ECM

EC-1431

< ECU DIAGNOSIS >

[K9K]

C

D

E

F

G

H

I

J

K

L

M

A

EC

N

P

O

JCBWA0209GB

EC-1432

< ECU DIAGNOSIS >

[K9K]

ECM

JCBWA0210GB

ECM

EC-1433

< ECU DIAGNOSIS >

[K9K]

C

D

E

F

G

H

I

J

K

L

M

A

EC

N

P

O

DTC Index

INFOID:0000000000896336

X: Applicable —: Not applicable

JCBWA0211GB

DTC*

Items

(CONSULT-III screen item)

Trip

MI lighting up

Reference page

Yellow

Red

P0001

FUEL SYSTEM

3

–

×

EC-1320

P0002

FUEL SYSTEM

3

–

–

EC-1320

EC-1434

< ECU DIAGNOSIS >

[K9K]

ECM

P0016

COHERENCE CMSFT/SN

3

–

–

EC-1320

P0045

TURBO ACT CIRC

3

–

×

EC-1327

P0069

PRESSURE COHERENCE

3

–

×

EC-1329

P0087

LOW FUEL PRESS

3

–

–

EC-1331

P0090

FUEL SYSTEM

3

–

×

EC-1333

P0100

AIR FLOW SEN CIRC

3

–

–

EC-1335

P0101

AIR FLOW SEN CIRC

3

–

–

EC-1338

P0110

IN-AIR TMP SEN CIR

3

–

–

EC-1341

P0115

WATER TMP SEN

1 or 3

–

–

EC-1343

P0120

TP SEN CIRC

3

–

–

EC-1345

P0180

FUEL TEMP SEN CIRC

1 or 3

–

–

EC-1347

P0190

RAIL/PRESS SEN CIR

3

–

×

EC-1349

P0200

INJECTOR CTRL CIRC

3

–

×

EC-1351

P0201

CYL 1 INJ CTRL CIR

3

×

×

EC-1353

P0202

CYL 2 INJ CTRL CIR

3

×

×

EC-1353

P0203

CYL 3 INJ CTRL CIR

3

×

×

EC-1353

P0204

CYL 4 INJ CTRL CIR

3

×

×

EC-1353

P0217

ENG OVER TEMP

1

–

–

EC-1355

P0225

PDL POTEN CIRC TK1

3

–

×

EC-1358

P0235

IN-MANI PRES CIRC

3

–

×

EC-1361

P0335

ENGNE SPD SEN CIRC

1

–

×

EC-1363

P0340

CAMSHAFT SEN CIRC

3

–

–

EC-1365

P0380

PRHT UNIT CTRL CIR

3

–

–

EC-1368

P0381

PRHT DGNSTC CNECT

3

–

–

EC-1370

P0409

EGR POSITN OFFSET

3

×

–

EC-1372

P0487

EGR COMMAND CIRC

3

–

–

EC-1374

P0488

EGR/V POSITN CTRL

3

–

×

 or –

EC-1376

P0500

VEHL/SPD INF CIRC

1

–

–

EC-1379

P0530

REFRIGERNT SEN CIR

1

–

–

EC-1380

P0560

CPU SUPPLY VOLTAGE

1

–

–

EC-1382

P0571

BRAKE SWITCH CIRC

1

–

–

EC-1385

P0575

SPD LIM/CRS CTRL

1

–

–

EC-1388

P0606

COMPUTER(C/U)

1 or 3

×

 or –

×

EC-1391

P0641

SEN SUPPLY N-1 VOL

3

–

×

EC-1393

P0651

SEN SUPPLY N-2 VOL

3

–

×

EC-1395

P0685

MAIN RLY CTRL CIRC

3

–

×

EC-1397

P0812

REVERSE INFO

1

–

–

EC-1399

P0830

CLUTCH SWITCH CIRC

1

–

–

EC-1400

P1089

RAIL PRESS REGULTN

3

–

×

 or –

EC-1402

P2101

ETC FUNCTION/CIRC

3

–

–

EC-1404

P2120

PDL POTEN CIRC TK2

3

–

×

EC-1407

P2226

ATMOS PRES SE CIR

3

–

–

EC-1409

P2263

T/C SYSTEM

3

–

×

EC-1410

DTC*

Items

(CONSULT-III screen item)

Trip

MI lighting up

Reference page

Yellow

Red
