Mazda Mazdaspeed 6 (2007 year). Manual

Black plate (345,1)

qCapacities

(Approximate Quantities)

Item

Capacity

Engine oil

With oil filter replacement

5.7 L (6.0 US qt, 5.0 Imp qt)

Without oil filter
replacement

5.3 L (5.6 US qt, 4.7 Imp qt)

Coolant

8.0 L (8.5 US qt, 7.0 Imp qt)

Manual transaxle oil

2.5 L (2.6 US qt, 2.2 Imp qt)

Transfer case oil

1.2 L (1.3 US qt, 1.1 Imp qt)

Rear differential oil

1.0 L (1.1 US qt, 0.9 Imp qt)

Fuel tank

60 L (15.9 US gal, 13.2 Imp gal)

Check oil and fluid levels with dipsticks or reservoir gauges.

qDimensions

Item

Model

Overall length

Without license plate holder

4,745 mm (186.8 in)

With license plate holder

4,765 mm (187.6 in)

Overall width

1,780 mm (70.1 in)

Overall height

1,430 mm (56.3 in)

Front tread

1,540 mm (60.6 in)

Rear tread

1,540 mm (60.6 in)

Wheelbase

2,675 mm (105.3 in)

qWeights

Item

Weight

GVWR (Gross Vehicle Weight Rating)

2,065 kg (4,552 lb)

GAWR (Gross Axle Weight Rating)

Front

1,111 kg (2,449 lb)

Rear

954 kg (2,103 lb)

CW (Curb Weight)

1,641 kg (3,618 lb)

qAir Conditioner

Gas complies with SAE J639

Maximum operating charge

HFC134a (R-134a)

0.47 kg (1.0 lb)

Specifications

10-5

Mazdaspeed6_8V77-EA-06F_Edition1 Page345
Tuesday, May 9 2006 10:46 AM

Black plate (346,1)

qLight Bulbs

Exterior light

Light bulb

Category

Wattage

ECE R

Trunk light

―

Overhead light/Map lights

W5W

Courtesy lights

W5W

Vanity mirror lights

1.2

―

qTires

NOTE

The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type
originally fitted to your vehicle. For details, contact an Authorized Mazda Dealer.

Check the tire pressure label for tire size and inflation pressure. Refer to Tire Inflation
Pressure on page 8-24.

Standard tire

Tire size

Inflation pressure

Front

Rear

215/45R18 93Y

260 kPa (38 psi)

10-6

Specifications

Mazdaspeed6_8V77-EA-06F_Edition1 Page346
Tuesday, May 9 2006 10:46 AM

Before Use

Getting

started

Routing

Address

Book

Navigation

Set Up

necessary

Preparation

NAVIGATION
SYSTEM

See page for specific information.

Immediate use

Advanced use

See page for specific information.

If necessary

Bef

ore Use

Na
vigation

Set Up

RDM-T

ne
ce
ss
ary

Rear Vie

nito

Accessories

Please contact an Authorized Mazda Dealer if you are missing the
following accessory.

Map Disc

CAUTION:
THIS PRODUCT IS A CLASS I LASER PRODUCT.
HOWEVER THIS PRODUCT USES A VISIBLE/
INVISIBLE LASER BEAM WHICH COULD CAUSE
HAZARDOUS RADIATION EXPOSURE IF DIRECTED.
BE SURE TO OPERATE THIS PRODUCT
CORRECTLY AS INSTRUCTED.
USE OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE. DO NOT
OPEN COVERS AND DO NOT REPAIR YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.

Laser products:
Wave length: 650 nm
Laser power: No hazardous radiation is emitted with safety protection.

Bef

ore Use

Na
vigation

Set Up

RDM-T

ne
ce
ss
ary

Rear Vie

nito

Contents

Preparation

Before Use
Accessories ........................................................................................ 2
Laser products: .................................................................................. 2
Contents ............................................................................................. 4
Safety Information .............................................................................. 6
Introduction ........................................................................................ 8

(Use This Product Safety), (Navigation System), (Screens)

Names and Functions ...................................................................... 10

Immediate use

Getting started

Activation....................................................................................... 12

(Removing the Map Disc), (Buttons on the screen)

Screen Names and Functions....................................................... 14

(Screens Before Setting Route), (Screens During Route Guidance),
(Menu), (Screen adjustments and settings)

Screen change .............................................................................. 16

(Changing the Map Orientation/Scale)

Routing

Destination Entry and Route Search............................................. 18

(Change (Change Search Area)), (Address), (Point of interest),
(Emergency), (Memory Point), (Home), (Preset Destination),
(Previous Destination), (Intersection), (Freeway On/Off Ramp),
(Coordinates), (Select from map)

Quick POI...................................................................................... 26

(Displaying POI(s) on a Map), (Local Search), (Deleting POI Markers),
(Showing POI Data)

Character Entry............................................................................. 27

(To enter the street name, city name, and other.),
(To enter the house phone number, and other.)

Direct Destination Input................................................................. 28

(Direct Destination Input), (Selecting Route)

POI Icons on Maps / Delete Destination ....................................... 29

(POI (Point of Interest) Icons), (Delete destination)

Route Options ............................................................................... 30

(Route Preferences), (Modification of Destination or Way Point Positions),
(Deletion of Destination or Way Points), (Detour), (Turn List),
(Display Preview), (Route Preview)
