8-1. Specifications

8-1.Specifications

: Unladen vehicle

: Vehicles without shark fin antenna

: Vehicles with shark fin antenna

■

Vehicle identification number

The vehicle identification number
(VIN) is the legal identifier for your
vehicle. This is the primary identifica-
tion number for your Lexus. It is used in
registering the ownership of your vehi-
cle.
This number is on the top left of the
instrument panel.

This number is also on the Certification
Label.

Maintenance data (fuel, oil level, etc.)

Dimensions and weight

Overall length

177.0 in. (4495 mm)

Overall width

72.4 in. (1840 mm)

Overall height

59.8 in. (1520 mm)

60.6 in. (1540 mm)

Wheelbase

103.9 in. (2640 mm)

Tread

Front

61.0 in. (1550 mm)

Rear

61.0 in. (1550 mm)

Vehicle capacity weight
(Occupants + luggage)

890 lb. (405 kg)

Seating capacity

5 (Front 2, Rear 3)

Vehicle identification

409

8-1. Specifications

Vehi

cle

spec

ifi

tions

This number is also stamped under the
right-hand front seat.

■

Engine number

The engine number is stamped on the
engine block as shown.

Engine

Model

2.0 L 4-cylinder (M20A-FXS)

Type

4-cylinder in line, 4-cycle, gasoline

Bore and stroke

3.17



3.84 in. (80.5



97.6 mm)

Displacement

121.3 cu.in. (1987 cm

)

Valve clearance

Automatic adjustment

Drive belt tension

Automatic adjustment

Fuel

Fuel type

Unleaded gasoline only

Octane Rating

87 (Research Octane Number 91) or higher

Fuel tank capacity (Reference)

10.6 gal. (40 L, 8.8 Imp.gal.)

410

8-1. Specifications



Front



Rear (AWD models)

■

Oil capacity (Drain and refill [Ref-
erence

])

: The engine oil capacity is a reference

quantity to be used when changing the
engine oil. When actually adding the
engine oil, make sure that the oil level is
between the low level mark and refill
upper limit mark (



P.332). Warm up

the engine and turn off the hybrid sys-
tem, wait about 5 minutes, and check the
oil level on the dipstick.

■

Engine oil selection

“Toyota Genuine Motor Oil” is used in
your Lexus vehicle. Use Lexus
approved “Toyota Genuine Motor
Oil” or equivalent to satisfy the follow-
ing grade and viscosity.
Oil grade:
ILSAC GF-6B multigrade engine oil
Recommended viscosity:
SAE 0W-16
SAE 0W-16 is the best choice for
good fuel economy and good starting
in cold weather.

Electric motor (traction motor)

Type

Permanent magnet synchronous motor

Maximum output

80 kW

Maximum torque

149.0 ft•lbf (202 N•m, 20.6 kgf•m)

Type

Induction asynchronous motor

Maximum output

5.3 kW

Maximum torque

40.6 ft•lbf (55 N•m, 5.6 kgf•m)

Hybrid battery (traction battery)

Type

Nickel-Metal hydride battery

Voltage

7.2 V/module

Capacity

6.5 Ah

Quantity

30 modules

Nominal voltage

216 V

Lubrication system

With filter

4.5 qt. (4.3 L, 3.8 Imp.qt.)

Without filter 4.1 qt. (3.9 L, 3.4 Imp.qt.)

411

8-1. Specifications

Vehi

cle

spec

ifi

tions

If SAE 0W-16 is not available, SAE
0W-20 oil may be used. However, it
must be replaced with SAE 0W-16 at
the next oil change.

Outside temperature

Oil viscosity (0W-16 is explained here
as an example):
• The 0W in 0W-16 indicates the

characteristic of the oil which allows
cold startability. Oils with a lower
value before the W allow for easier
starting of the engine in cold

weather.

• The 16 in 0W-16 indicates the vis-

cosity characteristic of the oil when
the oil is at high temperature. An oil
with a higher viscosity (one with a
higher value) may be better suited if
the vehicle is operated at high
speeds, or under extreme load con-
ditions.

How to read oil container label:
API registered mark is added to some
oil containers to help you select the oil
you should use.

: The coolant capacity is a reference quantity.

If replacement is necessary, contact your Lexus dealer.

Cooling system

Capacity

Gasoline
engine

6.3 qt. (6.0 L, 5.3 Imp.qt.)

Power con-
trol unit

1.8 qt. (1.7 L, 1.5 Imp.qt.)

Coolant type

Use either of the following:
• “Toyota Super Long Life Coolant”
• Similar high-quality ethylene glycol-based non-

silicate, non-amine, non-nitrite, and non-borate
coolant with long-life hybrid organic acid tech-
nology

Do not use plain water alone.

412

8-1. Specifications

■

Spark plug

■

12-volt battery

: The fluid capacity is a reference quantity.

If replacement is necessary, contact your Lexus dealer.

Ignition system

Make

DENSO FC16HR-Q8

Gap

0.031 in. (0.8 mm)

NOTICE

■

Iridium-tipped spark plugs

Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.

Electrical system

Open voltage at 68°F (20°C):

12.0 V or higher
If the voltage is lower than the standard value,
charge the battery.
(After charging the battery, turn on the high beam
headlights for 30 seconds with the power switch
OFF, and turn the headlights off.)

Charging rates:
Quick charge
Slow charge

15 A max.
5 A max.

Hybrid transmission

Fluid capacity

4.0 qt. (3.8 L, 3.3 Imp.qt.)

Fluid type

Toyota Genuine ATF WS

NOTICE

■

Hybrid transmission fluid type

Using transmission fluid other than the above type may cause abnormal noise or vibra-

tion, or ultimately damage the transmission of your vehicle.

413

8-1. Specifications

icle

ific

atio

: The fluid capacity is a reference quantity.

If replacement is necessary, contact your Lexus dealer.

: Minimum pedal clearance when depressed with a force of 67.4 lbf (300N, 30.6 kgf)

while the hybrid system is operating.

: Make sure to confirm that the brake system warning light (yellow) does not illuminate. (If

the brake system warning light illuminates, refer to P.379.)

Rear differential (rear electric motor) (AWD models)

Fluid capacity

1.3 qt. (1.2 L, 1.1 Imp.qt.)

Fluid type

Toyota Genuine ATF WS

NOTICE

■

Transmission fluid type

Using transmission fluid other than the above type may cause abnormal noise or vibra-

tion, or ultimately damage the transmission of your vehicle.

Brakes

Pedal clearance

4.29 in. (109 mm) Min.

Brake pad wear limit

0.04 in. (1.0 mm)

Pedal free play

0.04



0.24 in. (1.0



6.0 mm)

Parking brake indicator

When pushing the parking brake switch for 1 to 4
seconds: comes on
When pulling the parking brake switch for 1 to 4
seconds: turns off

Fluid type

SAE J1703 or FMVSS No. 116 DOT 3
SAE J1704 or FMVSS No. 116 DOT 4

Steering

Free play

Less than 1.2 in. (30 mm)

414

8-1. Specifications

A: Wedge base bulbs (amber)
B: Wedge base bulbs (clear)

Tires and wheels

Tire size

225/50RF18 95V

Tire inflation pressure
(Recommended cold tire inflation
pressure)

Front: 33 psi (230 kPa, 2.3 kgf/cm

or bar)

Rear: 33 psi (230 kPa, 2.3 kgf/cm

or bar)

Wheel size



7 J

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

Light bulbs

Bulb No.

Type

Exterior

Front turn signal lights (vehicles
with single-beam headlights)

WY21W

Interior

Vanity lights



415

8-1. Specifications

Vehi

cle

spec

ifi

tions

■

Gasoline quality

In very few cases, driveability problems may

be caused by the brand of gasoline you are

using. If driveability problems persist, try

changing the brand of gasoline. If this does

not correct the problem, consult your Lexus

dealer.

■

Recommendation of the use of gasoline

containing detergent additives

●

Lexus recommends the use of gasoline

that contains detergent additives to avoid

the build-up of engine deposits.

●

All gasoline sold in the U.S.A. contains

minimum detergent additives to clean

and/or keep clean intake systems, per

EPA’s lowest additives concentration

program.

●

Lexus strongly recommends the use of

Top Tier Detergent Gasoline. For more

information on Top Tier Detergent Gas-

oline and a list of marketers, please go to

the official website www.toptiergas.com.

■

Recommendation of the use of low

emissions gasoline

Gasolines containing oxygenates such as

ethers and ethanol, as well as reformulated

gasolines, are available in some cities.

These fuels are typically acceptable for use,

providing they meet other fuel require-

ments.

Lexus recommends these fuels, since the

formulations allow for reduced vehicle

emissions.

■

Non-recommendation of the use of

blended gasoline

●

Use only gasoline containing up to 15%
ethanol.
DO NOT use any flex-fuel or gasoline
that could contain more than 15% etha-
nol, including from any pump labeled
E30 (30% ethanol

), E50 (50% eth-

anol

), E85 (85% ethanol

)

(which are only some examples of fuel
containing more than 15% ethanol).

●

If you use gasohol in your vehicle, be sure

that it has an octane rating no lower than

87.

●

Lexus does not recommend the use of

gasoline containing methanol.

■

Non-recommendation of the use of gas-

oline containing MMT

Some gasoline contains an octane enhanc-

ing additive called MMT (Methylcyclopen-

tadienyl Manganese Tricarbonyl).
Lexus does not recommend the use of gas-

oline that contains MMT. If fuel containing

MMT is used, your emission control system

may be adversely affected.
The malfunction indicator lamp on the

instrument cluster may come on. If this hap-

pens, contact your Lexus dealer for service.

■

If your engine knocks

●

Consult your Lexus dealer.

●

You may occasionally notice light knock-

ing for a short time while accelerating or

driving uphill. This is normal and there is

no need for concern.

Fuel information

You must only use unleaded gaso-
line.
Select octane rating 87 (Research
Octane Number 91) or higher. Use
of unleaded gasoline with an octane
rating lower than 87 may result in
engine knocking. Persistent knock-
ing can lead to engine damage.

At minimum, the gasoline you use
should meet the specifications of
ASTM D4814 in the U.S.A.

416

8-1. Specifications

NOTICE

■

Notice on fuel quality

●

Do not use improper fuels. If improper

fuels are used, the engine will be dam-

aged.

●

Do not use leaded gasoline.

Leaded gasoline can cause damage to

your vehicle’s three-way catalytic con-

verters causing the emission control sys-

tem to malfunction.

●

Do not use gasohol other than the type

previously stated.

Other gasohol may cause fuel system

damage or vehicle performance prob-

lems.

●

Using unleaded gasoline with an

octane number or rating lower than

the level previously stated will cause

persistent heavy knocking.

At worst, this will lead to engine damage

and will void the vehicle warranty.

■

Fuel-related poor driveability

If poor driveability (poor hot starting,

vaporization, engine knocking, etc.) is

encountered after using a different type

of fuel, discontinue the use of that type of

fuel.

■

When refueling with gasohol

Take care not to spill gasohol. It can

damage your vehicle’s paint.

417

8-1. Specifications

Vehi

cle

spec

ifi

tions

Tire size (



P.418)

Run-flat tire (RFT) or standard tire (



P.392)

This vehicle can be equipped with either run-flat tires (RFT) or standard tires. A

mark is molded on the sidewall of the run-flat tire.

DOT and Tire Identification Number (TIN) (



P.418)

Location of treadwear indicators (



P.339)

Tire ply composition and materials

Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies
in a tire.

Radial tires or bias-ply tires

A radial tire has “RADIAL” on the sidewall. A tire not marked “RADIAL” is a bias-ply tire.

TUBELESS or TUBE TYPE

A tubeless tire does not have a tube and air is directly put into the tire. A tube type tire has a
tube inside the tire and the tube maintains the air pressure.

Load limit at maximum cold tire inflation pressure (



P.421)

Maximum cold tire inflation pressure (



P.421)

This means the pressure to which a tire may be inflated.

Uniform tire quality grading

For details, see “Uniform Tire Quality Grading” that follows.

Tire information

Typical tire symbols

A
B

C
D

418

8-1. Specifications

Summer tires or all season tires (



P.340)

An all season tire has “M+S” on the sidewall. A tire not marked “M+S” is a summer tire.



Type A

DOT symbol

Tire Identification Number (TIN)

Tire manufacturer’s identification
mark

Tire size code

Manufacturer’s optional tire type
code (3 or 4 letters)

Manufacturing week

Manufacturing year

: The DOT symbol certifies that the tire

conforms to applicable Federal Motor
Vehicle Safety Standards.



Type B

DOT symbol

Tire Identification Number (TIN)

Tire manufacturer’s identification
mark

Manufacturer’s code

Manufacturing week

Manufacturing year

: The DOT symbol certifies that the tire

conforms to applicable Federal Motor
Vehicle Safety Standards.

■

Typical tire size information

The illustration indicates typical tire
size.

Typical DOT and Tire Identifica-
tion Number (TIN)

A
B
C

Tire size

A
B
C

E
F

419

8-1. Specifications

Vehi

cle

spec

ifi

tions

Tire use
(P = Passenger car,
T = Temporary use)

Section width (millimeters)

Aspect ratio
(tire height to section width)

Tire construction code
(R = Radial, D = Diagonal)

Run-flat tire code

Wheel diameter (inches)

Load index (2 digits or 3 digits)

Speed symbol (alphabet with one
letter)

■

Tire dimensions

Section width

Tire height

Wheel diameter

Bead

Sidewall

Shoulder

Tread

Belt

Inner liner

Reinforcing rubber

Carcass

Rim lines

Bead wires

Chafer

This information has been prepared in
accordance with regulations issued by
the National Highway Traffic Safety
Administration of the U.S. Department
of Transportation.
It provides the purchasers and/or pro-
spective purchasers of Lexus vehicles
with information on uniform tire quality
grading.

Your Lexus dealer will help answer any
questions you may have as you read this

B
C

E
F

A
B
C

Tire section names

Uniform Tire Quality Grading

A
B
C
D

E
F

420

8-1. Specifications

information.

■

DOT quality grades

All passenger vehicle tires must con-
form to Federal Safety Requirements
in addition to these grades. Quality
grades can be found where applicable
on the tire sidewall between tread
shoulder and maximum section width.

For example: Treadwear 200 Traction AA
Temperature A

■

Treadwear

The treadwear grade is a comparative
rating based on the wear rate of the
tire when tested under controlled con-
ditions on a specified government test
course.

For example, a tire graded 150 would
wear one and a half (1 - 1/2) times as well
on the government course as a tire graded
100.
The relative performance of tires depends
upon the actual conditions of their use.
Performance may differ significantly from
the norm due to variations in driving habits,
service practices and differences in road
characteristics and climate.

■

Traction AA, A, B, C

The traction grades, from highest to
lowest, are AA, A, B and C, and they
represent the tire’s ability to stop on
wet pavement as measured under con-
trolled conditions on specified govern-
ment test surfaces of asphalt and
concrete.

A tire marked C may have poor traction
performance.
Warning: The traction grade assigned to
this tire is based on braking (straight
ahead) traction tests and does not include

cornering (turning) traction.

■

Temperature A, B, C

The temperature grades are A (the
highest), B, and C, representing the
tire’s resistance to the generation of
heat and its ability to dissipate heat
when tested under controlled condi-
tions on a specified indoor laboratory
test wheel.

Sustained high temperature can cause the
material of the tire to degenerate and
reduce tire life, and excessive temperature
can lead to sudden tire failure.
Grade C corresponds to a level of perfor-
mance which all passenger car tires must
meet under the Federal Motor Vehicle
Safety Standard No. 109.
Grades B and A represent higher levels of
performance on the laboratory test wheel
than the minimum required by law.
Warning: The temperature grades of a tire
assume that it is properly inflated and not
overloaded.
Excessive speed, underinflation, or exces-
sive loading, either separately or in combi-
nation, can cause heat buildup and
possible tire failure.

421

8-1. Specifications

Vehi

cle

spec

ifi

tions

Glossary of tire terminology

Tire related term

Meaning

Cold tire inflation pressure

Tire pressure when the vehicle has been parked for three
hours or more, or has not been driven more than 1 mile or
1.5 km under that condition

Maximum inflation pressure

The maximum cold inflated pressure to which a tire may be
inflated, shown on the sidewall of the tire

Recommended inflation
pressure

Cold tire inflation pressure recommended by a manufac-
turer

Accessory weight

The combined weight (in excess of those standard items
which may be replaced) of hybrid transmission, power
steering, power brakes, power windows, power seats, radio
and heater, to the extent that these items are available as
factory-installed equipment (whether installed or not)

Curb weight

The weight of a motor vehicle with standard equipment,
including the maximum capacity of fuel, oil and coolant, and
if so equipped, air conditioning and additional weight
optional engine

Maximum loaded vehicle
weight

The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight

Normal occupant weight

150 lb. (68 kg) times the number of occupants specified in
the second column of Table 1

that follows

Occupant distribution

Distribution of occupants in a vehicle as specified in the third
column of Table 1

below

Production options weight

The combined weight of installed regular production
options weighing over 5 lb. (2.3 kg) in excess of the stan-
dard items which they replace, not previously considered in
curb weight or accessory weight, including heavy duty
brakes, ride levelers, roof rack, heavy duty 12-volt battery,
and special trim

Rim

A metal support for a tire or a tire and tube assembly upon
which the tire beads are seated

Rim diameter
(Wheel diameter)

Nominal diameter of the bead seat

422

8-1. Specifications

Rim size designation

Rim diameter and width

Rim type designation

The industry manufacturer’s designation for a rim by style or
code

Rim width

Nominal distance between rim flanges

Vehicle capacity weight
(Total load capacity)

The rated cargo and luggage load plus 150 lb. (68 kg) times
the vehicle’s designated seating capacity

Vehicle maximum load on
the tire

The load on an individual tire that is determined by distribut-
ing to each axle its share of the maximum loaded vehicle
weight, and dividing by two

Vehicle normal load on the
tire

The load on an individual tire that is determined by distribut-
ing to each axle its share of curb weight, accessory weight,
and normal occupant weight (distributed in accordance
with Table 1

below), and dividing by two

Weather side

The surface area of the rim not covered by the inflated tire

Bead

The part of the tire that is made of steel wires, wrapped or
reinforced by ply cords and that is shaped to fit the rim

Bead separation

A breakdown of the bond between components in the bead

Bias ply tire

A pneumatic tire in which the ply cords that extend to the
beads are laid at alternate angles substantially less than 90
degrees to the centerline of the tread

Carcass

The tire structure, except tread and sidewall rubber which,
when inflated, bears the load

Chunking

The breaking away of pieces of the tread or sidewall

Cord

The strands forming the plies in the tire

Cord separation

The parting of cords from adjacent rubber compounds

Cracking

Any parting within the tread, sidewall, or innerliner of the tire
extending to cord material

A pneumatic tire with an inverted flange tire and rim system
in which the rim is designed with rim flanges pointed radially
inward and the tire is designed to fit on the underside of the
rim in a manner that encloses the rim flanges inside the air
cavity of the tire

Extra load tire

A tire designed to operate at higher loads and at higher
inflation pressures than the corresponding standard tire

Tire related term

Meaning

423

8-1. Specifications

Vehi

cle

spec

ifi

tions

Groove

The space between two adjacent tread ribs

Innerliner

The layer(s) forming the inside surface of a tubeless tire that
contains the inflating medium within the tire

Innerliner separation

The parting of the innerliner from cord material in the car-
cass

Intended outboard sidewall

(a) The sidewall that contains a whitewall, bears white letter-
ing, or bears manufacturer, brand, and/or model name
molding that is higher or deeper than the same molding on
the other sidewall of the tire, or
(b) The outward facing sidewall of an asymmetrical tire that
has a particular side that must always face outward when
mounted on a vehicle

Light truck (LT) tire

A tire designated by its manufacturer as primarily intended
for use on lightweight trucks or multipurpose passenger
vehicles

Load rating

The maximum load that a tire is rated to carry for a given
inflation pressure

Maximum load rating

The load rating for a tire at the maximum permissible infla-
tion pressure for that tire

Maximum permissible infla-
tion pressure

The maximum cold inflation pressure to which a tire may be
inflated

Measuring rim

The rim on which a tire is fitted for physical dimension
requirements

Open splice

Any parting at any junction of tread, sidewall, or innerliner
that extends to cord material

Outer diameter

The overall diameter of an inflated new tire

Overall width

The linear distance between the exteriors of the sidewalls of
an inflated tire, including elevations due to labeling, decora-
tions, or protective bands or ribs

Passenger car tire

A tire intended for use on passenger cars, multipurpose
passenger vehicles, and trucks, that have a gross vehicle
weight rating (GVWR) of 10,000 lb. or less.

Ply

A layer of rubber-coated parallel cords

Ply separation

A parting of rubber compound between adjacent plies

Tire related term

Meaning

424

8-1. Specifications

: Table 1



Occupant loading and distribution for vehicle normal load for various desig-

nated seating capacities

Pneumatic tire

A mechanical device made of rubber, chemicals, fabric and
steel or other materials, that, when mounted on an automo-
tive wheel, provides the traction and contains the gas or fluid
that sustains the load

Radial ply tire

A pneumatic tire in which the ply cords that extend to the
beads are laid at substantially 90 degrees to the centerline
of the tread

Reinforced tire

A tire designed to operate at higher loads and at higher
inflation pressures than the corresponding standard tire

Section width

The linear distance between the exteriors of the sidewalls of
an inflated tire, excluding elevations due to labeling, decora-
tion, or protective bands

Sidewall

That portion of a tire between the tread and bead

Sidewall separation

The parting of the rubber compound from the cord material
in the sidewall

Snow tire

A tire that attains a traction index equal to or greater than
110, compared to the ASTM E-1136 Standard Reference
Test Tire, when using the snow traction test as described in
ASTM F-1805-00, Standard Test Method for Single Wheel
Driving Traction in a Straight Line on Snow-and Ice-Cov-
ered Surfaces, and which is marked with an Alpine Symbol
(

) on at least one sidewall

Test rim

The rim on which a tire is fitted for testing, and may be any
rim listed as appropriate for use with that tire

Tread

That portion of a tire that comes into contact with the road

Tread rib

A tread section running circumferentially around a tire

Tread separation

Pulling away of the tread from the tire carcass

Treadwear indicators (TWI)

The projections within the principal grooves designed to
give a visual indication of the degrees of wear of the tread

Wheel-holding fixture

The fixture used to hold the wheel and tire assembly
securely during testing

Tire related term

Meaning

425

8-1. Specifications

Vehi

cle

spec

ifi

tions

Designated seating capac-

ity, Number of occupants

Vehicle normal load, Num-

ber of occupants

Occupant distribution in a

normally loaded vehicle

2 through 4

2 in front

5 through 10

2 in front, 1 in second seat

11 through 15

2 in front, 1 in second seat, 1 in

third seat, 1 in fourth seat

16 through 20

2 in front, 2 in second seat, 2

in third seat, 1 in fourth seat

426

8-2. Customization

8-2.Customization

■

Changing using the meter control
switches

Press

of the meter con-

trol switches, and select

Press

of the meter con-

trol switches, select the item, and
press “OK”.

Press

of the meter con-

trol switches, select the desired set-
ting, and press “OK”.

To go back to the previous screen or
exit the customize mode, press

■

Changing using the Center Dis-
play

Select

on the main menu.

Select “Vehicle customize” on the
sub menu.

Various setting can be changed. Refer to

the list of settings that can be changed for

details.

■

When customizing using the Center

Display

Stop the vehicle in a safe place, apply the

parking brake, and shift the shift lever to P.

Also, to prevent 12-volt battery discharge,

leave the hybrid system operating while

customizing the features.

Some function settings are changed simultaneously with other functions being cus-
tomized. Contact your Lexus dealer for further details.

Settings that can be changed using the Center Display
Settings that can be changed using the meter control switches
Settings that can be changed by your Lexus dealer

Definition of symbols: O = Available,



= Not available

Customizable features

Your vehicle includes a variety of
electronic features that can be per-
sonalized to your preferences. The
settings of these features can be
changed by using the meter control
switches, the Center Display or at
your Lexus dealer.

Customizing vehicle features

WARNING

■

Cautions during customization

As the hybrid system needs to be operat-

ing during customization, ensure that the

vehicle is parked in a place with ade-

quate ventilation. In a closed area such as

a garage, exhaust gases including harm-

ful carbon monoxide (CO) may collect

and enter the vehicle. This may lead to

death or a serious health hazard.

NOTICE

■

During customization

To prevent 12-volt battery discharge,

ensure that the hybrid system is operat-

ing while customizing features.

Customizable features

427

8-2. Customization

Vehi

cle

spec

ifi

tions

■

Gauges, meters and multi-information display (



P.79, 83, 89)

Function

Default setting

Customized set-

ting

Language

English

French



Spanish

Units

miles (MPG)

km (km/L)



km (L/100 km)

miles (MPG Impe-

rial)

Speedometer display

Digital

Analog



Drive information 1

Current fuel con-

sumption



Average fuel econ-

omy (after reset)

Drive information 2

Distance (driving

range)



Average vehicle

speed (after reset)

Pop-up display

Off



Accent color

Color 1

Color 2



Tachometer setting

Change according

to driving mode

Always tachome-

ter



Always Hybrid

System Indicator

Rev indicator

Off



Rev indicator red zone set-
ting

4000 rpm

2000 - 6200 rpm



Rev peak

Off



EV indicator

Off



Suggestion function

On (when the vehi-

cle is stopped)



Off

Rear seat reminder function

Off



428

8-2. Customization

: For details about each function:



P.79, 83, 93

: The setting can be changed on “General” of

: The default setting varies according to country.

: Except F SPORT models

: 2 of the following items: current fuel consumption, average fuel economy (after reset),

average fuel economy (after start), average fuel economy (after refuel), average vehicle
speed (after reset), average vehicle speed (after start), elapsed time (after reset),
elapsed time (after start), distance (driving range), distance (after start), blank.

: F SPORT models

: The setting can be changed on “Notifications” of

■

Head-up Display

(



P.95)

: If equipped

■

Door lock (



P.110, 396)

Function

Default setting

Customized set-

ting

Gauge information

Hybrid System

Indicator

Tachometer



No content

Route guidance to destination

Off



Driving support system display

Off



Compass

Off



Audio system operation status

Off



Rotation

Horizontal position

Rotating counter-

clockwise/clock-

wise



Function

Default setting

Customized set-

ting

Unlocking using a mechanical
key

Driver’s door

unlocked in one

step, all doors

unlocked in two

step

All doors unlocked

in one step

 

Automatic door locking func-
tion

Shift position linked

door locking oper-

ation

Off



Speed linked door

locking operation

429

8-2. Customization

Vehi

cle

spec

ifi

tions

■

Smart access system with push-button start and wireless remote control
(



P.106, 126)

■

Smart access system with push-button start (



P.126)

: This setting can be changed when the smart door unlocking setting is set to “Driver’s

door”.

Automatic door unlocking
function

Shift position linked

door unlocking

operation

Off



Driver’s door

linked door

unlocking opera-

tion

Function

Default setting

Customized set-

ting

Operating signal (Buzzers)

Standard

Desired volume



Operation signal (Emergency
flashers)

Off



Time elapsed before automatic
door lock function is activated if
door is not opened after being
unlocked

60 seconds

Off



30 seconds

120 seconds

Open door warning buzzer

Off

 

Function

Default setting

Customized set-

ting

Smart access system with push-
button start

Off

 

Smart door unlocking

Driver’s door

All the doors



Time elapsed before unlocking
all the door when gripping and
holding the driver’s door han-
dle

2 seconds

Off

 

1.5 seconds

2.5 seconds

Number of consecutive door
lock operations

2 times

As many as desired

 

Function

Default setting

Customized set-

ting

430

8-2. Customization

■

Wireless remote control (



P.106)

: If equipped

■

Power back door

(



P.117)

: If equipped

Function

Default setting

Customized set-

ting

Wireless remote control

Off

 

Unlocking operation

Driver’s door

unlocked in one

step, all doors

unlocked in two

step

All doors unlocked

in one step



Locking operation when door
opened

Off



Theft deterrent panic mode

Off

 

The function that activates the

switch of the wireless

remote control when locking
the door (



P.117)

On (Unlocking all

the door)

Off

 

On (Unlocking

back door only)

Function

Default setting

Customized set-

ting

Power back door operation

Off



Buzzer volume

Level 3

Level 1



Level 2

Hands Free Power Back Door
(kick sensor)

Off



Hands Free Power Back Door
(kick sensor) when the power
switch is off

Off

 

431

8-2. Customization

Vehi

cle

spec

ifi

tions

■

Driving position memory

(



P.133)

: If equipped

■

Outside rear view mirrors (



P.143)

: If equipped

■

Power windows and moon roof

(



P.145, 147)

: If equipped

Function

Default setting

Customized set-

ting

Selecting doors linked to the
memory recall function

Driver’s door

All doors

 

Driver’s seat slide movement
when exiting the vehicle

Full

Off



Partial

Steering wheel movement

Tilt only

Off



Telescopic only

Tilt and telescopic

Function

Default setting

Customized set-

ting

Automatic mirror folding and
extending operation

Linked to the lock-

ing/unlocking of

the doors

Off

 

Linked to opera-

tion of the power

switch

Function

Default setting

Customized set-

ting

Mechanical key linked opera-
tion

Off

 

Wireless remote control linked
operation

Off

On (open only)

 

Wireless remote control linked
operation signal (buzzer)

Off

 

432

8-2. Customization

■

Automatic light control system (



P.180)

■

Lights (



P.180)

: Except for Canada

: If equipped

■

Rear window wiper (



P.191)

Function

Default setting

Customized set-

ting

Light sensor sensitivity

Normal

Brighter



Bright

Dark

Darker

Time elapsed before head-
lights automatically turn off
after doors are closed

30 seconds

Off



60 seconds

90 seconds

Windshield wiper linked head-
light illumination

Off

 

Function

Default setting

Customized set-

ting

Daytime running lights

Off



Welcome lighting

Off

 

AFS (Adaptive Front-Lighting
System)

Off

 

Function

Default setting

Customized set-

ting

Rear window wiper operation
when the back door is opened

Off

 

Washer linked rear window
wiper operation

Off

 

Shift position linked rear win-
dow wiper operation

Once

Off

 

Continuous

433

8-2. Customization

Vehi

cle

spec

ifi

tions

■

PCS (Pre-Collision System) (



P.199)

: The system is automatically enabled each time the power switch is turned to ON.

■

LTA (Lane Tracing Assist) (



P.209)

■

RSA (Road Sign Assist)

(



P.218)

: If equipped

■

Dynamic radar cruise control with full-speed range (



P.221)

Function

Customized setting

PCS (Pre-Collision System)

function

On, Off



Adjust alert timing

Early, Middle, Late



Function

Customized setting

Lane centering function

On, Off



Alert type

Steering wheel vibration, Buzzer



Alert sensitivity

High, Standard



Vehicle sway warning function

On, Off



Vehicle sway warning sensitiv-
ity

High, Standard, Low



Function

Customized setting

RSA (Road Sign Assist)

On, Off



Excess speed notification
method

Display only, Display and buzzer, No

notification



Excess speed notification level

1 mph (2 km/h), 3 mph (5 km/h), 5 mph

(10 km/h)



Other notifications method
(No-entry notification)

Display only, Display and buzzer, No

notification



Function

Customized setting

Curve speed reduction func-
tion

High, Low, Off



434

8-2. Customization

■

BSM (Blind Spot Monitor)

(



P.232)

: If equipped

■

PKSA (Parking Support Alert)

(



P.236)

: If equipped

■

Intuitive parking assist

(



P.237)

: If equipped

■

RCTA (Rear Cross Traffic Alert) function

(



P.244)

: If equipped

Function

Default setting

Customized set-

ting

BSM (Blind Spot Monitor)

Off



Outside rear view mirror indi-
cator brightness

Bright

Dim



Alert timing for presence of
approaching vehicle (sensitiv-
ity)

Intermediate

Early



Late

Only when vehicle

detected in blind

spot

Function

Default setting

Customized set-

ting

Buzzer volume

Level 2

Level 1



Level 3

Function

Default setting

Customized set-

ting

Intuitive parking assist

Off



Function

Default setting

Customized set-

ting

RCTA (Rear Cross Traffic
Alert) function

Off



Buzzer volume

Level2

Level1



Level3

435

8-2. Customization

Vehi

cle

spec

ifi

tions

■

PKSB (Parking Support Brake)

(



P.249)

: If equipped

■

Driving mode select switch (



P.258)

: If equipped

■

Automatic air conditioning system (



P.275)

■

Seat heaters

/seat ventilators

(



P.282)

: If equipped

Function

Default setting

Customized set-

ting

PKSB (Parking Support Brake)
function

Off



Function

Default setting

Customized set-

ting

Powertrain control in Custom
mode

Normal

Power

 

Eco

Chassis control in Custom
mode

Normal

Sport

 

Air conditioning operation in
Custom mode

Normal

Eco

 

Function

Default setting

Customized set-

ting

A/C auto switch operation

Off



Function

Default setting

Customized set-

ting

Driver’s seat temperature pref-
erence in automatic mode

Standard

-2 (cooler) to 2

(warmer)



Passenger’s seat temperature
preference in automatic mode

Standard

-2 (cooler) to 2

(warmer)



436

8-2. Customization

■

Heated steering wheel

(



P.282)

: If equipped

■

Illumination (



P.285)

Function

Default setting

Customized set-

ting

Steering wheel heating prefer-
ence in automatic mode

Standard

-2 (low) to 2 (high) O



Function

Default setting

Customized set-

ting

Time elapsed before the inte-
rior lights turn off

15 seconds

Off



7.5 seconds

30 seconds

Operation after the power
switch is turned off

Off

 

Operation when the doors are
unlocked

Off

 

Operation when you approach
the vehicle with the electronic
key on your person

Off

 

Outside door handle lights

Off

 

Time elapsed before the out-
side door handle lights

turn off

15 seconds

Off



7.5 seconds

30 seconds

Operation of the outside door
handle lights

when you

approach the vehicle with the
electronic key on your person

Off

 

Operation of the outside door
handle lights

when the doors

are unlocked

Off

 

Operation of the outside door
handle lights

when a door is

opened

Off

 

437

8-2. Customization

Vehi

cle

spec

ifi

tions

: If equipped

■

Vehicle customization

●

When the smart access system with

push-button start is off, the entry unlock

function cannot be customized.

●

When the doors remain closed after

unlocking the doors and the timer acti-

vated automatic door lock function acti-

vates, signals will be generated in

accordance with the operation buzzer

volume and operational signal (Emer-

gency flashers) function settings.

●

Some settings can be changed using a

switch or the Center Display. If a setting

is changed using a switch, the changed

setting will not be reflected on the Center

Display. until the power switch is turned

off and then to ON.

Rear interior light and footwell
lights

Off

 

Fading out of the outside door
handle lights

when they turn off

Long

Short

 

Function

Default setting

Customized set-

ting

438

8-3. Initialization

8-3.Initialization

: If equipped

Items to initialize

The following items must be initialized for normal system operation after such
cases as the 12-volt battery being reconnected, or maintenance being per-
formed on the vehicle.

List of the items to initialize

Item

When to initialize

Reference

Intuitive parking assist

• After reconnecting or changing

the 12-volt battery

P.239

PKSB (Parking Support Brake)

• After reconnecting or changing

the 12-volt battery

P.253
