ENGINE MAINTENANCE (HR16DE)
MA-27
< ON-VEHICLE MAINTENANCE >
C
D
E
F
G
H
I
J
K
L
M
B
MA
N
O
A
10. Repeat steps 6 through 9 two or more times with reservoir tank cap installed until reservoir tank level no
longer drops.
11. Check cooling system for leaks with engine running.
12. Warm up the engine, and check for sound of engine coolant flow while running engine from idle up to
3,000 rpm with heater temperature controller set at several position between “COOL” and “WARM”.
• Sound may be noticeable at heater unit.
13. Repeat step 12 three times.
14. If sound is heard, bleed air from cooling system by repeating step 6 through 9 until reservoir tank level no
longer drops.
15. Check that the reservoir tank cap is tightened.
ENGINE COOLANT : Flushing
INFOID:0000000001095243
1.
Install reservoir tank if removed.
2.
Disconnect radiator hose (lower) and reservoir tank cap.
If water drain plugs on cylinder block are removed, close and tighten them. Refer to
.
3.
Fill reservoir tank with water and reinstall reservoir tank cap.
4.
Run the engine and warm it up to normal operating temperature.
5.
Rev the engine two or three times under no-load.
6.
Stop the engine and wait until it cools down.
7.
Drain water from the system. Refer to
.
8.
Repeat steps 1 through 7 until clear water begins to drain from radiator.
9.
Check that the reservoir tank cap is tightened.
RADIATOR CAP
RADIATOR CAP : Inspection
INFOID:0000000001095369
• Fit the adapter to the reservoir tank cap tester [SST: — (M.S. 554-
07)] (A) as shown.
• When connecting the reservoir tank cap to the reservoir tank cap
tester, apply water or LLC to the reservoir tank cap seal part.
• Check reservoir tank cap relief pressure.
• Replace the reservoir tank cap if the engine coolant passes
through it, or if any fur signs is detected.
CAUTION:
When installing reservoir tank cap, thoroughly wipe out the res-
ervoir tank filler neck to remove any waxy residue or foreign
material.
RADIATOR
RADIATOR : Inspection
INFOID:0000000001095495
Check radiator for mud or clogging. If necessary, clean radiator as follows.
CAUTION:
• Be careful not to bend or damage radiator fins.
• When radiator is cleaned without removal, remove all surrounding parts such as radiator cooling fan
assembly and horns. Then tape harness and connectors to prevent water from entering.
1.
Apply water by hose to the back side of the radiator core vertically downward.
2.
Apply water again to all radiator core surfaces once per minute.
3.
Stop washing if any stains no longer flow out from radiator.
4.
Blow air into the back side of radiator core vertically downward.
• Use compressed air lower than 490 kPa (5 kg/cm
2
, 71 psi) and keep distance more than 30 cm (11.8 in).
Standard and limit : Refer to
.
