Lexus RC300 (2023 year). Manual in english

342

8-1. Specifications

■

RC300

■

Oil capacity (Drain and refill [Reference

])

: The engine oil capacity is a reference quantity to be used when changing the engine oil.

Warm up and turn off the engine, wait more than 5 minutes, and check the oil level on the
dipstick.

Displacement

210.9 cu. in. (3456 cm

)

Drive belt tension

Automatic adjustment

Model

2.0 L 4-cylinder (8AR-FTS) engine

Type

4-cylinder in line, 4-cycle, gasoline (with tur-
bocharger)

Bore and stroke

3.39



3.39 in. (86.0



86.0 mm)

Displacement

121.9 cu. in. (1998 cm

)

Drive belt tension

Automatic adjustment

Fuel

Fuel type

Unleaded gasoline only

Octane Rating

91 (Research Octane Number 96) or higher

Fuel tank capacity (Reference)

17.5 gal. (66.4 L, 14.6 Imp. gal.)

Lubrication system

With filter



RC350

6.0 qt. (5.7 L, 5.0 Imp. qt.)



RC350 AWD/RC300 AWD

6.8 qt. (6.4 L, 5.6 Imp. qt.)



RC300

4.9 qt. (4.6 L, 4.0 Imp. qt.)

Without filter



RC350

5.8 qt. (5.5 L, 4.8 Imp. qt.)



RC350 AWD/RC300 AWD

6.3 qt. (6.0 L, 5.3 Imp. qt.)



RC300

4.5 qt. (4.3 L, 3.8 Imp. qt.)

343

8-1. Specifications

Vehi

cle

spec

ifi

tions

■

Engine oil selection

“Toyota Genuine Motor Oil” is used in
your Lexus vehicle. Use Lexus
approved “Toyota Genuine Motor Oil”
or equivalent to satisfy the following
grade and viscosity.
Oil grade: ILSAC GF-6A multigrade
engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for
good fuel economy and good starting
in cold weather.
If SAE 0W-20 is not available, SAE
5W-20 oil may be used. However, it
must be replaced with SAE 0W-20 at
the next oil change.

Outside temperature

Oil viscosity (0W-20 is explained here
as an example):
• The 0W in 0W-20 indicates the

characteristic of the oil which allows
cold startability. Oils with a lower
value before the W allow for easier
starting of the engine in cold
weather.

• The 20 in 0W-20 indicates the vis-

cosity characteristic of the oil when
the oil is at high temperature. An oil
with a higher viscosity (one with a

higher value) may be better suited if
the vehicle is operated at high
speeds, or under extreme load con-
ditions.

How to read oil container label:
The International Lubricant Specifica-
tion Advisory Committee (ILSAC)
Certification Mark is added to some oil
containers to help you select the oil you
should use.

344

8-1. Specifications

: The fluid capacity is a reference quantity.

If replacement is necessary, contact your Lexus dealer.

■

Spark plug

Cooling system

Capacity

RC350/RC3
00 AWD

10.0 qt. (9.5 L, 8.4 Imp. qt.)

RC300



Gasoline engine

8.5 qt. (8.0 L, 7.0 Imp. qt.)



Intercooler

3.3 qt. (3.1 L, 2.7 Imp. qt.)

Coolant type

Use either of the following:



“Toyota Super Long Life Coolant”



Similar high-quality ethylene glycol-based non-silicate,
non-amine, non-nitrite, and non-borate coolant with
long-life hybrid organic acid technology

Do not use plain water alone.

Ignition system (spark plug)

RC350/RC300 AWD

RC300

Make

DENSO FK20HBR8

NGK DILFR7K9G

Gap

0.031 in. (0.8 mm)

0.035 in. (0.9 mm)

NOTICE

■

Iridium-tipped spark plugs

Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.

Electrical system (battery)

Open voltage at 68°F (20°C):

12.3 V or higher
If the voltage is lower than the standard value,
charge the battery.
(Voltage is checked 20 minutes after the engine
and all lights are turned off.)

Charging rates

5 A max.

345

8-1. Specifications

icle

ific

atio

: The fluid capacity is a reference quantity.

If replacement is necessary, contact your Lexus dealer.



Vehicles without LSD (Limited Slip Differential)



Vehicles with LSD (Limited Slip Differential)

: Your Lexus vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory.

Use Lexus approved “Toyota Genuine Differential Gear Oil” or an equivalent oil of

Automatic transmission

Fluid capacity



RC350

10.0 qt. (9.5 L, 8.4 Imp. qt.)



RC350 AWD/RC300 AWD

10.6 qt. (10.0 L, 8.8 Imp. qt.)



RC300

9.2 qt. (8.7 L, 7.7 Imp. qt.)

Fluid type

Toyota Genuine ATF WS

NOTICE

■

Transmission fluid type

Using transmission fluid other than the above type may cause abnormal noise or vibra-

tion, or damage the transmission of your vehicle.

Front differential (AWD models)

Oil capacity

0.74 qt. (0.70 L, 0.61 Imp. qt.)

Oil type and viscosity

Hypoid gear oil API GL-5
Above 0°F (-18°C): SAE90
Below 0°F (-18°C): SAE80W or SAE80W-90

Rear differential

Oil capacity

1.42 qt. (1.35 L, 1.19 Imp. qt.)

Oil type and viscosity

Toyota Genuine Differential Gear Oil LT 75W-85
GL-5 or equivalent

Oil capacity

1.42 qt. (1.35 L, 1.19 Imp. qt.)

Oil type and viscosity

Toyota Genuine Differential Gear Oil LX 75W-85
GL-5 or equivalent

346

8-1. Specifications

matching quality to satisfy the above specification. Please contact your Lexus dealer for
further details.

: Minimum pedal clearance when depressed with a force of 112.4 lbf (500 N, 51.0 kgf)

while the engine is running.



Type A

Brakes

Pedal clearance



RC350 AWD/RC300 AWD

4.2 in. (107 mm) Min.



RC350/RC300

3.8 in. (97 mm) Min.

Pedal free play

0.04



0.24 in. (1.0



6.0 mm)

Brake pad wear limit

0.04 in. (1.0 mm)

Parking brake lining wear limit

0.04 in. (1.0 mm)

Fluid type

SAE J1703 or FMVSS No.116 DOT 3, or SAE
J1704 or FMVSS No.116 DOT 4 brake fluid

Steering

Free play

Less than 1.2 in. (30 mm)

Tires and wheels

Tire size

235/45R18 94Y, T155/70D17 110M (spare)

Tire inflation pressure (Rec-
ommended cold tire inflation
pressure)

Driving under normal conditions

Front: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Rear: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Spare: 60 psi (420 kPa, 4.2 kgf/cm

or bar)

Driving at high speeds (above 100 mph [160 km/h]) (in
countries where such speeds are permitted by law)

Add 3 psi (20 kPa, 0.2 kgf/cm

or bar) to the front tires, 6

psi (40 kPa, 0.4 kgf/cm

or bar) to the rear tires. Never

exceed the maximum cold tire inflation pressure indicated
on the tire sidewall.

347

8-1. Specifications

Vehi

cle

spec

ifi

tions



Type B



Type C

Wheel size



8 1/2J, 17



4T (spare)

Wheel bolt torque

103 ft•lbf (140 N•m, 14.3 kgf•m)

Tire size

235/45R18 94V, T155/70D17 110M (spare)

Tire inflation pressure (Rec-
ommended cold tire inflation
pressure)

Driving under normal conditions

Front: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Rear: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Spare: 60 psi (420 kPa, 4.2 kgf/cm

or bar)

Driving at high speeds (above 100 mph [160 km/h]) (in
countries where such speeds are permitted by law)

Add 3 psi (20 kPa, 0.2 kgf/cm

or bar) to the front tires, 6

psi (40 kPa, 0.4 kgf/cm

or bar) to the rear tires. Never

exceed the maximum cold tire inflation pressure indicated
on the tire sidewall.

Wheel size



8 1/2J, 17



4T (spare)

Wheel bolt torque

103 ft•lbf (140 N•m, 14.3 kgf•m)

Tire size

235/40R19 92V, T155/70D17 110M (spare)

Tire inflation pressure (Rec-
ommended cold tire inflation
pressure)

Driving under normal conditions

Front: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Rear: 36 psi (250 kPa, 2.5 kgf/cm

or bar)

Spare: 60 psi (420 kPa, 4.2 kgf/cm

or bar)

Driving at high speeds (above 100 mph [160 km/h]) (in
countries where such speeds are permitted by law)

Add 6 psi (40 kPa, 0.4 kgf/cm

or bar) to the front tires, 8

psi (50 kPa, 0.5 kgf/cm

or bar) to the rear tires. Never

exceed the maximum cold tire inflation pressure indicated
on the tire sidewall.

Wheel size



8 1/2J, 17



4T (spare)

Wheel bolt torque

103 ft•lbf (140 N•m, 14.3 kgf•m)

348

8-1. Specifications



Type D

Tire size

235/40R19 96Y XL, T155/70D17 110M (spare)

Tire inflation pressure (Rec-
ommended cold tire inflation
pressure)

Driving under normal conditions

Front: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Rear: 36 psi (250 kPa, 2.5 kgf/cm

or bar)

Spare: 60 psi (420 kPa, 4.2 kgf/cm

or bar)

Driving at high speeds (above 100 mph [160 km/h]) (in
countries where such speeds are permitted by law)
Add 6 psi (40 kPa, 0.4 kgf/cm

or bar) to the front tires, 8

psi (50 kPa, 0.5 kgf/cm

or bar) to the rear tires. Never

exceed the maximum cold tire inflation pressure indicated
on the tire sidewall.

Wheel size



8 1/2J, 17 x 4T (spare)

Wheel bolt torque

103 ft•lbf (140 N•m, 14.3 kgf•m)

349

8-1. Specifications

Vehi

cle

spec

ifi

tions



Type E

Tire size

Front tires: 235/40R19 92V
Rear tires: 265/35R19 94V
Spare tire: T155/70D17 110M

Tire inflation pressure (Rec-
ommended cold tire inflation
pressure)

Driving under normal conditions

Front: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Rear: 36 psi (250 kPa, 2.5 kgf/cm

or bar)

Spare: 60 psi (420 kPa, 4.2 kgf/cm

or bar)

Driving at high speeds (above 100 mph [160 km/h]) (in
countries where such speeds are permitted by law)

Add 6 psi (40 kPa, 0.4 kgf/cm

or bar) to the front tires.

Never exceed the maximum cold tire inflation pressure
indicated on the tire sidewall.

Wheel size

Front wheels: 19



8 1/2J

Rear wheels: 19



9 1/2J

Spare wheel: 17



Wheel bolt torque

103 ft•lbf (140 N•m, 14.3 kgf•m)

350

8-1. Specifications



Type F

A: Wedge base bulbs (amber)
B: Wedge base bulbs (clear)

Tire size

Front tires: 235/40R19 92Y
Rear tires: 265/35R19 94Y
Spare tire: T145/70D18 107M

Tire inflation pressure (Rec-
ommended cold tire inflation
pressure)

Driving under normal conditions

Front: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Rear: 36 psi (250 kPa, 2.5 kgf/cm

or bar)

Spare: 60 psi (420 kPa, 4.2 kgf/cm

or bar)

Driving at high speeds (above 100 mph [160 km/h]) (in
countries where such speeds are permitted by law)

Add 6 psi (40 kPa, 0.4 kgf/cm

or bar) to the front tires.

Never exceed the maximum cold tire inflation pressure
indicated on the tire sidewall.

Wheel size

Front wheels: 19



8 1/2J

Rear wheels: 19



9 1/2J

Spare wheel: 18



Wheel bolt torque

103 ft•lbf (140 N•m, 14.3 kgf•m)

Light bulbs

Bulb No.

Type

Exterior

Rear turn signal lights



Interior

Vanity lights



Footwell lights

194

3.8

Trunk light



351

8-1. Specifications

Vehi

cle

spec

ifi

tions

■

Gasoline quality

In very few cases, driveability problems may

be caused by the brand of gasoline you are

using. If driveability problems persist, try

changing the brand of gasoline. If this does

not correct the problem, consult your Lexus

dealer.

■

Recommendation of the use of gasoline

containing detergent additives

●

Lexus recommends the use of gasoline

that contains detergent additives to avoid

the build-up of engine deposits.

●

All gasoline sold in the U.S.A. contains

minimum detergent additives to clean

and/or keep clean intake systems, per

EPA’s lowest additives concentration pro-

gram.

●

Lexus strongly recommends the use of

Top Tier Detergent Gasoline. For more

information on Top Tier Detergent Gaso-

line and a list of marketers, please go to

the official website www.toptiergas.com.

■

Recommendation of the use of low

emissions gasoline

Gasolines containing oxygenates such as

ethers and ethanol, as well as reformulated

gasolines, are available in some cities.

These fuels are typically acceptable for use,

providing they meet other fuel require-

ments.
Lexus recommends these fuels, since the

formulations allow for reduced vehicle

emissions.

■

Non-recommendation of the use of

blended gasoline

●

Use only gasoline containing up to 15%

ethanol.

DO NOT use any flex-fuel or gasoline

that could contain more than 15% etha-

nol, including from any pump labeled
E30 (30% ethanol [

]), E50 (50%

ethanol [

]), E85 (85% ethanol [

])

(which are only some examples of fuel

containing more than 15% ethanol).

●

If you use gasohol in your vehicle, be sure

that it has an octane rating no lower than

91.

●

Lexus does not recommend the use of

gasoline containing methanol.

■

Non-recommendation of the use of gas-

oline containing MMT

Some gasoline contains an octane enhanc-

ing additive called MMT (Methylcyclopen-

tadienyl Manganese Tricarbonyl).
Lexus does not recommend the use of gas-

oline that contains MMT. If fuel containing

MMT is used, your emission control system

may be adversely affected.
The malfunction indicator lamp on the

instrument cluster may come on. If this hap-

pens, contact your Lexus dealer for service.

■

If your engine knocks

●

Consult your Lexus dealer.

●

You may occasionally notice light knock-

ing for a short time while accelerating or

Fuel information

You must only use unleaded gaso-
line.

Select premium unleaded gasoline
with an octane rating of 91
(Research Octane Number 96) or
higher required for optimum
engine performance and fuel econ-
omy.
If the octane rating is less than 91,
damage to the engine may occur
and may void the vehicle warranty.

At minimum, the gasoline you use
should meet the specifications of
ASTM D4814 in the U.S.A..

352

8-1. Specifications

driving uphill. This is normal and there is

no need for concern.

NOTICE

■

Notice on fuel quality

●

Do not use improper fuels. If improper

fuels are used, the engine will be dam-

aged.

●

Do not use leaded gasoline.

Leaded gasoline can cause damage to

your vehicle’s three-way catalytic con-

verters causing the emission control

system to malfunction.

●

Do not use gasohol other than the type

previously stated.

Other gasohol may cause fuel system

damage or vehicle performance prob-

lems.

●

Using unleaded gasoline with an

octane number or rating lower than

the level previously stated may cause

persistent heavy knocking.

At worst, this may lead to engine dam-

age and will void the vehicle warranty.

■

When refueling with gasohol

Take care not to spill gasohol. It can dam-

age your vehicle’s paint.

■

Fuel-related poor driveability

If poor driveability (poor hot starting,

vaporization, engine knocking, etc.) is

encountered after using a different type

of fuel, discontinue the use of that type of

fuel.

353

8-1. Specifications

Vehi

cle

spec

ifi

tions



Full-size tire

Tire size (



P.355)

DOT and Tire Identification Number (TIN) (



P.354)

Location of treadwear indicators (



P.274)

Tire ply composition and materials

Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies
in a tire.

Radial tires or bias-ply tires

A radial tire has “RADIAL” on the sidewall. A tire not marked “RADIAL” is a bias-ply tire.

TUBELESS or TUBE TYPE

A tubeless tire does not have a tube and air is directly put into the tire. A tube type tire has a
tube inside the tire and the tube maintains the air pressure.

Load limit at maximum cold tire inflation pressure (



P.357)

Maximum cold tire inflation pressure (



P.357)

This means the pressure to which a tire may be inflated.

Uniform tire quality grading

For details, see “Uniform Tire Quality Grading” that follows.

Summer tires or all season tires (



P.275)

An all season tire has “M+S” on the sidewall. A tire not marked “M+S” is a summer tire.

Tire information

Typical tire symbols

A
B
C
D

354

8-1. Specifications



Compact spare tire

Tire size (



P.355)

DOT and Tire Identification Number (TIN) (



P.354)

Location of treadwear indicators (



P.274)

Tire ply composition and materials

Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies
in a tire.

TUBELESS or TUBE TYPE

A tubeless tire does not have a tube and air is directly put into the tire. A tube type tire has a
tube inside the tire and the tube maintains the air pressure.

Load limit at maximum cold tire inflation pressure (



P.357)

Maximum cold tire inflation pressure (



P.357)

This means the pressure to which a tire may be inflated.

“TEMPORARY USE ONLY”

A compact spare tire is identified by the phrase “TEMPORARY USE ONLY” molded on its
sidewall. This tire is designed for temporary emergency use only.



Type A

A
B
C
D

Typical DOT and Tire Identifica-
tion Number (TIN)

355

8-1. Specifications

Vehi

cle

spec

ifi

tions

DOT symbol

Tire Identification Number (TIN)
Tire manufacturer’s identification
mark
Tire size code
Manufacturer’s optional tire type
code (3 or 4 letters)
Manufacturing week
Manufacturing year

: The DOT symbol certifies that the tire

conforms to applicable Federal Motor
Vehicle Safety Standards.



Type B

DOT symbol

Tire Identification Number (TIN)
Tire manufacturer’s identification
mark
Manufacturing week
Manufacturing year
Manufacturer’s code

: The DOT symbol certifies that the tire

conforms to applicable Federal Motor
Vehicle Safety Standards.

■

Typical tire size information

The illustration indicates typical tire
size.

Tire use (P = Passenger car, T =
Temporary use)
Section width (millimeters)
Aspect ratio (tire height to section
width)
Tire construction code (R = Radial,
D = Diagonal)
Wheel diameter (inches)
Load index (2 digits or 3 digits)
Speed symbol (alphabet with one
letter)

■

Tire dimensions

Section width
Tire height

A
B
C

E
F

Tire size

B
C

E
F

A
B

356

8-1. Specifications

Wheel diameter

Bead
Sidewall
Shoulder
Tread
Belt
Inner liner
Reinforcing rubber
Carcass
Rim lines
Bead wires
Chafer

This information has been prepared in
accordance with regulations issued by
the National Highway Traffic Safety
Administration of the U.S. Department
of Transportation.
It provides the purchasers and/or pro-
spective purchasers of Lexus vehicles
with information on uniform tire quality
grading.

Your Lexus dealer will help answer any

questions you may have as you read this
information.

■

DOT quality grades

All passenger vehicle tires must con-
form to Federal Safety Requirements in
addition to these grades. Quality
grades can be found where applicable
on the tire sidewall between tread
shoulder and maximum section width.

For example: Treadwear 200 Traction AA
Temperature A

■

Treadwear

The treadwear grade is a comparative
rating based on the wear rate of the tire
when tested under controlled condi-
tions on a specified government test
course.

For example, a tire graded 150 would wear
one and a half (1 - 1/2) times as well on the
government course as a tire graded 100.
The relative performance of tires depends
upon the actual conditions of their use.
Performance may differ significantly from
the norm due to variations in driving habits,
service practices and differences in road
characteristics and climate.

■

Traction AA, A, B, C

The traction grades, from highest to
lowest, are AA, A, B and C, and they
represent the tire’s ability to stop on
wet pavement as measured under con-
trolled conditions on specified govern-
ment test surfaces of asphalt and
concrete.

A tire marked C may have poor traction
performance.
Warning: The traction grade assigned to
this tire is based on braking (straight
ahead) traction tests and does not include

Tire section names

Uniform Tire Quality Grading

A
B
C
D

E
F

357

8-1. Specifications

Vehi

cle

spec

ifi

tions

cornering (turning) traction.

■

Temperature A, B, C

The temperature grades are A (the
highest), B, and C, representing the
tire’s resistance to the generation of
heat and its ability to dissipate heat
when tested under controlled condi-
tions on a specified indoor laboratory
test wheel.

Sustained high temperature can cause the
material of the tire to degenerate and
reduce tire life, and excessive temperature
can lead to sudden tire failure.

Grade C corresponds to a level of perfor-
mance which all passenger car tires must
meet under the Federal Motor Vehicle
Safety Standard No. 109.
Grades B and A represent higher levels of
performance on the laboratory test wheel
than the minimum required by law.
Warning: The temperature grades of a tire
assume that it is properly inflated and not
overloaded.
Excessive speed, underinflation, or exces-
sive loading, either separately or in combi-
nation, can cause heat buildup and
possible tire failure.

Glossary of tire terminology

Tire related term

Meaning

Cold tire inflation pressure

Tire pressure when the vehicle has been parked for
three hours or more, or has not been driven more
than 1 mile or 1.5 km under that condition

Maximum inflation pressure

The maximum cold inflated pressure to which a tire
may be inflated, shown on the sidewall of the tire

Recommended inflation pressure

Cold tire inflation pressure recommended by a
manufacturer

Accessory weight

The combined weight (in excess of those standard
items which may be replaced) of automatic trans-
mission, power steering, power brakes, power win-
dows, power seats, radio and heater, to the extent
that these items are available as factory-installed
equipment (whether installed or not)

Curb weight

The weight of a motor vehicle with standard equip-
ment, including the maximum capacity of fuel, oil
and coolant, and if so equipped, air conditioning
and additional weight optional engine

358

8-1. Specifications

Maximum loaded vehicle weight

The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight

Normal occupant weight

150 lb. (68 kg) times the number of occupants
specified in the second column of Table 1

that fol-

lows

Occupant distribution

Distribution of occupants in a vehicle as specified in
the third column of Table 1

below

Production options weight

The combined weight of installed regular produc-
tion options weighing over 5 lb. (2.3 kg) in excess of
the standard items which they replace, not previ-
ously considered in curb weight or accessory
weight, including heavy duty brakes, ride levelers,
roof rack, heavy duty battery, and special trim

Rim

A metal support for a tire or a tire and tube assem-
bly upon which the tire beads are seated

Rim diameter (Wheel diameter)

Nominal diameter of the bead seat

Rim size designation

Rim diameter and width

Rim type designation

The industry manufacturer’s designation for a rim
by style or code

Rim width

Nominal distance between rim flanges

Vehicle capacity weight (Total load
capacity)

The rated cargo and luggage load plus 150 lb. (68
kg) times the vehicle’s designated seating capacity

Vehicle maximum load on the tire

The load on an individual tire that is determined by
distributing to each axle its share of the maximum
loaded vehicle weight, and dividing by two

Vehicle normal load on the tire

The load on an individual tire that is determined by
distributing to each axle its share of curb weight,
accessory weight, and normal occupant weight
(distributed in accordance with Table 1

below), and

dividing by two

Weather side

The surface area of the rim not covered by the
inflated tire

Tire related term

Meaning

359

8-1. Specifications

Vehi

cle

spec

ifi

tions

Bead

The part of the tire that is made of steel wires,
wrapped or reinforced by ply cords and that is
shaped to fit the rim

Bead separation

A breakdown of the bond between components in
the bead

Bias ply tire

A pneumatic tire in which the ply cords that extend
to the beads are laid at alternate angles substan-
tially less than 90 degrees to the centerline of the
tread

Carcass

The tire structure, except tread and sidewall rubber
which, when inflated, bears the load

Chunking

The breaking away of pieces of the tread or sidewall

Cord

The strands forming the plies in the tire

Cord separation

The parting of cords from adjacent rubber com-
pounds

Cracking

Any parting within the tread, sidewall, or innerliner
of the tire extending to cord material

A pneumatic tire with an inverted flange tire and rim
system in which the rim is designed with rim flanges
pointed radially inward and the tire is designed to fit
on the underside of the rim in a manner that
encloses the rim flanges inside the air cavity of the
tire

Extra load tire

A tire designed to operate at higher loads and at
higher inflation pressures than the corresponding
standard tire

Groove

The space between two adjacent tread ribs

Innerliner

The layer(s) forming the inside surface of a tubeless
tire that contains the inflating medium within the tire

Innerliner separation

The parting of the innerliner from cord material in
the carcass

Tire related term

Meaning

360

8-1. Specifications

Intended outboard sidewall

(a) The sidewall that contains a whitewall, bears
white lettering, or bears manufacturer, brand,
and/or model name molding that is higher or
deeper than the same molding on the other sidewall
of the tire, or
(b) The outward facing sidewall of an asymmetrical
tire that has a particular side that must always face
outward when mounted on a vehicle

Light truck (LT) tire

A tire designated by its manufacturer as primarily
intended for use on lightweight trucks or multipur-
pose passenger vehicles

Load rating

The maximum load that a tire is rated to carry for a
given inflation pressure

Maximum load rating

The load rating for a tire at the maximum permissi-
ble inflation pressure for that tire

Maximum permissible inflation pres-
sure

The maximum cold inflation pressure to which a tire
may be inflated

Measuring rim

The rim on which a tire is fitted for physical dimen-
sion requirements

Open splice

Any parting at any junction of tread, sidewall, or
innerliner that extends to cord material

Outer diameter

The overall diameter of an inflated new tire

Overall width

The linear distance between the exteriors of the
sidewalls of an inflated tire, including elevations due
to labeling, decorations, or protective bands or ribs

Passenger car tire

A tire intended for use on passenger cars, multipur-
pose passenger vehicles, and trucks, that have a
gross vehicle weight rating (GVWR) of 10,000 lb.
or less.

Ply

A layer of rubber-coated parallel cords

Ply separation

A parting of rubber compound between adjacent
plies

Pneumatic tire

A mechanical device made of rubber, chemicals,
fabric and steel or other materials, that, when
mounted on an automotive wheel, provides the
traction and contains the gas or fluid that sustains
the load

Tire related term

Meaning

361

8-1. Specifications

Vehi

cle

spec

ifi

tions

: Table 1 - Occupant loading and distribution for vehicle normal load for various desig-

nated seating capacities

Radial ply tire

A pneumatic tire in which the ply cords that extend
to the beads are laid at substantially 90 degrees to
the centerline of the tread

Reinforced tire

A tire designed to operate at higher loads and at
higher inflation pressures than the corresponding
standard tire

Section width

The linear distance between the exteriors of the
sidewalls of an inflated tire, excluding elevations
due to labeling, decoration, or protective bands

Sidewall

That portion of a tire between the tread and bead

Sidewall separation

The parting of the rubber compound from the cord
material in the sidewall

Snow tire

A tire that attains a traction index equal to or
greater than 110, compared to the ASTM E-1136
Standard Reference Test Tire, when using the snow
traction test as described in ASTM F-1805-00,
Standard Test Method for Single Wheel Driving
Traction in a Straight Line on Snow-and Ice-Cov-
ered Surfaces, and which is marked with an Alpine

Symbol (

) on at least one sidewall

Test rim

The rim on which a tire is fitted for testing, and may
be any rim listed as appropriate for use with that tire

Tread

That portion of a tire that comes into contact with
the road

Tread rib

A tread section running circumferentially around a
tire

Tread separation

Pulling away of the tread from the tire carcass

Treadwear indicators (TWI)

The projections within the principal grooves
designed to give a visual indication of the degrees
of wear of the tread

Wheel-holding fixture

The fixture used to hold the wheel and tire assembly
securely during testing

Tire related term

Meaning

362

8-1. Specifications

Designated seating capac-

ity, Number of occupants

Vehicle normal load, Num-

ber of occupants

Occupant distribution in a

normally loaded vehicle

2 through 4

2 in front

5 through 10

2 in front, 1 in second seat

11 through 15

2 in front, 1 in second seat, 1 in

third seat, 1 in fourth seat

16 through 20

2 in front, 2 in second seat, 2

in third seat, 1 in fourth seat

363

8-2. Customization

icle

ific

atio

8-2.Customization

■

Changing by using the meter con-
trol switches

Press

to select

Operate the switches to select a
desired item.

Change the setting by referring to
the message displayed on the
screen.

■

Changing by using the Remote
Touch

Press the “MENU” button on the
Remote Touch.

Select “Setup” on the menu screen
and select “Vehicle”.

Select “Vehicle Customization”,
“LEXUS Park Assist” or “Drive
Mode Customization”.

Various setting can be changed. Refer
to the list of settings that can be
changed for details.
This system can also be operated by
the touch screen.
For details on the Remote Touch, refer
to the “NAVIGATION AND MULTI-
MEDIA SYSTEM OWNER’S MAN-
UAL”.

■

When customizing using the Remote

Touch

Stop the vehicle in a safe place, apply the

parking brake, and shift the shift lever to P.

Also, to prevent battery discharge, leave

the engine running while customizing the

features.

Some function settings are changed simultaneously with other functions being cus-
tomized. Contact your Lexus dealer for further details.

Settings that can be changed using the Remote Touch
Settings that can be changed using the meter control switches

Customizable features

Your vehicle includes a variety of
electronic features that can be per-
sonalized to your preferences. The
settings of these features can be
changed by using the meter control
switches, the Remote Touch or at
your Lexus dealer.

Customizing vehicle features

WARNING

■

During customization

As the engine needs to be running

during customization, ensure that the

vehicle is parked in a place with ade-

quate ventilation. In a closed area such as

a garage, exhaust gases including harm-

ful carbon monoxide (CO) may collect

and enter the vehicle. This may lead to

death or a serious health hazard.

NOTICE

■

During customization

To prevent battery discharge, ensure that

the engine is running while customizing

features.

Customizable features

A
B

364

8-2. Customization

Settings that can be changed by your Lexus dealer

Definition of symbols: O = Available, — = Not available

■

Gauges, meters and multi-information display (



P.62, 66, 71)

Function

Default setting

Customized setting

Language

English

French

—

Spanish

Units

miles (MPG US)

km (km/L)

—

km (L/100 km)

miles (MPG Impe-

rial)

Switch settings

Drive information 1

Desired status

screen

—

Drive information 1

Current fuel con-

sumption

Customizable items:



P.73

—

Average fuel econ-

omy (after reset)

Drive information 2

Distance (driving

range)

Average vehicle

speed (after reset)

Drive information 3

Average fuel con-

sumption (after

refuel)

Elapsed time (after

start)

Pop-up display

Off

—

Accent color

Color 1

Color 2

—

Rev indicator

5000 r/min.

Select to set the

desired engine

speed at which the

Rev indicator will

begin to be dis-

played.

—

Off

365

8-2. Customization

Vehi

cle

spec

ifi

tions

: For details about each function:



P.76

: The default setting varies according to country.

: Except F SPORT models

: Some status screens cannot be registered (indicated on the multi-information display)

: F SPORT models

: On multi-information display

■

Door lock (



P.86, 89, 328)

Rev peak

Off

—

Eco Driving Indicator Light

Off

—

Clock

12-hour display

24-hour display

—

Function

Default setting

Customized setting

Function

Default setting

Customized setting

Unlocking using a mechani-
cal key

Driver’s door

unlocked in one

step, both side doors

unlocked in two

steps

Both side doors

unlocked in one step

—

Automatic door lock

Shifting the shift

lever to position

other than P

Off

—

Vehicle speed is

approximately 12

mph (20 km/h) or

higher

Automatic door unlock

Shifting the shift

lever to P

Off

—

Driver’s door is

opened

Locking/unlocking of the
trunk when both side doors
are locked/unlocked

Off

—

366

8-2. Customization

■

Smart access system with push-button start and wireless remote control
(



P.86, 89)

■

Smart access system with push-button start (



P.86, 89, 93)

■

Wireless remote control (



P.82, 86, 89)

Function

Default setting

Customized setting

Operation buzzer volume

Off

—

1 to 7

Operation signal (Emer-
gency flashers)

Off

—

Time elapsed before auto-
matic door lock function is
activated if door is not
opened after being unlocked

60 seconds

Off

—

30 seconds

120 seconds

Open door warning buzzer

Off

—

Welcome light illumination
control

Off

—

Function

Default setting

Customized setting

Smart access system with
push-button start

Off

—

Smart door unlocking

Driver’s door

Both side doors

—

Number of consecutive door
lock operations

2 times

As many as desired

—

Function

Default setting

Customized setting

Wireless remote control

Off

—

Unlocking operation

Driver’s door

unlocked in one

step, both side doors

unlocked in two

steps

Both side doors

unlocked in one step

—

367

8-2. Customization

Vehi

cle

spec

ifi

tions

■

Driving position memory

(



P.100)

: If equipped

■

Power easy access system (



P.100)

: If equipped

■

Power windows (



P.110)

Trunk unlocking operation

Press and hold

(short)

One short press

—

Push twice

Press and hold

(long)

Off

Alarm (panic mode)

Off

—

Function

Default setting

Customized setting

Function

Default setting

Customized setting

Selecting the door linking
driving position memory with
door unlock operation

Driver’s door

Both side doors

—

Function

Default setting

Customized setting

Driver’s seat movement when
exiting the vehicle

Full

Off

—

Partial

Steering wheel movement

Off

—

Function

Default setting

Customized setting

Mechanical key linked opera-
tion

Off

—

Wireless remote control
linked operation

Off

On (Open only)

—

Wireless remote control
linked operation signal
(buzzer)

Off

—

368

8-2. Customization

■

Moon roof

(



P.112)

: If equipped

■

Turn signal lever (



P.134)

: After flashing the turn signal lights when turning left or right while this function is off and

the turn signal lever is moved to the first position in the direction of the flashing light, the
turn signal lights can be selected to be flashing or off.

: The turn signal lights keep flashing if the turn signal lever is moved to the first position in

the direction of flashing light.

: The turn signal lights will be off if the turn signal lever is moved to the first position in the

direction of flashing light.

■

Automatic light control system (



P.141)

Function

Default setting

Customized setting

Mechanical key linked opera-
tion

Off

—

Wireless remote control
linked operation

Off

On (Open only)

—

Wireless remote control
linked operation signal
(buzzer)

Off

—

Function

Default setting

Customized setting

The number of times the turn
signal lights flash automati-
cally when the turn signal
lever is moved to the first
position during a lane
change

—

Off

Function

Default setting

Customized setting

Light sensor sensitivity

Standard

-2 to 2

—

Time elapsed before head-
lights automatically turn off
after doors are closed

30 seconds

Off

—

60 seconds

90 seconds

369

8-2. Customization

Vehi

cle

spec

ifi

tions

■

Lights (



P.141)

■

PCS (Pre-Collision System) (



P.161)

: The system is automaticallyenabled each time the engine switch is turned to ON.

■

LTA (Lane Tracing Assist) (



P.171)

■

RSA (Road Sign Assist)

(



P.180)

: If equipped

Function

Default setting

Customized setting

Daytime running light system
(except Canada)

Off

—

Function

Customized setting

Adjust alert timing

Early, Middle, Late

—

PCS (Pre-Collision System)

On, Off

—

Function

Customized setting

Lane centering function

On, Off

—

Alert type

Steering wheel vibration,

Buzzer

—

Alert sensitivity

High, Standard

—

Vehicle sway warning function

On, Off

—

Vehicle sway warning sensitivity

High, Standard, Low

—

Function

Customized setting

RSA (Road Sign Assist)

On, Off

—

Excess speed notification
method

Display only, Display and buzzer, No notifi-

cation

—

Excess speed notification
level

1 mph (2 km/h), 3 mph (5 km/h), 5 mph

(10 km/h)

—

Other notifications method
(No-entry notification)

Display only, Display and buzzer, No notifi-

cation

—

370

8-2. Customization

■

Dynamic radar cruise control with full-speed range (



P.182)

■

Intuitive parking assist

(



P.193)

: If equipped

■

Driving mode select switch (



P.206)

: If equipped

■

Automatic air conditioning system (



P.223)

■

Seat heaters

(



P.231)

: If equipped

Function

Customized setting

Curve speed reduction function strength

High, Low, Off

—

Function

Default setting

Customized setting

Detection distance of the
front center sensor

Far

Near

—

Detection distance of the rear
center sensor

Far

Near

—

Buzzer volume

1 to 3

—

Function

Default setting

Customized setting

Powertrain control in Cus-
tom mode

Normal

Power

—

Eco

Chassis control in Custom
mode

Normal

Sport

—

Air conditioning operation in
Custom mode

Normal

Eco

—

Function

Default setting

Customized setting

A/C auto switch operation

Off

—

Exhaust gas sensor sensitivity

Standard

-3 to 3

—

Function

Default setting

Customized setting

Seat heater timer control

Off

—

371

8-2. Customization

Vehi

cle

spec

ifi

tions

■

Illumination (



P.233)

■

Seat belt reminder (



P.309)

■

Vehicle customization

●

When the smart access system with

push-button start is off, the entry unlock

Function

Default setting

Customized setting

Time elapsed before the inte-
rior lights turn off

15 seconds

Off

—

7.5 seconds

30 seconds

Operation after the engine
switch is turned off

Off

—

Operation when the doors
are unlocked

Off

—

Operation when you
approach the vehicle with the
electronic key on your person

Off

—

Remote Touch pad light

Off

—

Time elapsed before the outer
foot lights turn off

15 seconds

Off

—

7.5 seconds

30 seconds

Operation of the outer foot
lights when you approach the
vehicle with the electronic
key on your person

Off

—

Operation of the outer foot
lights when the doors are
unlocked with the power
door lock switch

Off

—

Operation of the outer foot
lights when a door is opened

Off

—

Fading out of the outer foot
lights when they turn off

Long

Short

—

Function

Default setting

Customized setting

Vehicle speed linked seat belt
reminder buzzer

Off

—

372

8-2. Customization

function cannot be customized.

●

When the doors remain closed after

unlocking the doors and the timer acti-

vated automatic door lock function acti-

vates, signals will be generated in

accordance with the operation buzzer

volume and operational signal (Emer-

gency flashers) function settings.

●

Some settings can be changed using a

switch or the Center Display. If a setting is

changed using a switch, the changed set-

ting will not be reflected on the Center

Display screen until the engine switch is

turned off and then to IGNITION ON

mode.

373

8-3. Items to initialize

Vehi

cle

spec

ifi

tions

8-3.Items to initialize

Items to initialize

The following items must be initialized for normal system operation after such
cases as the battery being reconnected, or maintenance being performed on
the vehicle:

List of items to initialize

Item

When to initialize

Reference

Message indicating
maintenance is
required

After the maintenance is performed

P.256

Engine oil mainte-
nance data

After changing the engine oil

P.268

Tire pressure warning
system

• When rotating the tires
• When changing the tire inflation pres-

sure by changing traveling speed or
load weight, etc.

P.279

Lexus RC300 (2023 year). Manual in english - page 11
