COMBINATION METER
*1 : With NAVI
*2 : Without NAVI
32
(Y)
Ground
Oil level sensor signal
Input
Ignition
switch
ON
—
Refer to
.
NOTE:
The measurement cannot be
performed because the signal is
input for a moment with the igni-
tion switch ON.
33
(P)
Ground
Oil level sensor signal
ground
—
Ignition
switch
ON
—
0 V
34
(B)
Ground
Fuel level sensor signal
Input
Ignition
switch
ON
—
35
(O)
Ground
Seat belt buckle switch sig-
nal (driver side)
Input
Ignition
switch
ON
When driver seat belt is fas-
tened
5 V
When driver seat belt is un-
fastened
0 V
36
(GR)
Ground
Seat belt buckle switch sig-
nal (passenger side)
Input
Ignition
switch
ON
• When getting in the pas-
senger seat
• When passenger seat
belt is fastened
12 V
• When getting in the pas-
senger seat
• When passenger seat
belt is not fastened
0 V
37
(R/Y)
Ground
Not manual mode signal
Input
Ignition
switch
ON
Manual mode
12 V
Other than the above
0 V
38
(LG)
Ground
Manual mode shift down
signal
Input
Ignition
switch
ON
Selector lever down opera-
tion
0 V
Other than the above
12 V
39
(G/W)
Ground
Manual mode shift up sig-
nal
Input
Ignition
switch
ON
Selector lever up operation
0 V
Other than the above
12 V
40
(L)
Ground
Manual mode signal
Input
Ignition
switch
ON
Manual mode
0 V
Other than the above
12 V
Terminal No.
(Wire color)
Description
Condition
Value
(Approx.)
+
–
Signal name
Input/
Output
