Mazda Mazdaspeed 6 (2007 year). Manual

Black plate (234,1)

Parking in an Emergency

The hazard warning lights should always
be used when you stop on or near a
roadway in an emergency.

The hazard warning lights warn other
drivers that your vehicle is a traffic hazard
and that they must take extreme caution
when near it.

Depress the hazard warning flasher and all
the turn signals will flash.

NOTE

The turn signals don't work when the
hazard warning lights are on.

Check local regulations about the use
of hazard warning lights while the
vehicle is being towed. They may
forbid it.

7-2

In Case of an Emergency

Parking in an Emergency

Mazdaspeed6_8V77-EA-06F_Edition1 Page234
Tuesday, May 9 2006 10:45 AM

Black plate (235,1)

Spare Tire and Tool Storage

Spare tire and tools are stored in the locations illustrated in the diagram.

Tiedown eyelet

Tool bag

Jack

Jack lever

Lug wrench

Spare tire

In Case of an Emergency

Flat Tire

7-3

Mazdaspeed6_8V77-EA-06F_Edition1 Page235
Tuesday, May 9 2006 10:45 AM

Black plate (236,1)

qJack

To remove the jack

1. Open the trunk mat.

2. Turn the wing bolt counterclockwise.

To secure the jack

Perform the removal procedure in reverse.

qSpare Tire

Your Mazda has a temporary spare tire.
The temporary spare tire is lighter and
smaller than a conventional tire, and is
designed only for emergency use and
should be used only for VERY short
periods. Temporary spare tires should
NEVER be used for long drives or
extended periods.

WARNING

Do not install the temporary spare tire
on the front wheels (driving wheels):
Driving with the temporary spare tire
on one of the front driving wheels is
dangerous. Handling will be affected.
You could lose control of the vehicle,
especially on ice or snow bound roads,
and have an accident. Move a regular
tire to the front wheel and install the
temporary spare tire to the rear.

CAUTION

When using the temporary spare tire,
driving stability may decrease
compared to when using only the
conventional tire. Drive carefully.

To avoid damage to the temporary
spare tire or to the vehicle, observe
the following precautions:

Do not exceed 80 km/h (50 mph).

Avoid driving over obstacles.
Also, do not drive through an
automatic car wash. This tire's
diameter is smaller than a
conventional tire, so the ground
clearance is reduced about 7 mm
(0.3 in).

Do not use tire chains on any type
of tire, including the spare tire.

Do not use your temporary spare
tire on any other vehicle, it has
been designed only for your
Mazda.

Use only one temporary spare tire
on your vehicle at the same time.

7-4

In Case of an Emergency

Flat Tire

Mazdaspeed6_8V77-EA-06F_Edition1 Page236
Tuesday, May 9 2006 10:45 AM

Black plate (237,1)

To remove the spare tire

1. Remove the trunk mat.

2. Turn the tire wing bolt

counterclockwise.

Wing bolt

Tire clamp

To secure the spare tire

Perform the removal procedure in reverse.

Changing a Flat Tire

NOTE

If the following occurs while driving, it
could indicate a flat tire.

Steering becomes difficult.

The vehicle begins to vibrate
excessively.

The vehicle pulls in one direction.

If you have a flat tire, drive slowly to a
level spot that is well off the road and out
of the way of traffic to change the tire.
Stopping in traffic or on the shoulder of a
busy road is dangerous.

WARNING

Be sure to follow the directions for
changing a tire, and never get under a
vehicle that is supported only by a
jack:
Changing a tire is dangerous if not
done properly. The vehicle can slip off
the jack and seriously injure someone.

Never allow anyone inside a vehicle
supported by a jack:
Allowing someone to remain in a
vehicle supported by a jack is
dangerous. The occupant could cause
the vehicle to fall resulting in serious
injury.

NOTE

Make sure the jack is well lubricated
before using it.

In Case of an Emergency

Flat Tire

7-5

Mazdaspeed6_8V77-EA-06F_Edition1 Page237
Tuesday, May 9 2006 10:45 AM

Black plate (238,1)

1. Park on a level surface off the right-of-

way and firmly set the parking brake.

2. Shift into Reverse (R) or 1 and turn off

the engine.

3. Turn on the hazard warning flasher.

4. Have everyone get out of the vehicle

and away from the vehicle and traffic.

5. Remove the jack, tool bag, and spare

tire (page 7-3).

6. Block the wheel diagonally opposite

the flat tire. When blocking a wheel,
place a tire block both in front and
behind the tire.

NOTE

When blocking a tire, use rocks or
wood blocks of sufficient size to hold
the tire in place.

qRemoving a Flat Tire

1. Loosen the lug nuts by turning them

counterclockwise one turn each, but
don't remove any lug nuts until the tire
has been raised off the ground.

2. Place the jack under the jacking

position closest to the tire being
changed.

Jacking position

7-6

In Case of an Emergency

Flat Tire

Mazdaspeed6_8V77-EA-06F_Edition1 Page238
Tuesday, May 9 2006 10:45 AM

Black plate (239,1)

WARNING

Use only the front and rear jacking
positions recommended in this
manual:
Attempting to jack the vehicle in
positions other than those
recommended in this manual is
dangerous. The vehicle could slip off
the jack and seriously injure or even
kill someone. Use only the front and
rear jacking positions recommended
in this manual.

Use only the jack provided with your
Mazda:
Using a jack that is not designed for
your Mazda is dangerous. The vehicle
could slip off the jack and seriously
injure someone.

Never place objects under the jack:
Jacking the vehicle with an object
under the jack is dangerous. The jack
could slip and someone could be
seriously injured by the jack or the
falling vehicle.

3. Insert the jack lever and attach the lug

wrench to tire jack.

4. Turn the lug wrench clockwise and

raise the vehicle high enough so that
the spare tire can be installed. Before
removing the lug nuts, make sure your
Mazda is firmly in position and that it
cannot slip or move.

5. Remove the lug nuts by turning them

counterclockwise; then remove the
wheel.

In Case of an Emergency

Flat Tire

7-7

Mazdaspeed6_8V77-EA-06F_Edition1 Page239
Tuesday, May 9 2006 10:45 AM

Black plate (240,1)

qLocking Lug Nuts

If your vehicle has optional antitheft
wheel lug nuts, one on each wheel will
lock the tires and you must use a special
key to unlock them. This key is attached
to the lug wrench and is stored with the
spare tire. Register them with the lock
manufacturer by filling out the card
provided in the glove box and mailing it
in the accompanying envelope. If you lose
this key, consult an Authorized Mazda
Dealer or use the lock manufacturer's
order form, which is with the registration
card.

Special key

Antitheft lug nut

To remove an antitheft lug nut

1. Obtain the key for the antitheft lug nut.

2. Place the key on top of the nut, and be

sure to hold the key square to it. If you
hold the key at an angle, you may
damage both key and nut. Don't use a
power impact wrench.

3. Place the lug wrench on top of the key

and apply pressure. Turn the wrench
counterclockwise.

To install the nut

1. Place the key on top of the nut, and be

sure to hold the key square to it. If you
hold the key at an angle, you may
damage both key and nut. Don't use a
power impact wrench.

2. Place the lug wrench on top of the key,

apply pressure, and turn it clockwise.

qMounting the Spare Tire

1. Remove dirt and grime from the

mounting surfaces of the wheel and
hub, including the hub bolts, with a
cloth.

WARNING

Make sure the mounting surfaces of
the wheel, hub and lug nuts are clean
before changing or replacing tires:
When changing or replacing a tire,
not removing dirt and grime from the
mounting surfaces of the wheel, hub
and hub bolts is dangerous. The lug
nuts could loosen while driving and
cause the tire to come off, resulting in
an accident.

2. Mount the spare tire.

7-8

In Case of an Emergency

Some models.

Flat Tire

Mazdaspeed6_8V77-EA-06F_Edition1 Page240
Tuesday, May 9 2006 10:45 AM

Black plate (241,1)

3. Install the lug nuts with the beveled

edge inward; tighten them by hand.

WARNING

Do not apply oil or grease to lug nuts
and bolts and do not tighten the lug
nuts beyond the recommended
tightening torque:
Applying oil or grease to lug nuts and
bolts is dangerous. The lug nuts could
loosen while driving and cause the tire
to come off, resulting in an accident.
In addition, lug nuts and bolts could
be damaged if tightened more than
necessary.

4. Turn the lug wrench counterclockwise

and lower the vehicle. Use the lug
wrench to tighten the nuts in the order
shown.

If you're unsure of how tight the nuts
should be, have them inspected at an
Authorized Mazda Dealer.

Nut tightening torque

N·m (kgf·m, ft·lbf)

―118 (9―12, 65―87)

WARNING

Always securely and correctly tighten
the lug nuts:
Improperly or loosely tightened lug
nuts are dangerous. The wheel could
wobble or come off. This could result
in loss of vehicle control and cause a
serious accident.

Be sure to reinstall the same nuts you
removed or replace them with metric
nuts of the same configuration:
Because the wheel studs and lug nuts
on your Mazda have metric threads,
using a non-metric nut is dangerous.
On a metric stud, it would not secure
the wheel and would damage the stud,
which could cause the wheel to slip off
and cause an accident.

In Case of an Emergency

Flat Tire

7-9

Mazdaspeed6_8V77-EA-06F_Edition1 Page241
Tuesday, May 9 2006 10:45 AM

Black plate (242,1)

5. Remove the center cap by tapping it

with the lug wrench.

6. Store the damaged tire, using the wing

bolt to hold it in place.

Wing bolt

Tire clamp

7. Check the inflation pressure. Refer to

the specification charts on page 10-6.

8. Have the flat tire repaired or replaced

as soon as possible.

WARNING

Do not drive with any tires that have
incorrect air pressure:
Driving on tires with incorrect air
pressure is dangerous. Tires with
incorrect pressure could affect
handling and result in an accident.
When you check the regular tires' air
pressure, check the spare tire, too.

NOTE

To prevent the jack and tool from
rattling, store them properly.

7-10

In Case of an Emergency

Flat Tire

Mazdaspeed6_8V77-EA-06F_Edition1 Page242
Tuesday, May 9 2006 10:45 AM

Black plate (243,1)

Overheating

If the temperature gauge indicates
overheating, the vehicle loses power, or
you hear a loud knocking or pinging
noise, the engine is probably too hot.

WARNING

Turn off the ignition switch and

make sure the fan is not running
before attempting to work near the
electrical cooling fan:
Working near the electrical cooling
fan when it is running is dangerous.
You could be hit by the fan and
seriously injured.

Do not remove either

cooling system caps when the engine
and radiator are hot:
When the engine and radiator are hot,
scalding coolant and steam may shoot
out under pressure and cause serious
injury.

Open the hood ONLY after steam is no
longer escaping from the engine:
Steam from an overheated engine is
dangerous. The escaping steam could
seriously burn you.

NOTE

Once the engine coolant exceeds a
preset temperature, an electrical cooling
fan turns on. It will continue running
for about 10 minutes after the ignition
switch is turned to off.

If the temperature gauge indicates
overheating:

1. Drive safely to the side of the road and

park off the right-of-way.

2. Shift into neutral.

3. Apply the parking brake.

4. Turn off the air conditioner.

5. Check whether coolant or steam is

escaping from under the hood or from
the engine compartment.

If steam is coming from the engine
compartment:
Don't go near the front of the vehicle.
Stop the engine.
Wait until the steam dissipates, then
open the hood and start the engine.

If neither coolant nor steam is
escaping:
Open the hood and idle the engine until
it cools.

CAUTION

If the cooling fan does not operate
while the engine is running, the engine
temperature will increase. Stop the
engine and call an Authorized Mazda
Dealer.

In Case of an Emergency

Overheating

7-11

Mazdaspeed6_8V77-EA-06F_Edition1 Page243
Tuesday, May 9 2006 10:45 AM

Black plate (244,1)

6. Make sure the cooling fan is operating,

then turn off the engine after the
temperature has decreased.

7. When cool, check the coolant level.

If it's low, look for coolant leaks from
the radiator and hoses.

If you find a leak or other damage, or if
coolant is still leaking:
Stop the engine and call an Authorized
Mazda Dealer.

Coolant reservoir

Cooling system cap

If you find no problems, the engine is
cool, and no leaks are obvious:
Carefully add coolant as required (page
8-15).

CAUTION

If the engine continues to overheat or
frequently overheats, have the cooling
system inspected. The engine could be
seriously damaged unless repairs are
made. Consult an Authorized Mazda
Dealer.

7-12

In Case of an Emergency

Overheating

Mazdaspeed6_8V77-EA-06F_Edition1 Page244
Tuesday, May 9 2006 10:45 AM

Black plate (245,1)

Starting a Flooded Engine

If the engine fails to start, it may be
flooded (excessive fuel in the engine).

Follow this procedure:

1. Depress the accelerator all the way and

hold it there.

2. Turn the ignition switch to the START

position and hold it there

―for up to 10

seconds. If the engine starts, release the
key and accelerator immediately
because the engine will suddenly rev
up.

3. If the engine fails to start, crank it

without depressing the accelerator

―for

up to 10 seconds.

In Case of an Emergency

Emergency Starting

7-13

Mazdaspeed6_8V77-EA-06F_Edition1 Page245
Tuesday, May 9 2006 10:45 AM

Black plate (246,1)

Jump-Starting

Jump-starting is dangerous if done incorrectly. So follow the procedure carefully. If you
feel unsure about jump-starting, we strongly recommend that you have a competent service
technician do the work.

WARNING

Follow These Precautions Carefully:

To ensure safe and correct handling of the battery, read the following precautions
carefully before using the battery or inspecting it.

Always wear eye protection when working near the battery:

Working without eye protection is dangerous. Battery fluid contains SULFURIC
ACID which could cause blindness if splashed into your eyes. Also, hydrogen gas
produced during normal battery operation, could ignite and cause the battery to
explode.

Wear eye protection and protective gloves to prevent contact with battery fluid:

Spilled battery fluid is dangerous.
Battery fluid contains SULFURIC ACID which could cause serious injuries if it gets
in eyes, skin or clothing. If this happens, immediately flush your eyes with water for
15 minutes or wash your skin thoroughly and get medical attention.

Always keep batteries out of the reach of children:

Allowing children to play near batteries is dangerous. Battery fluid could cause
serious injuries if it gets in the eyes or on the skin.

Do not allow the positive (

) terminal to contact any other metal object that

could cause sparks:
Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced
during normal battery operation, could ignite and cause the battery to explode. An
exploding battery can cause serious burns and injuries. When working near a battery,
do not allow metal tools to contact the positive (

) or negative (

) terminal of the

battery.

7-14

In Case of an Emergency

Emergency Starting

Mazdaspeed6_8V77-EA-06F_Edition1 Page246
Tuesday, May 9 2006 10:45 AM

Black plate (247,1)

WARNING

Keep all flames, including cigarettes, and sparks away from open battery cells:

Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced
during normal battery operation, could ignite and cause the battery to explode. An
exploding battery can cause serious burns and injuries.

Do not jump-start a frozen battery or one with a low fluid level:
Jump-starting a frozen battery or one with a low fluid level is dangerous. It may
rupture or explode, causing serious injury.

Connect the negative cable to a good ground point away from the battery:
Connecting the end of the second jumper cable to the negative (

) terminal of the

discharged battery is dangerous.
A spark could cause the gas around the battery to explode and injure someone.

Route the jumper cables away from parts that will be moving:
Connecting a jumper cable near or to moving parts (cooling fans, belts) is dangerous.
The cable could get caught when the engine starts and cause serious injury.

CAUTION

Use only a 12 V booster system. You can damage a 12 V starter, ignition system, and
other electrical parts beyond repair with a 24 V power supply (two 12 V batteries in
series or a 24 V motor generator set).

In Case of an Emergency

Emergency Starting

7-15

Mazdaspeed6_8V77-EA-06F_Edition1 Page247
Tuesday, May 9 2006 10:45 AM

Black plate (248,1)

Booster battery

Jumper cables

Connect cables in numerical order and disconnect in reverse order.

Discharged
battery

1. Make sure the booster battery is 12 V

and that its negative terminal is
grounded.

2. If the booster battery is in another

vehicle, don't allow both vehicles to
touch. Turn off the engine of the
vehicle with the booster battery and all
unnecessary electrical loads in both
vehicles.

3. Connect the jumper cables in the exact

sequence as in the illustration.

Connect one end of a cable to the
positive terminal on the discharged
battery (1).

Attach the other end to the positive
terminal on the booster battery (2).

Connect one end of the other cable
to the negative terminal of the
booster battery (3).

Connect the other end to a solid,
stationary, exposed metallic point
(for example, the strut mounting
bolt) away from the discharged
battery (4).

4. Start the engine of the booster vehicle

and run it a few minutes. Then start the
engine of the other vehicle.

5. When finished, carefully disconnect the

cables in the reverse order described in
the illustration.

7-16

In Case of an Emergency

Emergency Starting

Mazdaspeed6_8V77-EA-06F_Edition1 Page248
Tuesday, May 9 2006 10:45 AM

Mazda Mazdaspeed 6 (2007 year). Manual - part 15
