Front passenger occupant classification system

Your vehicle is equipped with a front passenger occupant classification system.
This system detects the conditions of the front passenger seat and activates or
deactivates the following airbags.

●

SRS front passenger airbag

●

SRS front passenger knee airbag

●

Front passenger's seat SRS seat cushion airbag

SRS warning light

Front passenger’s seat belt reminder light

"AIR BAG OFF" indicator light

"AIR BAG ON" indicator light

WARNING

■

Front passenger occupant classification system precautions

Observe the following precautions regarding the front passenger occupant classification
system. Failure to do so may cause death or serious injury.

●

Wear the seat belt properly.

●

Make sure the front passenger’s seat belt plate has not been left inserted into the
buckle before someone sits in the front passenger seat.

●

Make sure the "AIR BAG OFF" indicator light is not illuminated when using the seat
belt extender for the front passenger seat. If the "AIR BAG OFF" indicator light is
illuminated, disconnect the extender tongue from the seat belt buckle, and reconnect
the seat belt. Reconnect the seat belt extender after making sure the "AIR BAG ON"
indicator light is illuminated. If you use the seat belt extender while the "AIR BAG

6-3. Reducing impact to the occupants in a collision

473

Driving suppor

t s

ystem

WARNING

OFF" indicator light is illuminated, the SRS airbags for the front passenger will not
activate, which could cause death or serious injury in the event of a collision.

●

Do not apply a heavy load to the front passenger seat or equipment (e.g. seatback
pocket or armrest).

●

Do not put weight on the front passenger seat by putting your hands or feet on the
front passenger seat seatback from the rear passenger seat.

●

Do not let a rear passenger lift the front passenger seat with their feet or press on the
seatback with their legs.

●

Do not put objects under the front passenger seat.

●

Do not recline the front passenger seatback so far that it touches a rear seat. This may
cause the "AIR BAG OFF" indicator light to be illuminated, which indicates that the
SRS airbags for the front passenger will not activate in the event of a severe accident. If
the seatback touches the rear seat, return the seatback to a position where it does not
touch the rear seat. Keep the front passenger seatback as upright as possible when the
vehicle is moving. Reclining the seatback excessively may lessen the effectiveness of
the seat belt system.

●

If an adult sits in the front passenger seat, the "AIR BAG ON" indicator light is
illuminated. If the "AIR BAG OFF" indicator is illuminated, ask the passenger to sit up
straight, well back in the seat, feet on the floor, and with the seat belt worn correctly.
If the "AIR BAG OFF" indicator still remains illuminated, either ask the passenger to
move to the rear seat, or if that is not possible, move the front passenger seat fully
rearward.

●

When it is unavoidable to install a forward-facing child restraint system on the front
passenger seat, install the child restraint system on the front passenger seat in the
proper order.

●

Do not modify or remove the front seats.

●

Do not kick the front passenger seat or subject it to severe impact. Otherwise, the SRS
warning light may come on to indicate a malfunction of the front passenger occupant
classification system.
In this case, contact your Lexus dealer immediately.

●

Child restraint systems installed on the rear seat should not contact the front seat-
backs.

●

Do not use a seat accessory, such as a cushion and seat cover, that covers the seat
cushion surface.

●

Do not modify or replace the upholstery of the front seat.

6-3. Reducing impact to the occupants in a collision

474

Related Links

Child restraint system(P. 30)
Child restraint system installation method(P. 31)

Front passenger occupant classification system conditions and opera-
tion

▶

Adult

(1)

Indicators / warning
lights

"AIR BAG ON" and "AIR BAG OFF"
indicator lights

"AIR BAG ON"

SRS warning light

Off

Front passenger’s seat belt reminder
light

Off

(2)

or flashing

(3)

Devices

Front passenger airbag

Activated

Seat cushion airbag in the front pas-
senger side

Activated

(2)

or deacti-

vated

(3)

(1)

The system judges a person of adult size as an adult. When a smaller adult sits in the

front passenger seat, the system may not recognize him/her as an adult depending on

his/her physique and posture.

(2)

In the event the front passenger is wearing a seat belt.

(3)

In the event the front passenger does not wear a seat belt.

▶

Child

(3)

Indicators / warning
lights

"AIR BAG ON" and "AIR BAG
OFF" indicator lights

"AIR BAG OFF" or "AIR
BAG ON"

(3)

SRS warning light

Off

Front passenger’s seat belt re-
minder light

Off

(1)

or flashing

(2)

Devices

Front passenger airbag

Deactivated or activated

(3)

Seat cushion airbag in the front
passenger side

Deactivated or activated

(1)(3)

(1)

In the event the front passenger is wearing a seat belt.

(2)

In the event the front passenger does not wear a seat belt.

6-3. Reducing impact to the occupants in a collision

475

Driving suppor

t s

ystem

(3)

For some children, child in seat, child in booster seat or child in convertible seat, the

system may not recognize him/her as a child. Factors which may affect this can be the

physique or posture.

▶

Child restraint system with infant

(3)

Indicators / warning
lights

"AIR BAG ON" and "AIR BAG OFF"
indicator lights

"AIR BAG OFF"

(4)

SRS warning light

Off

Front passenger’s seat belt reminder
light

Off

(1)

or flashing

(2)

Devices

Front passenger airbag

Deactivated

Seat cushion airbag in the front passen-
ger side

(1)

In the event the front passenger is wearing a seat belt.

(2)

In the event the front passenger does not wear a seat belt.

(3)

Never install a rear-facing child restraint system on the front passenger seat. A

forward-facing child restraint system should only be installed on the front passenger

seat when it is unavoidable.

(4)

In case the indicator light is not illuminated, consult this manual on how to install the

child restraint system properly.

▶

Unoccupied

Indicators / warning lights

"AIR BAG ON" and "AIR BAG OFF" indi-
cator lights

"AIR BAG OFF"

SRS warning light

Off

Front passenger’s seat belt reminder light

Devices

Front passenger airbag

Deactivated

Seat cushion airbag in the front passenger
side

▶

System malfunction

Indicators / warning lights

"AIR BAG ON" and "AIR BAG OFF" indi-
cator lights

"AIR BAG OFF"

SRS warning light

Front passenger’s seat belt reminder light

Devices

Front passenger airbag

Deactivated

6-3. Reducing impact to the occupants in a collision

476

Connected Services

Safety Connect

Safety Connect is a subscription-based telematics service that uses Global Posi-
tioning System (GPS) data and embedded cellular technology to provide safety
and security features to subscribers. Safety Connect is supported by Lexus’ desig-
nated response center, which operates 24 hours per day, 7 days per week.Safety
Connect service is available by subscription on select, telematics hardware-equip-
ped vehicles.By using the Safety Connect service, you are agreeing to be bound
by the Telematics Subscription Service Agreement and its Terms and Conditions,
as in effect and amended from time to time, a current copy of which is available at
Lexus.com. All use of the Safety Connect service is subject to such then-applicable
Terms and Conditions.

System components

Microphone

[SOS] button

LED light indicators

Services

Subscribers have the following Safety Connect services available:

●

Automatic Collision Notification

Helps drivers receive necessary response from emergency service provid-
ers.

→

P.482

●

Stolen Vehicle Location
Helps drivers in the event of vehicle theft.

→

P.482

●

Emergency Assistance Button ([SOS])
Connects drivers to response-center support.

→

P.482

●

Enhanced Roadside Assistance
Provides drivers various on-road assistance.

→

P.482

* :

If equipped

*1 :

U.S. Patent No. 7,508,298 B2

7-1. Connected Services

480

Subscription

After you have signed the Telematics Subscription Service Agreement and are
enrolled, you can begin receiving services.
A variety of subscription terms is available for purchase. Contact your Lexus
dealer, call the following or push the [SOS] button in your vehicle for further
subscription details.

●

The United States
1-800-25-LEXUS (1-800-255-3987)

●

Canada
1-800-26-LEXUS (1-800-265-3987)

●

Puerto Rico
1-877-539-8777

INFORMATION

■

Safety Connect Services Information

●

Phone calls using the vehicles Bluetooth

technology will not be possible during

Safety Connect.

●

Safety Connect is available beginning Fall 2009 on select Lexus models (in the
contiguous United States only). Contact with the Safety Connect response center
is dependent upon the telematics device being in operative condition, cellular connec-
tion availability, and GPS satellite signal reception, which can limit the ability to reach
the response center or receive emergency service support. Enrollment and Telematics
Subscription Service Agreement required. A variety of subscription terms is available;
charges vary by subscription term selected and location.

●

Automatic Collision Notification, Emergency Assistance and Stolen Vehicle Location
will function in the United States, including Hawaii and Alaska, Puerto Rico and in
Canada, and Enhanced Roadside Assistance will function in the United States, Puerto
Rico and in Canada.

●

Automatic Collision Notification, Emergency Assistance, Stolen Vehicle and En-
hanced Road Assistance will not function in the United States Virgin Islands. For
vehicles first sold in the USVI, no Safety Connect services will function in and outside
the United States Virgin Islands.

●

Safety Connect services are not subject to section 255 of the Telecommunications
Act and the device is not TTY compatible.

7-1. Connected Services

481

ireles
s communication

■

Languages

The Safety Connect response center will offer support in multiple languages. The Safety
Connect system will offer voice prompts in English, Spanish, and French. Please indicate
your language of choice when enrolling.

■

When contacting the response center

You may be unable to contact the response center if the network is busy.

Safety Connect LED light Indicators

When the engine switch is turned to ON, the red indicator light comes on for 2
seconds then turns off. Afterward, the green indicator light comes on, indicating
that the service is active.The following indicator light patterns indicate specific
system usage conditions:

●

Green indicator light on = Active service

●

Green indicator light flashing = Safety Connect call in process

●

Red indicator light (except at vehicle start-up) = System malfunction (contact
your Lexus dealer)

●

No indicator light (off) = Safety Connect service not active

Safety Connect services

■

Automatic Collision Notification

In case of either airbag deployment or severe rear-end collision, the system is
designed to automatically call the response center. The responding agent receives
the vehicle’s location and attempts to speak with the vehicle occupants to assess
the level of emergency. If the occupants are unable to communicate, the agent
automatically treats the call as an emergency, contacts the nearest emergency
services provider to describe the situation, and requests that assistance be sent to
the location.

■

Stolen Vehicle Location

If your vehicle is stolen, Safety Connect can work with local authorities to assist
them in locating and recovering the vehicle. After filing a police report, call the
Safety Connect response center at 1-800-25-LEXUS (1-800-255-3987) in the
United States, 1-877-539-8777 in Puerto Rico or 1-800-265-3987 in Canada,
and follow the prompts for Safety Connect to initiate this service.
In addition to assisting law enforcement with recovery of a stolen vehicle, Safety-
Connect-equipped vehicle location data may, under certain circumstances, be
shared with third parties to locate your vehicle. Further information is available at
Lexus.com.

7-1. Connected Services

482

■

Emergency Assistance Button ([SOS])

In the event of an emergency on the road, push the [SOS] button to reach the
Safety Connect response center. The answering agent will determine your vehicle’s
location, assess the emergency, and dispatch the necessary assistance required.
If you accidentally press the [SOS] button, tell the response-center agent that you
are not experiencing an emergency.

■

Enhanced Roadside Assistance

Enhanced Roadside Assistance adds GPS data to the already included warranty-
based Lexus roadside service.
Subscribers can press the [SOS] button to reach a Safety Connect response-cen-
ter agent, who can help with a wide range of needs, such as: towing, flat tire, fuel
delivery, etc. For a description of the Roadside Assistance services and their limita-
tions, please see the Safety Connect Terms and Conditions, which are available at
Lexus.com.

Safety information for Safety Connect

Important! Read this information about exposure to radio frequency signals before
using Safety Connect;The Safety Connect system installed in your vehicle is a
low-power radio transmitter and receiver. It receives and also sends out radio
frequency (RF) signals.In August 1996, the Federal Communications Commission
(FCC) adopted RF exposure guidelines with safety levels for mobile wireless
phones. Those guidelines are consistent with the safety standards previously set by
the following U.S. and international standards bodies.

●

ANSI (American National Standards Institute) C95.1 [1992]

●

NCRP (National Council on Radiation Protection and Measurement) Report
86 [1986]

●

ICNIRP (International Commission on Non-Ionizing Radiation Protection)
[1996]

Those standards were based on comprehensive and periodic evaluations of the
relevant scientific literature. Over 120 scientists, engineers, and physicians from
universities, and government health agencies and industries reviewed the available
body of research to develop the ANSI Standard (C95.1).
The design of Safety Connect complies with the FCC guidelines in addition to
those standards.

7-1. Connected Services

483

ireles
s communication

Remote Connect

Remote Connect is a smartphone application that lets you view and remotely
control certain aspects of your vehicle.For details about the functions and services
of this application, refer to http://www.lexus.com/enform/.Function of the Remote
Connect is achieved by using an embedded cellular device in the vehicle (DCM:
Data Communication Module).

Remote Connect subscription

After you sign the Telematics Subscription Service Agreement, download the
Lexus App from your smartphone’s app store, and register within the app (or enroll
and complete registration at the dealer), you can begin using these services.A
variety of subscription terms are available. Contact your Lexus dealer, or call
1-800-25-LEXUS (1-800-255-3987) for further subscription details.

INFORMATION

■

Availability of service

Remote Connect is not available in some countries or areas.

■

Remote Connect Information

●

Remote Connect should only be used by authorized users.

●

Laws in some communities may require that the vehicle be within view of the user
when operating Remote Connect. In some states, use of Remote Connect may violate
state or local laws. Before using Remote Connect, check your state and local laws.

●

Any malfunction of the Lexus should be repaired by your Lexus dealer.

●

Remote Connect is designed to work at temperatures above -22°F (-30°C). This
specification is related to the Remote Connect operation, but is dependent on the
vehicle’s operating temperature range which may be different.

●

Content is subject to change without notice.

●

Some features of the Remote Connect may not be available on some models.

●

Additional information can be found at https://www.lexus.com/enform/.

●

Availability of functions of the Remote Connect service is dependent on network
reception level.

■

Safety information for Remote Connect

Refer to the safety information for Safety Connect:

→

P.483

* :

If equipped

7-1. Connected Services

484

Service Connect

Service Connect uses embedded telematics hardware to collect and transmit
vehicle data that allows Lexus to provide:

●

Vehicle Health Report (VHR) (Safety Recalls, Service Campaigns, Current
Vehicle Alerts, Required Maintenance, and Vehicle Condition Status)

●

Maintenance Notifications

●

Vehicle Alert Notifications

For details about this service and how to register, refer to http://www.lexus.com/
enform/. The Service Connect is achieved by using a Data Communication Mod-
ule (DCM) built in the vehicle.

INFORMATION

■

Availability of service

Service Connect is not available in some countries or areas.

■

Service Connect Information

Availability of functions of the Service Connect is dependent on network reception level.

■

Safety information for Service Connect

Refer to the safety information for Safety Connect:

→

P.483

* :

If equipped

7-1. Connected Services

485

ireles
s communication

Maintenance and care

8-1. Exterior maintenance and care

Washing the vehicle ..............

488

8-2. Cleaning and protecting the ve-

hicle interior

Cleaning the vehicle interi-

or .................................................

494

Cleaning the areas with sat-

in-finish metal accents........

496

Cleaning the leather areas..

497

Cleaning the synthetic

leather areas...........................

498

8-3. Maintenance

Maintenance requirements.

499

Scheduled maintenance

outline.......................................

500

Do-it-yourself maintenance

501

General maintenance ...........

502

Engine compartment main-

tenance items list .................

503

Vehicle interior mainte-

nance items list .....................

504

Vehicle exterior mainte-

nance items list .....................

505

Emission inspection and

maintenance (I/M) pro-
grams........................................

506

8-4. Inspection of consumables

Do-it-yourself service pre-

cautions ....................................

507

Opening the hood ..................

510

Engine compartment...............

511

Adding washer fluid ...............

523

Air conditioning filter main-

tenance.....................................

524

8-5. Tire maintenance

Tire maintenance .....................

526

Tire inspection items...............

527

Run-flat tire features..............

530

Operation of the tire pres-

sure warning system.............

531

Checking tire inflation pres-

sure.............................................

543

Lifting the vehicle with a

floor jack...................................

545

Rotating the tires......................

546

Wheels.........................................

547

Headlight aim............................

549

487

Maintenance and car

Exterior maintenance and care

Washing the vehicle

WARNING

●

When washing the vehicle, do not apply water to the inside of the engine compart-
ment.
If water contacts electrical components, it may cause the vehicle to catch fire.

●

Exhaust gasses cause the exhaust pipes to become quite hot.
When washing the vehicle, be careful not to touch the exhaust pipes until they have
cooled sufficiently. Touching a hot exhaust pipe can cause burns.

NOTICE

■

To prevent paint deterioration and corrosion of the body and components (wheels,
etc.)

●

Wash the vehicle immediately in the following cases:

•

After driving near the sea coast

•

After driving on salted roads

•

If coal tar or tree sap is present on the paint surface

•

If dead insects, insect droppings or bird droppings are present on the paint surface

•

After driving in an area contaminated with soot, oily smoke, mine dust, iron powder
or chemical substances

•

If the vehicle becomes heavily soiled with dust or mud

•

If liquids such as benzine or gasoline are spilled on the paint surface

●

If the paint is chipped or scratched, have it repaired immediately.

●

To prevent the wheels from corroding, remove any dirt and store in a place with low
humidity when storing the wheels.

■

To prevent damage to the windshield wiper arms

When lifting the wiper arms away from the windshield, pull the driver side wiper arm
upward first, and repeat for the passenger side. When returning the wipers to their
original position, do so from the passenger side first.

Perform cleaning in a manner appropriate to each component and its material.

●

Working from top to bottom, liberally apply water to the vehicle body, wheel
wells and underside of the vehicle to remove any dirt and dust.

●

Wash the vehicle body using a sponge or soft cloth, such as a chamois.

●

For hard-to-remove marks, use car wash soap and rinse thoroughly with water.

●

Wipe away any water.

8-1. Exterior maintenance and care

488

INFORMATION

■

Self-restoring coat

The vehicle body has a self-restoring coating that is resistant to small surface scratches
caused by a car wash, etc.

●

The coating lasts for 5 to 8 years from when the vehicle is delivered from the plant.

●

The restoration time differs depending on the depth of the scratch and outside
temperature.
The restoration time may become shorter when the coating is warmed by applying
warm water.

●

Deep scratches caused by keys, coins, etc., cannot be restored.

●

Do not use waxes that contain abrasives.

■

When using a car wash

If the door handle becomes wet while the electronic key is within the effective range,
the door may lock and unlock repeatedly. In that case, follow the following correction
procedures to wash the vehicle:

●

Place the key in a position 6 ft. (2 m) or more separate from the vehicle while the
vehicle is being washed.
Take care to ensure that the key is not stolen.

●

Set the electronic key to battery-saving mode to disable the smart access system with
push-button start.

■

Brake pads and calipers

Rust may form if the vehicle is parked with wet brake pads or disc rotors, causing them
to stick. Before parking the vehicle after it is washed, drive slowly and apply the brakes
several times to dry the parts.

Using an automatic car wash

NOTICE

Vehicles with rain-sensing windshield wipers:
When using an automatic car wash, move the wiper lever to the off position.
If the wiper lever is in the AUTO position, the wipers may operate unintentionally and the
wiper blades may be damaged.

●

Perform the following before washing your vehicle:

•

Fold the mirrors.

•

Vehicles with power back door:
Turn off the power back door.

8-1. Exterior maintenance and care

489

Maintenance and car

Start washing from the front of the vehicle.
Extend the mirrors before driving.

●

Brushes used in automatic car washes may scratch the vehicle surface, parts
(wheel, etc.) and harm your vehicle’s paint.

●

Depending on the automatic car wash, the rear spoiler may become caught,
preventing it from being washed or causing damage to it.

●

When the shift position needs to be held in N, refer to P.154

Using a high pressure washer to wash the vehicle

NOTICE

●

When washing the vehicle, do not spray any of the cameras or their surrounding area
directly. The shock from high pressure water may cause a camera to malfunction.

●

Do not bring the tip of the nozzle close to connectors or the boots (rubber or resin
cover) of the following parts.
The parts may be damaged if sprayed by high-pressure water.

•

Drivetrain related parts

•

Steering parts

•

Suspension parts

•

Brake parts

●

Keep the tip of the nozzle at least 11.9 in. (30 cm) away from the vehicle body.
Otherwise resin parts, such as the moldings, bumpers, etc., may be deformed and
damaged. Also, do not continuously spray water on the same place.

●

Do not spray the lower part of the windshield continuously. If water enters the air
conditioning system intake located near the lower part of the windshield, the air
conditioning system may not operate correctly.

●

Do not wash the underside of the vehicle using a high pressure washer.

When using a high pressure washer, as water may enter the cabin, do not bring the
tip of the nozzle near the gaps around the doors or perimeter of the windows, or
spray these areas continuously.

Cleaning the wheels and wheel ornaments

Perform the following:

●

Remove any dirt immediately using a neutral cleaning agent.

●

Wash detergent off with water immediately after use.

8-1. Exterior maintenance and care

490

●

To protect the finish from damage, make sure to observe the following precau-
tions.

•

Do not use acidic, alkaline or abrasive cleaners

•

Do not use hard brushes

•

Do not use detergent on the wheels when they are hot, such as after driving or
parking in hot weather

Cleaning the bumpers

WARNING

If the paint of the front or rear bumper is chipped or scratched, the following systems may
not function correctly. If this occurs, consult your Lexus dealer.

●

Lexus Safety System + 3

●

BSM

●

Safe Exit Assist (with door opening control)

●

RCTA

●

PKSB

Do not scrub with abrasive cleaners.

Cleaning and protecting the plated portions

If dirt cannot be removed, clean the parts as follows:

●

Use a soft cloth dampened with an approximately 5 % solution of neutral
detergent and water to clean the dirt off.

●

Wipe the surface with a dry, soft cloth to remove any remaining moisture.

●

To remove oily deposits, use alcohol wet wipes or a similar product.

INFORMATION

■

Black stainless steel window moldings

The stainless steel window moldings are made of black oxide coated stainless steel.
When cleaning the vehicle, do not scrub the moldings with an abrasive cleaner as
their finish may be damaged or the color may change.

* :

If equipped

8-1. Exterior maintenance and care

491

Maintenance and car

Cleaning the exterior lights

NOTICE

●

Wash carefully. Do not use organic substances or scrub with a hard brush.
Doing so may damage the surface of the lights.

●

Do not apply wax to the lights.
Wax may damage the lenses.

Cleaning the windshield

WARNING

Vehicles with rain-sensing windshield wipers:
Move the wiper lever to the off position.
If the wiper lever is in the AUTO position, the wipers may operate unexpectedly in the
following situations, possibly leading serious injury from a hand being caught, or damage
to the wiper blades.

Off

AUTO

●

When the upper part of the windshield where the raindrop sensor is located is
touched by hand

●

When a wet rag or similar is held close to the raindrop sensor

●

If something bumps against the windshield

8-1. Exterior maintenance and care

492

Cleaning and protecting the vehicle interior

Cleaning the vehicle interior

WARNING

■

Water in the vehicle

●

Do not splash or spill liquid in the vehicle. Doing so may cause electrical components,
etc., to malfunction or catch fire.

●

Do not get any of the SRS components or wiring in the vehicle interior wet.
An electrical malfunction may cause the airbags to deploy or not function properly,
resulting in death or serious injury.

■

Cleaning the interior (especially instrument panel)

Do not use wax polish or a polishing cleaner on the instrument panel. The instrument
panel may reflect off the windshield, obstructing the driver’s view and leading to an
accident, resulting in death or serious injury.

NOTICE

■

Cleaning solvents

●

Do not use the following cleaning solvents, as they may discolor the vehicle interior or
cause streaks or damage to painted surfaces:

•

Areas other than the seats: Organic substances such as benzine or gasoline,
alkaline or acidic solutions, dye, and bleach

•

Seats: thinner, benzine, alcohol, or alkaline or acidic solutions

●

Do not use wax polish or a polishing cleaner. The painted surfaces of the instrument
panel or other interior parts may be damaged.

■

Water on the floor

Do not wash the vehicle floor with water.
If water contacts audio system or other electrical components under the floor carpet, it
may cause the vehicle to malfunction. Water may also cause the body to rust.

■

When cleaning the inside of the windshield

Do not allow glass cleaner to contact the lens of the front camera. Also, do not touch the
lens.

■

Cleaning the inside of the windshield and rear window

●

Do not use glass cleaners to clean the rear window, as this may cause damage to the
rear window defogger heater wires or antenna. Use a cloth dampened with lukewarm
water to gently wipe the window clean. Wipe the window in strokes running parallel to
the heater wires or antenna.

●

Be careful not to scratch or damage the heater wires or antenna.

8-2. Cleaning and protecting the vehicle interior

494

Perform cleaning in a manner appropriate to each component and its material.

●

Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth
dampened with lukewarm water.

●

If dirt cannot be removed, wipe it off with a soft cloth dampened with neutral
detergent diluted to approximately 1%.

Wring out any excess water from the cloth and thoroughly wipe off remaining traces of
detergent and water.

INFORMATION

■

Shampooing the carpets

Excellent results can be obtained by keeping the carpet as dry as possible. When
cleaning, use a commercially available foaming-type cleaner.
Use a sponge or brush to apply the foam and rub it in overlapping circles. Do not use
water. Wipe the surface to remove the cleaner and dirt and let it dry.

■

Handling the seat belts

Clean with mild soap and lukewarm water using a cloth or sponge. Also check the
belts periodically for excessive wear, fraying or cuts.

8-2. Cleaning and protecting the vehicle interior

495

Maintenance and car

Cleaning the leather areas

NOTICE

Observe the following precautions to avoid damage to and deterioration of leather
surfaces:

●

Remove any dust or dirt from leather surfaces immediately.

●

Do not expose the vehicle to direct sunlight for extended periods of time.
Park the vehicle in the shade, especially during summer.

●

Do not place items made of vinyl, plastic, or containing wax on the upholstery, as they
may stick to the leather surface if the vehicle interior heats up significantly.

●

Remove dirt and dust using a vacuum cleaner.

●

Wipe off any excess dirt and dust with a soft cloth dampened with diluted
detergent.

Use a diluted water solution of approximately 5% neutral wool detergent.

●

Wring out any excess water from the cloth and thoroughly wipe off all remain-
ing traces of detergent.

●

Wipe the surface with a dry, soft cloth to remove any remaining moisture. Allow
the leather to dry in a shaded and ventilated area.

INFORMATION

■

Caring for leather areas

Lexus recommends cleaning the interior of the vehicle at least twice a year to
maintain the quality of the vehicle’s interior.

8-2. Cleaning and protecting the vehicle interior

497

Maintenance and car

Maintenance

Maintenance requirements

To ensure safe and economical driving, day-to-day care and regular maintenance
are essential. It is the owner’s responsibility to perform regular checks. Lexus
recommends the following maintenance:

WARNING

■

If your vehicle is not properly maintained

Improper maintenance could result in serious damage to the vehicle and possible death
or serious injury.

■

Handling of the battery

●

Engine exhaust, some of its constituents, and a wide variety of automobile components
contain or emit chemicals known to the State of California to cause cancer and birth
defects and other reproductive harm. Work in a well ventilated area.

●

Oils, fuels and fluids contained in vehicles as well as waste produced by component
wear contain or emit chemicals known to the State of California to cause cancer and
birth defects or other reproductive harm. Avoid exposure and wash any affected area
immediately.

●

Battery posts, terminals and related accessories contain lead and lead compounds
which are known to cause brain damage. Wash your hands after handling.

INFORMATION

■

Repair and replacement

It is recommended that genuine Lexus parts be used for repairs to ensure performance
of each system. If non-Lexus parts are used in replacement or if a repair shop other than a
Lexus dealer performs repairs, confirm the warranty coverage.

■

Allow inspection and repairs to be performed by a Lexus dealer

●

Lexus technicians are well-trained specialists and are kept up to date with the latest
service information. They are well informed about the operation of all systems on your
vehicle.

●

Keep a copy of the repair order. It proves that the maintenance that has been
performed is under warranty coverage. If any problem should arise while your vehicle
is under warranty, your Lexus dealer will promptly take care of it.

■

General maintenance

General maintenance should be performed on a daily basis. This can be done by yourself
or by a Lexus dealer.

8-3. Maintenance

499

Maintenance and car

Scheduled maintenance outline

Scheduled maintenance should be performed at specified intervals according to
the maintenance schedule.
For details about maintenance items and schedules, refer to the "Warranty and
Service Guide", "Owner’s Manual Supplement" or "Scheduled Maintenance".

Resetting the message indicating maintenance is required

After the required maintenance is preformed according to the maintenance
schedule, the message must be reset. To reset the message, perform the following
procedure:

Select the

on the center display.

Select [Vehicle customize].

Select [Utility].

Select [Scheduled maintenance].

Select [Reset].

"The data has been reset" will be displayed on the center display when the reset
procedure has been completed.

Resetting the engine oil change message

After the engine oil has been replaced, the engine oil maintenance data should be
reset. Perform the following procedure:

Select the

on the center display.

Select [Vehicle customize].

Select [Utility].

Select [Oil maintenance].

Select [Reset].

"The data has been reset." will be displayed on the center display when the reset
procedure has been completed.

8-3. Maintenance

500

Engine compartment maintenance items list

Items

Check points

Battery

Check the connections.

→

P.520

Brake fluid

Is the brake fluid at the correct level?

→

P.518

NX350: Engine/intercooler

coolant

Is the engine/intercooler coolant at the correct level?

→

P.515

NX250: Engine coolant

Is the engine coolant at the correct level?

→

P.515

Engine oil

Is the engine oil at the correct level?

→

P.513

Exhaust system

There should not be any fumes or strange sounds.

NX350: Radiator, condens-

er and intercooler radiator

The radiator, condenser and intercooler radiator should
be free from foreign objects.

→

P.517

NX250: Radiator/condens-

The radiator and condenser should be free from foreign
objects.

→

P.517

Washer fluid

Is there sufficient washer fluid?

→

P.523

8-3. Maintenance

503

Maintenance and car

Lexus NX250 (2024 year). Manual in english - page 15
