Lexus NX (2023 year). Manual in english

The intersection collision avoidance support (for left/right turning vehicles) will not
operate when the turn signal lights are not flashing.

Detectable

objects

Vehicle speed

Oncoming vehi-

cle speed

Relative speed between

your vehicle and object

Oncoming
vehicles

Approximately 5 to 40
km/h (3 to 25 mph)

Approximately
5 to 75 km/h (3
to 45 mph)

Approximately 10 to 115
km/h (7 to 70 mph)

Pedestrians

Approximately 5 to 30
km/h (3 to 20 mph)

Approximately 5 to 40
km/h (3 to 25 mph)

Bicycles

Approximately 5 to 30
km/h (3 to 20 mph)

Approximately 5 to 50
km/h (3 to 30 mph)

Oncoming
motorcycles

Approximately 5 to 40
km/h (3 to 25 mph)

Approximately
5 to 75 km/h (3
to 45 mph)

Approximately 10 to 115
km/h (7 to 70 mph)

●

Intersection collision avoidance support (crossing vehicles)

Detecta-

ble objects

Vehicle speed

Crossing vehicle speed

Relative speed be-

tween your vehicle

and object

Vehicles
(side)

Approximately 5
to 60 km/h (3 to
38 mph)

●

Your vehicle speed or
less

●

Approximately 40 km/h
or less (25 mph or less)

Approximately 5 to
60 km/h (3 to 38
mph)

Motorcy-
cles (side)

Approximately 5
to 60 km/h (3 to
38 mph)

●

Your vehicle speed or
less

●

Approximately 40 km/h
or less (25 mph or less)

Approximately 5 to
60 km/h (3 to 38
mph)

●

Acceleration Suppression at Low Speed
The Acceleration Suppression at Low Speed function will not operate when the turn
signal lights are flashing.

Detectable ob-

jects

Vehicle speed

Relative speed between your ve-

hicle and object

Preceding vehi-
cles, stopped ve-
hicles

Approximately 0 to 15 km/h
(0 to 9 mph)

Approximately 0 to 15 km/h (0 to
9 mph)

6-2. Using the safe driving support functions

341

Driving suppor

t s

ystem

Detectable ob-

jects

Vehicle speed

Relative speed between your ve-

hicle and object

Bicycles

Approximately 0 to 15 km/h
(0 to 9 mph)

Approximately 0 to 15 km/h (0 to
9 mph)

Pedestrians

Approximately 0 to 15 km/h
(0 to 9 mph)

Approximately 0 to 15 km/h (0 to
9 mph)

While the Acceleration Suppression at Low Speed function is operating, if any of
the following are performed, the low speed sudden acceleration suppression function
operation will be cancelled:

•

The accelerator pedal is released.

•

The steering wheel is operated heavily or suddenly

■

Detection of detectable objects

Objects are detected based on their size, shape, and
movement. Depending on the ambient brightness,
movement, posture and direction of a detectable ob-
ject, it may not be detected and the system may not
operate properly. The system detects shapes, such as
the following, as detectable objects.

■

Situations in which the system may operate even though the possibility of a collision
is not high

●

In certain situations, such as the following, the system may determine that the possibili-
ty of a collision is high and operate:

•

When passing a detectable object

•

When changing lanes while overtaking a detectable object

•

When suddenly approaching a detectable object

•

When approaching a detectable object or other object on the roadside, such as
guardrails, utility poles, trees, walls, etc.

•

When there is a detectable object or other ob-
ject by the roadside at the entrance of a curve

6-2. Using the safe driving support functions

342

•

When there are patterns or a painting ahead of the vehicle that may be mistaken for
a detectable object

•

When passing a detectable object that is
changing lanes or turning left/right

•

When passing a detectable object which is
stopped to make a left/right turn

•

When a detectable object stops immediately before entering the path of the vehicle

•

When passing through a location with a struc-
ture above the road (traffic sign, billboard, etc.)

•

When approaching an electric toll gate barrier, parking lot barrier, or other barrier
that opens and closes

•

When turning left/right and an oncoming vehicle or pedestrian crosses in front of
the vehicle

•

When attempting to turn left/right in front of an oncoming vehicle or pedestrian

•

When turning left/right and an oncoming vehicle or pedestrian stops immediately
before entering the path of the vehicle

6-2. Using the safe driving support functions

343

Driving suppor

t s

ystem

•

When turning left/right and an oncoming vehi-
cle turns left/right in front of the vehicle

•

When the steering wheel is operated toward the path of an oncoming vehicle

■

Situations in which the system may not operate properly

●

In certain situations, such as the following, a detectable object may not be detected by
the front sensors, and the system may not operate properly:

•

When a detectable object is approaching your vehicle

•

When your vehicle or a detectable object is wandering

•

When a detectable object makes an abrupt maneuver (such as sudden swerving,
acceleration or deceleration)

•

When suddenly approaching a detectable object

•

When the detectable object is near a wall, fence, guardrail, manhole cover, steel
plate on the road surface, or another vehicle

•

When there is a structure above a detectable object

•

When part of a detectable object is hidden by another object (large luggage,
umbrella, guardrail, etc.)

•

When multiple detectable objects are overlapping

•

When a bright light, such as the sun, is reflecting off of a detectable object

•

When a detectable object is white and looks extremely bright

•

When the color or brightness of a detectable object causes it to blend in with its
surroundings

•

When a detectable object cuts in front of or suddenly emerges in front of your
vehicle

•

When approaching a vehicle which is diagonal

•

If a vehicle ahead is a child sized bicycle, is carrying a large load, is carrying an extra
passenger, or has an unusual shape (bicycles equipped with a child seat, tandem
bicycles, etc.)

•

If a pedestrian or bicycle is shorter than approximately 1 m (3.2 ft.) or taller than
approximately 2 m (6.5 ft.).

6-2. Using the safe driving support functions

344

•

When the silhouette of a pedestrian or bicycle is unclear (such as when they are
wearing a raincoat, long skirt, etc.)

•

When a pedestrian or bicycle is bending forward or squatting

•

When a pedestrian or bicycle is moving at high speed

•

When a pedestrian is pushing a stroller, wheelchair, bicycle or other vehicle

•

When a detectable object blends in with the surrounding area, such as when it is
dim (at dawn or dusk) or dark (at night or in a tunnel)

•

When the vehicle has not been driven for a certain amount of time after the engine
was started

•

While turning left/right or a few seconds after turning left/right

•

While driving around a curve and a few seconds after driving around a curve

•

When turning left/right and an oncoming vehicle is driving in a lane 3 or more lanes
from the vehicle

•

When turning left/right and the direction of the
vehicle differs greatly from the direction traffic
flows in the oncoming lane

•

When turning left/right and approaching a pe-
destrian which was traveling in the same direc-
tion as the vehicle and continues straight

●

In addition to the preceding, in certain situations, such as the following, the emergency
steering assist may not operate properly:

•

When a detectable object is too close to the vehicle

•

When there is insufficient space to perform evasive steering maneuvers or an
obstruction exists in the evasion direction

•

When there is an oncoming vehicle

6-2. Using the safe driving support functions

345

Driving suppor

t s

ystem

Changing the pre-collision setting

●

The pre-collision system can be enabled/disabled through a customize set-
ting.

→

P.660

The system is enabled each time the engine switch is turned to ON.

●

When the system is disabled, the PCS warning light will illuminate and a mes-
sage will be displayed on the multi-information display.

●

The pre-collision settings can be changed on the customize settings.

→

P.660

●

When the pre-collision warning timing is changed, the emergency steering
assist (excluding the active steering function) timing will also be changed. When
[Later] is selected, the emergency steering assist (excluding the active steering
function) will not operate in most cases.
When the dynamic radar cruise control is operating, the pre-collision warning
will operate at the [Earlier] timing, regardless of the user setting.

6-2. Using the safe driving support functions

346

Lane Tracing Assist

LTA (Lane Tracing Assist)

LTA functions

●

When driving on a road with clear lane lines
with the dynamic radar cruise control operat-
ing, lane lines and preceding and surrounding
vehicles are detected using the front camera
and radar sensor, and the steering wheel is op-
erated to maintain the vehicle’s lane position.

Use the this function only on highways and ex-
pressways.
If the dynamic radar cruise control is not operating,
the function will not operate.
In situations where the lane lines are difficult to see
or are not visible, such as when in a traffic jam, sup-
port will be provided using the path of preceding
and surrounding vehicles.
If the system determines that the steering wheel has not been operated for a certain
amount of time or the steering wheel is not being firmly gripped, the driver will be
alerted via a display and this function will be temporarily canceled.
If the steering wheel is firmly gripped, the function will begin operating again.

●

When the function is operating, if the vehicle is
likely to depart from its lane, the driver will be
alerted via a display and buzzer.

When the buzzer sounds, check the area around
the vehicle and carefully operate the steering
wheel to move the vehicle back to the center of
the lane.

6-2. Using the safe driving support functions

347

Driving suppor

t s

ystem

WARNING

■

Before using the LTA system

●

Do not overly rely on the LTA system. The LTA system is a system which provides
automated assistance in driving. However, as it is not a system which reduces the
amount of attention necessary for safe driving. The driver is solely responsible for
paying attention to their surroundings and operating the steering wheel as necessary
to ensure safety. Also, the driver is responsible for taking adequate breaks when
fatigued, such as when driving for a long time.
Failure to perform appropriate driving operations and pay careful attention may lead
to an accident.

●

When not using the LTA system, turn it off using the LTA switch.

INFORMATION

■

Operating conditions of function

●

This function is operable when all of the following conditions are met:

•

The LTA system detects lane lines or the path of preceding or surrounding vehicles
(except when the preceding vehicle is small, such as a motorcycle).

•

The dynamic radar cruise control is operating.

•

The lane width is approximately 3 to 4 m (10 to 13 ft.).

•

The turn signal lever is not being operated.

•

The vehicle is not being driven around a sharp curve.

•

The vehicle is not accelerating or decelerating more than a certain amount.

•

The steering wheel is not being turned with a large force.

•

The hands off steering wheel warning

(

→

P.349)

is not operating.

•

The vehicle is being driven in the center of a lane.

■

Temporary cancelation of functions

●

When the operating conditions are no longer met, a function may be temporarily
canceled. However, when the operation conditions are met again, operation of the
function will automatically be restored.

(

→

P.348)

●

If the operating conditions of a function are no longer met while the function is
operating, a buzzer may sound to indicate that the function has been temporarily
canceled.

●

The steering assist operation of the function can be overridden by the steering wheel
operation of the driver.

6-2. Using the safe driving support functions

348

■

Lane departure warning function when the LTA is operating

●

Even if the LDA warning method is changed to vibration of the steering wheel, if the
vehicle deviates from the lane while the LTA is operating, the warning buzzer will
sound to alert the driver.

●

If steering wheel operation equivalent to that necessary for a lane change is detected,
the system will determine the vehicle is not deviating from the lane and the warning will
not operate.

■

Hands off steering wheel warning operation

In the following situations, a message urging the driv-
er to grip the steering wheel and the icon shown in
the illustration will be displayed on the multi-informa-
tion display to warn the driver. If the system detects
that the steering wheel is held, the warning will be
canceled. When using the system, make sure to grip
the steering wheel firmly, regardless of whether the
warning is operating or not.

●

When the system determines the driver is not holding the steering wheel while the
function is operating
If no operations are detected for a certain amount of time, a buzzer will sound, the
warning will operate, and the function will be temporarily canceled. This warning may
also operate if the driver only operates steering wheel a small amount continuously.

●

Depending on the condition of the vehicle, handle control condition and road surface,
the warning function may not operate.
Vehicles with LCA:In the following situations, the system may not be able to detect
when the driver’s hands are off the steering wheel.

•

When a steering wheel cover is installed

•

When the driver is wearing gloves

•

When foreign matter is attached to the steering wheel

•

When the driver is gripping the wood trim, seam of the leather, spokes, or other
part of the steering wheel that does not have sensors

Vehicles with LCA: In the following situations, the hands off steering wheel warning
may not operate and the LTA function may continue operating even though the
driver’s hands are off the steering wheel:

•

When something other than a hand is contacting the steering wheel

•

When a wide object or arms are held across the steering wheel

6-2. Using the safe driving support functions

349

Driving suppor

t s

ystem

Enabling/disabling the system

The LTA will change between enabled/disabled
each time the LTA switch is pressed.

When the LTA is enabled, the LTA indicator will illumi-
nate.

WARNING

■

Situations in which the functions may not operate properly

In the following situations, the functions may not operate properly and the vehicle may
depart from its lane. Do not overly rely on these functions. The driver is solely responsible
for paying attention to their surroundings and operating the steering wheel as necessary
to ensure safety.

●

When a preceding or surrounding vehicle
changes lanes (Your vehicle may follow the pre-
ceding or surrounding vehicle and also change
lanes)

●

When a preceding or surrounding vehicle is swaying (Your vehicle may sway accord-
ingly and depart from the lane)

●

When a preceding or surrounding vehicle departs from a lane (Your vehicle may
follow the preceding or surrounding vehicle and also depart from the lane)

●

When a preceding or surrounding vehicle is being driven extremely close to the
left/right lane line (Your vehicle may follow the preceding or surrounding vehicle
accordingly and depart from the lane)

▶

Vehicles without a head-up

display

▶

Vehicles with a head-up dis-

play

6-2. Using the safe driving support functions

350

WARNING

●

When there are moving objects or structures in the surrounding area (Depending on
the position of the moving object or structure relative to your vehicle, your vehicle may
sway)

●

When the vehicle is struck by a crosswind or the turbulence of other nearby vehicles

●

Situations in which the sensors may not operate properly:

→

P.321

●

Situations in which the lane may not be detected:

→

P.323

●

When it is necessary to disable the system:

→

P.316

Operation display of steering wheel operation support

The operating state of the LTA system is indicated.

Indicator Lane display Steering icon

Situation

White

Gray

Grey

LTA is on standby

Green

LTA is operating

Orange
Flashing

Green

The vehicle is departing the lane toward the side
which the lane display is flashing

6-2. Using the safe driving support functions

351

Driving suppor

t s

ystem

Lane Change Assist

LCA (Lane Change Assist)

LCA functions

This function is linked to the LTA and provides assistance in performing lane
changes through steering wheel operations when the turn signal lever is held
partway

When not using the LCA system, turn it off using the LCA switch.
Use the this function only on highways and expressways.
The steering assist operation can be overridden by the steering wheel operation of the
driver.
The lane change assist function is not designed to operate when changing lanes at a
junction.

WARNING

■

Before using the LCA system

●

Do not overly rely on the LCA system.
The LCA system is a system which provides automated assistance in driving. However,
as it is not a system which reduces the need for checking an adjacent lane for
other vehicles, approaching vehicles, etc. when changing lanes. The driver is solely
responsible for paying attention to their surroundings and operating the steering
wheel as necessary to ensure safety.
Also, do not use the LCA to change lanes into which a lane change should not be
performed (oncoming lanes, road shoulders, etc.).

●

Failure to perform appropriate driving operations and pay careful attention may lead
to an accident.

INFORMATION

■

Operating conditions of function

●

This function is operable when all of the following conditions are met:

•

The LTA is operating.

•

The lane change assist function is enabled by a customize setting.

•

The vehicle speed is between approximately 100 and 140 km/h (60 and 85 mph).

•

The system recognizes the current road as a highway or expressway.

* :

If equipped

6-2. Using the safe driving support functions

352

•

The system detects a broken white line on the side which the lane change is to be
performed.

•

A vehicle is not detected in the lane toward which the turn signal is operated.

•

The navigation system map data is current.

•

The steering wheel is not being turned with a large force.

•

The hands off steering wheel warning

(

→

P.353)

is not operating.

•

The system has detected a moving object behind the vehicle at least once since the
engine was started.

■

Cancelation of functions

●

If the operating conditions are no longer met while the LCA is operating, a message
may be displayed and buzzer may sound to indicate that the LCA has been can-
celed.

→

P.352

In the following situations, operation of the LCA may be canceled:

●

When the system can no longer detect lane lines

●

When the turn signal lever is operated to the left/right turn position

●

When the LTA system detects operation of the steering wheel, brake pedal or acceler-
ator pedal by the driver

●

When the system determines the driver is not holding the steering wheel while the
function is operating

If the system detects that a vehicle is quickly approaching in the lane toward which the
turn signal is operated, a buzzer will sound, the steering wheel will vibrate, and a message
will be displayed to alert the driver. At the same time the steering wheel may be slightly
operated to help keep the vehicle away from the approaching vehicle.

■

Hands off steering wheel warning operation

●

When the system determines the driver is not holding the steering wheel while LCA is
operating

6-2. Using the safe driving support functions

353

Driving suppor

t s

ystem

Operating the LCA

If the turn signal lever is held in the lane change position, the lane change direction
will be displayed and the function will operate.

WARNING

■

Situations in which the LCA should not be used

●

When driving on a one lane road

●

When there is no broken white line between the current lane and the lane to be
changed to

Enabling/disabling the system

●

LCA can be enabled/disabled through a customize setting.

→

P.660

Operation display of steering wheel operation support

The operating state of the LCA system is indicated.

LCA display

Steering icon

Condition

Blue arrow and white line

Green

LCA on standby

6-2. Using the safe driving support functions

354

Lane Departure Alert

LDA (Lane Departure Alert)

Basic functions

The LDA system warns the driver if the vehicle may deviate from the current lane
or course

, and also can slightly operate the steering wheel to help avoid deviation

from the lane or course

The front camera is used to detect lane lines or a course

■

Lane departure alert function

When the system determines that the vehicle
might depart from its lane or course

, a warning

is displayed on a display, and either a warning
buzzer will sound or the steering wheel will vi-
brate to alert the driver.

Check the area around your vehicle and carefully
operate the steering wheel to move the vehicle back
to the center of the lane or course

Vehicles with BSM: If the system determines that the
vehicle may collide with a vehicle in an adjacent lane,
the lane departure alert will operate even if the turn
signals are operating.

*1 :

Boundary between the asphalt and grass, soil, etc., or structures, such as a curb,

guardrail, etc.

6-2. Using the safe driving support functions

356

■

Lane departure prevention function

If the system determines that the vehicle is likely
to depart from its lane or course

, it provides

assistance through steering wheel operations to
help avoid deviation from the lane or course.
If the system determines that the steering wheel
has not been operated for a certain amount of
time or the steering wheel is not being firmly
gripped, a warning message may be displayed
and a warning buzzer may sound to alert the
driver.
Vehicles with BSM: If the system determines that
the vehicle may collide with a vehicle in an adja-
cent lane, the lane departure prevention function
will operate even if the turn signals are operating.

■

Break suggestion function

If the vehicle is swaying, a message will be dis-
played and a warning buzzer will sound to urge
the driver to take a break.

WARNING

■

Before using the LDA system

●

Do not overly rely on the LDA system. The LDA system is a system which provides
automated assistance in driving. However, as it is not a system which reduces the
amount of attention necessary for safe driving. The driver is solely responsible for
paying attention to their surroundings and operating the steering wheel as necessary

6-2. Using the safe driving support functions

357

Driving suppor

t s

ystem

WARNING

to ensure safety. Also, the driver is responsible for taking adequate breaks when
fatigued, such as when driving for a long time.

●

Failure to perform appropriate driving operations and pay careful attention may lead
to an accident.

INFORMATION

■

Operating conditions of each function

●

Lane departure alert/prevention function
This function is operable when all of the following conditions are met:

•

The vehicle speed is approximately 50 km/h (30 mph) or more.
Operation may be possible when the vehicle speed is approximately 40 km/h (25
mph) or more if vehicles, motorcycles, bicycles, or pedestrians are detected near
the lane.

•

The system recognizes a lane or course

. (When recognized on only one side

the system will operate only for the recognized side.)

•

The lane width is approximately 3 m (9.8 ft.) or more.

•

The turn signal lever is not being operated.
(Vehicles with BSM: Except when a vehicle is detected in the direction that the turn
signal lever is operated.)

•

The vehicle is not being driven around a sharp curve.

•

The vehicle is not accelerating or decelerating more than a certain amount.

•

The steering wheel is not being turned sufficiently to perform a lane change.

●

Break suggestion function
This function is operable when all of the following conditions are met:

•

The vehicle speed is approximately 50 km/h (30 mph) or more.

•

The lane width is approximately 3 m (9.8 ft.) or more.

■

Temporary cancellation of functions

When the operating conditions are no longer met, a function may be temporarily can-
celed. However, when the operation conditions are met again, operation of the function
will automatically be restored.

(

→

P.358)

*2 :

Boundary between the asphalt and grass, soil, etc., or structures, such as a curb,

guardrail, etc.

6-2. Using the safe driving support functions

358

■

Operation of the lane departure alert function/lane departure prevention function

●

Depending on the vehicle speed, road conditions, lane departure angle, etc., opera-
tion of the lane departure prevention function may not be felt or the function may not
operate.

●

Depending on the conditions, the warning buzzer may operate even if vibration is
selected through a customize setting.

●

If a course

is not clear or straight, the lane departure alert function or lane departure

prevention function may not operate.

●

The lane departure alert function or lane departure prevention function may not
operate if the system judges that the vehicle is intentionally being steered to avoid a
pedestrian or parked vehicle.

●

Vehicles with BSM: It may not be possible for the system to judge if there is danger of a
collision with a vehicle in an adjacent lane.

●

The steering assist operation of the lane departure prevention function can be overrid-
den by the steering wheel operation of the driver.

■

Hands off steering wheel warning operation

In the following situations, a message urging the driv-
er to operate the steering wheel and an icon will
be displayed and a buzzer will sound to warn the
driver. When using the system, make sure to grip
the steering wheel firmly, regardless of whether the
warning is operating or not.

●

When the system determines that the driver is
not securely holding the steering wheel, or the
steering wheel is not being operated when the steering assist operation of the lane
departure prevention function is operating
The length of time that the warning buzzer operates will become longer as the
frequency of the steering assist operating increases. Even if the system judges that the
steering wheel has been operated, the warning buzzer will sound for a certain amount
of time.

■

Break suggestion function

If the vehicle is swaying, a message will be displayed
and a warning buzzer will sound to urge the driver to
take a break.
Depending on the condition of the vehicle and road
surface, the break suggestion function may not oper-
ate.

6-2. Using the safe driving support functions

359

Driving suppor

t s

ystem

Displays and system operation

The operating state of the lane departure alert function and steering assist opera-
tion of the lane departure prevention function are indicated.

Indicator

Lane display

Steering icon

Situation

Orange
Illuminated

Not illuminated Not illuminated System disabled

Not illuminated

Gray

Not illuminated

Lane lines are not detected by the
system

Not illuminated

White

Not illuminated Lane lines are detected by the system

Orange
Flashing

Not illuminated

Lane departure alert function is op-
erating for the side which the lane
display is flashing

Green

Lane departure prevention function
is operating for the side which the
lane display is illuminated

Orange
Flashing

Green

Lane departure alert function/lane
departure prevention function is op-
erating for the side which the lane
display is flashing

6-2. Using the safe driving support functions

360

Changing LDA settings

●

The LDA system can be enabled/disabled through a customize setting.

→

P.660

●

The following settings of the LDA can be changed through customize set-
tings.

→

P.660

WARNING

■

Situations in which the LDA should not be used

In the following situations, disable the LDA system. Failure to do so may lead to an
accident.

●

When it is necessary to disable the system:

→

P.316

■

Situations in which the system may not operate properly

In the following situations, the system may not operate properly and the vehicle may
depart from its lane. Do not overly rely on these functions. The driver is solely responsible
for paying attention to their surroundings and operating the steering wheel as necessary
to ensure safety.

●

When the boundary between the asphalt and grass, soil, etc., or structures, such as a
curb, guardrail, etc. is not clear or straight

●

When the vehicle is struck by a crosswind or the turbulence of other nearby vehicles

●

Situations in which the lane may not be detected :

→

P.323

●

Situations in which the sensors may not operate properly:

→

P.321

●

Situations in which some or all of the functions of the system cannot operate:

→

P.323

6-2. Using the safe driving support functions

361

Driving suppor

t s

ystem

Front crossing traffic alert

FCTA

（

Front crossing traffic alert

）

When approaching an intersection, etc., at a low speed, vehicles approaching from
the left and right of the front of the vehicle can be detected and the driver informed
of these vehicles.

FCTA system control

●

When the system detects a vehicle approach-
ing from the left or right in front of your vehicle
when approaching an intersection, a notifica-
tion will be displayed.

●

When the system determines that your vehicle
may be about to enter an intersection even
though a vehicle is approaching from the left
or right in front of your vehicle, a buzzer will
sound and a message will be displayed to urge
you to depress the brake pedal.

WARNING

■

For safe use

Driving safely is solely the responsibility of the driver. Pay careful attention to the sur-
rounding conditions in order to ensure safe driving. The FCTA system is a supplementary
system that informs the driver of vehicles approaching from the left and right of the
front of the vehicle. Over-reliance on this system may lead to an accident resulting in
death or serious injury. The details of the warning display may differ from the actual
traffic conditions. Although the warning display will stop being displayed after a certain
amount of time, this does not necessarily indicate that there are no longer any vehicles or
pedestrians around your vehicle.

▶

Head-up display

▶

Multi-information display

* :

If equipped

6-2. Using the safe driving support functions

362

INFORMATION

■

FCTA system operating conditions

The system will operate when all of the following conditions are met:

●

A shift position other than P or R is selected

●

The vehicle speed is approximately 15 km/h (10 mph) or less

●

A vehicle is approaching from the left or right in front of your vehicle at a speed
between approximately 10 to 60 km/h (7 to 37 mph)

●

There are no vehicles in front of your vehicle

●

The accelerator pedal is not being strongly depressed

●

The brake pedal is not being strongly depressed

■

Situations in which the system may operate even though no vehicles are approach-
ing

In certain situations, such as the following, the system may operate even though no
vehicles are approaching:

●

When approaching objects on the roadside, such as guardrails, traffic signs, utility
poles, street lights, trees, tall grass, walls, etc.

●

When passing an object on the side of the road, such as a parked vehicle

●

When a vehicle or pedestrian is approaching from the left or right in front of your
vehicle in the distance

●

When a vehicle or pedestrian is moving within a parking spot, etc., next to the lane
your vehicle is in

●

When a pedestrian or bicyclist is approaching on a sidewalk

●

When a vehicle or pedestrian is moving away from your vehicle

●

When an approaching vehicle is decelerating or stops

●

When an approaching vehicle makes a left/right turn immediately in front of your
vehicle

●

When a pedestrian is approaching your vehicle

●

When an oncoming vehicle makes a right/left turn

●

When your vehicle enters an intersection before a vehicle approaching from the left or
right in front of your vehicle

●

When stopped at traffic light and a vehicle approaches from the left or right in front of
your vehicle

6-2. Using the safe driving support functions

363

Driving suppor

t s

ystem

●

When making a left/right turn in front of an ap-
proaching vehicle

●

When an oncoming vehicle approaches and pass-
es

●

When being overtaken by another vehicle

●

When driving next to another vehicle or a pedes-
trian

●

When a vehicle or pedestrian approaches the side of your vehicle

■

Situations in which the system may not operate properly

In situations such as the following, a vehicle may not be detected by a front side radar
sensor and the system may not operate properly:

●

If an approaching vehicle moves suddenly (sudden steering, acceleration, decelera-
tion, etc.)

●

If a vehicle is approaching from the left or right of the front of your vehicle diagonally

●

When a vehicle is approaching from the left or right in front of your vehicle in the
distance

●

When there is an object between your vehicle and an approaching vehicle

●

When several vehicles are approaching with little space between them

●

Situations in which the sensors may not operate properly:

→

P.321

●

Situations in which some or all of the functions of the system cannot operate:

→

P.323

Changing FCTA system settings

●

The FCTA can be enabled/disabled through a customize setting.

→

P.659

●

The following settings of the FCTA can be changed through customize set-
tings.

→

P.659

6-2. Using the safe driving support functions

364

Assistance in detecting vehicles behind when changing lanes

The Blind Spot Monitor is a system that uses rear side radar sensors installed on
the inner side of the rear bumper on the left and right side to assist the driver in
confirming safety when changing lanes.

WARNING

■

Cautions regarding the use of the system

The driver is solely responsible for safe driving. Always drive safely, taking care to
observe your surroundings.
The Blind Spot Monitor is a supplementary function which alerts the driver that a vehicle
is in a blind spot of the outside rear view mirrors or is approaching rapidly from behind
into a blind spot. Do not overly rely on the Blind Spot Monitor. As the function cannot
judge if it is safe to change lanes, over reliance could lead to an accident resulting in
death or serious injury.
As the system may not function correctly under certain conditions, the driver’s own visual
confirmation of safety is necessary.

Related Links

Customizable features(P. 650)

Purpose of the Blind Spot Monitor

INFORMATION

■

Conditions under which the system will not detect a vehicle

The Blind Spot Monitor is not designed to detect the following types of vehicles and/or
objects:

●

Small motorcycles, bicycles, pedestrians, etc.

●

Vehicles traveling in the opposite direction

●

Guardrails, walls, signs, parked vehicles and similar stationary objects

●

Following vehicles that are in the same lane

●

Vehicles traveling 2 lanes away from your vehicle

●

Vehicles which are being overtaken rapidly by your vehicle

* :

If equipped

*1 :

Depending on the conditions, detection of a vehicle and/or object may occur.

6-2. Using the safe driving support functions

365

Driving suppor

t s

ystem

System components

Center display
Turning the Blind Spot Monitor on/off.

Outside rear view mirror indicators
When a vehicle is detected in a blind spot of
the outside rear view mirrors or approach-
ing rapidly from behind into a blind spot,
the outside rear view mirror indicator on
the detected side will illuminate. If the turn
signal lever is operated toward the detected
side, the outside rear view mirror indicator
flashes.

INFORMATION

■

Outside rear view mirror indicator visibility

In strong sunlight, the outside rear view mirror indicator may be difficult to see.

WARNING

■

To ensure the system can operate properly

Blind Spot Monitor sensors are installed behind the left and right sides of the rear bumper
respectively. Observe the following to ensure the Blind Spot Monitor can operate
correctly.

●

Keep the sensors and the surrounding areas on
the rear bumper clean at all times.
If a sensor or its surrounding area on the rear
bumper is dirty or covered with snow, the Blind
Spot Monitor may not operate and a warning
message will be displayed. In this situation, clear
off the dirt or snow and drive the vehicle with the
operation conditions of the BSM function satisfied
for approximately 10 minutes. If the warning message does not disappear, have the
vehicle inspected by any authorized Lexus retailer or Lexus authorized repairer, or any
reliable repairer.

●

Do not attach accessories, stickers (including transparent stickers), aluminum tape,
etc., to a sensor or its surrounding area on the rear bumper.

●

Do not subject a sensor or its surrounding area on the rear bumper to a strong impact.

6-2. Using the safe driving support functions

366

WARNING

If a sensor is moved even slightly off position, the system may malfunction and vehicles
may not be detected correctly. In the following situations, have your vehicle inspected
by any authorized Lexus retailer or Lexus authorized repairer, or any reliable repairer.

•

A sensor or its surrounding area is subject to a strong impact.

•

If the surrounding area of a sensor is scratched or dented, or part of them has
become disconnected.

●

Do not disassemble the sensor.

●

Do not modify the sensor or surrounding area on the rear bumper.

●

If a sensor or the rear bumper needs to be removed/installed or replaced, contact any
authorized Lexus retailer or Lexus authorized repairer, or any reliable repairer.

●

Do not paint the rear bumper any color other than an official Lexus color.

Vehicles that can be detected by the Blind Spot Monitor

The Blind Spot Monitor uses rear side radar sensors to detect the following
vehicles traveling in adjacent lanes and advises the driver of the presence of such
vehicles via the indicators on the outside rear view mirrors.

Vehicles that are traveling in areas that are not visible using the outside rear
view mirrors (the blind spots)

Vehicles that are approaching rapidly from behind in areas that are not visible
using the outside rear view mirrors (the blind spots)

The Blind Spot Monitor detection areas

The areas that vehicles can be detected in are outlined below.

6-2. Using the safe driving support functions

367

Driving suppor

t s

ystem

The range of each detection area is:

Approximately 0.5 m (1.6 ft.) to 3.5 m (11.5 ft.) from either side of the vehicle

Approximately 1 m (3.3 ft.) forward of the rear bumper

Approximately 3 m (9.8 ft.) from the rear bumper

Approximately 3 m (9.8 ft.) to 60 m (197 ft.) from the rear bumper

Turning the Blind Spot Monitor system ON/OFF

The Blind Spot Monitor system can be changed between ON and OFF on the
center display

Select

Select [Driving assist].

Select [Blind spot monitor].

When the BSM function is disabled, the driving assist infomation indicator illumi-
nates.
Each time the engine switch is turned off then changed to ON, the Blind Spot
Monitor will be enabled automatically.

INFORMATION

■

The Blind Spot Monitor is operational when

The Blind Spot Monitor is operational when all of the following conditions are met:

●

The Blind Spot Monitor is on.

●

The vehicle speed is greater than approximately 10 km/h (7 mph).

●

The shift position is in a position other than R.

*2 :

The area between the side of the vehicle and 0.5 m (1.6 ft.) from the side of the vehicle

cannot be detected.

*3 :

The greater the difference in speed between your vehicle and the detected vehicle

is, the farther away the vehicle will be detected, causing the outside rear view mirror

indicator to illuminate or flash.

6-2. Using the safe driving support functions

368

■

The Blind Spot Monitor will detect a vehicle when

The Blind Spot Monitor will detect a vehicle present in the detection area in the following
situations:

●

A vehicle in an adjacent lane overtakes your vehicle.

●

You overtake a vehicle in an adjacent lane slowly.

●

Another vehicle enters the detection area when it changes lanes.

■

Conditions under which the system may not function correctly

●

The Blind Spot Monitor may not detect vehicles correctly in the following situations:

•

When the sensor is misaligned due to a strong impact to the sensor or its surround-
ing area

•

When mud, snow, ice, a sticker, etc., is covering the sensor or surrounding area on
the rear bumper

•

When driving on a road surface that is wet with standing water during bad weather,
such as heavy rain, snow, or fog

•

When multiple vehicles are approaching with only a small gap between each
vehicle

•

When the distance between your vehicle and a following vehicle is short

•

When there is a significant difference in speed between your vehicle and the
vehicle that enters the detection area

•

When the difference in speed between your vehicle and another vehicle is chang-
ing

•

When a vehicle enters a detection area traveling at about the same speed as your
vehicle

•

As your vehicle starts from a stop, a vehicle remains in the detection area

•

When driving up and down consecutive steep inclines, such as hills, dips in the road,
etc.

•

When driving on roads with sharp bends, consecutive curves, or uneven surfaces

•

When vehicle lanes are wide, or when driving on the edge of a lane, and the vehicle
in an adjacent lane is far away from your vehicle

•

When an accessory (such as a bicycle carrier) is installed to the rear of the vehicle

•

When there is a significant difference in height between your vehicle and the
vehicle that enters the detection area

•

Immediately after the Blind Spot Monitor is turned on

●

Instances of the Blind Spot Monitor unnecessarily detecting a vehicle and/or object
may increase in the following situations:

6-2. Using the safe driving support functions

369

Driving suppor

t s

ystem

•

When the sensor is misaligned due to a strong impact to the sensor or its surround-
ing area

•

When the distance between your vehicle and a guardrail, wall, etc., that enters the
detection area is short

•

When driving up and down consecutive steep inclines, such as hills, dips in the road,
etc.

•

When vehicle lanes are narrow, or when driving on the edge of a lane, and a vehicle
traveling in a lane other than the adjacent lanes enters the detection area

•

When driving on roads with sharp bends, consecutive curves, or uneven surfaces

•

When the tires are slipping or spinning

•

When the distance between your vehicle and a following vehicle is short

•

When an accessory (such as a bicycle carrier) is installed to the rear of the vehicle

6-2. Using the safe driving support functions

370

Supporting safe exit by detecting detectable objects at the rear of
the vehicle by outputting sounds, displaying screens as a warning or
cancelling opening of the doors

The Safe exit assist (with door opening control) is a system that uses radar sensors
installed on the inner side of the rear bumper to help occupants judge if an
approaching vehicle or bicycle may collide with a door when opening it or cancel
opening of a door, to reduce the possibility of a collision.

WARNING

■

Cautions regarding the use of the system

●

The driver is solely responsible for safe driving. Always drive safely, taking care to
observe your surroundings.

●

Safe exit assist is a supplementary system that, when the vehicle is stopped, informs
occupants of the existence of approaching vehicles and bicycles. As this system alone
cannot used to judge safety, over-reliance on this system may lead to an accident
resulting in death or serious injury.
As the system may not function correctly under certain conditions, the driver’s own
visual confirmation of safety is necessary.

Lexus NX (2023 year). Manual in english - page 11
