1-1. For safe use



Adjust the position of the seatback.
Sit up straight and well back in the
seat.



Do not twist the seat belt.

■

Child seat belt usage

The seat belts of your vehicle were princi-

pally designed for persons of adult size.

●

Use a child restraint system appropriate

for the child, until the child becomes large

enough to properly wear the vehicle’s

seat belt. (



P.53)

●

When the child becomes large enough to

properly wear the vehicle’s seat belt, fol-

low the instructions regarding seat belt

usage.

■

Seat belt regulations

If seat belt regulations exist in the country

where you reside, please contact any

authorized Lexus retailer or Lexus autho-

rized repairer, or any reliable repairer for

seat belt replacement or installation.

■

Rear seat belt

Use the seat belt after passing it through the

guide if the seat belt comes free from the

guide.

To fasten the seat belt, push the
plate into the buckle until a click
sound is heard.

To release the seat belt, press the
release button

■

Emergency locking retractor (ELR)

The retractor will lock the belt during a sud-

den stop or on impact. It may also lock if you

lean forward too quickly. A slow, easy

motion will allow the belt to extend so that

you can move around fully.

Push the seat belt shoulder anchor
down while pressing the release
button .

Fastening and releasing the seat
belt

Adjusting the seat belt shoulder
anchor height (front seats)

1-1. For safe use

For
sa

d s

uri

Push the seat belt shoulder anchor
up while pressing the release but-
ton .

Move the height adjuster up and down as
needed until you hear a click.

The pretensioners help the seat belts to
quickly restrain the occupants by
retracting the seat belts when the vehi-
cle is subjected to certain types of
severe frontal or side collision.

The pretensioners do not activate in the
event of a minor frontal impact, a minor
side impact, a rear impact or a vehicle roll-
over.

■

Replacing the belt after the preten-

sioner has been activated

If the vehicle is involved in multiple colli-

sions, the pretensioner will activate for the

first collision, but will not activate for the

second or subsequent collisions.

■

PCS-linked seat belt pretensioner con-

trol (vehicles with Lexus Safety System

If the PCS (Pre-Collision System) deter-

mines that the possibility of a collision with a

vehicle is high, the seat belt pretensioners

will be prepared to operate.

WARNING

■

Adjustable shoulder anchor

Always make sure the shoulder belt is

positioned across the center of your

shoulder. The belt should be kept away

from your neck, but not falling off your

shoulder. Failure to do so could reduce

the amount of protection in an accident

and cause death or serious injuries in the

event of a sudden stop, sudden swerve

or accident.

Seat belt pretensioners (front
and outboard rear seats)

WARNING

■

Seat belt pretensioners

If the pretensioner has activated, the SRS

warning light will come on. In that case,

the seat belt cannot be used again and

must be replaced at any authorized

Lexus retailer or Lexus authorized

repairer, or any reliable repairer. Failure

to do so may cause death or serious

injury.

1-1. For safe use

■

Location of the SRS airbags



SRS front airbags

SRS driver airbag/front passenger airbag
Can help protect the head and chest of the driver and front passenger from
impact with interior components

SRS knee airbags
Can help provide driver and front passenger protection



SRS side and curtain shield airbags

SRS front side airbags
Can help protect the torso of the front seat occupants

SRS rear side airbags
Can help protect the torso of occupants in the rear outer seats

SRS airbags

The SRS airbags inflate when the vehicle is subjected to certain types of
severe impacts that may cause significant injury to the occupants. They work
together with the seat belts to help reduce the risk of death or serious injury.

SRS airbag system

1-1. For safe use

For
sa

d s

uri

SRS curtain shield airbags
Can help protect primarily the head of occupants in the outer seats

■

SRS airbag system components

Airbag manual on-off switch

Knee airbags

Front passenger airbag

Curtain shield airbags

Side impact sensors (front door)

Seat belt pretensioners and force limiters

Side impact sensors (front)

Front side airbags

Rear side airbags

Driver airbag

SRS warning light

Driver’s seat position sensor

Driver’s seat belt buckle switch

A
B
C
D

E
F

1-1. For safe use

Airbag sensor assembly

“PASSENGER AIR BAG” indicator lights

Front passenger’s seat belt buckle switch

Front impact sensors

The main SRS airbag system components are shown above. The SRS airbag sys-
tem is controlled by the airbag sensor assembly. As the airbags deploy, a chemical
reaction in the inflators quickly fills the airbags with non-toxic gas to help restrain
the motion of the occupants.

■

If the SRS airbags deploy (inflate)

●

Slight abrasions, burns, bruising etc., may

be sustained from SRS airbags, due to the

extremely high speed deployment (infla-

tion) by hot gases.

●

A loud noise and white powder will be

emitted.

●

Parts of the airbag module (steering

wheel hub, airbag cover and inflator) as

well as the front seats, parts of the front

and rear pillars, and roof side rails, may

be hot for several minutes. The airbag

itself may also be hot.

●

The windshield may crack.

●

The hybrid system will be stopped and

fuel supply to the engine will be stopped.

(



P.85)

●

All of the doors will be unlocked.

(



P.129)

●

The brakes and stop lights will be con-

trolled automatically. (



P.305)

●

The interior lights will turn on automati-

cally. (



P.331)

●

The emergency flashers will turn on auto-

matically. (



P.396)

●

Vehicles with eCall: If any of the following

situations occur, the system is designed

to send an emergency call to the eCall

control center, notifying them of the vehi-

cle’s location (without needing to push

the “SOS” button) and an agent will

attempt to speak with the occupants to

ascertain the level of emergency and

assistance required. If the occupants are

unable to communicate, the agent auto-

matically treats the call as an emergency

and helps to dispatch the necessary

emergency services. (



P.69)

• An SRS airbag is deployed.

• A seat belt pretensioner is activated.

• The vehicle is involved in a severe rear-

end collision.

■

SRS airbag deployment conditions (SRS

front airbags)

●

The SRS front airbags will deploy in the

event of an impact that exceeds the set

threshold level (the level of force corre-

sponding to an approximately 20 - 30

km/h [12 - 18 mph] frontal collision with a

fixed wall that does not move or deform).

However, this threshold velocity will be

considerably higher in the following situ-

ations:

• If the vehicle strikes an object, such as a

parked vehicle or sign pole, which can

move or deform on impact

• If the vehicle is involved in an underride

collision, such as a collision in which the

front of the vehicle “underrides”, or goes

under, the bed of a truck

●

Depending on the type of collision, it is

possible that only the seat belt preten-

sioners will activate.

■

SRS airbag deployment conditions (SRS

side and curtain shield airbags)

●

The SRS side and curtain shield airbags

will deploy in the event of an impact that

exceeds the set threshold level (the level

of force corresponding to the impact

force produced by an approximately

1500 kg [3300 lb.] vehicle colliding with

N
O

1-1. For safe use

For
sa

d s

uri

the vehicle cabin from a direction per-

pendicular to the vehicle orientation at an

approximate speed of 20 - 30 km/h [12 -

18 mph]).

●

Both SRS curtain shield airbags will

deploy in the event of a side collision on

either side.

●

Both SRS curtain shield airbags may also

deploy in the event of a severe frontal

collision.

■

Conditions under which the SRS air-

bags may deploy (inflate), other than a

collision

The SRS front airbags and SRS curtain

shield airbags may also deploy if a serious

impact occurs to the underside of your

vehicle. Some examples are shown in the

illustration.

●

Hitting a curb, edge of pavement or hard

surface

●

Falling into or jumping over a deep hole

●

Landing hard or falling

■

Types of collisions that may not deploy

the SRS airbags (SRS front airbags)

The SRS front airbags do not generally

inflate if the vehicle is involved in a side or

rear collision, if it rolls over, or if it is involved

in a low-speed frontal collision. But, when-

ever a collision of any type causes sufficient

forward deceleration of the vehicle, deploy-

ment of the SRS front airbags may occur.

●

Collision from the side

●

Collision from the rear

●

Vehicle rollover

■

Types of collisions that may not deploy

the SRS airbags (SRS side and curtain

shield airbags)

The SRS side and curtain shield airbags

may not activate if the vehicle is subjected

to a collision from the side at certain angles,

or a collision to the side of the vehicle body

other than the passenger compartment.

●

Collision from the side to the vehicle

body other than the passenger compart-

ment

●

Collision from the side at an angle

The SRS side airbags do not generally

inflate if the vehicle is involved in a frontal or

rear collision, if it rolls over, or if it is involved

in a low-speed side collision.

●

Collision from the front

●

Collision from the rear

●

Vehicle rollover

The SRS curtain shield airbags do not gen-

erally inflate if the vehicle is involved in a

rear collision, if it rolls over, or if it is involved

1-1. For safe use

in a low-speed side or low-speed frontal

collision.

●

Collision from the rear

●

Vehicle rollover

■

When to contact any authorized Lexus

retailer or Lexus authorized repairer, or

any reliable repairer

In the following cases, the vehicle will

require inspection and/or repair. Contact

any authorized Lexus retailer or Lexus

authorized repairer, or any reliable repairer

as soon as possible.

●

Any of the SRS airbags have been

inflated.

●

The front of the vehicle is damaged or

deformed, or was involved in an accident

that was not severe enough to cause the

SRS front airbags to inflate.

●

A portion of a door or its surrounding

area is damaged, deformed or has had a

hole made in it, or the vehicle was

involved in an accident that was not

severe enough to cause the SRS side and

curtain shield airbags to inflate.

●

The pad section of the steering wheel,

dashboard near the front passenger air-

bag or lower portion of the instrument

panel is scratched, cracked, or otherwise

damaged.

●

The surface of the seats with the SRS side

airbag is scratched, cracked, or other-

wise damaged.

●

The portion of the front pillars, rear pillars

or roof side rail garnishes (padding) con-

taining the SRS curtain shield airbags

inside is scratched, cracked, or otherwise

damaged.

1-1. For safe use

For
sa

d s

uri

WARNING

■

SRS airbag precautions

Observe the following precautions

regarding the SRS airbags.

Failure to do so may cause death or seri-

ous injury.

●

The driver and all passengers in the

vehicle must wear their seat belts

properly.

The SRS airbags are supplemental

devices to be used with the seat belts.

●

The SRS driver airbag deploys with

considerable force, and can cause

death or serious injury especially if the

driver is very close to the airbag.

Since the risk zone for the driver’s air-

bag is the first 50 - 75 mm (2 - 3 in.) of

inflation, placing yourself 250 mm (10

in.) from your driver airbag provides

you with a clear margin of safety. This

distance is measured from the center

of the steering wheel to your breast-

bone. If you sit less than 250 mm (10

in.) away now, you can change your

driving position in several ways:

• Move your seat to the rear as far as

you can while still reaching the pedals

comfortably.

• Slightly recline the back of the seat.

Although vehicle designs vary, many

drivers can achieve the 250 mm (10

in.) distance, even with the driver seat

all the way forward, simply by reclining

the back of the seat somewhat. If

reclining the back of your seat makes it

hard to see the road, raise yourself by

using a firm, non-slippery cushion, or

raise the seat if your vehicle has that

feature.

• If your steering wheel is adjustable, tilt

it downward. This points the airbag

toward your chest instead of your

head and neck.

The seat should be adjusted as recom-
mended above, while still maintaining
control of the foot pedals, steering wheel,
and your view of the instrument panel
controls.

●

The SRS front passenger airbag also

deploys with considerable force, and

can cause death or serious injury

especially if the front passenger is very

close to the airbag. The front passen-

ger seat should be as far from the air-

bag as possible with the seatback

adjusted, so the front passenger sits

upright.

1-1. For safe use

WARNING

●

Improperly seated and/or restrained

infants and children can be killed or

seriously injured by a deploying air-

bag. An infant or child who is too small

to use a seat belt should be properly

secured using a child restraint system.

Lexus strongly recommends that all

infants and children be placed in the

rear seats of the vehicle and properly

restrained. The rear seats are safer for

infants and children than the front pas-

senger seat. (



P.53)

●

Do not sit on the edge of the seat or

lean against the dashboard.

●

Do not allow a child to stand in front of

the SRS front passenger airbag unit or

sit on the knees of a front passenger.

●

Do not allow the front seat occupants

to hold items on their knees.

●

Do not lean against the door, the roof

side rail or the front, side and rear pil-

lars.

●

Do not allow anyone to kneel on the

passenger seats toward the door or

put their head or hands outside the

vehicle.

●

Do not attach anything to or lean any-

thing against areas such as the dash-

board, steering wheel pad and lower

portion of the instrument panel.

These items can become projectiles

when the SRS driver, front passenger

and knee airbags deploy.

1-1. For safe use

For
sa

d s

uri

WARNING

●

Do not attach anything to areas such

as a door, windshield, side window,

front or rear pillar, roof side rail and

assist grip. (Except for the speed limit

label



P.423)

●

Do not hang coat hangers or other

hard objects on the coat hooks. All of

these items could become projectiles

and may cause death or serious injury,

should the SRS curtain shield airbags

deploy.

●

If a vinyl cover is put on the area where

the SRS knee airbag will deploy, be

sure to remove it.

●

Do not use seat accessories which

cover the parts where the SRS side air-

bags inflate as they may interfere with

inflation of the SRS airbags. Such

accessories may prevent the side air-

bags from activating correctly, disable

the system or cause the side airbags to

inflate accidentally, resulting in death

or serious injury.

●

Do not strike or apply significant levels

of force to the area of the SRS airbag

components or the front doors.

Doing so can cause the SRS airbags to

malfunction.

●

Do not touch any of the component

parts immediately after the SRS air-

bags have deployed (inflated) as they

may be hot.

●

If breathing becomes difficult after the

SRS airbags have deployed, open a

door or window to allow fresh air in, or

leave the vehicle if it is safe to do so.

Wash off any residue as soon as possi-

ble to prevent skin irritation.

●

If the areas where the SRS airbags are

stored, such as the steering wheel pad

and front and rear pillar garnishes, are

damaged or cracked, have them

replaced by any authorized Lexus

retailer or Lexus authorized repairer,

or any reliable repairer.

■

Modification and disposal of SRS air-

bag system components

Do not dispose of your vehicle or per-

form any of the following modifications

without consulting any authorized Lexus

retailer or Lexus authorized repairer, or

any reliable repairer. The SRS airbags

may malfunction or deploy (inflate) acci-

dentally, causing death or serious injury.

●

Installation, removal, disassembly and

repair of the SRS airbags

●

Repairs, modifications, removal or

replacement of the steering wheel,

instrument panel, dashboard, seats or

seat upholstery, front, side and rear pil-

lars, roof side rails, front door panels,

front door trims or front door speakers

●

Modifications to the front door panel

(such as making a hole in it)

●

Repairs or modifications of the front

fender, front bumper, or side of the

occupant compartment

●

Installation of a grille guard (bull bars,

kangaroo bar, etc.), snow plows or

winches

●

Modifications to the vehicle’s suspen-

sion system

●

Installation of electronic devices such

as RF-transmitter and CD players

1-1. For safe use

Sensors

Hood

Lifters

■

Pop Up Hood precautions

●

Before scrapping your vehicle, make

sure to contact any authorized Lexus

retailer or Lexus authorized repairer, or

any reliable repairer.

●

The Pop Up Hood system cannot be

reused once it has operated. Have it

replaced by any authorized Lexus

retailer or Lexus authorized repairer, or

any reliable repairer.

■

PCS-linked Pop Up Hood operation

control (if equipped)

If the PCS (Pre-Collision System) deter-

mines that the possibility of a collision with a

pedestrian or bicyclist is high, the Pop Up

Hood will be prepared to operate.

■

Pop Up Hood operational conditions

The Pop Up Hood will operate when the

vehicle detects an impact such as the fol-

lowing:

●

The front bumper detects a frontal

impact equivalent to or greater than that

of a pedestrian while the vehicle being

driven within the operational speed

range of approximately 25 to 55 km/h

(16 to 34 mph). (The system is operated

by an impact of threshold level or greater,

even in the case of a minor collision that

may not leave a trace on the front

bumper. Also, depending on the impact

conditions or vehicle speed, the system

may operate by a collision with a light or

small object or a small animal.)

●

In other situations such as the following,

the system may operate when an impact

is applied to the lower part of the vehicle

or front bumper:

• Colliding with a curb

• Falling into a deep hole

• Landing hard

• Hitting the slope of a parking lot, an

undulating road, a protruding object or

falling object

■

Conditions under which the Pop Up

Hood may not operate properly

●

If a pedestrian collides with the right or

left corner of the front bumper or the side

of the vehicle. As such impacts may be

difficult to detect, the system may not

operate.

●

If the vehicle speed is not detected cor-

rectly, such as if the vehicle is sliding side-

ways, the system may not operate

properly.

Pop Up Hood

In the event of a frontal collision
with a body, such as a pedestrian,
the Pop Up Hood system raises the
hood to reduce the possibility of a
serious impact to the pedestrian’s
head area by adding clearance to
the engine compartment.
When the sensors located at the
back of the front bumper detect a
frontal impact with a body, such as a
pedestrian, which meets or
exceeds the threshold level while
the vehicle is being driven within
the operational speed range, the
system operates.

System components

A
B
C

1-1. For safe use

For
sa

d s

uri

■

Conditions under which the Pop Up

Hood will not operate

The Pop Up Hood will not operate in the

following situations:

●

Colliding with a lying person

●

A frontal impact applied to the front

bumper while driving at speeds outside

of the operational speed range

●

A side impact or rear impact

●

A vehicle rollover (In some accident situ-

ations, the Pop Up Hood may operate.)

WARNING

■

When the Pop Up Hood is operated

●

Do not pull the hood lock release

lever. Doing so after the Pop Up Hood

has operated will further raise the

hood and may cause an injury. Do not

drive with the hood raised, as doing so

may block the driver’s vision, possibly

causing an accident.

●

Do not forcibly push down the hood.

As the popped up hood cannot be

lowered by hand, doing so may

deform the hood or cause an injury.

●

If the Pop Up Hood has operated,

have it replaced by any authorized

Lexus retailer or Lexus authorized

repairer, or any reliable repairer. If the

Pop Up Hood has operated, stop the

vehicle in a safe place and contact any

authorized Lexus retailer or Lexus

authorized repairer, or any reliable

repairer.

●

Do not touch the lifters immediately

after the Pop Up Hood has operated,

as the lifters may be hot and burn you.

NOTICE

■

Pop Up Hood precautions

●

Make sure to close the hood before

driving, as the system may not operate

properly if the hood is not fully closed.

●

Make sure that all 4 tires are of the

specified size and inflated to the speci-

fied tire pressure. If tires of a different

size are used, the system may not

operate properly.

●

If something has hit the area around

the front bumper, the sensors may be

damaged even if the Pop Up Hood has

not operated. Have the vehicle

inspected by any authorized Lexus

retailer or Lexus authorized repairer,

or any reliable repairer.

●

Do not remove or repair the parts or

wiring of the Pop Up Hood, as doing

so may cause accidental operation or

prevent the system from operating

properly. If repair or replacement is

necessary, contact any authorized

Lexus retailer or Lexus authorized

repairer, or any reliable repairer.

●

Do not remove such components as

the front bumper, hood or suspension,

or replace them with non-genuine

parts, as doing so may prevent the sys-

tem from operating properly.

●

Do not install anything to the front

bumper or hood, as doing so may pre-

vent the sensors from detecting an

impact correctly and prevent the sys-

tem from operating properly.

●

Do not close the hood with force or

apply load to the lifters, as doing so

may damage the lifters and prevent

the system from operating properly.

●

Do not modify the suspension, as

changes made to the vehicle height

may prevent the system from operat-

ing properly.

1-1. For safe use

Exhaust gas precautions

Harmful substance to the human
body is included in exhaust gases if
inhaled.

WARNING

Exhaust gases include harmful carbon

monoxide (CO), which is colorless and

odorless. Observe the following precau-

tions.

Failure to do so may cause exhaust gases

enter the vehicle and may lead to an

accident caused by light-headedness, or

may lead to death or a serious health

hazard.

■

Important points while driving

●

Keep the trunk lid closed.

●

If you smell exhaust gases in the vehi-

cle even when the trunk lid is closed,

open the windows and have the vehi-

cle inspected at any authorized Lexus

retailer or Lexus authorized repairer,

or any reliable repairer as soon as pos-

sible.

■

When parking

●

If the vehicle is in a poorly ventilated

area or a closed area, such as a

garage, stop the hybrid system.

●

Do not leave the vehicle with the

hybrid system on for a long time.

If such a situation cannot be avoided,

park the vehicle in an open space and

ensure that exhaust fumes do not enter

the vehicle interior.

●

Do not leave the hybrid system oper-

ating in an area with snow build-up, or

where it is snowing. If snowbanks build

up around the vehicle while the hybrid

system is operating, exhaust gases

may collect and enter the vehicle.

■

Exhaust pipe

The exhaust system needs to be checked

periodically. If there is a hole or crack

caused by corrosion, damage to a joint

or abnormal exhaust noise, be sure to

have the vehicle inspected and repaired

by any authorized Lexus retailer or Lexus

authorized repairer, or any reliable

repairer.

1-2. Child safety

For
sa

d s

uri

1-2.Child safety

“PASSENGER AIR BAG” indica-
tor

“PASSENGER AIR BAG” and “ON” indi-
cator lights turn on when the airbag system
is on, and about after 60 seconds they go
off (only when the power switch is in ON
mode).

Airbag manual on-off switch

■

“PASSENGER AIR BAG” indicator

information

If any of the following problems occur, it is

possible that there is a malfunction in the

system. Have the vehicle inspected by any

authorized Lexus retailer or Lexus autho-

rized repairer, or any reliable repairer.

●

The “OFF” indicator does not illuminate

when the airbag manual on-off switch is

set to “OFF”.

●

The indicator light does not change when

the airbag manual on-off switch is

switched to “ON” or “OFF”.

Insert the mechanical key into the cyl-
inder and rotate to the “OFF” position.

The “OFF” indicator light turns on (only
when the power switch is in ON mode).

Airbag manual on-off system

This system deactivates the front
passenger airbag and front passen-
ger knee airbag.
Only deactivate the airbags when
using a child restraint system on the
front passenger seat.

System components

Deactivating the airbags for the
front passenger

WARNING

■

When installing a child restraint sys-

tem

For safety reasons, always install a child

restraint system in a rear seat. In the

event that the rear seat cannot be used,

the front seat can be used as long as the

airbag manual on-off system is set to

“OFF”.

If the airbag manual on-off system is left

on, the strong impact of the airbag

deployment (inflation) may cause serious

injury or even death.

1-2. Child safety

WARNING

■

When a child restraint system is not

installed on the front passenger seat

Ensure that the airbag manual on-off sys-

tem is set to “ON”.

If it is left off, the airbag will not deploy in

the event of an accident, which may

result in serious injury or even death.

Riding with children

Observe the following precautions
when children are in the vehicle.
Use a child restraint system appro-
priate for the child, until the child
becomes large enough to properly
wear the vehicle’s seat belt.



It is recommended that children
sit in the rear seats to avoid acci-
dental contact with the shift lever,
wiper switch, etc.



Use the rear door child-protector
lock or the window lock switch to
avoid children opening the door
while driving or operating the
power window accidentally.
(



P.131, 174)



Do not let small children operate
equipment which may catch or
pinch body parts, such as the
power window, hood, trunk, seats
etc.

WARNING

■

When children are in the vehicle

Never leave children unattended in the

vehicle, and never allow children to have

or use the key.
Children may be able to start the vehicle

or shift the vehicle into neutral. There is

also a danger that children may injure

themselves by playing with the windows,

the moon roof or other features of the

vehicle. In addition, heat build-up or

extremely cold temperatures inside the

vehicle can be fatal to children.

1-2. Child safety

For
sa

d s

uri

Points to remember: P.53
When using a child restraint system:
P.54
Child restraint system compatibility for
each seating position: P.57
Child restraint system installation
method: P.63
• Fixed with a seat belt: P.64
• Fixed with an ISOFIX lower anchor-

age: P.66

• Using a top tether anchorage: P.67



Prioritize and observe the warnings,
as well as the laws and regulations
for child restraint systems.



Use a child restraint system until the
child becomes large enough to
properly wear the vehicle’s seat
belt.



Choose a child restraint system
appropriate to the age and size of
the child.



Note that not all child restraint sys-
tems can fit in all vehicles.
Before using or purchasing a child
restraint system, check the compati-
bility of the child restraint system
with seat positions. (



P.57)

Child restraint systems

Before installing a child restraint
system in the vehicle, there are pre-
cautions that need to be observed,
different types of child restraint sys-
tems, as well as installation meth-
ods, etc., written in this manual.



Use a child restraint system when
riding with a small child that can-
not properly use a seat belt. For
the child’s safety, install the child
restraint system to a rear seat. Be
sure to follow the installation
method that is in the operation
manual enclosed with the
restraint system.



The use of a Lexus genuine child
restraint system is recommended,
as it is safer to use in this vehicle.
Lexus genuine child restraint sys-
tems are made specifically for
Lexus vehicles. They can be pur-
chased at a Lexus dealer.

Table of contents

Points to remember

WARNING

■

When a child is riding

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

For effective protection in automobile

accidents and sudden stops, a child

must be properly restrained, using a

seat belt or child restraint system

which is correctly installed. For instal-

lation details, refer to the operation

manual enclosed with the child

restraint system. General installation

instruction is provided in this manual.

Content .. 1 2 3 4 ..
