Mazda Mazdaspeed 6 (2007 year). Manual

Black plate (89,1)

When Warning Indicator/Beep is Activated

Under the following conditions, warning beeps are heard and a warning/indicator light in
the instrument cluster illuminates to notify the driver of improper operation of the
advanced key to prevent theft of the vehicle (page 3-16).

Warning

What to check

When a door is open, a continuous beep sound will be
heard.

Check whether the start knob has been returned to the
LOCK position.

When a door is open, 3 beep sounds are heard, and the
KEY warning light (red) in the instrument cluster
flashes.

Check whether the advanced key has been removed
from the vehicle.

When a door is closed, a beep sound is heard 3 times,
and the KEY warning light (red) in the instrument
cluster flashes.

Check whether the advanced key has been removed
from the vehicle.

When attempting to lock the doors, a beep sound is
heard.

Check whether the advanced key has been left in the
vehicle.

Check whether the start knob has been returned to the
LOCK position.

Check whether a door or the trunk lid is open.

When the KEY indicator light (green) flashes in the
instrument cluster.

The advanced key battery power is low. Replace the
battery with a new one.
Refer to Advanced Key Maintenance on page 3-5.

When the KEY warning light (red) remains illuminated
in the instrument cluster.

The advanced key is malfunctioning. Park the vehicle in
a safe place, and use the auxiliary key to continue
driving the vehicle. Have the vehicle inspected at an
Authorized Mazda Dealer as soon as possible.

Knowing Your Mazda

Advanced Keyless Entry and Start System

3-19

Mazdaspeed6_8V77-EA-06F_Edition1 Page89
Tuesday, May 9 2006 10:43 AM

Black plate (90,1)

Keys

WARNING

Do not leave the keys in your vehicle
with children and keep them in a place
where your children will not find or
play with them:
Leaving children in a vehicle with the
key is dangerous. This could result in
someone being badly injured or even
killed. These new kinds of keys are
fascinating to children. They could
play with power windows or other
controls, or even make the vehicle
move.

NOTE

If your vehicle is equipped with the
advanced key, refer to Advanced
Keys (page 3-2).

Refer to Immobilizer System (page
3-49) for information regarding keys
and engine starting.

Refer to Theft-Deterrent System
(page 3-52) for information
regarding keys and the prevention of
vehicle and vehicle contents theft.

Your Mazda has two kinds of keys.

Valet key

Master key
(Retractable
type key)

Key code number plate

Here's what the keys are used for:

Lock Operates

Master key

Valet key

Ignition switch and

steering column lock

Yes

Driver's door

Yes

Glove box

Yes

Trunk lid

Yes

If you must leave your vehicle with
another person, such as a parking
attendant, protect items by locking the
glove box and trunk lid with the master
key. Keep that key and give the other
person only the valet key.

A code number is stamped on the plate
attached to the key set; detach this plate
and store it in a safe place (not in the
vehicle) for use if you need to make a
replacement key.

NOTE

Write down the code number and keep
it in a separate safe and convenient
place, but not in the vehicle.
If your key is lost, consult your
Authorized Mazda Dealer and have
your code number ready.

3-20

Knowing Your Mazda

Doors and Locks

Mazdaspeed6_8V77-EA-06F_Edition1 Page90
Tuesday, May 9 2006 10:43 AM

Black plate (91,1)

Key extend/retract method (Retractable
type key)

To extend the key, press the release
button.

To retract the key, rotate it into the holder
while pressing the release button.

Keyless Entry System (with
Retractable Type Key)

This system remotely locks and unlocks
the doors and the trunk lid, and opens the
power windows.
It can also help you signal for attention.
Press the buttons slowly and carefully.

CAUTION

To avoid damage to the transmitter, do
not:

Drop it.

Get it wet.

Disassemble it.

Expose it to high temperatures on
places such as the dashboard or
hood, under direct sunlight.

Knowing Your Mazda

Doors and Locks

3-21

Mazdaspeed6_8V77-EA-06F_Edition1 Page91
Tuesday, May 9 2006 10:43 AM

Black plate (92,1)

NOTE

The keyless entry system is designed
to operate up to about 2.5 m (8 ft)
from the center of the vehicle, but
this may vary due to local
conditions.

The system doesn't operate when the
key is in the ignition switch.

Doors and the trunk lid cannot be
locked by pressing the lock button
while any other door or the trunk lid
is open. Also, the hazard warning
lights will not flash.

If the transmitter does not operate
when pressing a button or the
operation range becomes too small,
the battery may be dead. To install a
new battery, refer to Maintenance
(page 3-23).

Additional transmitters can be
obtained at an Authorized Mazda
Dealer. Up to 3 transmitters can be
used with the keyless entry system
per vehicle. Bring all transmitters to
an Authorized Mazda Dealer when
additional transmitters are required.

qTransmitter

Lock button

Unlock button

Panic button

Operation
indicator light

NOTE

(U.S.A.)
This device complies with Part 15 of
the FCC Rules. Operation is subject
to the following two conditions: (1)
this device may not cause harmful
interference, and (2) this device must
accept any interference received,
including interference that may cause
undesired operation.

(CANADA)
This device complies with RSS-210
of Industry CANADA. Operation is
subject to the following two
conditions: (1) this device may not
cause interference, and (2) this
device must accept any interference,
including interference that may cause
undesired operation of the device.

NOTE

The unlock button can be used to open
the power windows, but the lock button
cannot be used to close the power
windows. Refer to Opening/Closing the
Power Windows from Outside (page
3-38).

3-22

Knowing Your Mazda

Doors and Locks

Mazdaspeed6_8V77-EA-06F_Edition1 Page92
Tuesday, May 9 2006 10:44 AM

Black plate (93,1)

The operation indicator light flashes when
the buttons are pressed.

Lock button

To lock the doors and the trunk lid, press
the lock button and the hazard warning
lights will flash once.

To confirm that all doors and the trunk lid
have been locked, press the lock button
again within 5 seconds. If they are closed
and locked, the horn will sound.

NOTE

All doors and the trunk lid cannot be
locked when any door or the trunk
lid is open and the key is in the
ignition switch.

Confirm that all doors and the trunk
lid are locked visually or audibly by
use of the double click.

Unlock button

To unlock the driver's door, press the
unlock button and the hazard warning
lights will flash twice.

To unlock all doors and the trunk lid,
press the unlock button again within 5
seconds.

NOTE

After unlocking with the transmitter, all
doors and the trunk lid will
automatically lock if one of the doors or
the trunk lid is not opened within about
30 seconds.

Panic button

If you witness from a distance someone
attempting to break into or damage your
vehicle, pressing the panic button will
activate the vehicle's alarm.

NOTE

The panic button will work whether any
door or the trunk lid is open or closed.

Turning on the alarm

Pressing the panic button for 1 second or
more will trigger the alarm for about 2
minutes and 30 seconds, and the
following will occur:

The horn sounds intermittently.

The hazard warning lights flash.

Turning off the alarm

Press any button on the transmitter.

qTransmitter Maintenance

If the buttons on the transmitter are
inoperable and the operation indicator
light does not flash, the battery may be
dead.
Replace with a new battery before the
transmitter becomes unusable.

Knowing Your Mazda

Doors and Locks

3-23

Mazdaspeed6_8V77-EA-06F_Edition1 Page93
Tuesday, May 9 2006 10:44 AM

Black plate (94,1)

CAUTION

Install the battery with the positive
pole (

) facing down. Battery

leakage could occur if it is not
installed correctly.

When replacing the battery, be
careful not to bend the electrical
terminals or get oil on them. Also be
careful not to get dirt in the
transmitter as it could be damaged.

There is the danger of explosion if
the battery is not correctly replaced.

Replace only with the same type
battery (CR1620 or equivalent).

Dispose of used batteries according
to the following instructions.

Insulate the plus and minus
terminals of the battery using
cellophane or equivalent tape.

Never disassemble.

Never throw the battery into fire
and/or water.

Never deform or crush.

Replacing the transmitter battery

1. Unfold the key (page 3-20).

2. Insert a small screwdriver into the slot

and push the tab to remove the key
from the transmitter.

Tab

3. Insert a small screwdriver into the slot

and gently pry open the transmitter.

4. Press the portion of the battery

indicated by A and remove the battery.

3-24

Knowing Your Mazda

Doors and Locks

Mazdaspeed6_8V77-EA-06F_Edition1 Page94
Tuesday, May 9 2006 10:44 AM

Black plate (95,1)

NOTE

If it is difficult to remove the battery by
pressing with a finger, use a small
screwdriver to press out the battery.

5. Put in the new battery (CR1620 or

equivalent) with the positive pole (

)

facing down.

6. Align the front and back covers and

snap the transmitter shut.

7. Install the key to the transmitter.

qService

If you have a problem with the keyless
entry system, consult an Authorized
Mazda Dealer.

If your transmitter is lost or stolen, bring
all remaining transmitters to an
Authorized Mazda Dealer as soon as
possible for a replacement and to make
the lost or stolen transmitter inoperative.

CAUTION

Radio equipment like this is governed
by laws in the United States.
Changes or modifications not expressly
approved by the party responsible for
compliance could void the user's
authority to operate the equipment.

Knowing Your Mazda

Doors and Locks

3-25

Mazdaspeed6_8V77-EA-06F_Edition1 Page95
Tuesday, May 9 2006 10:44 AM

Black plate (96,1)

Door Locks

WARNING

Always take all children and pets with
you or leave a responsible person with
them:
Leaving a child or a pet unattended in
a parked vehicle is dangerous. In hot
weather, temperatures inside a vehicle
can become high enough to cause
brain damage or even death.

Do not leave the keys in your vehicle
with children and keep them in a place
where your children will not find or
play with them:
Leaving children in a vehicle with the
key is dangerous. This could result in
someone being badly injured or even
killed. They could play with power
windows or other controls, or even
make the vehicle move.

Keep all doors locked when driving:
Unlocked doors in a moving vehicle
are dangerous. Passengers can fall out
if a door is accidentally opened and
can more easily be thrown out in an
accident.

Always close all the windows, lock the
doors and take the key with you when
leaving your vehicle unattended:
Leaving your vehicle unlocked is
dangerous as children could lock
themselves in a hot vehicle, which
could result in death. Also, a vehicle
left unlocked becomes an easy target
for thieves and intruders.

qLocking, Unlocking with Key

The driver's door can be locked/unlocked
with the key.
Turn the key toward the front to unlock,
toward the back to lock.

Lock

Unlock

qLocking, Unlocking with Request

Switch (with Advanced Key)

The doors can be locked/unlocked by
operating the request switch while
carrying the advanced key outside the
vehicle, refer to Operations Using
Advanced Keyless Functions (page 3-7).

qLocking, Unlocking with

Transmitter (with Advanced Key)

The doors can be locked/unlocked by
operating the keyless entry system
transmitter, refer to Keyless Entry System
(page 3-13).

qLocking, Unlocking with Transmitter

(with Retractable Type Key)

The doors can be locked/unlocked by
operating the keyless entry system
transmitter, refer to Keyless Entry System
(page 3-21).

3-26

Knowing Your Mazda

Doors and Locks

Mazdaspeed6_8V77-EA-06F_Edition1 Page96
Tuesday, May 9 2006 10:44 AM

Black plate (97,1)

qLocking, Unlocking with Door-

Lock Knob

To lock any door from the inside, push the
door-lock knob.
To unlock, pull it out.
This does not operate the other door
locks.

Unlock

Lock

To lock any door with the door-lock knob
from the outside, push the door-lock knob
to the lock position and close the door.
This does not operate the other door
locks.

Door-lock knob

NOTE

When locking the doors this way, be
careful not to leave the key inside the
vehicle.

qPower Door Locks

Vehicle lock-out prevention

(With advanced key)
The vehicle lock-out prevention feature
prevents you from locking yourself out of
the vehicle. All doors and the trunk lid
will automatically unlock if they are
locked using the power door locks with
any door or the trunk lid open.
(Without advanced key)
The vehicle lock-out prevention feature
prevents you from locking yourself out of
the vehicle. With the key in the ignition
switch, all doors and the trunk lid will
automatically unlock if they are locked
using the power door locks with any door
or the trunk lid open.

Locking, unlocking with key

All doors and the trunk lid lock
automatically when the driver's door is
locked with the key. All doors and the
trunk lid unlock when the driver's door is
unlocked and the key is held in the unlock
position for one second or longer.

Lock

Unlock

Knowing Your Mazda

Doors and Locks

3-27

Mazdaspeed6_8V77-EA-06F_Edition1 Page97
Tuesday, May 9 2006 10:44 AM

Black plate (98,1)

NOTE

Holding the key in the unlocked
position in the driver's door lock for
about a second unlocks all doors and
the trunk lid. To unlock only the driver's
door, insert the key into the driver's
door lock and turn the key briefly to the
unlock position and then immediately
return it to the center position.

Locking, unlocking with door-lock
switch

All doors and the trunk lid lock
automatically when LOCK is pushed.
They all unlock when the unmarked part
of the door-lock switch is pushed.

Lock

Unlock

Locking, unlocking with request switch
(with advanced key)

All doors and the trunk lid can be locked/
unlocked by operating the request switch
while carrying the advanced key outside
the vehicle, refer to Operations Using
Advanced Keyless Functions (page 3-7).

Locking, unlocking with transmitter
(with advanced key)

All doors and the trunk lid can be locked/
unlocked by operating the keyless entry
system transmitter, refer to Keyless Entry
System (page 3-13).

Locking, unlocking with transmitter
(with retractable type key)

All doors and the trunk lid can be locked/
unlocked by operating the keyless entry
system transmitter, refer to Keyless Entry
System (page 3-21).

qRear Door Child Safety Locks

These locks are intended to help prevent
children from accidentally opening the
rear doors. Use them both whenever a
child rides in the vehicle.

If you slide the child safety lock to the
lock position before closing that door, the
door cannot be opened from the inside.
The door can be opened only by pulling
the outside handle.

Unlock

Lock

3-28

Knowing Your Mazda

Doors and Locks

Mazdaspeed6_8V77-EA-06F_Edition1 Page98
Tuesday, May 9 2006 10:44 AM

Black plate (99,1)

Trunk Lid

WARNING

Never allow a person to ride in the
trunk:
Allowing a person to ride in the trunk
is dangerous. In addition, the person
in the trunk could be seriously injured
or killed during sudden braking or a
collision.

Keep the trunk closed when driving:
Exhaust gas entering the cabin of a
vehicle through an open trunk is
dangerous. This gas contains CO
(carbon monoxide), which is colorless,
odorless, and highly poisonous. If
inhaled, it can cause loss of
consciousness and death.

qLocking, Unlocking with Key

To lock the trunk lid, insert the master key
into the key slot and turn it
counterclockwise, then return it to the
center position and remove it.

Lock

Unlock

To unlock the trunk lid, insert the master
key into the key slot and turn it clockwise,
then return it to the center position and
remove it.

The trunk lid can be locked/unlocked by
inserting the key into the driver's door key
slot, refer to Power Door Locks (page
3-27).

qLocking, Unlocking with Request

Switch (with Advanced Key)

The trunk lid can be locked/unlocked by
operating the request switch while
carrying the advanced key outside the
vehicle, refer to Operations Using
Advanced Keyless Functions (page 3-7).

qLocking, Unlocking with

Transmitter (with Advanced Key)

The trunk lid can be locked/unlocked by
operating the keyless entry system
transmitter, refer to Keyless Entry System
(page 3-13).

qLocking, Unlocking with Transmitter

(with Retractable Type Key)

The trunk lid can be locked/unlocked by
operating the keyless entry system
transmitter, refer to Keyless Entry System
(page 3-21).

qLocking, Unlocking with Door-

Lock Switch

The trunk lid can be locked/unlocked by
operating the door-lock switch, refer to
Power Door Locks (page 3-27).

Knowing Your Mazda

Doors and Locks

3-29

Mazdaspeed6_8V77-EA-06F_Edition1 Page99
Tuesday, May 9 2006 10:44 AM

Black plate (100,1)

qOpening and Closing the Trunk Lid

WARNING

Close the trunk lid, lock the rear
seatbacks and do not allow children to
play inside the vehicle:
Leaving the trunk lid open or leaving
children in the vehicle with the keys is
dangerous. Children could open the
trunk lid and climb inside resulting in
possible injury or death from heat
exposure.

Always keep the car from being a
tempting place to play by locking rear
seats, doors and the trunk, and
keeping the keys where children can
not play with them:
Leaving children or animals
unattended in a parked vehicle is
dangerous. Babies left sleeping and
children who lock themselves in cars
or trunks can die very quickly from
heat prostration. Do not leave your
children or pets alone in a car at any
time. Do not leave the car, the rear
folding seats or the trunk unlocked.

CAUTION

For vehicles equipped with a rear
spoiler, do not lift the trunk lid by the
spoiler. Lifting up the trunk lid by the
rear spoiler could cause damage to the
rear spoiler and the trunk lid.

Opening the trunk lid

Pull up on the handle.

Closing the trunk lid

Grasp the inner handle and pull the trunk
lid down, then push the trunk lid down
until it locks securely. Be careful not to
slam it. Pull up on the trunk lid to make
sure it is secured.

Handle

3-30

Knowing Your Mazda

Doors and Locks

Mazdaspeed6_8V77-EA-06F_Edition1 Page100
Tuesday, May 9 2006 10:44 AM

Black plate (101,1)

qTrunk Security

In some situations you may want to
prevent the trunk from being unlocked
when the doors are unlocked with the key.

If you must leave your Mazda with
another person, such as a parking
attendant, protect valuables in the trunk
by locking the trunk with the master key,
or the request switch (with advanced key)
on the trunk lid and giving the other
person only the valet key, which does not
open the trunk.

With master key

To secure the trunk lid, close the trunk,
insert the master key and turn it
counterclockwise. Remove the key.

To cancel the security feature, insert the
master key into the lock, turn the key
clockwise to the center position and
remove it.

With request switch (with advanced
key)

NOTE

The trunk lid cannot be secured when
any door or the trunk lid is open.

To secure the trunk lid, press the request
switch on the trunk lid for about 3
seconds. This will lock only the trunk lid.

Request switch

To cancel the security feature, press the
request switch on the trunk lid for about 3
seconds again.

Knowing Your Mazda

Doors and Locks

3-31

Mazdaspeed6_8V77-EA-06F_Edition1 Page101
Tuesday, May 9 2006 10:44 AM

Black plate (102,1)

qTrunk Light

The trunk light is on when the lid is open
and off when it's closed.

NOTE

To prevent the battery from being
discharged, do not leave the trunk open
for a long period when the engine is not
running.

Inside Trunk Release Lever

Your vehicle is equipped with an inside
trunk release lever that provides a means
of escape for children and adults in the
event they become locked inside the
trunk.

No matter how careful adults might be
with keys and locking their cars, parents
should be aware that children may be
tempted to play around vehicles and use
the trunk as a hiding place.

Adults are advised to familiarize
themselves with the operation and
location of the inside trunk release lever
so that all children can be told about it in
an appropriate way, keeping in mind that
most vehicles don't have such levers.

3-32

Knowing Your Mazda

Doors and Locks

Mazdaspeed6_8V77-EA-06F_Edition1 Page102
Tuesday, May 9 2006 10:44 AM

Black plate (103,1)

WARNING

Close the trunk lid and do not allow
children to play inside the vehicle:
Leaving the trunk lid open or leaving
children in the vehicle with the keys is
dangerous. Children could open the
trunk lid and climb inside resulting in
possible injury or death from heat
exposure.

Always keep the car from being a
tempting place to play by locking
doors and the trunk, and keeping the
keys where children can not play with
them:
Leaving children or animals
unattended in a parked vehicle is
dangerous. Babies left sleeping and
children who lock themselves in cars
or trunks can die very quickly from
heat prostration. Do not leave your
children or pets alone in a car at any
time. Do not leave the car or the trunk
unlocked.

qOpening the Trunk Lid from the

Inside

Slide the inside trunk release lever in the
direction of the arrow. The lever is made
of material that will glow for hours in the
darkness of the trunk following a brief
exposure to ambient light.

The inside trunk release lever is located
on the inside of the trunk lid.

Open

Knowing Your Mazda

Doors and Locks

3-33

Mazdaspeed6_8V77-EA-06F_Edition1 Page103
Tuesday, May 9 2006 10:44 AM

Black plate (104,1)

Power Windows

The ignition switch must be in the ON
position for the power windows to
operate.

WARNING

Make sure the opening is clear before
closing a window:
Closing power windows are
dangerous. A person's hands, head, or
even neck could be caught by the
window and result in serious injury or
even death.
This warning applies especially to
children.

Always lock all passenger power
windows with the power window lock
switch on the driver's side while
children are in the vehicle, and never
allow children to play with power
window switches:
Leaving the power window switches
unlocked while children are in the
vehicle is dangerous. Power window
switches that are not locked with the
power window lock switch would allow
children to operate power windows
unintentionally which could result in
serious injury if a child's hands, head
or neck becomes caught by the
window.

CAUTION

To prevent burning out the fuse and
damaging the power window system,
do not open or close more than three
windows at once.

qOperating the Power Windows

NOTE

Each passenger window can be
operated with each door switch when
the power window lock switch on
the driver's door is in the unlocked
position (page 3-37).

Each passenger window can also be
operated by the power window
master control switches on the
driver's door.

Front passenger's
window

Right rear window

Left rear window

Driver's window

Master control switches

The following functions can be
performed for each power window
using the power window master
control switches on the driver's door
or each door switch.

Manual opening/closing

Auto-opening/closing

Two-step down function

3-34

Knowing Your Mazda

Doors and Locks

Mazdaspeed6_8V77-EA-06F_Edition1 Page104
Tuesday, May 9 2006 10:44 AM

Mazda Mazdaspeed 6 (2007 year). Manual - part 6
