Lexus RX500h (2023 year). Manual in english

For safety and security

1-1. For safe use

Before driving................................

For safe driving...............................

Seat belts .........................................

SRS airbags ....................................

Front passenger occupant classifi-

cation system ..............................

Exhaust gas precautions ...........

1-2. Child safety

Riding with children.....................

Child restraint systems ..............

1-3. Connected Services

Safety Connect .............................

Remote Connect..........................

Service Connect ............................

1-4. Hybrid system

Hybrid system features...............

Hybrid system precautions......

1-5. Theft deterrent system

Immobilizer system .....................

Alarm.................................................

1-1. For safe use

1-1.For safe use

Use only floor mats designed specifi-
cally for vehicles of the same model
and model year as your vehicle. Fix
them securely in place onto the carpet.

Insert the retaining hooks (clips)
into the floor mat eyelets.

Turn the upper knob of each retain-
ing hook (clip) to secure the floor
mats in place.

Always align the

marks

The shape of the retaining hooks (clips)
may differ from that shown in the illustra-
tion.

Before driving

Observe the following before start-
ing off in the vehicle to ensure
safety of driving.

Installing floor mats

WARNING

Observe the following precautions.

Failure to do so may cause the driver’s

floor mat to slip, possibly interfering with

the pedals while driving. An unexpect-

edly high speed may result or it may

become difficult to stop the vehicle. This

could lead to an accident, resulting in

death or serious injury.

■

When installing the driver’s floor mat

●

Do not use floor mats designed for

other models or different model year

vehicles, even if they are Lexus Genu-

ine floor mats.

●

Only use floor mats designed for the

driver’s seat.

●

Always install the floor mat securely

using the retaining hooks (clips) pro-

vided.

●

Do not use two or more floor mats on

top of each other.

●

Do not place the floor mat bot-

tom-side up or upside-down.

■

Before driving

●

Check that the floor mat is securely

fixed in the correct place with all the

provided retaining hooks (clips). Be

especially careful to perform this

check after cleaning the floor.

●

With the hybrid system stopped and

the shift position in P, fully depress

each pedal to the floor to make sure it

does not interfere with the floor mat.

1-1. For safe use

For
safety

and
security

Adjust the angle of the seatback so
that you are sitting straight up and
so that you do not have to lean for-
ward to steer. (



P.144)

Adjust the seat so that you can
depress the pedals fully and so that
your arms bend slightly at the
elbow when gripping the steering
wheel. (



P.144)

Lock the head restraint in place
with the center of the head restraint
closest to the top of your ears.
(



P.152)

Wear the seat belt correctly.
(



P.28)

Make sure that all occupants are wear-
ing their seat belts before driving the
vehicle. (



P.28)

Use a child restraint system appropri-
ate for the child until the child becomes
large enough to properly wear the
vehicle’s seat belt. (



P.45)

Make sure that you can see backward
clearly by adjusting the inside and out-
side rear view mirrors properly.
(



P.156, 157, 166)

For safe driving

For safe driving, adjust the seat and
mirror to an appropriate position
before driving.

Correct driving posture

WARNING

■

For safe driving

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

Do not adjust the position of the

driver’s seat while driving.

Doing so could cause the driver to lose

control of the vehicle.

●

Do not place a cushion between the

driver or passenger and the seatback.

A cushion may prevent correct pos-

ture from being achieved, and reduce

the effectiveness of the seat belt and

head restraint.

●

Do not place anything under the front

seats.

Objects placed under the front seats

may become jammed in the seat

tracks and stop the seat from locking in

place. This may lead to an accident

and the adjustment mechanism may

also be damaged.

●

Always observe the legal speed limit

when driving on public roads.

●

When driving over long distances, take

regular breaks before you start to feel

tired.

Also, if you feel tired or sleepy while

driving, do not force yourself to con-

tinue driving and take a break immedi-

ately.

Correct use of the seat belts

Adjusting the mirrors

1-1. For safe use

Seat belts

Make sure that all occupants are
wearing their seat belts before driv-
ing the vehicle.

WARNING

Observe the following precautions to

reduce the risk of injury in the event of

sudden braking, sudden swerving or an

accident.

Failure to do so may cause death or seri-

ous injury.

■

Wearing a seat belt

●

Ensure that all passengers wear a seat

belt.

●

Always wear a seat belt properly.

●

Each seat belt should be used by one

person only. Do not use a seat belt for

more than one person at once, includ-

ing children.

●

Lexus recommends that children be

seated in the rear seat and always use

a seat belt and/or an appropriate child

restraint system.

●

To achieve a proper seating position,

do not recline the seat more than nec-

essary. The seat belt is most effective

when the occupants are sitting up

straight and well back in the seats.

●

Do not wear the shoulder belt under

your arm.

●

Always wear your seat belt low and

snug across your hips.

●

When using the rear center seat seat

belt, check that the portion

in the

illustration is buckled.

If not buckled, make sure to buckle it

before using the seat belt.

■

Pregnant women

Obtain medical advice and wear the seat

belt in the proper way. (



P.29)

Women who are pregnant should posi-

tion the lap belt as low as possible over

the hips in the same manner as other

occupants, extending the shoulder belt

completely over the shoulder and avoid-

ing belt contact with the rounding of the

abdominal area.

If the seat belt is not worn properly, not

only the pregnant woman, but also the

fetus could suffer death or serious injury

as a result of sudden braking or a colli-

sion.

1-1. For safe use

For
safety

and
security



Extend the shoulder belt so that it
comes fully over the shoulder, but
does not come into contact with the
neck or slide off the shoulder.



Position the lap belt as low as possi-
ble over the hips.



Adjust the position of the seatback.
Sit up straight and well back in the
seat.



Do not twist the seat belt.

■

Child seat belt usage

The seat belts of your vehicle were princi-

pally designed for persons of adult size.

●

Use a child restraint system appropriate

for the child, until the child becomes large

enough to properly wear the vehicle’s

seat belt. (



P.45)

●

When the child becomes large enough to

properly wear the vehicle’s seat belt, fol-

low the instructions regarding seat belt

usage. (



P.28)

■

Seat belt extender

If your seat belts cannot be fastened

securely because they are not long enough,

a personalized seat belt extender is avail-

able from your Lexus dealer free of charge.

WARNING

■

People suffering illness

Obtain medical advice and wear the seat

belt in the proper way. (



P.29)

■

When children are in the vehicle



P.57

■

Seat belt damage and wear

●

Do not damage the seat belts by allow-

ing the belt, plate, or buckle to be

jammed in the door.

●

Inspect the seat belt system periodi-

cally. Check for cuts, fraying, and loose

parts. Do not use a damaged seat belt

until it is replaced. Damaged seat belts

cannot protect an occupant from

death or serious injury.

●

Ensure that the belt and plate are

locked and the belt is not twisted.

If the seat belt does not function cor-

rectly, immediately contact your Lexus

dealer.

●

Replace the seat assembly, including

the belts, if your vehicle has been

involved in a serious accident, even if

there is no obvious damage.

●

Do not attempt to install, remove,

modify, disassemble or dispose of the

seat belts. Have any necessary repairs

carried out by your Lexus dealer. Inap-

propriate handling may lead to incor-

rect operation.

Correct use of the seat belts

1-1. For safe use

To fasten the seat belt, push the
plate into the buckle until a click
sound is heard.

To release the seat belt, press the
release button .

■

Emergency locking retractor (ELR)

The retractor will lock the belt during a sud-

den stop or on impact. It may also lock if you

lean forward too quickly. When the seat belt

locks, pull the belt strongly and then release

the belt, then a slow and easy pulling will

allow the belt to extend.

■

Automatic locking retractor (ALR)

When a passenger’s shoulder belt is com-

pletely extended and then retracted even

slightly, the belt is locked in that position and

cannot be extended. This feature is used to

hold the child restraint system (CRS) firmly.

To free the belt again, fully retract the belt

and then pull the belt out once more.

(



P.45)

WARNING

■

Using a seat belt extender

Observe the following precautions to

reduce the risk of injury in the event of

sudden braking, sudden swerving or an

accident.

Failure to do so may cause death or seri-

ous injury.

●

Do not wear the seat belt extender if

you can fasten the seat belt without the

extender.

●

Do not use the seat belt extender

when installing a child restraint system

because the belt will not securely hold

the child restraint system, increasing

the risk of death or serious injury in the

event of an accident.

●

The personalized extender may not be

safe on another vehicle, when used by

another person, or at a different seat-

ing position other than the one origi-

nally intended.

NOTICE

■

When using a seat belt extender

When releasing the seat belt, press on

the buckle release button on the

extender, not on the seat belt.

This helps prevent damage to the vehicle

interior and the extender itself.

Fastening and releasing the seat
belt

1-1. For safe use

For
safety

and
security

Push the seat belt shoulder anchor
down while pressing the release
button .

Push the seat belt shoulder anchor
up while pressing the release but-
ton .

Move the height adjuster up and down as
needed until you hear a click.

When the vehicle is subjected to a
severe frontal or side impact or roll-
over, the pretensioners retract the seat
belts of the front seats and rear outer
seats to securely restrain the occu-
pants.

The pretensioners will not operate in minor
frontal or side impacts, or rear impacts.

■

Replacing the belt after the preten-

sioner has been activated

If the vehicle is involved in multiple colli-

sions, the pretensioner will activate for the

first collision, but will not activate for the

second or subsequent collisions.

■

PCS-linked control

If the PCS (Pre-Collision System) deter-

mines that the possibility of a collision with a

vehicle is high, the seat belt pretensioners

will be prepared to operate.

Adjusting the seat belt shoulder
anchor height (front seats)

WARNING

■

Adjustable shoulder anchor

Always make sure the shoulder belt is

positioned across the center of your

shoulder. The belt should be kept away

from your neck, but not falling off your

shoulder. Failure to do so could reduce

the amount of protection in an accident

and cause death or serious injuries in the

event of a sudden stop, sudden swerve or

accident.

Seat belt pretensioners (front
and outboard rear seats)

WARNING

■

Seat belt pretensioners

Observe the following precautions to

reduce the risk of injury in the event of

sudden braking or an accident.

Failure to do so may result in death or

serious injury.

●

Do not place anything, such as a cush-

ion, on the front passenger’s seat.

Doing so will disperse the passenger’s

weight, which prevents the sensor

from detecting the passenger’s weight

properly. As a result, the seat belt pre-

tensioner for the front passenger’s seat

may not operate in the event of a colli-

sion.

●

If a pretensioner has operated, the

SRS warning light will illuminate. In this

situation, the seat belt cannot be used

and must be replaced by your Lexus

dealer.

1-1. For safe use

SRS driver airbag/front passenger airbag

Help reduce impact to the head and chest of the driver and front passenger

SRS knee airbag

Help reduce impact to the driver

SRS seat cushion airbags

• Helps reduce impact to the front passenger

SRS side airbags

• Help reduce impact to the chest of the occupants of the front seats
• Help reduce impact to the chest of the occupants of the rear outer seats

SRS curtain shield airbags

• Help reduce impact to the heads of the occupants of the front and rear outer seats
• Can help prevent the occupants from being thrown from the vehicle in the event of a

vehicle rollover

SRS airbags

The SRS airbags deploy when the vehicle is subjected to certain types of
severe impact that may cause significant injury to the occupants. The airbags
work together with the seat belts to help reduce the risk of death or serious
injury.

SRS airbag system

1-1. For safe use

For safety and security

Your vehicle is equipped with ADVANCED AIRBAGS designed based on US
motor vehicle safety standards (FMVSS208). The airbag sensor assembly (ECU)
controls airbag deployment based on information obtained from the sensors, etc.,
shown in the system components diagram above. This information includes crash
severity and occupant information. As the airbags deploy, a chemical reaction in
the inflators quickly fills the airbags with non-toxic gas to help restrain the motion of
the occupants.

■

If the SRS airbags deploy (inflate)

●

Slight abrasions, burns, bruising, etc., may

be sustained from SRS airbags, due to the

extremely high speed of deployment

(inflation) by hot gases.

●

A loud noise and white powder will be

emitted.

●

Parts of the airbag module (steering

wheel hub, airbag cover and inflator) as

well as the parts around the airbags may

be hot for several minutes. The airbag

itself may also be hot.

●

The windshield may crack.

●

The hybrid system will be stopped and

fuel supply to the engine will be stopped.

(



P.80)

●

All of the doors will be unlocked.

(



P.120)

●

The brakes and stop lights will be con-

trolled automatically. (



P.395)

●

The interior lights will turn on automati-

cally. (



P.426)

●

The emergency flashers will turn on auto-

matically. (



P.510)

●

Vehicles with Safety Connect: If any of

the following situations occur, the system

is designed to send an emergency call to

the response center, notifying them of the

vehicle’s location (without needing to

push the “SOS” button) and an agent will

attempt to speak with the occupants to

ascertain the level of emergency and

assistance required. If the occupants are

unable to communicate, the agent auto-

matically treats the call as an emergency

and helps to dispatch the necessary

emergency services. (



P.67)

• When an SRS airbag has been deployed

• When a seat belt pretensioner has oper-

ated

• When the vehicle has been involved in a

severe rear-end collision

■

The SRS airbags deploy in a frontal

impact when

●

The following SRS airbags will deploy in

the event of an impact that exceeds a

threshold level (level of force corre-

sponding to an approximately 12 - 18

mph [20 - 30 km/h] frontal collision with

a fixed wall that does not move or

deform):

• SRS front airbags

• SRS seat cushion airbags

• SRS knee airbags

●

The threshold level at which the SRS air-

bags will deploy will be higher than nor-

mal in the in the following situations:

• When the vehicle collides with an object,

such as a parked vehicle or sign pole,

which moves or deforms on impact

• If the vehicle is involved in an underride

collision, such as a collision in which the

front of the vehicle “underrides”, or goes

under, the bed of a truck

●

Depending on the type of collision, only

the following may deploy:

• Seat belt pretensioners

●

The SRS airbags for the front passenger’s

seat will not deploy if there is no passen-

ger in the front passenger seat. However,

the SRS airbags for the front passenger’s

seat may deploy, even if the seat is unoc-

cupied, if luggage is put on the seat.

●

The SRS seat cushion airbag for the front

passenger’s seat will not deploy if the seat

belt of the front passenger’s seat is unfas-

tened.

●

In the event of an especially severe frontal

collision, the left and right SRS curtain

shield airbags may also deploy.

1-1. For safe use

■

The SRS airbags deploy in a side impact

when

●

The following SRS airbags will deploy in

the event of an impact that exceeds the

set threshold level (level of force corre-

sponding to the impact force produced

by an approximately 3300 lb. [1500 kg]

vehicle colliding with the passenger com-

partment at a perpendicular angle at an

approximate speed of 12 - 18 mph [20 -

30 km/h]):

• SRS side airbags

• SRS curtain shield airbags

●

If the vehicle is involved in a rollover, the

following SRS airbags will deploy:

• Both left and right SRS curtain shield air-

bags

■

The SRS airbags deploy in an underside

impact when

●

The following airbags may deploy if the

underside of the vehicle collides with a

hard object:

• SRS front airbags

• SRS knee airbags

• SRS seat cushion airbags

• SRS side airbags

• SRS curtain shield airbags

●

The following airbags may deploy if the

vehicle becomes significantly tilted or is

strongly impacted by skidding into a curb,

etc.:

• SRS seat cushion airbags

■

The SRS side airbags will not deploy

when

●

The following SRS airbags will not nor-

mally deploy in side or rear collisions,

vehicle rollovers, or low speed frontal

collisions. However, if such a collision

causes sufficient sudden deceleration,

the SRS airbags may deploy.

• SRS front airbags

• SRS knee airbags

• SRS seat cushion airbags

●

The following SRS airbags may not

deploy if the vehicle is collided with at a

certain angle or in a side collision where

an area of the vehicle other than the pas-

senger compartment is collided with:

• SRS side airbags

• SRS curtain shield airbags

●

The following SRS airbags will not nor-

mally deploy in front or rear collisions,

vehicle rollovers, or low speed side colli-

sions:

• SRS side airbags

●

The following SRS airbags will not nor-

mally deploy in rear collisions, end over

1-1. For safe use

For
safety

and
security

end vehicle rollovers, or low speed front

or side collisions:

• SRS curtain shield airbags

■

When to contact your Lexus dealer

In the following situations, the vehicle will

require inspection and/or repair. Contact

your Lexus dealer as soon as possible.

●

When any of the SRS airbags have been

deployed

●

When the front of the vehicle is damaged

or deformed, or was involved in a colli-

sion that was not severe enough to cause

any of the following SRS airbags to

deploy:

• SRS front airbags

• SRS knee airbags

• SRS seat cushion airbags

●

When a door or its surrounding area is

damaged, deformed or has had a hole

made in it, or was involved in a collision

that was not severe enough to cause any

of the following SRS airbags to deploy:

• SRS side airbags

• SRS curtain shield airbags

●

When the pad section of the steering

wheel, the dashboard near the front pas-

senger SRS airbag or the lower side of

the instrument panel is scratched,

cracked, or otherwise damaged.

●

When the seat cushion surface is

scratched, cracked, or otherwise dam-

aged.

●

When the surface of a seat with an SRS

side airbag is scratched, cracked, or oth-

erwise damaged.

●

When the part of a front pillar, rear pillar

or roof side rail garnish (padding) which

covers a SRS curtain shield airbag is

scratched, cracked, or otherwise dam-

aged.

WARNING

■

SRS airbag precautions

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

The driver and all passengers must

wear their seat belts correctly.

The SRS airbags are supplemental

devices to be used with the seat belts.

●

The SRS driver airbag deploys with

considerable force, and can cause

death or serious injury, especially if the

driver is very close to the airbag. The

National Highway Traffic Safety

Administration (NHTSA) advises:

Since the risk zone for the driver’s airbag
is the first 2 - 3 in. (50 - 75 mm) of infla-
tion, placing yourself 10 in. (250 mm)
from your driver airbag provides you with
a clear margin of safety. This distance is
measured from the center of the steering
wheel to your breastbone. If your current
driving position places you less than 10
in. (250 mm) away from the driver air-
bag, you can change your driving posi-
tion in several ways:
• Move your seat to the rear as far as

possible while still being able to reach

the pedals comfortably.

1-1. For safe use

WARNING

• Slightly recline the seatback. Although

vehicle designs vary, many drivers can

achieve the 10 in. (251 mm) distance,

even with the driver seat all the way

forward, simply by reclining the seat-

back somewhat. If reclining the seat-

back makes it hard to see the road,

raise yourself by using a firm, non-slip-

pery cushion, or raise the seat if your

vehicle has that feature.

• If your steering wheel is adjustable, tilt

it downward. This points the airbag

toward your chest instead of your head

and neck. The seat should be adjusted

as recommended by the NHTSA,

while still being able to control the

vehicle with the pedals and steering

wheel, and maintaining your view of

the instrument panel controls.

●

If a seat belt extender has been con-

nected to the front passenger seat belt

buckle but the latch plate of the front

passenger seat belt has not been fas-

tened to the seat belt extender, the

SRS airbag system will judge that the

front passenger is wearing the seat

belt even though the seat belt has not

been fastened. In this case, the SRS

front airbags for the front passenger

may not deploy correctly in a collision,

resulting in death or serious injury. Be

sure to wear the seat belt correctly

when using a seat belt extender.

●

The SRS front passenger airbag

deploys with considerable force, and

can cause death or serious injury,

especially if the front passenger is very

close to the airbag. The front passen-

ger seat should be positioned as far

possible from the airbag with the seat-

back adjusted so that the passenger is

sat upright.

●

Improperly seated and/or restrained

infants and children can be killed or

seriously injured by a deploying airbag.

An infant or child who is too small to

use a seat belt should be properly

secured using a child restraint system.

Lexus strongly recommends that all

infants and children be placed in the

rear seats of the vehicle and properly

restrained. The rear seats are safer for

infants and children than the front pas-

senger seat. (



P.45)

●

Do not sit on the edge of the seat or

lean against the dashboard.

●

Do not allow a child to stand in front of

the SRS front passenger airbag or sit

on the lap of a front passenger.

●

Front seat occupants should never

hold items on their lap.

1-1. For safe use

For
safety

and
security

WARNING

●

Do not lean against the door, roof side

rail, or front, side, or rear pillar.

●

Do not allow anyone to kneel on a seat

toward the door or put their head or

hands outside the vehicle.

●

Do not attach anything to or lean any-

thing against areas such as the dash-

board, steering wheel pad and lower

portion of the instrument panel.

●

Do not attach anything to areas such

as the doors, windshield, side windows,

front or rear pillars, roof side rails and

assist grips.

●

Do not hang coat hangers or other

hard objects on the coat hooks. These

items could become projectiles if the

SRS curtain shield airbags deploy, pos-

sibly leading to death or serious injury.

●

If a vinyl cover is attached to the area

where the SRS knee airbag deploys,

be sure to remove it.

●

Do not use seat accessories which

cover the parts from which the SRS

airbags deploy, as they may interfere

with inflation of the SRS airbags. Such

accessories may prevent the SRS air-

bags from deploying correctly, may

disable the system or cause the SRS

airbags to inflate unintentionally, possi-

bly resulting in death or serious injury.

●

Do not strike or apply significant force

to the SRS airbag system components,

front doors or their surrounding area.

Doing so may cause the SRS airbags

to malfunction.

●

Do not touch any components of the

SRS airbags immediately after the SRS

airbags have deployed (inflated) as

they may be hot.

●

If breathing becomes difficult after the

SRS airbags have deployed, open a

door or window to allow fresh air in, or

leave the vehicle if it is safe to do so.

Wash off any residue as soon as possi-

ble to prevent skin irritation.

1-1. For safe use

WARNING

●

If a part where an SRS airbag is stored

is damaged or cracked, have it

replaced by your Lexus dealer.

●

Do not place anything, such as a cush-

ion, on the front passenger’s seat.

Doing so will disperse the passenger’s

weight, which prevents the sensor

from detecting the passenger’s weight

properly. As a result, the SRS front air-

bags for the front passenger’s seat may

not deploy in the event of a collision.

■

Modification and disposal of SRS air-

bag system components

Do not dispose of your vehicle or per-

form any of the following modifications

without consulting your Lexus dealer.

The SRS airbags may malfunction or

deploy unintentionally, possibly leading

to death or serious injury.

●

Removal, installation, disassembly or

repair of the SRS airbags

●

Repair, removal or modification of the

following parts or their surrounding

• Steering wheel

• Instrument panel

• Dashboard

• Seats

• Seat upholstery

• Front pillars

• Side pillars

• Rear pillars

• Roof side rails

• Front door panels

• Front door trim

• Front door speakers

●

Modifications to the front door panels

(such as making holes in them)

●

Repair or modification of the following

parts or their surrounding

• Front fender

• Front bumper

• Sides of the vehicle interior

●

Installation of the following parts or

accessories

• Bull bars or kangaroo bars

• Snow plows

• Winches

• Roof lugguage carriers

●

Modifications to the vehicle’s suspen-

sion

●

Installation of electronic devices such

as mobile two-way radios and CD

players

●

Modifications to your vehicle for a per-

sons with a physical disability

1-1. For safe use

SRS warning light
Front passenger’s seat belt reminder light
“AIR BAG OFF” indicator light
“AIR BAG ON” indicator light

System components

WARNING

■

Front passenger occupant classifica-

tion system precautions

Observe the following precautions

regarding the front passenger occupant

classification system.

Failure to do so may cause death or seri-

ous injury.

●

Wear the seat belt properly.

●

Make sure the front passenger’s seat

belt plate has not been left inserted

into the buckle before someone sits in

the front passenger seat.

●

Make sure the “AIR BAG OFF” indica-

tor light is not illuminated when using

the seat belt extender for the front pas-

senger seat. If the “AIR BAG OFF”

indicator light is illuminated, discon-

nect the extender tongue from the seat

belt buckle, and reconnect the seat

belt. Reconnect the seat belt extender

after making sure the “AIR BAG ON”

indicator light is illuminated. If you use

the seat belt extender while the “AIR

BAG OFF” indicator light is illumi-

nated, the SRS airbags for the front

passenger will not activate, which

could cause death or serious injury in

the event of a collision.

●

Do not apply a heavy load to the front

passenger seat or equipment (e.g.

seatback pocket).

●

Do not put weight on the front passen-

ger seat by putting your hands or feet

on the front passenger seat seatback

from the rear passenger seat.

1-1. For safe use

For
safety

and
security

WARNING

●

Do not let a rear passenger lift the

front passenger seat with their feet or

press on the seatback with their legs.

●

Do not put objects under the front pas-

senger seat.

●

Do not recline the front passenger

seatback so far that it touches a rear

seat. This may cause the “AIR BAG

OFF” indicator light to be illuminated,

which indicates that the SRS airbags

for the front passenger will not activate

in the event of a severe accident. If the

seatback touches the rear seat, return

the seatback to a position where it

does not touch the rear seat. Keep the

front passenger seatback as upright as

possible when the vehicle is moving.

Reclining the seatback excessively

may lessen the effectiveness of the

seat belt system.

●

If an adult sits in the front passenger

seat, the “AIR BAG ON” indicator light

is illuminated. If the “AIR BAG OFF”

indicator is illuminated, ask the passen-

ger to sit up straight, well back in the

seat, feet on the floor, and with the seat

belt worn correctly. If the “AIR BAG

OFF” indicator still remains illumi-

nated, either ask the passenger to

move to the rear seat, or if that is not

possible, move the front passenger

seat fully rearward.

●

When it is unavoidable to install a for-

ward-facing child restraint system on

the front passenger seat, install the

child restraint system on the front pas-

senger seat in the proper order.

(



P.51)

●

Do not modify or remove the front

seats.

●

Do not kick the front passenger seat or

subject it to severe impact. Otherwise,

the SRS warning light may come on to

indicate a malfunction of the front pas-

senger occupant classification system.

In this case, contact your Lexus dealer

immediately.

●

Child restraint systems installed on the

rear seat should not contact the front

seatbacks.

●

Do not use a seat accessory, such as a

cushion and seat cover, that covers the

seat cushion surface.

●

Do not modify or replace the uphol-

stery of the front seat.

1-1. For safe use

■

Adult

■

Child

■

Child restraint system with infant

Front passenger occupant classification system conditions and opera-
tion

Indicator/warning light

“AIR BAG ON” and “AIR BAG OFF” indi-

cator lights

“AIR BAG ON”

SRS warning light

Off

Front passenger’s seat belt reminder light

Off

or flashing

Devices

Front passenger airbag

Activated

Seat cushion airbag in the front passenger

side

Activated

or deacti-

vated

Indicator/warning light

“AIR BAG ON” and “AIR BAG OFF” indi-

cator lights

“AIR BAG OFF” or

“AIR BAG ON”

SRS warning light

Off

Front passenger’s seat belt reminder light

Off

or flashing

Devices

Front passenger airbag

Deactivated or acti-

vated

Seat cushion airbag in the front passenger

side

Deactivated or acti-

vated

*4, 2

Indicator/warning light

“AIR BAG ON” and “AIR BAG OFF” indi-

cator lights

“AIR BAG OFF”

SRS warning light

Off

Front passenger’s seat belt reminder light

Off

or flashing

Devices

Front passenger airbag

Deactivated

Seat cushion airbag in the front passenger

side

1-1. For safe use

For safety and security

■

Unoccupied

■

System malfunction

: The system judges a person of adult size as an adult. When a smaller adult sits in the

front passenger seat, the system may not recognize them as an adult depending on their
physique and posture.

: In the event the front passenger is wearing a seat belt.

: In the event the front passenger does not wear a seat belt.

: For some children, child in seat, child in booster seat or child in convertible seat, the sys-

tem may not recognize them as a child. Factors which may affect this can be the phy-
sique or posture.

: Never install a rear-facing child restraint system on the front passenger seat. A for-

ward-facing child restraint system should only be installed on the front passenger seat
when it is unavoidable. (



P.45)

: In case the indicator light is not illuminated, consult this manual on how to install the child

restraint system properly. (



P.51)

Indicator/warning light

“AIR BAG ON” and “AIR BAG OFF” indi-

cator lights

“AIR BAG OFF”

SRS warning light

Off

Front passenger’s seat belt reminder light

Devices

Front passenger airbag

Deactivated

Seat cushion airbag in the front passenger

side

Indicator/warning light

“AIR BAG ON” and “AIR BAG OFF” indi-

cator lights

“AIR BAG OFF”

SRS warning light

Front passenger’s seat belt reminder light

Off

Devices

Front passenger airbag

Deactivated

Seat cushion airbag in the front passenger

side

1-1. For safe use

Exhaust gas precautions

Harmful substance to the human
body is included in exhaust gases if
inhaled.

WARNING

Exhaust gases include harmful carbon

monoxide (CO), which is colorless and

odorless. Observe the following precau-

tions.

Failure to do so may cause exhaust gases

enter the vehicle and may lead to an

accident caused by light-headedness, or

may lead to death or a serious health

hazard.

■

Important points while driving

●

Keep the back door closed.

●

If you smell exhaust gases in the vehi-

cle even when the back door is closed,

open the windows and have the vehi-

cle inspected at your Lexus dealer as

soon as possible.

■

When parking

●

If the vehicle is in a poorly ventilated

area or a closed area, such as a

garage, stop the hybrid system.

●

Do not leave the vehicle with the

hybrid system on for a long time.

If such a situation cannot be avoided,

park the vehicle in an open space and

ensure that exhaust fumes do not enter

the vehicle interior.

●

Do not leave the hybrid system operat-

ing in an area with snow build-up, or

where it is snowing. If snowbanks build

up around the vehicle while the hybrid

system is operating, exhaust gases

may collect and enter the vehicle.

■

Exhaust pipe

The exhaust system needs to be checked

periodically. If there is a hole or crack

caused by corrosion, damage to a joint

or abnormal exhaust noise, be sure to

have the vehicle inspected and repaired

by your Lexus dealer.

1-2. Child safety

For
safety

and
security

1-2.Child safety

Points to remember: P.46
Child restraint system: P.51
When using a child restraint system:
P.52
Child restraint system compatibility for
each seating position (for Puerto Rico):
P.47
Child restraint system installation
method
• Fixed with a seat belt: P.54
• Fixed with a child restraint LATCH

anchor (except for Puerto Rico):
P.60

• Fixed with an ISOFIX lower anchor-

age (for Puerto Rico): P.60

• Using an anchor bracket (for top

tether strap) (except for Puerto
Rico): P.65

• Using a top tether anchorage (for

Riding with children

Observe the following precautions
when children are in the vehicle.
Use a child restraint system appro-
priate for the child, until the child
becomes large enough to properly
wear the vehicle’s seat belt.



It is recommended that children
sit in the rear seats to avoid acci-
dental contact with the shift lever,
wiper switch, etc.



Use the rear door child-protector
lock or the window lock switch to
avoid children opening the door
while driving or operating the
power window accidentally.
(



P.123, 171)



Do not let small children operate
equipment which may catch or
pinch body parts, such as the
power window, hood, back door,
seats etc.

WARNING

■

When children are in the vehicle

Never leave children unattended in the

vehicle, and never allow children to have

or use the key.

Children may be able to start the vehicle

or shift the vehicle into neutral. There is

also a danger that children may injure

themselves by playing with the windows,

the moon roof or panoramic moon roof,

or other features of the vehicle. In addi-

tion, heat build-up or extremely cold

temperatures inside the vehicle can be

fatal to children.

Child restraint systems

Before installing a child restraint
system in the vehicle, there are pre-
cautions that need to be observed,
different types of child restraint sys-
tems, as well as installation meth-
ods, etc., written in this manual.

Use a child restraint system when
riding with a small child that cannot
properly use a seat belt. For the
child’s safety, install the child restraint
system to a rear seat. Be sure to fol-
low the installation method that is in
the operation manual enclosed with
the restraint system.

Table of contents

1-2. Child safety

Puerto Rico): P.65

The laws of all 50 states of the U.S.A.
as well as Canada now require the use
of child restraint systems.



Prioritize and observe the warn-
ings, as well as the laws and regula-
tions for child restraint systems.



Use a child restraint system until the
child becomes large enough to
properly wear the vehicle’s seat belt.



Choose a child restraint system that
suits your vehicle and is appropriate
to the age and size of the child.

Points to remember

WARNING

■

When a child is riding

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

For effective protection in automobile

accidents and sudden stops, a child

must be properly restrained, using a

seat belt or child restraint system

which is correctly installed. For installa-

tion details, refer to the operation man-

ual enclosed with the child restraint

system. General installation instruction

is provided in this manual.

●

Lexus strongly urges the use of a

proper child restraint system that con-

forms to the weight and size of the

child, installed on the rear seat.

According to accident statistics, the

child is safer when properly restrained

in the rear seat than in the front seat.

●

Holding a child in your or someone

else’s arms is not a substitute for a child

restraint system. In an accident, the

child can be crushed against the wind-

shield or between the holder and the

interior of the vehicle.

■

Handling the child restraint system

If the child restraint system is not prop-

erly fixed in place, the child or other pas-

sengers may be seriously injured or even

killed in the event of sudden braking, sud-

den swerving, or an accident.

●

If the vehicle were to receive a strong

impact from an accident, etc., it is pos-

sible that the child restraint system has

damage that is not readily visible. In

such cases, do not reuse the restraint

system.

●

Except for Puerto Rico: Make sure you

have complied with all installation

instructions provided with the child

restraint system manufacturer and that

the system is properly secured.

●

For Puerto Rico: Depending on the

child restraint system, installation may

be difficult or impossible. In those

cases, check whether the child

restraint system is suitable for install-

ment in the vehicle. (



P.47) Be sure to

install and observe the usage rules

after carefully reading the child

restraint system fixing method in this

manual, as well as the operation man-

ual enclosed with the child restraint

system.

●

Keep the child restraint system prop-

erly secured on the seat even if it is not

in use. Do not store the child restraint

system unsecured in the passenger

compartment.

●

If it is necessary to detach the child

restraint system, remove it from the

vehicle or store it securely in the lug-

gage compartment.

1-2. Child safety

For safety and security

■

Child restraint system compatibil-
ity for each seating position

Compatibility of each seating position
with child restraint systems (



P.48)

displays the type of child restraint sys-
tems that can be used and possible
seating positions for installation using
symbols. Also, the recommended child
restraint system that is suitable for your
child can be selected.
Otherwise, check [Recommended
child restraint systems and Compatibil-
ity table] for recommended child
restraint systems. (



P.50)

Check the selected child restraint sys-
tem together with the following
[Before confirming the compatibility of
each seating position with child
restraint systems].

■

Before confirming the compatibil-
ity of each seating position with
child restraint systems

Checking the child restraint system
standards.
Use a child restraint system that
conforms to UN(ECE) R44

UN(ECE) R129

*1, 2

The following approval mark is dis-
played on child restraint systems
which are conformed.
Check for an approval mark

attached to the child restraint sys-
tem.

Example of the displayed regulation Num-
ber

UN(ECE) R44 approval mark

The weight range of the child who is
applicable for an UN(ECE) R44
approval mark is indicated.

UN(ECE) R129 approval mark

The height range of the child who is
applicable as well as available
weights for an UN(ECE) R129
approval mark is indicated.

Checking the category of the child
restraint system.
Check the approval mark of the
child restraint system for which of
the following categories the child
restraint system is suitable.
Also, if there are any uncertainties,
check the user’s guide included
with the child restraint system or
contact the retailer of the child
restraint system.

• “universal”
• “semi-universal”
• “restricted”

Child restraint system compati-
bility for each seating position
(for Puerto Rico)

1-2. Child safety

• “vehicle specific”

: UN(ECE) R44 and UN(ECE) R129

are U.N. regulations for child restraint
systems.

: The child restraint systems mentioned in

the table may not be available outside of
the EU area.

: The displayed mark may differ depend-

ing on the product.

■

Compatibility of each seating posi-
tion with child restraint systems

: Move the front seat fully rearward. If the

passenger seat height can be adjusted,
move it to the upper most position.

: Adjust the seatback angle to the most

upright position. When installing a for-
ward-facing child seat, if there is a gap
between the child seat and the seat-
back, adjust the seatback angle until
good contact is achieved.

*1, 2, 3

*2, 3

Suitable for “universal” category
child restraint system fixed with
the seat belt.
Suitable for fixed installing a for-
ward-facing child seat with vehicle
seat belt “universal” category child
restraint system.
Suitable for child restraint systems
given on recommended child
restraint systems and compatibility
table (



P.50).

Suitable for ISOFIX child restraint
system.

Includes a top tether anchorage
point.
Never use a rear-facing child
restraint system on the front pas-
senger seat.

1-2. Child safety

For safety and security

: If the head restraint interferes with your

child restraint system, and the head
restraint can be removed, remove the
head restraint.

Otherwise, put the head restraint in the
upper most position.

: Use only a front-facing child restraint

system.

■

Detail information for child restraint systems installation

ISOFIX child restraint systems are divided into different “fixture”. The child
restraint system can be used in the seating positions for “fixture” mentioned in the
table above. For kind of “fixture” relation, confirm the following table.
If your child restraint system has no kind of “fixture” (or if you cannot find informa-
tion in the table below), please refer to the child restraint system “vehicle list” for
compatibility information or ask the retailer of your child seat.

Seating position

Seat position number

Seating position suitable for uni-

versal belted (Yes/No)

Yes

For-

ward-facing

only

Yes

i-Size seating position (Yes/No)

Yes

Seating position suitable for lateral

fixture (L1/L2/No)

Suitable rearward facing fixture

(R1/R2X/R2/R3/No)

R1, R2X, R2,

Suitable forward facing fixture

(F2X/F2/F3/No)

F2X, F2, F3

Suitable junior seat fixture

(B2/B3/No)

B2, B3

1-2. Child safety

■

Recommended child restraint systems and Compatibility table

The child restraint systems mentioned in the table may not be available outside the
LATIN America and the Caribbean countries.
When securing some types of child
restraint systems in rear seat, it may not
be possible to properly use the seat
belts in positions next to the child
restraint without interfering with it or
affecting seat belt effectiveness. Be
sure your seat belt fits snugly across
your shoulder and low on your hips. If it
does not, or if it interferes with the child
restraint, move to a different position.
Failure to do so may result in death or
serious injury.



When installing a child restraint in
the rear seats, adjust the front seat
so that it does not interfere with the
child or child restraint system.



When installing a child seat with
support base, if the child seat inter-
feres with the seatback when latch-
ing it into the support base, adjust
the seatback rearward until there is
no interference.



If the seat belt shoulder anchor is
ahead of the child seat belt guide,
move the seat cushion forward.

Fixture

Description

Full-height, forward-facing child restraint systems

Reduced-height forward-facing child restraint systems

F2X

Reduced-height forward-facing child restraint systems

Full-size, rearward-facing child restraint systems

Reduced-size, rearward-facing child restraint systems

R2X

Reduced-size, rearward-facing child restraint systems

Rearward-facing infant seat

Left lateral-facing (carrycot) infant seat

Right lateral-facing (carrycot) infant seat

Junior seat

Recommended Child

Restraint System

Seating position

i-Size child Restraint
system

i-Size MIDI (Yes/No)

Yes

1-2. Child safety

■

When installing a child restraint
system to a front passenger seat

For the safety of a child, install child
restraint systems to a rear seats. When
installing child restraint system to a
front passenger seat is unavoidable,
adjust the seat as follows and install the
child restraint system.



Move the seat fully rearward.



Move the seat height to the upper
most position.



Adjust the seatback angle to the
most upright position.

If there is a gap between the child seat and
the seatback, adjust the seatback angle
until good contact is achieved.



If the head restraint interferes with
your child restraint system, and the
head restraint can be removed,
remove the head restraint.

Otherwise, put the head restraint in the
upper most position.

Except for Puerto Rico:

Child restraint LATCH

anchors attachment

For Puerto Rico: ISOFIX

lower anchorage attach-

ment

P.60

Except for Puerto Rico:

Anchor brackets (for top

tether strap) attachment

For Puerto Rico: Top tether

anchorage attachment

P.65

Installation method

Page

When using a child restraint sys-
tem

WARNING

■

When using a child restraint system

Observe the following precautions.

Failure to do so may result in death or

serious injury.

1-2. Child safety

For
safety

and
security

WARNING

●

Never install a rear-facing child

restraint system on the front passenger

seat even if the “AIR BAG OFF” indi-

cator light is illuminated. In the event of

an accident, the force of the rapid infla-

tion of the front passenger airbag can

cause death or serious injury to the

child if the rear-facing child restraint

system is installed on the front passen-

ger seat.

●

A forward-facing child restraint system

may be installed on the front passen-

ger seat only when it is unavoidable. A

child restraint system that requires a

top tether strap should not be used in

the front passenger seat since there is

no top tether strap anchor for the front

passenger seat.

●

A forward-facing child restraint system

may be installed on the front passen-

ger seat only when it is unavoidable.

When installing a forward-facing child

restraint system on the front passenger

seat, raise the seatback as much as

possible, move the seat to the rear-

most position, and raise the seat to the

highest position, even if the “AIR BAG

OFF” indicator light is illuminated.

If the head restraint interferes with the
installation of the child restraint system,
and the head restraint can be removed,
remove the head restraint.
If the head restraint cannot be removed,
raise it to the uppermost position.

●

Do not allow the child to lean his/her

head or any part of his/her body

against the door or the area of the seat,

front or rear pillars, or roof side rails

from which the SRS side airbags or

SRS curtain shield airbags deploy even

if the child is seated in the child

restraint system. It is dangerous if the

SRS side airbags and curtain shield air-

bags inflate, and the impact could

cause death or serious injury to the

child.

●

When a booster seat is installed,

always ensure that the shoulder belt is

positioned across the center of the

child’s shoulder. The belt should be

kept away from the child’s neck, but

not so that it could fall off the child’s

shoulder.

●

Use child restraint system suitable to

the age and size of the child and install

it to the rear seat.

●

If the driver’s seat interferes with the

child restraint system and prevents it

from being attached correctly, attach

the child restraint system to the

right-hand rear seat.

●

Adjust the front passenger seat so that

it does not interfere with the child

restraint system.

1-2. Child safety

A child restraint system for a small
child or baby must itself be properly
restrained on the seat with the lap por-
tion of the lap/shoulder belt.

■

Installing child restraint system
using a seat belt (child restraint
lock function belt)

Install the child restraint system in
accordance to the operation manual
enclosed with the child restraint sys-
tem.
For Puerto Rico: If the child restraint
system on hand is not within the “uni-
versal” category (or the necessary
information is not in the table), refer to
the “Vehicle List” provided by the child
restraint system maker for various pos-
sible installation positions, or check the
compatibility after asking the retailer of
the child seat. (



P.47)

■

Rear-facing



Infant seat/con-

vertible seat

Adjust the rear seat.

If there is a gap between the child seat and

the seatback, adjust the seatback angle

until good contact is achieved.

Place the child restraint system on
the rear seat facing the rear of the
vehicle.

Run the seat belt through the child
restraint system and insert the plate
into the buckle. Make sure that the
belt is not twisted.

Fully extend the shoulder belt and
allow it to retract to put it in lock
mode. In lock mode, the belt cannot
be extended.

While pushing the child restraint
system down into the rear seat,
allow the shoulder belt to retract

Child restraint system fixed with
a seat belt

1-2. Child safety

For safety and security

until the child restraint system is
securely in place.

After the shoulder belt has retracted to a

point where there is no slack in the belt,

pull the belt to check that it cannot be

extended.

After installing the child restraint
system, rock it back and forth to
ensure that it is installed securely.
(



P.57)

■

Forward-facing



Convertible

seat

Adjust the seat.



When using the front passenger
seat

If installing the child restraint system to the
front passenger seat is unavoidable, refer
to P.52for the front passenger seat adjust-
ment.



When using the rear seat

If there is a gap between the child seat and
the seatback, adjust the seatback angle
until good contact is achieved.

Remove the head restraint if it inter-
feres with your child restraint sys-
tem. (



P.152)

If the head restraint cannot be removed,

raise it to the uppermost position.

Place the child restraint system on
the seat facing the front of the vehi-
cle.

Run the seat belt through the child
restraint system and insert the plate
into the buckle. Make sure that the
belt is not twisted.

Fully extend the shoulder belt and
allow it to retract to put it in lock

1-2. Child safety

mode. In lock mode, the belt cannot
be extended.

While pushing the child restraint
system into the rear seat, allow the
shoulder belt to retract until the
child restraint system is securely in
place.

After the shoulder belt has retracted to a

point where there is no slack in the belt,

pull the belt to check that it cannot be

extended.

If the child restraint has a top tether
strap, follow the child restraint man-
ufacturer’s operation manual
regarding the installation, using the
top tether strap to latch onto the
top tether strap anchor. (



P.65)

After installing the child restraint
system, rock it back and forth to
ensure that it is installed securely.
(



P.57)

■

Booster seat

If installing the child restraint sys-
tem to the front passenger seat is
unavoidable, refer to P.52for the
front passenger seat adjustment.

High back type: Remove the head
restraint if it interferes with your
child restraint system. (



P.152)

If the head restraint cannot be removed,

raise it to the uppermost position.

Place the child restraint system on
the seat facing the front of the vehi-
cle.



Booster type

Lexus RX500h (2023 year). Manual in english - page 1
