It has
a built-in safety valve needed for
proper operation of the fuel system
and emission control system. An in-
correct cap can result in a serious mal-
function and possible injury. It could
also cause the

Malfunction Indi-

cator Light (MIL) to come on.

∙ Never pour fuel into the throttle body

to attempt to start your vehicle.

∙ Do not fill a portable fuel container in

the vehicle or trailer. Static electricity
can cause an explosion of flammable
liquid, vapor or gas in any vehicle or
trailer. To reduce the risk of serious
injury or death when filling portable
fuel containers:

– Always place the container on the

ground when filling.

– Do not use electronic devices when

filling.

– Keep the pump nozzle in contact

with the container while you are
filling it.

– Use only approved portable fuel

containers for flammable liquid.

CAUTION

∙ Do not use E-15 or E-85 fuel in your

vehicle. For additional information,
refer to “Fuel recommendation” in the
“Technical and consumer informa-
tion” section of this manual.

∙ The LOOSE FUEL CAP warning will ap-

pear if the fuel-filler cap is not prop-
erly tightened. It may take a few driv-
ing trips for the message to be
displayed. Failure to tighten the fuel-
filler cap properly after the LOOSE
FUEL CAP warning appears may cause
the

Malfunction Indicator Light

(MIL) to illuminate.

LPD2668

3-14

Pre-driving checks and adjustments

∙ Failure to tighten the fuel-filler cap

properly may cause the

Mal-

function Indicator Light (MIL) to illumi-
nate. If the

light illuminates be-

cause the fuel-filler cap is loose or
missing, tighten or install the cap and
continue

drive

the

vehicle.

The

light should turn off after a

few driving trips. If the

light does

not turn off after a few driving trips,
have the vehicle inspected. It is rec-
ommended that you visit a NISSAN
dealer for this service.

∙ For additional information, refer to

“Malfunction Indicator Light (MIL)” in
the “Instruments and controls” sec-
tion of this manual.

∙ If fuel is spilled on the vehicle body,

flush it away with water to avoid paint
damage.

To remove the fuel-filler cap:

1. Turn the fuel-filler cap counterclock-

wise to remove.

2. Loop the tether strap around the hook

䊊

while refueling.

To install the fuel-filler cap:

1. Insert the fuel-filler cap straight into the

fuel-filler tube.

2. Turn the fuel-filler cap clockwise until a

single click is heard.

LOOSE FUEL CAP warning

The LOOSE FUEL CAP warning appears in
the trip computer when the fuel-filler cap is
not tightened correctly after the vehicle
has been refueled. It may take a few driving
trips for the message to be displayed. To
turn off the warning, perform the following:

1. Remove and install the fuel-filler cap as

soon as possible.

2. Tighten the fuel-filler cap until it clicks.

LPD2669

LPD2008

Pre-driving checks and adjustments

3-15

3. Press the INFO knob

䊊

on the instru-

ment panel located behind the steer-
ing wheel for about one second to turn
off the LOOSE FUEL CAP warning

䊊

after tightening the fuel-filler cap.

TILT OPERATION

WARNING

∙ Do not adjust the steering wheel while

driving. You could lose control of your
vehicle and cause an accident.

∙ Do not adjust the steering wheel any

closer to you than is necessary for
proper steering operation and com-
fort. The driver’s air bag inflates with
great force. If you are unrestrained,
leaning forward, sitting sideways or
out of position in any way, you are at
greater risk of injury or death in a
crash. You may also receive serious or
fatal injuries from the air bag if you
are up against it when it inflates. Al-
ways sit back against the seatback
and as far away as practical from the
steering wheel. Always use the seat
belts.

Pull the lock lever toward the driver and
hold it to adjust the steering wheel up or
down to the desired position.

Release the lock lever to lock the steering
wheel in place.

LPD2012

STEERING WHEEL

3-16

Pre-driving checks and adjustments

1. To block out glare from the front, swing

down the sun visor

䊊

2. To block glare from the side, discon-

nect the sun visor from the center
mount and swing it to the side

䊊

STORAGE CLIP

To access the storage clip, pull the sun visor
down. Insert items such as business cards,
directions, etc. under the clip. Do not view
information while operating the vehicle.

MANUAL ANTI-GLARE REARVIEW
MIRROR (if so equipped)

Use the night position

䊊

to reduce glare

from the headlights of vehicles behind you
at night.

Use the day position

䊊

when driving in

daylight hours.

WARNING

Use the night position only when neces-
sary, because it reduces rear view
clarity.

LPD2021

Driver’s and passenger’s side

LPD2007

WPD0126

SUN VISORS

MIRRORS

Pre-driving checks and adjustments

3-17

AUTOMATIC ANTI-GLARE
REARVIEW MIRROR (if so equipped)

The inside mirror is designed so that it au-
tomatically dims during night time condi-
tions and according to the intensity of the
headlights of the vehicle following you. The
automatic anti-glare feature is activated
when the ignition switch is placed in the ON
position.

NOTE:

Do not hang any objects over the sen-
sors

䊊

or apply glass cleaner to the sen-

sors. Doing so will reduce the sensitivity
of the sensors, resulting in improper op-
eration.

The indicator light

䊊

will illuminate when

the automatic anti-glare feature is operat-
ing.

With the ignition switch placed in the ON
position, press the

button as de-

scribed:

∙ To turn off the anti-glare feature, press

and hold the

button for 8 sec-

onds. The indicator light will turn off.

∙ To turn on the anti-glare feature, press

and hold the

button again for

8 seconds. The indicator light will turn
on.

For information on the compass display

䊊

(if so equipped), refer to “Compass display”
in the “Instruments and controls” section of
this manual.

LPD2315

3-18

Pre-driving checks and adjustments

OUTSIDE MIRRORS

WARNING

Objects viewed in the convex portion of
the mirror are closer than they appear.
Be careful when changing lanes or turn-
ing. Using only the convex mirror could
cause an accident. Use the other mir-
rors or glance over your shoulder to
properly

judge

distances

other

objects.

Use the outside mirror remote control to
adjust the top portion of the mirror.

The lower portion of the mirror can be
moved manually in any direction for a bet-
ter rear view.

Pull the trailer tow mirror outward to ex-
tend it to the desired position for better
visibility while towing a trailer.

WARNING

Do not extend or retract mirrors while
driving. You may lose control of your ve-
hicle and cause an accident.

CAUTION

Driving in tight spaces with mirrors ex-
tended may cause damage to the
vehicle.

Type A (if so equipped)

LPD2017

Type B (Trailer tow) (if so equipped)

LPD0279

Trailer tow extension

LPD0268

Pre-driving checks and adjustments

3-19

Content .. 8 9 10 11 ..
