LEXUS RX 350 L (2019 year). Manual - part 11

173

3-3. Adjusting the seats

3

Op
era
tio

n of
 ea

ch

 co

m

po

ne

nt

RX350/RX350L_U

Your preferred driving position (the position of the driver’s seat, steering wheel,
outside rear view mirrors and head-up display

*

) can be recorded and recalled

by pressing a button.
Three different driving positions can be recorded into memory.

*

: If equipped

■

Recording procedure

Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Adjust the driver’s seat, steering wheel, outside rear view mirrors and
head-up display (if equipped) to the desired positions.
While pressing the “SET” button,
or within 3 seconds after the
“SET” button is pressed, press
button “1”, “2” or “3” until the
buzzer sounds.

If the selected button has already

been preset, the previously recorded

position will be overwritten.

Driving position memory

1

2
3

4

174

3-3. Adjusting the seats

RX350/RX350L_U

■

Recall procedure

Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Press one of the buttons for the
driving position you want to recall
until the buzzer sounds.

■

To stop the position recall operation part-way through
Perform any of the following:

●

Press the “SET” button.

●

Press button “1”, “2” or “3”.

●

Operate any of the seat adjustment switches (only cancels seat position recall).

●

Operate the tilt and telescopic steering control switch (only cancels steering wheel

position recall).

■

Seat positions that can be memorized (

P. 156)

The adjusted positions other than the position adjusted by lumbar support switch can be

recorded.

■

Operating the driving position memory after turning the engine switch off
Recorded seat positions can be activated up to 180 seconds after the driver’s door is

opened and another 60 seconds after it is closed again.

■

In order to correctly use the driving position memory function
If a seat position is already in the furthest possible position and the seat is operated in the

same direction, the recorded position may be slightly different when it is recalled.

1

2

3

175

3-3. Adjusting the seats

3

Op
era
tio

n of
 ea

ch

 co

m

po

ne

nt

RX350/RX350L_U

Each electronic key can be registered to recall your preferred driving position.

■

Registering procedure
Record your driving position to button “1”, “2” or “3” before performing the
following:
Carry only the key you want to register, and then close the driver’s door.
If 2 or more keys are in the vehicle, the driving position cannot be recorded
properly.

Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Recall the driving position that you want to record.
While pressing the recalled but-
ton, press and hold the door lock
switch (either lock or unlock) until
the buzzer sounds.

If the button could not be registered,

the buzzer sounds continuously for

approximately 3 seconds.

■

Recall procedure

Make sure that the doors are locked before recalling the driving position.
Carry the electronic key that has been registered to the driving position,
and then unlock and open the driver’s door using the smart access system
with push-button start or wireless remote control.

The driving position will move to the recorded position (not including the steering

wheel and head-up display

*

). However, the seat will  move to a position slightly

behind the recorded position in order to make entering the vehicle easier.

If the driving position is in a position that has already been recorded, the seat and

outside rear view mirrors will not move.

*

:   If  equipped

Turn the engine switch to ACCESSORY mode or IGNITION ON mode,
or fasten a seat belt.

The seat, steering wheel and head-up display (if equipped) will move to the

recorded position.

Memory recall function (driver’s side only)

1

2
3

4

1

2

176

3-3. Adjusting the seats

RX350/RX350L_U

■

Cancelation procedure
Carry only the key you want to cancel and then close the driver’s door.
If 2 or more keys are in the vehicle, the driving position cannot be canceled
properly.

Turn the engine switch to IGNITION ON mode.
While pressing the “SET” button, press and hold the door lock switch
(either lock or unlock) until the buzzer sounds twice.

If it button could not be canceled, the buzzer sounds continuously for approxi-

mately 3 seconds.

■

Recalling the driving position using the memory recall function

●

Different driving positions can be registered for each electronic key. Therefore, the

driving position that is recalled may be different depending on the key being carried.

●

If a door other than the driver’s door is unlocked with the smart access system with

push-button start, the driving position cannot be recalled. In this case, press the driving

position button which has been set.

■

Customization
Some functions can be customized. (

P. 722)

WARNING

■

Seat adjustment caution
Take care during seat adjustment so that the seat does not strike the rear passenger or

squeeze your body against the steering wheel.

1

2

177

3-3. Adjusting the seats

3

Op
era
tio

n of
 ea

ch

 co

m

po

ne

nt

RX350/RX350L_U

◆

Vertical adjustment

Up

Pull the head restraints up.

Down

Push the head restraint down while

pressing the lock release button.

◆

Horizontal adjustment (if equipped)

The position of the head restraint
can be adjusted forward in 4 stages.

If the head restraint is pulled forward

from the foremost position, it will

return to the rearmost position.

Up

Pull the head restraints up.

Down

Push the head restraint down while

pressing the lock release button.

Head restraints

Head restraints are provided for all seats.

Front seats

Lock release button

1

2

Second-row seats

Lock release button

1

2

178

3-3. Adjusting the seats

RX350/RX350L_U

Up

Pull the head restraints up.

Down

Push the head restraint down while

pressing the lock release button.

■

Removing the head restraints



Front and second-row seats



Third-row seats

■

Installing the head restraints



Front and second-row seats

Third-row seats (RX350L)

Lock release button

1

2

Pull the head restraint up while pressing the lock

release button.
If the head restraint touches the ceiling, making

the removal difficult, change the seat height or

angle. (

P. 156, 157)

Pull the head restraint up while pressing the lock

release button.
If the head restraint touches the ceiling, making

the removal difficult, change the seat angle.

(

 P. 157)

Align the head restraint with the installation

holes and push it down to the lock position.
Press and hold the lock release button when

lowering the head restraint.

Lock release button

Lock release button

Lock release button

179

3-3. Adjusting the seats

3

Op
era
tio

n of
 ea

ch

 co

m

po

ne

nt

RX350/RX350L_U



Third-row seats

■

Adjusting the height of the head restraints

■

Adjusting the second-row center and third-row seat head restraints
Always raise the head restraint one level from the stowed position when using.

Align the head restraint with the installation

holes and push it down to the lock position.
Press and hold the lock release button when

lowering the head restraint.

Make sure that the head restraints are adjusted

so that the center of the head restraint is closest

to the top of your ears.

WARNING

■

Head restraint precautions
Observe the following precautions regarding the head restraints.

Failure to do so may result in death or serious injury.

●

Use the head restraints designed for each respective seat.

●

Adjust the head restraints to the correct position at all times.

●

After adjusting the head restraints, push down on them and make sure they are

locked in position.

●

Do not drive with the head restraints removed.

Lock release
button

180

RX350/RX350L_U

3-4. Adjusting the steering wheel and mirrors

Operating the switch moves the steering wheel in the following directions:

Up
Down
Toward the driver
Away from the driver

When the engine switch is turned off,
the steering wheel returns to its stowed
position by moving up and away to
enable easier driver entry and exit.

Turning the engine switch to ACCES-

SORY or IGNITION ON mode will

return the steering wheel to the original

position.

To sound the horn, press on or close to
the

mark.

Steering wheel

Adjustment procedure

1

2
3
4

Auto tilt away

Horn

181

3-4. Adjusting the steering wheel and mirrors

3

Op
era
tio

n of
 ea

ch

 co

m

po

ne

nt

RX350/RX350L_U

■

The steering wheel can be adjusted when
The engine switch is in ACCESSORY or IGNITION ON mode

*

.

*

: If the driver’s seat belt is fastened, the steering wheel can be adjusted regardless of

engine switch mode.

■

Automatic adjustment of the steering position (if equipped)
A desired steering position can be entered to memory and recalled automatically by the

driving position memory system. (

P. 172)

■

Power easy access system
The steering wheel and driver’s seat (on some models) move in accordance with engine

switch mode and the driver’s seat belt condition. (

P. 172)

■

Customization
Some functions can be customized. (

P. 722)

WARNING

Do not adjust the steering wheel while driving.

Doing so may cause the driver to mishandle the vehicle and cause an accident, result-

ing in death or serious injury.

182

3-4. Adjusting the steering wheel and mirrors

RX350/RX350L_U

The height of the rear view mirror can be adjusted to suit your driving posture.
Adjust the height of the rear view mir-
ror by moving it up and down.

Responding to the level of brightness of the headlights of vehicles behind, the
reflected light is automatically reduced.
Changing automatic anti-glare func-
tion mode
ON/OFF

When the automatic anti-glare function

is in ON mode, the indicator illuminates.

The function will set to ON mode each

time the engine switch is turned to

IGNITION ON mode.

Pressing the button turns the function to

OFF mode. (The indicator also turns

off.)

Inside rear view mirror

The rear view mirror’s position can be adjusted to enable sufficient confirma-
tion of the rear view.

Adjusting the height of rear view mirror

Auto anti-glare function

Indicator

183

3-4. Adjusting the steering wheel and mirrors

3

Op
era
tio

n of
 ea

ch

 co

m

po

ne

nt

RX350/RX350L_U

■

To prevent sensor error
To ensure that the sensors operate properly, do

not touch or cover them.

WARNING

Do not adjust the position of the mirror while driving.

Doing so may lead to mishandling of the vehicle and cause an accident, resulting in

death or serious injury.

184

3-4. Adjusting the steering wheel and mirrors

RX350/RX350L_U

To select a mirror to adjust, press the
switch.

Left
Right

Pressing the same switch again will

put the switch in neutral.

To adjust the mirror, press the switch.

Up
Right
Down
Left

Push the mirror back in the direction of
the vehicle’s rear.

Outside rear view mirrors

Adjustment procedure

1

1

2

2

1

2
3
4

Folding the mirrors (manual type)

185

3-4. Adjusting the steering wheel and mirrors

3

Op
era
tio

n of
 ea

ch

 co

m

po

ne

nt

RX350/RX350L_U

■

Using the switch
Press the switch to fold the mirrors.

Press it again to extend them to the

original position.

■

Setting automatic mode
Automatic mode allows the folding or extending of the mirrors to be linked to
locking/unlocking of the doors.
Press the “AUTO” switch to set auto-
matic mode.

The indicator will come on.
Pressing the switch once more will

return to manual mode.

When the mirror select switch is in the “L” or “R” position, the outside rear view
mirrors will automatically angle downwards when the vehicle is reversing in
order to give a better view of the ground.
To disable this function, select neither “L” nor “R” of the mirror select switch.

■

Adjusting the mirror angle when the vehicle is reversing
With the shift lever in R, adjust the mirror angle at a desired position.
The adjusted angle will be memorized and the mirror will automatically tilt to
the memorized angle whenever the shift lever is shifted to R from next time.

The memorized downward tilt position of the mirror is linked to the normal position

(angle adjusted with the shift lever in other than R). Therefore, if the normal posi-

tion is changed after adjustment, the tilt position will also change.

When the normal position is changed, readjust the angle in reversing.

Folding and extending the mirrors (power type)

Indicator

Linked mirror function when reversing

186

3-4. Adjusting the steering wheel and mirrors

RX350/RX350L_U

■

Mirror angle can be adjusted when
The engine switch is in ACCESSORY or IGNITION ON mode.

■

When disconnecting and reconnecting battery terminals (vehicles with an automatic

folding/extending mirror function)
The automatic folding/extending mirror function will return to off as default. To turn the

function on, press the switch again to select on.

■

When the mirrors are fogged up
The outside rear view mirrors can be cleared using the mirror defoggers. Turn on the

rear window defogger to turn on the outside rear view mirror defoggers. (

P. 513)

■

Automatic adjustment of the mirror angle (if equipped)
A desired mirror face angle can be entered to memory and recalled automatically by the

driving position memory. (

P. 172)

■

Auto anti-glare function (if equipped)
When the anti-glare inside rear view mirror is set to automatic mode, the outside rear

view mirrors will activate in conjunction with the anti-glare inside rear view mirror to

reduce reflected light. (

P. 182)

■

Using automatic mode in cold weather (if equipped)
When  automatic  mode  is  used  in  cold  weather,  the  door  mirror  could  freeze  up  and

automatic stowing and return may not be possible. In this case, remove any ice and snow

from the door mirror, then either operate the mirror using manual mode or move the mir-

ror by hand.

■

Customization
Some functions can be customized. (

P. 722)

WARNING

■

Important points while driving
Observe the following precautions while driving.

Failing to do so may result in loss of control of the vehicle and cause an accident, result-

ing in death or serious injury.

●

Do not adjust the mirrors while driving.

●

Do not drive with the mirrors folded.

●

Both the driver and passenger side mirrors must be extended and properly adjusted

before driving.

■

When a mirror is moving
To avoid personal injury and mirror malfunction, be careful not to get your hand caught

by the moving mirror.

■

When the mirror defoggers are operating
Do not touch the rear view mirror surfaces, as they can become very hot and burn you.

187

3

Op
era
tio

n of
 ea

ch

 co

m

po

ne

nt

RX350/RX350L_U

3-5. Opening, closing the windows and moon roof

The power windows can be opened and closed using the switches.
Operating the switch moves the windows as follows:

Closing
One-touch closing

*

Opening
One-touch opening

*

*

: To stop the window partway, operate the

switch in the opposite direction.

Press the switch down to lock the pas-
senger windows. The indicator light will
come on when the passenger windows
are locked.

Use this switch to prevent children from

accidentally opening or closing a pas-

senger window.
The passenger windows can still be

opened and closed using the driver’s

switch even if the lock switch is on.

Power windows

Opening and closing procedures

1

2
3
4

Window lock switch

Indicator

188

3-5. Opening, closing the windows and moon roof

RX350/RX350L_U

■

The power windows can be operated when
The engine switch is in IGNITION ON mode.

■

Operating the power windows after turning the engine off
The power windows can be operated for approximately 45 seconds even after the

engine switch is turned to ACCESSORY mode or turned off. They cannot, however, be

operated once either front door is opened.

■

Jam protection function
If an object becomes jammed between the window and the window frame while the win-

dow is closing, window movement is stopped and the window is opened slightly.

■

Catch protection function
If an object becomes caught between the door and window while the window is opening,

window movement is stopped.

■

When the window cannot be opened or closed
When the jam protection function or catch protection function operates unusually and

the door window cannot be opened or closed, perform the following operations with the

power window switch of that door.

●

Stop the vehicle. With the engine switch in IGNITION ON mode, within 4 seconds of

the jam protection function or catch protection function activating, continuously oper-

ate the power window switch in the one-touch closing direction or one-touch opening

direction so that the door window can be opened and closed.

●

If the door window cannot be opened and closed even when performing the above

operations, perform the following procedure for function initialization.

Turn the engine switch to IGNITION ON mode.
Pull and hold the power window switch in the one-touch closing direction and com-

pletely close the door window.
Release the power window switch for a moment, resume pulling the switch in the

one-touch closing direction, and hold it there for approximately 6 seconds or more.
Press and hold the power window switch in the one-touch opening direction. After

the door window is completely opened, continue holding the switch for an additional

1 second or more.
Release the power window switch for a moment, resume pushing the switch in the

one-touch opening direction, and hold it there for approximately 4 seconds or

more.
Pull and hold the power window switch in the one-touch closing direction again.

After the door window is completely closed, continue holding the switch for a fur-

ther 1 second or more.

If you release the switch while the window is moving, start again from the beginning.

If the window reverses and cannot be fully closed or opened, have the vehicle inspected

by your Lexus dealer.

1

2

3

4

5

6
