Engine specifications

E01100604713

Petrol-powered vehicles

Item

1600 models

2000 models

Engine model

4A92

4B11

No. of cylinders

4 in line

4 in line

Total displacement

1,590 cc

1,998 cc

Bore

75.0 mm

86.0 mm

Stroke

90.0 mm

86.0 mm

Camshaft

Double overhead

Double overhead

Mixture preparation

Electronic injection

Electronic injection

Maximum output (EEC net)

86 kW/6,000 r/min,

86 kW/6,100 r/min

*1

85 kW/6,000 r/min

*2

110 kW/6,000 r/min

Maximum torque (EEC net)

154 N•m/4,000 r/min

197 N•m/4,200 r/min

*1

: Vehicles for Russia, Kazakhstan, Moldova and Ukraine

*2

: Vehicles for Belgium and Norway

Diesel-powered vehicles

Item

1600 models

2200 models

Engine model

9HD

4N14

No. of cylinders

4 in line

4 in line

Total displacement

1,560 cc

2,268 cc

Engine specifications

11-10

OGAE18E1

Specifications

11

Item

1600 models

2200 models

Bore

75.0 mm

86.0 mm

Stroke

88.3 mm

97.6 mm

Camshaft

Single overhead

Double overhead

Mixture preparation

Electronic direct injection

Electronic direct injection

Maximum output (EEC net)

84 kW/3,600 r/min

110 kW/3,500 r/min

Maximum torque (EEC net)

270 N•m/1,750 r/min

360 N•m/1,500 to 2,750 r/min



Electrical system

E01100804614

Item

Petrol-powered vehicles

Diesel-powered vehicles

1600 models

2000 models

1600 models

2200 models

Battery

Voltage

12 V

Type (JIS)

75D23L, Q-85

*1

75D23L

T-105

95D31L

Capacity (5HR)

52Ah, 55Ah

*1

52 Ah

73Ah

64 Ah

Alternator capacity

95 A, 85 A

*2

105 A

150 A

130 A

Spark plug type

NGK

DILFR5A11

LZFR5BI-11

*2

FR6EI

—

DENSO

—

K20PSR-B8

*1

: Vehicles for equipped with Auto Stop & Go (AS&G) system

*2

: Vehicles for Russia, Kazakhstan, Moldova and Ukraine

Electrical system

11-11

OGAE18E1

Specifications

11

NOTE

l

Vehicles equipped with the Auto Stop & Go (AS&G) system have a dedicated AS&G battery type.
The use of a different battery could cause the battery to run down quickly or the AS&G system not to operate normally.
Please contact a MITSUBISHI MOTORS Authorized Service Point when replacing the battery.



Tyres and wheels

E01100904875

Tyre

215/65R16 98H

215/70R16 100H

215/60R17 96H

225/55R18 98V

P225/55R18 97H

Wheel

Size

16x6 1/2J

17x6 1/2 J

18x7J

Offset

46 mm

38 mm

NOTE

l

Contact your MITSUBISHI MOTORS Authorized Service Point for details on the combination used on your vehicle.



Fuel consumption

E01101102043

Petrol-powered vehicles

Tyres and wheels

11-12

OGAE18E1

Specifications

11

Item

Combined

Urban condi-

tions

Extra-urban

conditions

CO

2

 (g/km)

Fuel consump-

tion (L/100 km)

Fuel consump-

tion (L/100 km)

Fuel consump-

tion (L/100 km)

1600 models

INFORM

Without AS&G

135

5.8

7.4

4.9

INVITE

135, 141

*

5.8, 6.1

*

7.4, 7.7

*

4.9, 5.1

*

INTENSE
INSTYLE

136

5.9

7.4

5.0

INFORM
INVITE

With AS&G

131

5.7

6.9

4.9

INTENSE
INSTYLE

132

5.7

7.0

5.0

2000 models

184

7.9

10.0

6.8

*

: Vehicles for Russia, Kazakhstan, Moldova and Ukraine

AS&G: Auto Stop & Go (AS&G) system

NOTE

l

The results given do not express or imply any guarantee of the fuel consumption of the particular vehicle.
The vehicle itself has not been tested and there are inevitably differences between individual vehicles of the same model. In addition, this vehicle may incor-
porate particular modifications. Furthermore, the driver’s style and road and traffic conditions, as well as the extent to which the vehicle has been driven and
the standard of maintenance, will all affect its fuel consumption.

Diesel-powered vehicles

Fuel consumption

11-13

OGAE18E1

Specifications

11

Item

Combined

Urban condi-

tions

Extra-urban

conditions

CO

2

 (g/km)

Fuel consump-

tion (L/100 km)

Fuel consump-

tion (L/100 km)

Fuel consump-

tion (L/100 km)

1600 models

2WD

119

4.6

5.2

4.2

4WD

132

5.0

5.6

4.7

2200 models

INFORM
INVITE

152

5.8

7.2

5.0

INTENSE
INSTYLE

152

5.8

7.1

5.0

NOTE

l

The results given do not express or imply any guarantee of the fuel consumption of the particular vehicle.
The vehicle itself has not been tested and there are inevitably differences between individual vehicles of the same model. In addition, this vehicle may incor-
porate particular modifications. Furthermore, the driver’s style and road and traffic conditions, as well as the extent to which the vehicle has been driven and
the standard of maintenance, will all affect its fuel consumption.



Fuel consumption

11-14

OGAE18E1

Specifications

11

Refill capacities

E01101307213

Petrol-powered vehicles
1600 models

RHD

LHD

2000 models

Refill capacities

11-15

OGAE18E1

Specifications

11

Diesel-powered vehicles

1600 models

2200 models

LHD

LHD

RHD

RHD

Refill capacities

11-16

OGAE18E1

Specifications

11

No.

Item

Quantity

Lubricants

1

Engine oil

Petrol-powered
vehicles

1600 models

Oil pan

4.0 litres

Refer to page 10-05.

Oil filter

0.2 litre

2000 models

Oil pan

4.0 litres

Oil filter

0.3 litre

Diesel-powered
vehicles

1600 models

3.25 litres

*1

3.75 litres

*2

2200 models

Oil pan

7.1 litres

Oil filter

0.3 litre

*1

: Oil capacity without replacement of the oil filter cartridge

*2

: Oil capacity with replacement of the oil filter cartridge

No.

Item

Quantity

Lubricants

2

Brake fluid

As required

Brake fluid DOT 3 or DOT 4

Clutch fluid

3

Washer fluid

4.5 litres

—

4

Engine coolant (pet-
rol-powered vehicles)

1600 models

6.0 litres [includes
0.65 litre in the re-

serve tank]

MITSUBISHI MOTORS GENUINE SUPER

LONG LIFE COOLANT PREMIUM or equiva-

lent

*

2000 models

7.5 litres [includes
0.65 litre in the re-

serve tank]

*

: similar high quality ethylene glycol based non-silicate, non-amine, non-nitrate and non-borate coolant with long life hybrid organic acid tech-

nology

Refill capacities

11-17

OGAE18E1

Specifications

11

No.

Item

Quantity

Lubricants

Engine coolant (die-
sel-powered vehicles)

1600 models

7.4 litres [includes
0.62 litre in the re-

serve tank]

ALTECO Freecor DSC, BASF Glysantin Alu

Protect Premium/G30 or G33, or Brugarolas Bra-

dol 497

2200 models

7.5 litres [includes
0.65 litre in the re-

serve tank]

MITSUBISHI MOTORS GENUINE SUPER

LONG LIFE COOLANT PREMIUM or equiva-

lent

*

5

Automatic transmission fluid

8.2 litres

MITSUBISHI MOTORS GENUINE ATF-J3

6

CVT fluid

6.9 litres

MITSUBISHI MOTORS GENUINE CVTF-J4

*

: similar high quality ethylene glycol based non-silicate, non-amine, non-nitrate and non-borate coolant with long life hybrid organic acid tech-

nology

CAUTION

l

For the automatic transmission fluid, use only the MITSUBISHI MOTORS GENUINE ATF and for the CVT fluid, use only the MITSUBISHI MOTORS
GENUINE CVTF. Use of a different fluids could damage the transmission.

No.

Item

Quantity

Lubricants

7

Manual transmission oil

5 M/T

1600 models

2.0 litres MITSUBISHI MOTORS GENUINE NEW MUL-

TI GEAR OIL ECO API GL-4, SAE 75W-80 or

MITSUBISHI MOTORS GENUINE NEW MUL-

TI GEAR OIL API GL-3, SAE 75W-80

6 M/T

1600 mod-

els

2WD

2.6 litres

4WD

2.7 litres

8

Transfer oil

0.5 litre

MITSUBISHI MOTORS GENUINE Super Hy-

poid Gear Oil API GL-5 SAE 80

9

Rear differential oil

0.4 litre

MITSUBISHI MOTORS GENUINE Super Hy-

poid Gear Oil API GL-5 SAE 80

Refill capacities

11-18

OGAE18E1

Specifications

11

No.

Item

Quantity

Lubricants

10

Refrigerant
(air condi-
tioning)

Except for vehicles for Russia, Kazakhstan, Moldova and Uk-
raine

480 - 520 g

HFO-1234yf

Vehicles for Russia, Kazakhstan, Moldova and Ukraine

HFC-134a
