RF-34

< ECU DIAGNOSIS >

SUNSHADE SYSTEM

JCKWA0331GB

SUNSHADE SYSTEM

RF-35

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

J

L

M

A

B

RF

N

O

P

JCKWA0332GB

RF-36

< ECU DIAGNOSIS >

SUNSHADE SYSTEM

JCKWA0333GB

SUNSHADE SYSTEM DOES NOT OPERATE PROPERLY

RF-37

< SYMPTOM DIAGNOSIS >

C

D

E

F

G

H

I

J

L

M

A

B

RF

N

O

P

SYMPTOM DIAGNOSIS

SUNSHADE SYSTEM DOES NOT OPERATE PROPERLY

Diagnosis Procedure

INFOID:0000000000978165

1.

CHECK BCM POWER SUPPLY AND GROUND CIRCUIT

Check BCM power supply and ground circuit.
Refer to

BCS-34, "Diagnosis Procedure"

Is the inspection result normal?

YES

>> GO TO 2.

NO

>> Repair or replace the malfunctioning parts.

2.

CHECK SUNSHADE MOTOR ASSEMBLY POWER SUPPLY AND GROUND CIRCUIT

Check sunshade motor assembly power supply and ground circuit.
Refer to

RF-8, "SUNSHADE MOTOR ASSEMBLY : Component Function Check"

Is the inspection result normal?

YES

>> Inspection end.

NO

>> Check intermittent incident. Refer to

GI-39, "Intermittent Incident"
