MWI-50

< ECU DIAGNOSIS >

COMBINATION METER

Fail Safe

INFOID:0000000000892344

The combination meter activates the fail-safe control if the CAN communication lines between each unit are
malfunctioning.

JCNWA0220GB

MWI

COMBINATION METER

MWI-51

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

DTC Index

INFOID:0000000000892345

Function

Specifications

Speedometer

Reset to zero by suspending communication.

Tachometer

Meter illumination control

Changed to nighttime mode.

Buzzer

Turned off by suspending communication.

Warning lamp/indicator
lamp

ABS warning lamp

Turned on by suspending communication.

Brake warning lamp

EPS OFF indicator lamp

VDC OFF indicator lamp

SLIP indicator lamp

CVT warning lamp

Turned off by suspending communication.

Oil pressure warning lamp

Door warning lamp

Malfunction indicator lamp

CRUISE indicator lamp

Tail lamp indicator

Front fog indicator lamp

Rear fog indicator lamp

Glow indicator lamp

Malfunction indicator lamp 2

Trailer indicator lamp

Key R/G warning lamp

KEY LOCK warning lamp

High beam indicator lamp

Turn signal indicator lamp

Display contents of CONSULT-III

Time

Diagnostic item is detected when ...

Refer to

CAN COMM CIRCUIT
[U1000]

CRNT, 1 - 39

Combination meter is not transmitting or receiving CAN communica-
tion signal for 2 seconds or more.

MWI-26

VEHICLE SPEED
[B2205]

CRNT, 1 - 39

The abnormal vehicle speed signal is input from ABS actuator and
electric unit (control unit) for 2 seconds or more.

MWI-27

MWI-52

< ECU DIAGNOSIS >

IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)

IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE
ROOM)

Reference Value

INFOID:0000000001102063

VALUES ON THE DIAGNOSIS TOOL

Monitor Item

Condition

Value/Status

MOTOR FAN REQ

Engine idle speed

Changes depending on engine
coolant temperature, air condition-
er operation status, vehicle speed,
etc.

1 - 3

AC COMP REQ

Engine running

A/C switch OFF

Off

A/C switch ON
(Compressor is operating)

On

TAIL&CLR REQ

Lighting switch OFF

Off

Lighting switch 1ST, 2ND or AUTO (Light is illuminated)

On

HL LO REQ

Lighting switch OFF

Off

Lighting switch 2ND or AUTO (Light is illuminated)

On

HL HI REQ

Lighting switch OFF

Off

Lighting switch HI (Light is illuminated)

On

FR FOG REQ

Lighting switch 2ND or
AUTO (Light is illuminated)

Front fog lamp switch OFF

Off

Front fog lamp switch ON

On

HL WASHER REQ

Ignition switch ON, and low
beam headlamp is ON

Front washer switch OFF

Off

Front washer switch ON
(When headlamp washer is operat-
ing)

On

FR WIP REQ

Ignition switch ON

Front wiper switch OFF

STOP

Front wiper switch INT

1LOW

Front wiper switch LO

Low

Front wiper switch HI

Hi

WIP AUTO STOP

Ignition switch ON

Front wiper stop position

STOP P

Any position other than front wiper
stop position

ACT P

WIP PROT

Ignition switch ON

Front wiper operates normally

Off

Front wiper stops at fail-safe oper-
ation

BLOCK

ST RLY REQ
NOTE:
Vehicle without Intelligent Key system indi-
cates only “ON”, and it does not change.

When Intelligent Key is outside the vehicle, and the push switch
is pushed

Off

When Intelligent Key is inside the vehicle, and the push switch is
pushed

On

IGN RLY

Ignition switch OFF or ACC

Off

Ignition switch ON

On

RR DEF REQ

Ignition switch ON

Rear window defogger switch OFF

Off

Rear window defogger switch ON
(Rear window defogger is operat-
ing)

On

OIL P SW

Ignition switch OFF, ACC or engine running

Open

Ignition switch ON

Close

MWI

IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)

MWI-53

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

REV SW

Except selector lever R position

Off

Selector lever R position

On

HOOD SW
NOTE:
This item is monitored only on the vehicle
with the Vehicle Security (Theft Warning)
system.

Close the hood

Off

Open the hood

On

THFT HRN REQ
NOTE:
This item is monitored only on the vehicle
with the Vehicle Security (Theft Warning)
system.

Not operation

Off

Horn is activated with Vehicle Security (Theft Warning) system.

On

HORN CHIRP

NOTE:
This item is indicated, but not monitored.

Off

IGN ON SW

Ignition switch OFF or ACC

Off

Ignition switch ON

On

Monitor Item

Condition

Value/Status
