SERVICE DATA AND SPECIFICATIONS (SDS)

DLN-113

< SERVICE DATA AND SPECIFICATIONS (SDS)

[REAR PROPELLER SHAFT: 3F SPL18-DOJ75]

C

E

F

G

H

I

J

K

L

M

A

B

DLN

N

O

P

SERVICE DATA AND SPECIFICATIONS (SDS)

SERVICE DATA AND SPECIFICATIONS (SDS)

General Specifications

INFOID:0000000000972156

Propeller Shaft Runout

INFOID:0000000000972157

Unit: mm (in)

Journal Axial Play

INFOID:0000000000972158

Unit: mm (in)

Applied model

4WD

 MR20DE

M/T

CVT

Propeller shaft model

3F SPL18-DOJ75

Number of joints

3

Type of journal bearings
(Non-disassembly type)

1st joint

Shell type

2nd joint

Cardan type

3rd joint

Shell type

Coupling method with transfer

Flange type

Coupling method with rear final drive

Flange type

Shaft length

1st (Spider to cardan joint center)

1091 mm (42.95 in)

2nd (Cardan joint center to spider)

831 mm (32.72 in)

Shaft outer diameter

1st

57 mm (2.24 in)

2nd

70 mm (2.76 in)

Item

Limit

Propeller shaft runout

0.6 (0.024)

Item

Standard

Journal axial play

0 (0)

DLN-114

< SYMPTOM DIAGNOSIS >

[REAR FINAL DRIVE: R145]

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

SYMPTOM DIAGNOSIS

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NVH Troubleshooting Chart

INFOID:0000000000972159

Use the chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.

×

: Applicable

Reference

DL

N-1

4

9

, "I

ns

pe

ct

ion

 Af

ter Di

sa

ss

em

bl

y"

DLN

-14

6,

 "Ad

just

m

en

t"

DL

N-1

4

9

, "I

ns

pe

ct

ion

 Af

ter Di

sa

ss

em

bl

y"

DLN

-14

6,

 "Ad

just

m

en

t"

DLN

-14

6,

 "Ad

just

m

en

t"

DLN

-12

0,

 "In

s

p

e

c

ti

o

n"

NVH in DLN section

NVH in F

AX,

RAX, FSU and

R

S

U sections

NVH in WT section

NVH in WT section

NVH i

n

 F

AX and RAX

secti

o

n

NVH in B

R

 section

NVH in S

T

 section

Possible cause and SUSPECTED PARTS

Gea

r to

ot

h ro

ug

h

Ge

ar co

nt

a

c

t im

pro

p

e

r

T

o

o

th su

rfac

es

 wo

rn

Ba

ck

la

sh

 in

co

rrec

t

Com

p

ani

on

 fl

an

ge

 ex

ce

ss

iv

e

run

o

u

t

Ge

ar oi

l im

pro

p

e

r

PROPELLER S

H

AFT

AXLE AND S

U

S

PENSION

TI

RE

S

ROAD WHEE

L

DRIVE SHAFT

BRAKE

S

STE

E

RING

Symptom

Noise

×

×

×

×

×

×

×

×

×

×

×

×

×

PRECAUTIONS

DLN-115

< PRECAUTION >

[REAR FINAL DRIVE: R145]

C

E

F

G

H

I

J

K

L

M

A

B

DLN

N

O

P

PRECAUTION

PRECAUTIONS

Service Notice or Precautions for Rear Final Drive

INFOID:0000000000972160

CAUTION:

• Check for the correct installation status prior to removal or disassembly. If matching marks are

required, be certain they do not interfere with the function of the parts when applied.

• Overhaul should be done in a clean work area, it is preferable to work in dustproof area.
• Before disassembly, using steam or white gasoline, completely remove sand and mud from the exte-

rior of the unit, preventing them from entering into the unit during disassembly or assembly.

• Check appearance of the disassembled parts for damage, deformation, and unusual wear. Replace

them with a new one if necessary.

• Gaskets, seals and O-rings should be replaced any time when the unit is disassembled.
• In principle, tighten bolts or nuts gradually in several steps working diagonally from inside to out-

side. If tightening sequence is specified, observe it.

• Clean and flush the parts sufficiently and blow-dry them.
• Be careful not to damage sliding surfaces and mating surfaces.
• When applying sealant, remove the old sealant from the mounting surface; then remove any mois-

ture, oil, and foreign materials from the application and mounting surfaces.

• Always use shop paper for cleaning the inside of components.
• Avoid using cotton gloves or shop rags to prevent entering of lint.
• During assembly, observe the specified tightening torque, and apply new gear oil, petroleum jelly, or

multi-purpose grease as specified for each vehicle, if necessary.

DLN-116

< PREPARATION >

[REAR FINAL DRIVE: R145]

PREPARATION

PREPARATION

PREPARATION

Special Service Tools

INFOID:0000000000972161

Tool number
Tool name

Description

KV38100200
Drift
a: 65 mm (2.56 in) dia.
b: 49 mm (1.93 in) dia.

• Installing front oil seal
• Installing side oil seal

ST27861000
Drift
a: 62 mm (2.44 in) dia.
b: 52 mm (2.05 in) dia.

Installing front oil seal

ST35271000
Drift
a: 72 mm (2.83 in) dia.
b: 63 mm (2.48 in) dia.

Installing center oil seal

ST22360002
Drift
a: 29 mm (1.14 in) dia.
b: 23 mm (0.91 in) dia.
c: 150 mm (5.91 in)

Installing coupling front bearing

ST33052000
Drift
a: 22 mm (0.87 in) dia.
b: 28 mm (1.10 in) dia.

Removing side bearing inner race

KV38108400
Pinion nut wrench

Removing and installing drive pinion nut

ZZA1143D

ZZA0832D

ZZA0814D

ZZA0546D

ZZA1023D

ZZA1206D
