Functions which aid in safe opening and closing of the panoramic moon
roof

The following functions aid in safe opening and closing of the panoramic moon
roof.

●

Jam protection function
If an object is detected between the panoramic moon roof and the frame while
the panoramic moon roof is closing or tilting down, travel is stopped and the
panoramic moon roof opens slightly.

●

panoramic moon roof open warning buzzer
The buzzer sounds and a message is shown on the multi-information display in
the instrument cluster when the engine switch is turned off and the driver’s door
is opened with the panoramic moon roof open.

WARNING

■

Jam protection function

●

Never use any part of your body to intentionally activate the jam protection function.

●

The jam protection function may not operate if something gets caught just before the
panoramic moon roof is fully closed.
Also, the jam protection function is not designed to operate while the moon roof
switch is being pressed.
Take care so that your fingers, etc. do not get caught.

Opening the panoramic moon roof

Press the

switch.

Lightly press either end of the panoramic moon roof

switch to stop the panoramic moon roof while it is

operating.

*1 :

Press the

The panoramic moon roof and electronic sunshade will open automati-

cally.

4-3. Adjusting the temperature/environment inside the vehicle

245

Interior feat

Closing the panoramic moon roof

Press the

switch.

The panoramic moon roof can be opened from the
tilt-up position.

Press the

switch forward. The panoramic moon

roof will fully close automatically.

Tilting up the panoramic moon roof

Press the

switch.

When the panoramic moon roof is tilted up, the elec-
tronic sunshade will open to the half-open position of
the roof.

Tilting down the panoramic moon roof

Press and hold the

switch.

The panoramic moon roof can be tilted down only
when it is in the tilt-up position.

*2 :

Lightly press either end of the panoramic moon roof

switch to stop the panoramic

moon roof while it is operating.

*3 :

Lightly press either end of the panoramic moon roof

switch to stop the panoramic

moon roof while it is operating.

4-3. Adjusting the temperature/environment inside the vehicle

246

Opening and closing the electronic sunshade

For comfortable cabin experience, the electronic sunshade can be opened.

WARNING

Observe the following precautions when opening and closing the electronic sunshade.

●

Make sure that all passengers do not have any part of their body in a position where it
could be caught when the electronic sunshade is being operated.

●

Do not allow children to operate the electronic sunshade. Closing the electronic
sunshade on someone can cause death or serious injury.

●

Keep fingers free of the gaps between the underside of the roof and the electronic
sunshade.
Otherwise a hand may become pinched, possibly causing injury. Also, if the vehicle is
left in direct sunlight for a long time, the underside of the roof could be very hot and
possibly cause burns.

INFORMATION

■

Operating conditions of the electronic sunshade

The engine switch is in ON.

■

Operating the electronic sunshade after turning the engine off

The electronic sunshade can be operated for approximately 45 seconds after the engine
switch is turned to ACC or OFF.
They cannot, however, be operated once either front door is opened.

Functions which aid in safe opening and closing of the electronic sun-
shade

The following function aid in safe opening and closing of the electronic sunshade.
Jam protection function

If an object is detected between the electronic sunshade and the frame while the electronic
sunshade is closing, travel is stopped and the electronic sunshade opens slightly.
When the jam protection function has operated, even if the

side of the switch is

pressed again, the electronic sunshade will not move in the close direction until the reverse
operation has stopped completely.
Depending on the driving conditions and the surroundings, the electronic sunshade may
collide with something and operate in reverse.

* :

If equipped

4-3. Adjusting the temperature/environment inside the vehicle

247

Interior feat

WARNING

●

Never use any part of your body to intentionally activate the jam protection function.

●

The jam protection function may not work if something gets caught just before the
electronic sunshade fully closes.
Also, the jam protection function is not designed to operate while the moon roof
switch is being pressed.
Take care so that your fingers, etc. do not get caught.

Opening the electronic sunshade

Press the switch.

The electronic sunshade will open.
If the

switch is pressed and held, the electronic

sunshade will fully open automatically.

Closing the electronic sunshade

Press the switch.

The electronic sunshade will close.
If the

switch is pressed and held, the electronic

sunshade will fully close automatically.

*1 :

Lightly press either end of the

switch to stop the electronic sunshade while it is

operating.

*2 :

Lightly press either end of the

switch to stop the electronic sunshade while it is

operating.

4-3. Adjusting the temperature/environment inside the vehicle

248

Illuminating the interior

Using the interior lights

Location of the interior lights

Rear interior light

Front interior light

Personal lights

Door trim ornament lights

Inside door handle lights

Door courtesy lights

Center console light

**1

Outer foot lights

Footwell lights

●

When the engine switch is in ON, the door trim ornament lights, inside door handle
lights, center console light, footwell lights will turn on. However, if the instrument
panel light control switch is turned to minimum, the footwell lights will turn off.

●

When the shift position is in a position other than P, the brightness of the door trim
ornament lights, inside door handle lights, center console light, footwell lights will
reduce intensity.

* :

If equipped

4-4. Illuminating the interior

249

Interior feat

INFORMATION

■

Each lights automatic on/off

●

Illuminated entry system: The lights automatically turn on/off according to engine
switch mode, the presence of the electronic key, whether the doors are locked/un-
locked, and whether the doors are opened/closed.

●

If the interior lights remain on when the engine switch is turned off, the lights will go off
automatically after 20 minutes.

■

Automatic illumination of the interior lights

If any of the SRS airbags deploy (inflate) or in the event of a strong rear impact, the
interior lights will turn on automatically. The interior lights will turn off automatically after
approximately 20 minutes.
The interior lights can be turned off manually. However, in order to help prevent further
collisions, it is recommended that they be left on until safety can be ensured. (The interior
lights may not turn on automatically depending on the force of the impact and conditions
of the collision.)

■

Using the voice control system

The following operations can be performed using the voice control system:

●

Turning interior light on/off

●

Changing color of each lights

For details, refer to the"Multimedia owner's manual".

NOTICE

■

Removing light lenses

Never remove the lens for the front interior light and personal lights. Otherwise, the lights
will be damaged. If the lens need to remove, contact any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer.

■

To prevent battery discharge

Do not leave the lights on longer than necessary when the engine is off.

Related Links

Customizable features(P. 650)

*1 :

The illumination color can also be changed.

Refer to the "Multimedia owner's manual"

to change the settings.

4-4. Illuminating the interior

250

Interior lights

INFORMATION

■

The front interior lights may not operate normally when

The front interior lights may not operate normally in the following situations:

●

When water, dirt, etc., have adhered to the lens surface

●

When operated with a wet hand

●

When wearing gloves, etc.

Turning the interior lights on/off

Touch the light.

The front interior light will turn on/off each time it is
touched.
The rear interior light will also turn on/off.
However, when the rear interior light has already been
turned on, it will not be controlled by front interior light
operations.

Linking the opening/closing of the doors to the front interior light operation

Press the

switch.

The link between the front interior light operation and
doors will change between ON/OFF each time the

switch is pressed.

The operation of the rear interior lights will also be
linked to the opening/closing of the doors.

When the door link is turned on, the indicator

will

illuminate.

Turning the rear interior light on/off

Press the

switch.

The rear interior light will turn on/off each time the

switch is pressed.

Operation of the rear interior light is linked to the
turning on/off of the front interior light.

4-4. Illuminating the interior

251

Interior feat

When the rear interior light has been turned on by front interior light operation, the rear
interior light cannot be turned off by pressing the switch.

Personal lights

INFORMATION

■

The personal lights may not operate normally when

The personal lights may not operate normally in the following situations:

●

When water, dirt, etc., have adhered to the lens surface

●

When operated with a wet hand

●

When wearing gloves, etc.

Using the personal lights

Touch the light.

The personal lights will turn on/off each time they are
touched.

4-4. Illuminating the interior

252

Using the interior features

Location of the storage features

WARNING

Do not leave eyeglasses, lighters or spray cans in the storage spaces, as the following
may occur when cabin temperature becomes high:

●

Eyeglasses may be deformed by heat or cracked if they come into contact with other
stored items.

●

Lighters or spray cans may explode. If they come into contact with other stored items,
a lighter may catch fire or a spray can may release gas, causing a fire hazard.

Glove box

Auxiliary boxes

Card holders

Bottle holders

Console box

Cup holders

Coin box

INFORMATION

■

Glove box light and console box light

The glove box light and the console box light turn on when the tail lights are on.

4-5. Using the interior features

253

Interior feat

Using the auxiliary boxes

Press in the lid.

WARNING

●

Do not store items heavier than 200 g (0.44 lb.). Doing so may cause the auxiliary
box to open and the items inside may fall out, resulting in an accident.

●

When driving or when the auxiliary box is not in use, keep the lid closed. In the event of
sudden braking or sudden swerving, an accident may occur due to an occupant being
struck by the items stored inside.

Push the lid.

To close, press in and release the lid.

WARNING

▶

Type A

▶

Type B

4-5. Using the interior features

254

Location of the card holders

Using the glove box

WARNING

When driving or when the glove box is not in use, keep it closed.
If left open, in the event of sudden braking or swerving, the front passenger may strike the
glove box lid or stowed items may fly out, possibly leading to an accident.

To open the glove box, pull the lever. The glove box can be locked and unlocked
using the mechanical key.

To open the glove box, pull the lever.

Lock with the mechanical key.

Unlock with the mechanical key.

INFORMATION

■

Glove box light

The glove box light turns on when the tail lights are on.

Use the cup holders

WARNING

Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or sudden
braking, causing injury.
If possible, cover hot drinks to prevent burns.

4-5. Using the interior features

255

Interior feat

▶

Front

▶

Rear

Pull down the armrest.

Locations of the bottle holders

NOTICE

When using a bottle holder, observe the following precautions.

●

Do not place open bottles, glass cups, or paper cups containing liquid in the bottle
holders.
The liquid may spill out and glass cups may break.

●

When storing a bottle, close the cap.

▶

Front

4-5. Using the interior features

256

INFORMATION

■

Bottle holders

A bottle may not be able to be stored depending on its size or shape.

Using the console box

WARNING

When driving or when the console box is not in use, keep it closed.
If left open, in the event of sudden braking or swerving, an occupant may strike the
console box lid or stowed items may fly out, possibly leading to an accident.

To open the console box, lift the lid while pushing the button.

The console box can be opened from either side.

INFORMATION

■

Console box light

The console box light turns on when the tail lights are on.

▶

Rear

4-5. Using the interior features

257

Interior feat

Convenient interior features

Function and operation of the USB charging port

NOTICE

■

To prevent damage to the USB charging ports

●

Do not insert foreign objects into the ports.

●

Do not spill water or other liquids into the ports.

●

Rear console: When the USB charging ports are not in use, close the lids. If a foreign
object or liquid enters a port may cause a short circuit.

●

Do not apply excessive force to or impact the USB charging ports.

●

Do not disassemble or modify the USB charging ports.

■

To prevent damage to external devices

●

Do not leave external devices in the vehicle. The temperature inside the vehicle may
become high, resulting in damage to an external device.

●

Do not push down on or apply unnecessary force to an external device or the cable of
an external device while it is connected.

■

To prevent battery discharge

Do not use the USB charging ports for a long period of time with the engine stopped.

The USB charging ports are used to supply 3.0 A of electricity at 5 V to external
devices.
The USB charging ports are for charging only. They are not designed for data
transfer or other purposes.
Depending on the external device, it may not charge properly. Refer to the manual
included with the device before using a USB charging port.

INFORMATION

■

The USB charging ports can be used when

The engine switch is in ACC or ON mode.

■

Situations in which the USB charging ports may not operate correctly

●

If a device which consumes more than 3.0 A at 5 V is connected.

●

If a device designed to communicate with a personal computer, such as a USB
memory device, is connected

●

If the connected external device is turned off (depending on device)

4-5. Using the interior features

259

Interior feat

●

If the temperature inside the vehicle is high, such as after the vehicle has been parked
in the sun

■

About connected external devices

Depending on the connected external device, charging may occasionally be suspended
and then start again. This is not a malfunction.

Use the USB charging port

▶

Instrument panel

▶

On the rear console

Open the lid.

Function and operation of the power outlet (12 VDC)

NOTICE

■

To prevent damage to the power outlet (12 VDC)

●

Do not insert foreign objects into the ports.

●

Do not spill water or other liquids into the ports.

●

When the power outlets (12 VDC) are not in use, close the lids. If a foreign object or
liquid enters a port may cause a short circuit.

●

Do not apply excessive force to or impact the power outlets (12 VDC) ports.

4-5. Using the interior features

260

NOTICE

■

To prevent battery discharge

Do not use the power outlets (12 VDC) for a long period of time with the engine stopped.

The power outlet can be used to supply power for devices which operate on 12
VDC at less than 10A (power consumption of 120 W).

When connecting multiple devices, make sure that the total power consumption of all the
connected devices is less than 120 W.

INFORMATION

■

The power outlet can be used when

The engine switch is in ACC or ON.

■

When turning the engine switch off

Disconnect electrical devices with charging functions, such as mobile battery packs.
If such devices are left connected, the engine switch may not be turned off normally.

Using the accessory sockets (12 VDC)

▶

On the instrument panel (left-hand drive vehicles)

▶

On the rear console

Open the lid.

4-5. Using the interior features

261

Interior feat

▶

In the luggage compartment

Open the lid.

Function and operation of the wireless charger

A portable device, such as a smartphone or mobile battery, can be charged by
just placing it on the charging area, provided the device is compatible with the Qi
wireless charging standard created by the Wireless Power Consortium.

WARNING

■

Caution while driving

When charging a portable device while driving, for safety reasons, the driver should not
operate the portable device.

■

Precautions for when driving

Do not charge small, lightweight portable devices, such as wireless earbuds, while driv-
ing. Lightweight devices may fly off of the charging tray, possibly leading to an accident.

■

Caution regarding interference with electronic devices

People with implantable cardiac pacemakers, cardiac resynchronization therapy pace-
makers or implantable cardioverter defibrillators, as well as any other electrical medical
device, should consult their physician about the usage of the wireless charger.
Operations of the wireless charger may have an affect on medical devices.

■

To prevent damage or burns

Observe the following precautions.

●

Do not put any metallic objects between the charging area and the portable device
while charging.

●

Do not attach metallic objects, such as aluminum stickers, to the charging area.

●

Do not charge portable devices with aluminum stickers or other metallic objects
attached to the side which touches the charging area.

●

Do not store items on the wireless charger instead of in an auxiliary box.

4-5. Using the interior features

262

WARNING

●

Do not apply force or impact to the wireless charger.

●

Do not disassemble, modify or remove the wireless charger.

●

Do not attempt to charge portable devices which are not compatible with the Qi
wireless charging standard.

●

Do not allow magnetic objects to come near the wireless charge

●

Do not perform charging if the charging area is dirty

●

When not using the wireless charger, to prevent foreign matter or liquids from con-
tacting it, make sure to close the lid.

●

Do not cover the wireless charger with a cloth or other object while charging.

NOTICE

■

Preventing malfunction and corruption of data

●

Do not bring magnetic cards, such as credit cards, or magnetic recording media, etc.,
close to the charger while charging, otherwise, data may be erased.
Additionally, do not bring precision instruments such as wrist watches, close to the
wireless charger, as such objects may malfunction.

●

Do not perform charging with a contactless smart card, such as a credit card, between
the charging surface of a portable device and the charging area. The IC chip in the
card may become extremely hot, possibly damaging the portable device or smart
card.Failure to do so may result in the possibility of fire, equipment failure or damage,
or burns due to heat.
Be extra careful to not charge a portable device with a case or cover which a
contactless smart card can be inserted.

●

Do not leave portable devices in the vehicle. The temperature inside the vehicle may
become high, when in direct sunlight, possibly damaging the device.

■

To prevent battery discharge

When the engine is stopped, do not use the wireless charger for longer than necessary.

INFORMATION

■

The wireless charger can be operated when

The engine switch is in ACC or ON.

■

About connected portable devices

4-5. Using the interior features

263

Interior feat

●

Portable devices compatible with the Qi wireless charging standard can be charged
by the wireless charger. However, compatibility with all devices which meet the Qi
wireless charging standard is not guaranteed.

●

The wireless charger is designed to supply low power electricity (5 W or less) to a
cellular phone, smartphone, or other portable device.

●

Failure to do so may result in the possibility of fire,However, portable devices, such as
the following, can be charged with more than 5 W.

•

7.5 W charging compatible iPhones can be charged at 7.5 W or less.

•

Portable devices which conform to WPC Ver 1.2.4

（

Extended Power profile

）

can be charged at 10 W or less.

■

Using the smart entry & start system

During charging, when the smart entry & start system searches for an electronic key,
charging may be temporarily suspended.

■

If a cover or accessory is attached to the portable device

Do not charge a portable device if a cover or accessory which is not Qi compatible is
attached.
Even if a device is “Qi” compatible, charging may not be possible if a cover or accessories
are attached. (

→

P.266

）

■

Charging precautions

While charging, the wireless charger and the portable device will become warm. This is
not a malfunction.
If a portable device becomes warm while charging and charging stops due to the
protection function of the portable device, wait until the portable device cools down and
charge it again.
Also, to decrease the temperature inside the wireless charger, a fan may operate. This
does not indicate a malfunction.

■

Sound generated during operation

Operation sounds may be heard when the engine switch is pressed to change to ACC or
ON, or when a portable device is being detected. This does not indicate a malfunction.

■

“Qi” symbol

The “Qi” logo is a trademark of the Wireless Power Consortium.

4-5. Using the interior features

264

Names of the parts of the wireless charger

Operation indicator light

Charging area

Charging tray

Use the wireless charger

●

Place a portable device on the charging tray.

Depending on the portable device, its charging coil
may not be in the center of the device. In this case,
place the portable device so that its charging coil is
centered in the charging area.
While charging, the operation indicator light on the
charging tray (orange) will be illuminated.
If charging does not begin, move the portable de-
vice as close to the center of the charging area as possible.
When charging is complete, the operation indicator light on the charging tray (green)
will illuminate.

INFORMATION

■

Recharging function

●

If a certain amount of time has elapsed since charging completed and the portable
device has not been moved, the wireless charger will restart charging.

●

If a portable device is moved significantly within the charging area, the charging coil
may disconnect and charging may temporarily be stopped. However, if a charging
coil is detected within the charging area, the charging coil inside the wireless
charger will move near the other coil and charging will resume.

■

Rapid charging function

Portable devices, such as the following, can be rapidly charged.

●

Rapid charging capable devices which conform to WPC Ver1.2.4 EPP

（

Extended

Power profile)

4-5. Using the interior features

265

Interior feat

●

7.5 W charging capable iPhones (iPhone 8 and later)

■

Situations in which the wireless charger may not operate correctly

In the following situations, the wireless charger may not operate correctly:

●

When a portable device is fully charged

●

When a portable device is being charged by a wired connection.

●

When there is foreign matter between the charging area and portable device

●

When the temperature of a portable device becomes high while charging

●

When the temperature near the charging tray is 35°C (95°F) or more due to being
in direct sunlight, etc.

●

When a portable device is placed with its charging surface facing up

●

When a portable device is not centered on the charging area

●

When a portable device is larger than the charging tray

●

When a foldable portable device is placed outside of the charging area

●

When the vehicle is near a TV tower, electric power plant, fuel station, radio station,
large display, airport, or other facility that generates strong radio waves or electrical
noise

●

When the any of the following objects are between or attached to a portable device
and cause a gap of 2 mm (0.08 in.) or more between the charging surface of a
portable device and the charging area:

•

Thick cases or covers

•

Thick decorations

•

Cases or covers which the charging surface is not flat, but is grooved or changes
in thickness

•

Accessories, such as finger rings, straps, etc.

●

When the portable device is in contact with, or is covered by any of the following
metallic objects:

•

Cards covered with metal, such as aluminum foil

•

Cigarette boxes that have aluminum foil inside

•

Metallic wallets or bags

•

Coins

•

Heat packs

•

Recorded media such as CDs and DVDs

•

Metallic decorations

•

Metallic cases or covers

4-5. Using the interior features

266

●

When wireless keys (that emit radio waves) other than those of your vehicle are
being used nearby

●

When 2 or more portable devices are placed on the charging tray at the same time

In situations other than above, if the wireless charger does not operate properly
or the operation indicator light blinks continuously, the wireless charger may be
malfunctioning.
Contact any authorized Lexus retailer or Lexus authorized repairer, or any reliable
repairer.

Wireless charger operation indicator light status

The operation indicator light of the wireless charger indicates the operating state
of the wireless charger as follows:

Operation indicator light

State

Charging tray

Center dis-

play

Off

The Wireless charger is off

Green (illumi-

nated)

Gray

Standby (charging is possible)

(1)

Charging is complete

(2)

Orange (illu-

minated)

Blue

A portable device has been placed on the charging area
(identifying the portable device)

A portable device, such as the following, is being rapidly
charged

●

Rapid charging capable devices which conform to
WPC Ver 1.2.4.

●

7.5 W charging capable iPhone (iPhone 8 and later)

(1)

While in standby, charging power is not output. If a metal object is placed on the

charging tray in this state, the object will not heat up.

(2)

Depending on the portable device, the operation indicator light may stay illuminated

(orange) after charging has completed.

Using the armrest

NOTICE

Do not apply excessive load to the armrest. Doing so may damage the armrest.

4-5. Using the interior features

267

Interior feat

●

Fold down the armrest for use.

Assist grip functions and operation

WARNING

Do not use the assist grip when getting in or out of the vehicle or rising from your seat.

NOTICE

Do not hang any heavy object or put a heavy load on the assist grip.

An assist grip installed on the ceiling can be used
to support your body while sitting on the seat.

Locations of coat hooks

WARNING

Do not hang coat hangers or other hard or sharp objects on the hook. If the SRS curtain
shield airbags deploy, these items may become projectiles, causing death or serious
injury.

The coat hooks are provided with the rear assist
grips.

4-5. Using the interior features

268

Using the vanity mirrors

●

Slide the cover to open.

The vanity light turns on when the cover is opened.

NOTICE

Do not leave the vanity lights on longer than necessary with the engine stopped. Doing
so may lead to the battery becoming discharged.

INFORMATION

■

Automatic light off function

When the engine switch is off, if the vanity lights are turned on, they will be turned off
automatically after 20 minutes.

4-5. Using the interior features

269

Interior feat

Deck board

Opening the deck board

WARNING

If a deck board has been opened or removed, return it to its original position before
driving. Otherwise, in the event of sudden braking or an accident, a deck board or stored
items may fly out and strike an occupant.

Open the back door.

Open the deck board.

▶

Pattern A

▶

Pattern B

4-6. Using the luggage compartment

273

Interior feat

Stowing the luggage cover

Unhook each cord.

Pull the lever upwards and fold the deck
board.

Remove the luggage cover.

If a rear seat seatback is reclined, remove the
luggage cover after moving the seatback to the
upright position.

Fold the luggage cover.

4-6. Using the luggage compartment

275

Interior feat

Lexus NX (2023 year). Manual in english - page 8
