(Flashes or illuminates)

PCS warning light (if equipped)

Indicates a malfunction in the PCS (Pre-Collision System) or that

the system is temporarily unavailable due to the vehicle being

extremely hot/cold, or dirt around a front sensor, etc. (

P. 266,

531)

 Follow the instructions displayed on the multi-information dis-

play. (

P. 266, 5 31)

If the PCS (Pre-Collision System) or VSC (Vehicle Stability Con-

trol) system is disabled, the PCS warning light will illuminate.

 P. 266

Slip indicator

Indicates a malfunction in:

• The Multi-terrain Select;

• The Crawl Control;

• The VSC (Vehicle Stability Control) system;

• Active TRAC (Traction Control) system;

• Trailer Sway Control; or

• The hill-start assist control system

The light will flash when any of the above systems other than the

Multi-terrain Select are operating.

 Have the vehicle inspected by your Lexus dealer immediately.

Automatic headlight leveling system warning light

Indicates a malfunction in the automatic headlight leveling system

 Have the vehicle inspected by your Lexus dealer immediately.

Warning light

Warning light/Details/Actions

525

When trouble

(Flashes)

Low speed four-wheel drive indicator light

Indicates a malfunction in the four-wheel drive system if the light

continues flashing. (

P. 309)

 Have the vehicle inspected by your Lexus dealer immediately.

(Flashes)

Center differential lock indicator light

Indicates a malfunction in the four-wheel drive system if the light

continues flashing. (

P. 309)

 Have the vehicle inspected by your Lexus dealer immediately.

Open door warning light (warning buzzer)

Indicates that a door is not fully closed

 Check that all the doors are closed.

Low fuel level warning light

Indicates that remaining fuel is approximately 4.0 gal. (15.0 L,

3.3 Imp.gal.) or less

 Refuel the vehicle.

Driver’s seat belt reminder light (warning buzzer)

Warns the driver to fasten his/her seat belt.

 Fasten the seat belt.

(On the center panel)

Front passenger’s seat belt reminder light (warning buzzer)

Warns the front passenger to fasten his/her seat belt.

 Fasten the seat belt.

Master warning light

A buzzer sounds and the warning light comes on or flashes to indi-

cate that the master warning system has detected a malfunction.

 P. 531

Tire pressure warning light

Indicates that:

• Flat tire

• Natural causes

• The tire pressure warning system is malfunctioning

 Immediately stop the vehicle in a safe place.

Handling method (

P. 528)

Power steering system warning light (warning buzzer)

Indicates a malfunction in the power steering system

 Have the vehicle inspected by your Lexus dealer immediately.

(Flashes)

(U.S.A.)

(Flashes)

(Canada)

Parking brake indicator

Indicates that the parking brake is not fully engaged or released

 Operate the parking brake switch once again.

This light comes on when the parking brake is not released.

If the

light turns off after the parking brake is fully released, the system is

operating normally.

Warning light

Warning light/Details/Actions

526

: Brake system warning buzzer:

The buzzer sounds to indicate that the brake fluid level is low (with the vehicle
reached a speed of 3 mph [5 km/h]).

: Open door warning buzzer:

The open door warning buzzer sounds to alert one or more of the doors is not fully
closed (with the vehicle having reached a speed of 3mph [5 km/h]).

: Driver’s seat belt buzzer:

The driver’s seat belt buzzer sounds to alert the driver that his or her seat belt is not
fastened. Once the engine switch is turned to IGNITION ON mode, the buzzer
sounds for 6 seconds. If the vehicle reaches a speed of 12 mph (20 km/h), the buzzer
sounds once. If the seat belt is still unfastened after 24 seconds, the buzzer will sound
intermittently for 10 seconds. Then, if the seat belt is still unfastened, the buzzer will
sound in a different tone for 20 more seconds.
Front passenger’s seat belt buzzer:
The front passenger’s seat belt buzzer sounds to alert the front passenger that his or
her seat belt is not fastened. The buzzer sounds once if the vehicle reaches a speed of
12 mph (20 km/h). If the seat belt is still unfastened after 24 seconds, the buzzer will
sound intermittently for 10 seconds. Then, if the seat belt is still unfastened, the buzzer
will sound in a different tone for 20 more seconds.

: Parking brake engaged warning buzzer:

A buzzer sounds to indicate that the parking brake is still engaged (with the vehicle
having reached a speed of 3 mph [5 km/h]).

Brake system warning light

Indicates a malfunction in the electric parking brake system

 Have the vehicle inspected by your Lexus dealer immediately.

Warning light

Warning light/Details/Actions

527

When trouble

■

SRS warning light
This warning light system monitors the airbag sensor assembly, front impact sensors, side

impact sensors (rear), side impact sensors (front door), safing sensor (rear), driver’s seat

belt buckle switch, driver’s seat position sensor, front passenger’s seat belt buckle switch,

airbags, interconnecting wiring and power sources, front passenger occupant classifica-

tion system, “AIR BAG ON” and “AIR BAG OFF” indicator lights, seat belt pretensioners

and force limiters. (

P. 38)

■

Front passenger detection sensor, seat belt reminder and warning buzzer

●

If luggage is placed on the front passenger seat, the front passenger detection sensor

may cause the warning light to flash and the warning buzzer to sound even if a passen-

ger is not sitting in the seat.

●

If a cushion is placed on the seat, the sensor may not detect a passenger, and the warn-

ing light may not operate properly.

■

If the malfunction indicator lamp comes on while driving
First check the following:

●

Is the fuel tank empty?
If it is, fill the fuel tank immediately.

●

Is the fuel tank cap loose?
If it is, tighten it securely.

The light will go off after several driving trips.

If the light does not go off even after several trips, contact your Lexus dealer as soon as

possible.

■

If the low speed four-wheel drive indicator light or the center differential lock indicator

light blinks
Take the specified steps. (

P. 311)

If the brake system warning light or the malfunction indicator light also comes on, or the

low speed four-wheel drive indicator light or the center differential lock indicator light

continues to blink after taking the specified steps, there may be a malfunction in the

engine, the brake system or the four-wheel drive system. In this case, you may not be able

to transfer between “H4” and “L4” modes, and the center differential lock may not be

able to be locked or unlocked. Have the vehicle inspected by your Lexus dealer, immedi-

ately.

528

■

When the tire pressure warning light comes on
Inspect the tires to check if a tire is punctured.
If a tire is punctured:

P. 535

If none of the tires are punctured:

Turn the engine switch off then turn it to IGNITION ON mode. Check if the tire pressure

warning light comes on or flashes.



If the tire pressure warning light comes on
After the temperature of the tires has lowered sufficiently, check the inflation pressure

of each tire and adjust them to the specified level.
If the warning light does not turn off even after several minutes have elapsed, check

that the inflation pressure of each tire is at the specified level and perform initialization.

(

P. 489)

If the warning light does not turn off even after several minutes have elapsed, have the

vehicle inspected by your Lexus dealer immediately.



If the tire pressure warning light flashes for 1 minute then stay on

There may be a malfunction in the tire pressure warning system. Have the vehicle

inspected by your Lexus dealer immediately.

■

The tire pressure warning light may turn on due to natural causes
The tire pressure warning light may turn on due to natural causes such as natural air leaks

or tire inflation pressure changes caused by temperature. In this case, adjusting the tire

inflation pressure will turn off the warning light (after a few minutes).

■

When a tire is replaced with a spare tire
The spare tire is also equipped with the tire pressure warning valve and transmitter. The

tire pressure warning light will turn on if the tire inflation pressure of the spare tire is low. If

a tire goes flat, even though the flat tire is replaced with the spare tire, the tire pressure

warning light does not turn off. Replace the spare tire with the repaired tire and adjust the

proper tire inflation pressure. The tire pressure warning light will turn off after a few min-

utes.

■

Conditions that the tire pressure warning system may not function properly
P. 492

■

Changing the engine oil
Make sure to reset oil change system

■

Warning buzzer
In some cases, the buzzer may not be heard due to being in a noisy location or audio

sound.

529

When trouble

WARNING

■

If both the ABS and the brake system warning lights remain on
Stop your vehicle in a safe place immediately and contact your Lexus dealer. The vehi-

cle will become extremely unstable during braking, and the ABS system may fail, which

could cause an accident resulting in death or serious injury.

■

If the tire pressure warning light comes on
Be sure to observe the following precautions. Failure to do so could cause loss of vehi-

cle control and result in death or serious injury.

●

Stop your vehicle in a safe place as soon as possible. Adjust the tire inflation pressure

immediately.

●

If the tire pressure warning light comes on even after tire inflation pressure adjust-

ment, it is probable that you have a flat tire. Check the tires. If the tire is flat, change to

the spare tire and have the flat tire repaired by the nearest Lexus dealer.

●

Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you could lose

control of the steering wheel or the brakes.

■

If a blowout or sudden air leakage should occur
The tire pressure warning system may not activate immediately.

530

WARNING

■

Maintenance of the tires
Each tire, including the spare (if provided), should be checked monthly when cold and

inflated to the inflation pressure recommended by the vehicle manufacturer on the

vehicle placard or tire inflation pressure label (tire and load information label). (If your

vehicle has tires of a different size than the size indicated on the vehicle placard or tire

inflation pressure label [tire and load information label], you should determine the

proper tire inflation pressure for those tires.)
As an added safety feature, your vehicle has been equipped with a tire pressure moni-

toring system (TPMS-tire pressure warning system) that illuminates a low tire pressure

telltale (tire pressure warning light) when one or more of your tires is significantly

under-inflated. Accordingly, when the low tire pressure telltale (tire pressure warning

light) illuminates, you should stop and check your tires as soon as possible, and inflate

them to the proper pressure. Driving on a significantly under-inflated tire causes the

tire to overheat and can lead to tire failure. Under-inflation also reduces fuel efficiency

and tire tread life, and may affect the vehicle’s handling and stopping ability.
Please note that the TPMS (tire pressure warning system) is not a substitute for proper

tire maintenance, and it is the driver’s responsibility to maintain correct tire pressure,

even if under-inflation has not reached the level to trigger illumination of the TPMS low

tire pressure telltale (tire pressure warning light).
Your vehicle has also been equipped with a TPMS (tire pressure warning system) mal-

function indicator to indicate when the system is not operating properly. The TPMS

(tire pressure warning system) malfunction indicator is combined with the low tire pres-

sure telltale (tire pressure warning light). When the system detects a malfunction, the

telltale will flash for approximately one minute and then remain continuously illumi-

nated. This sequence will continue upon subsequent vehicle start-ups as long as the

malfunction exists. When the malfunction indicator is illuminated, the system may not

be able to detect or signal low tire pressure as intended.
TPMS (tire pressure warning system) malfunctions may occur for a variety of reasons,

including the installation of replacement or alternate tires or wheels on the vehicle that

prevent the TPMS (tire pressure warning system) from functioning properly. Always

check the TPMS (tire pressure warning system) malfunction telltale after replacing one

or more tires or wheels on your vehicle to ensure that the replacement or alternate

tires and wheels allow the TPMS (tire pressure warning system) to continue to function

properly.

NOTICE

■

To ensure the tire pressure warning system operates properly
Do not install tires with different specifications or makers, as the tire pressure warning

system may not operate properly.

531

When trouble

If a warning message is displayed

Master warning light

The master warning light also comes on

or flashes in order to indicate that a mes-

sage is currently being displayed on the

instrument cluster.

Multi-information display
Handling Method

Follow the instructions of the message

on the multi-information display.

If any of the warning messages are shown again after the following actions have
been performed, contact your Lexus dealer.

The multi-information display shows warnings of system malfunctions, incor-
rectly performed operations, and messages that indicate a need for mainte-
nance. When a message is shown, perform the correction procedure
appropriate to the message.

2
3

532

The warning lights and warning buzzers operate as follows depending on the
content of the message. If a message indicates the need for inspection by a
dealer, have the vehicle inspected by your Lexus dealer immediately.

: A buzzer sounds the first time a message is shown on the multi-information display.

■

System warning lights
The master warning light does not come on or flash in the following case. Instead, a sepa-

rate system warning light will come on along with a message or image shown on the

multi-information display.

●

Indicates that the PCS (Pre-Collision System) is not currently functional

The PCS warning light comes on. (

P. 524)

Messages and warnings

System

warning

light

Warning

buzzer

Warning

Comes on

Sounds

Indicates an important situation, such as

when a system related to driving is malfunc-

tioning or that danger may result if the cor-

rection procedure is not performed

Comes on



Sounds



Comes on

or flashes

Sounds

Indicates an important situation, such as

when the systems shown on the multi-infor-

mation display may be malfunctioning

Flashes



Sounds

Indicates a situation, such as when damage

to the vehicle or danger may result

Comes on



Does not

sound

Indicates a condition, such as malfunction of

electrical components, their condition, or

indicates the need for maintenance

Flashes



Does not

sound

Indicates a situation, such as when an opera-

tion has been performed incorrectly, or indi-

cates how to perform an operation correctly

533

When trouble

■

If “See Owner’s Manual” is shown

●

If “Smart Access System Malfunction” is shown, this may be a malfunction.

Immediately have the vehicle inspected by your Lexus dealer.

●

If “Transmission Fluid Temp High” is shown, it indicates that the automatic transmission

fluid temperature is too high.
Immediately stop the vehicle in a safe place, shift the shift lever to P and wait until the

warning message and light go off. If the warning message and light go off, you may

start the vehicle again. If the warning message and light do not go off, contact your

Lexus dealer.

■

If “Shift to P Before Exiting Vehicle” is shown
Message is displayed when the driver’s door is opened without turning the engine switch

to off with the shift lever in any position other than P.

Shift the shift lever to P.

■

If “Power Turned Off to Save Battery” is shown
Power was turned off due to the automatic power off function.

Next time when starting the engine, increase the engine speed slightly and maintain that

level for approximately 5 minutes to recharge the battery.

■

When a message that indicates the need for the shift lever operation is shown
To prevent the shift lever from being operated incorrectly or the vehicle from moving

unexpectedly, a message that requires shifting the shift lever may be shown on the multi-

information display. In that case, follow the instruction of the message and shift the shift

lever.

■

When “Headlight System Malfunction Visit Your Dealer” is displayed on the multi-

information display
The following systems may be malfunctioning. Have the vehicle inspected by your Lexus

dealer.

●

The LED headlight system

●

The automatic headlight leveling system

●

Automatic High Beam

■

If “Forward Camera System Unavailable” or “Forward Camera System Unavailable

Clean Windshield” is displayed (if equipped)
The following systems may be suspended until the problem shown in the message is

resolved. (

P. 266, 523)

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert)

●

Dynamic radar cruise control with full-speed range

●

Automatic High Beam

■

If “Engine Oil Level Low” is shown
Indicates that engine oil level is low.

Check the level of engine oil, and add if necessary.

This message may appear if the vehicle is stopped on a slope.

Move the vehicle to a level surface and check to see if the message disappears.

534

■

If a following message is shown, take appropriate action and confirm that the message

has disappeared. (

P. 313)

●

“Crawl Not Available Select L4 and Shift to [D] or [R] Position”

●

“Crawl Not Available Check System Operation Conditions”

●

“Turn Assist Function Not Available Check System Operation Conditions”

●

“Turn Assist Function Not Available Activate Crawl Control”

■

If “Maintenance Required Soon” is shown (U.S.A. only)
Indicates that all maintenance according to the driven distance on the maintenance

schedule

should be performed soon.

Comes on approximately 4500 miles (7200 km) after the message has been reset.

If necessary, perform maintenance.

: Refer to the separate “Scheduled Maintenance Guide” or “Owner’s Manual Supple-

ment” for the maintenance interval applicable to your vehicle.

■

If “Maintenance Required Visit Your Dealer” is shown (U.S.A. only)
Indicates that all maintenance is required to correspond to the driven distance on the

maintenance schedule

Comes on approximately 5000 miles (8000 km) after the message has been reset.

(The indicator will not work properly unless the message has been reset.)

Perform the necessary maintenance. Please reset the message after the maintenance is

performed (

P. 467)

: Refer to the separate “Scheduled Maintenance Guide” or “Owner’s Manual Supple-

ment” for the maintenance interval applicable to your vehicle.

■

If “Oil Maintenance Required Soon” is shown
Indicates that the engine oil is scheduled to be changed. (The indicator will not work

properly unless the message has been reset.)

Check the engine oil, and change if necessary. After changing the engine oil, the mes-

sage should be reset. (

P. 477)

■

If “Oil Maintenance Required Visit Your Dealer” is shown
Indicates that the engine oil should be changed. (The indicator will not work properly

unless the message has been reset.)

Check and change the engine oil, and oil filter by your Lexus dealer. After changing the

engine oil, the message should be reset. (

P. 477)

■

If “Visit Your Dealer” is shown
The system or part shown on the multi-information display is malfunctioning. Have the

vehicle inspected by your Lexus dealer immediately.

■

Warning buzzer
In some cases, the buzzer may not be heard due to being in a noisy location or audio

sound.

NOTICE

■

While the engine oil level warning is displayed
Continued engine operation with low engine oil will damage the engine.

535

When trouble

If you have a flat tire

●

Stop the vehicle in a safe place on a hard, flat surface.

●

Set the parking brake.

●

Shift the shift lever to “P”.

●

Turn off the 4-Wheel AHC. (

P. 301)

●

Stop the engine.

●

Turn on the emergency flashers.

Your vehicle is equipped with a spare tire. The flat tire can be replaced with
the spare tire.
For details about tires:

P. 488

WARNING

■

If you have a flat tire
Do not continue driving with a flat tire.

Driving even a short distance with a flat tire can damage the tire and the wheel beyond

repair, which could result in an accident.

Before jacking up the vehicle

Location of the spare tire, jack and tools

Jack
Spare tire

Tool box

536

WARNING

■

Using the tire jack
Improper use of the tire jack may lead to death or serious injuries due to the vehicle

suddenly falling off the jack.

●

Do not use the tire jack for any purpose other than replacing tires or installing and

removing tire chains.

●

Only use the tire jack that comes with this vehicle for replacing a flat tire.

Do not use it on other vehicles, and do not use other tire jacks for replacing tires on

this vehicle.

●

Always check that the tire jack is securely set to the jack point.

●

Be sure to turn off the 4-Wheel AHC and stop the engine.

●

Do not put any part of your body under the vehicle supported by a jack.

●

Do not start or run the engine while your vehicle is supported by the jack.

●

Do not raise the vehicle while someone is in it.

●

When raising the vehicle, do not put an object on or under the jack.

●

Do not raise the vehicle to a height greater than that required to replace the tire.

●

Use a jack stand if it is necessary to get under the vehicle.

Take particular care when lowering the vehicle to ensure that no one working on or

near the vehicle will be injured.

■

Using the jack handle
Tighten all the jack handle bolts securely using a Phillips-head screwdriver, to prevent

the extension parts from coming apart unexpectedly.

537

When trouble

Remove the cover.

Unhook the rubber band and take
out the jack.

Loosen
Tighten

Loosen and remove the jack.

Remove the cover.

Take out the tool box.

Taking out the jack

Taking out the tool box

538
