LEXUS GS F (2018 year). Manual - part 14

214

■

When the parking brake is set automatically while the system is holding the brakes
The parking brake will not be released automatically. Perform one of the following proce-

dures to release the parking brake and confirm that the parking brake indicator light

turns off. (

→P. 211)

●

With the brake pedal depressed, operate the parking brake switch.

●

Fasten your seat belt, check that the shift lever is in either D or R and slowly depress the

accelerator pedal.

■

Warning message and buzzers
Warning messages and buzzers are used to indicate a system malfunction or to inform

the driver of the need for caution. (

→P. 441)

WARNING

■

When the vehicle is on a steep incline
When using the brake hold system on a steep incline exercise caution. The brake hold

function may not hold the vehicle in such a situation.

■

When stopped on a slippery road
The system cannot stop the vehicle when the gripping ability of the tires has been

exceeded. Do not use the system when stopped on a slippery road.

NOTICE

■

When parking the vehicle
The brake hold system is not designed for use when parking the vehicle for a long

period of time. Turning the engine switch off while the system is holding the brake may

release the brake, which would cause the vehicle to move. When operating the engine

switch, depress the brake pedal, set the parking brake and shift the shift lever to P.

215

4-2. Driving procedures

iving

ASC (Active Sound Control) (GS F)

The ASC system can be operated
when the driving mode select switch is
in the following modes. (

→P. 276)

●

SPORT S mode/customized mode
(powertrain control is set to
“POWER”): Sounds are output from
the rear.

●

SPORT S+ mode: When the engine
speed is in the low-to-medium
speed range, sounds are output
from the rear. At high engine speeds,
sounds are mainly output from the
front.

Press the ASC switch.

The indicator on switch will turn off.

Press the switch again to turn the system

back on.
Even if the indicator is illuminated, when

the driving mode select switch is in Nor-

mal, Eco drive or customized mode

(powertrain control is not set to

“POWER”), ASC does not operate.

■

Automatic reactivation of ASC system
Even after the ASC system has been turned off, turning the engine off and then on again

will automatically reactivate the ASC system.

The ASC system directs certain sounds from the front and rear of the cabin to
the vehicle interior, and harmonizes these sounds with the actual sound of the
engine and exhaust in order to allow the driver to feel acceleration and the
state of the engine more strongly.

Disabling the ASC system

216

4-3. Operating the lights and wipers

Headlight switch

Turning the end of the lever turns on the lights as follows:

With the headlights on, push the
lever away from you to turn on the
high beams.

Pull the lever toward you to the center

position to turn the high beams off.

Pull the lever toward you and release
it to flash the high beams once.

You can flash the high beams with the

headlights on or off.

The headlights can be operated manually or automatically.

Operating instructions

U.S.A. Canada

The side marker, parking, tail,
license plate, instrument panel
lights, and daytime running
lights (

→P. 217) turn on.

The headlights and all lights
listed above (except daytime
running lights) turn on.
The headlights, daytime run-
ning lights (

→P. 217) and all

the lights listed above turn on
and off automatically.
(When the engine switch is in
IGNITION ON mode.)
Off

The daytime running lights
turn on. (

→P. 217)

(U.S.A.)

(Canada)

Turning on the high beam headlights

217

4-3. Operating the lights and wipers

iving

AFS (Adaptive Front-lighting System) secures excellent visibility at intersections
and on curves by automatically adjusting the direction of the light axis of the
headlights according to vehicle speed and the degree of the tire’s angle as con-
trolled by steering input.

AFS operates at speeds of 6 mph (10 km/h) or higher.

■

Deactivating AFS
Settings can be changed from

on the multi-information display

(

→P. 100).

Press

on the meter control switch and select “AFS”.

Press

on the meter control

switch and select “Off”.

The indicator turns on when the AFS

is deactivated.

■

Daytime running light system

●

The daytime running lights illuminate using the same lights as the parking lights and illu-

minate brighter than the parking lights.

●

To make your vehicle more visible to other drivers during daytime driving, the daytime

running lights turn on automatically when all of the following conditions are met. (The

daytime running lights are not designed for use at night.)
• The engine is running

• The parking brake is released
• The headlight switch is in the

(Canada only),

or “AUTO”

position

: When the surroundings are bright

The daytime running lights remain on after they illuminate, even if the parking brake is set

again.

●

For the U.S.A.: Daytime running lights can be turned off by operating the switch.

●

Compared to turning on the headlights, the daytime running light system offers greater

durability and consumes less electricity, so it can help improve fuel economy.

AFS (Adaptive Front-lighting System) (if equipped)

218

4-3. Operating the lights and wipers

■

Headlight control sensor

■

Automatic light off system

●

When the headlights are on: The headlights and tail lights turn off 30 seconds after the

engine switch is turned off and a door is opened and all of the doors and trunk are
closed. (The lights turn off immediately if

on the key is pressed twice after all the

doors are closed.)

●

When only the tail lights are on: The tail lights turn off automatically if the engine switch

is turned off and the driver’s door is opened.

To turn the lights on again, turn the engine switch to IGNITION ON mode, or turn the
light switch off once and then back to

If any of the doors or trunk lid is kept open, the lights automatically turn off after 20 min-

utes.

■

Light reminder buzzer
A buzzer sounds when the engine switch is turned off or turned to ACCESSORY mode

and the driver’s door is opened while the lights are turned on.

■

Automatic headlight leveling system
The level of the headlights is automatically adjusted according to the number of passen-

gers and the loading condition of the vehicle to ensure that the headlights do not inter-

fere with other road users.

■

If the “AFS OFF” indicator flashes
It may indicate a malfunction in the system. Contact your Lexus dealer.

■

Customization
Settings (e.g. light sensor sensitivity) can be changed.

(Customizable features:

→P. 545)

The sensor may not function properly if an

object is placed on the sensor, or anything that

blocks the sensor is affixed to the windshield.

Doing so interferes with the sensor detecting

the level of ambient light and may cause the

automatic headlight system to malfunction.

NOTICE

■

To prevent battery discharge
Do not leave the lights on longer than necessary when the engine is not running.

219

4-3. Operating the lights and wipers

iving

Automatic High Beam

∗

Push the lever away from you with
the headlight switch in the

position.

Press the Automatic High Beam
switch.

The Automatic High Beam indicator will

come on when the headlights are turned

on automatically to indicate that the sys-

tem is active.

∗

: If equipped

The Automatic High Beam uses an in-vehicle camera sensor to assess the
brightness of streetlights, the lights of vehicles ahead, etc., and automatically
turns the high beam on or off as necessary.

WARNING

■

Limitations of the Automatic High Beam
Do not rely on the Automatic High Beam. Always drive safely, taking care to observe

your surroundings and turning the high beam on or off manually if necessary.

■

To prevent incorrect operation of the Automatic High Beam system
Do not overload the vehicle.

Activating the Automatic High Beam system

220

4-3. Operating the lights and wipers

■

Switching to low beam
Pull the lever to the original position.

The Automatic High Beam indicator

will turn off.
Push the lever away from you to acti-

vate the Automatic High Beam sys-

tem again.

■

Switching to high beam
Press the Automatic High Beam
switch.

The Automatic High Beam indicator

will turn off and the high beam indi-

cator will turn on.
Press the switch to activate the Auto-

matic High Beam system again.

■

High beam automatic turning on or off conditions

●

When all of the following conditions are fulfilled, the high beam will be automatically

turned on:
• Vehicle speed is above approximately 21 mph (34 km/h).

• The area ahead of the vehicle is dark.

• There are no vehicles ahead with headlights or tail lights turned on.

• There are few streetlights on the road ahead.

●

If any of the following conditions are fulfilled, high beam will be automatically turned off:
• Vehicle speed drops below approximately 17 mph (27 km/h).

• The area ahead of the vehicle is not dark.

• Oncoming or preceding vehicles have headlights or tail lights turned on.

• There are many streetlights on the road ahead.

Turning the high beam on/off manually

221

4-3. Operating the lights and wipers

iving

■

Camera sensor detection information

●

The high beam may not be automatically turned off in the following situations:
• When oncoming vehicles suddenly appear from a curve

• When the vehicle is cut in front of by another vehicle

• When vehicles ahead are hidden from sight due to repeated curves, road dividers or

roadside trees

• When vehicles ahead appear from the faraway lane on wide road

• When vehicles ahead have no lights

●

The high beam may be turned off if a vehicle ahead that is using fog lights without using

the headlights is detected.

●

House lights, street lights, traffic signals, and illuminated billboards or signs may cause

the high beam to switch to the low beams, or the low beams to remain on.

●

The following factors may affect the amount of time taken to turn the high beam on or

off:
• The brightness of headlights, fog lights, and tail lights of vehicles ahead

• The movement and direction of vehicles ahead

• When vehicle ahead only has operational lights on one side

• When vehicle ahead is a two-wheeled vehicle

• The condition of the road (gradient, curve, condition of the road surface etc.)

• The number of passengers and amount of luggage

●

The high beam may be turned on or off when the driver does not expect it.

●

Bicycles or similar objects may not be detected.

●

In the situations shown below, the system may not be able to accurately detect sur-

rounding brightness levels. This may cause the low beams to remain on or the high

beams to cause problems for pedestrians, vehicles ahead or other parties. In these

cases, manually switch between the high and low beams.
• In bad weather (rain, snow, fog, sandstorms etc.)

• The windshield is obscured by fog, mist, ice, dirt etc.

• The windshield is cracked or damaged.

• The camera sensor is deformed or dirty.

• The camera sensor temperature is extremely high.

• Surrounding brightness levels are equal to those of headlights, tail lights or fog lights.

• Vehicles ahead have headlights that are either switched off, dirty, are changing color,

or are not aimed properly.

• When driving through an area of intermittently changing brightness and darkness.

• When frequently and repeatedly driving ascending/descending roads, or roads with

rough, bumpy or uneven surfaces (such as stone-paved roads, gravel tracks etc.).

• When frequently and repeatedly taking curves or driving on a winding road.

• There is a highly reflective object ahead of the vehicle, such as a sign or a mirror.

• The back of a vehicle ahead is highly reflective, such as a container on a truck.

• The vehicle’s headlights are damaged or dirty, or are not aimed properly.

• The vehicle is listing or tilting, due to a flat tire, a trailer being towed etc.

• The high beam and low beam are repeatedly being switched between in an abnor-

mal manner.

• The driver believes that the high beam may be causing problems or distress to other

drivers or pedestrians nearby.

222

4-3. Operating the lights and wipers

■

Temporarily lowering sensor sensitivity
The sensitivity of the sensor can be temporarily lowered.

Turn the engine switch off while the following conditions are met.

• The headlight switch is in

• The headlight switch lever is in high beam position.

• Automatic High Beam switch is on.
Turn the engine switch to IGNITION ON mode.
Within 30 seconds after , repeat pulling the headlight switch lever to the original

position then pushing it to the high beam position quickly 10 times, then leave the lever

in high beam position.
If the sensitivity is changed, the Automatic High Beam indicator is turn on and off 3

times.

Automatic High Beam (headlights) may turn on even the vehicle is stopped.

■

Warning message
Warning messages are used to indicate a system malfunction or to inform the driver of

the need for caution. (

→P. 441)

2
3

223

4-3. Operating the lights and wipers

iving

Windshield wipers and washer

Operate the lever as follows to operate the wipers. The lever will return to its
original position immediately after operation.



Intermittent windshield wipers with interval adjuster

(U.S.A.)

(Canada)

Move the lever up 2 levels

Move the lever up 1 level

(U.S.A.)

(Canada)

Move the lever down 1 level

(U.S.A.)

(Canada)

Move the lever down 2 levels

Operating the wiper lever

Off

Temporary

operation

Temporary

operation

Intermittent

operation

High speed

operation

Intermittent

operation

Off

Low speed

operation

High speed

operation

Low speed

operation

Off

Intermittent

operation

High speed

operation

High speed

operation

High speed

operation

Off

Low speed

operation

No change

Status

before

operation

Operation

224

4-3. Operating the lights and wipers

Wiper intervals can be adjusted when intermittent operation is selected.

Increases the intermittent windshield
wiper frequency
Decreases the intermittent wind-
shield wiper frequency

Washer/wiper dual operation

Wipers will automatically operate a cou-

ple of times after the washer squirts.
Vehicles with headlight cleaners:
When the headlights are on and the

lever is pulled and held, the headlight

cleaners will operate once. After this,

the headlight cleaners will operate

every 5th time the lever is pulled.



Rain-sensing windshield wipers

(U.S.A.)

(Canada)

Move the lever up 2 levels

Move the lever up 1 level

(U.S.A.)

(Canada)

Move the lever down 1 level

(U.S.A.)

(Canada)

Move the lever down 2 levels

AUTO mode on/off switch

AUTO mode
indicator

225

4-3. Operating the lights and wipers

iving

With AUTO mode selected, the wipers will operate automatically when the sensor

detects falling rain. The system automatically adjusts wiper timing in accordance with

rain volume and vehicle speed.
AUTO mode indicator will turn on when AUTO mode is selected.

: After temporary operation, the mode will return to AUTO mode.

: AUTO mode will be canceled.

When AUTO mode is selected, the sensor sensitivity can be adjusted by turning
the switch ring.

Increases the sensitivity
Decreases the sensitivity

Washer/wiper dual operation

Wipers will automatically operate a cou-

ple of times after the washer squirts.
Vehicles with headlight cleaners:
When the headlights are on and the

lever is pulled and held, the headlight

cleaners will operate once. After this,

the headlight cleaners will operate

every 5th time the lever is pulled.

Off

Temporary

operation

Temporary

operation

Low speed

operation

High speed

operation

Low speed

operation

Off

High speed

operation

High speed

operation

High speed

operation

Off

Low speed

operation

No change

AUTO

mode

Intermittent

operation

Off

Temporary

operation

Low speed

operation

High speed

operation

Continuously

No change

Operation

Status

before

operation

6
7

226

4-3. Operating the lights and wipers

The wipers can be used as intermittent windshield wipers, which operate regard-
less of vehicle speed or amount of raindrops. The intermittent windshield wiper
operation can be switched when the vehicle is stopped and the wiper is off. The
wiper operation cannot be switched during AUTO mode or while the intermit-
tent windshield wipers are operating.

Press and hold

until the AUTO

mode indicator stops flashing.

is pressed and held until the

AUTO mode indicator stops flashing

again, it will return to its previous state.

■

The windshield wiper and washer can be operated when
The engine switch is in IGNITION ON mode.

■

Dripping prevention wiper sweep
After washing and wiping operation several times, the wipers operate one more time

after a short delay to prevent dripping.
However, the last sweep will not happen while the vehicle is moving.

■

Effects of vehicle speed on wiper operation

●

Intermittent windshield wipers interval changes when the vehicle is stopped.

●

With low speed operation selected, wiper operation will be switched from low speed to

intermittent operation only when the vehicle is stationary.

■

Raindrop sensor

●

If AUTO mode is selected while the engine switch is in IGNITION ON mode, the wip-

ers will operate once to show that AUTO mode is activated.

●

If the temperature of the raindrop sensor is 185°F (85°C) or higher, or -22°F

(-30°C) or lower, automatic operation may not occur. In this case, operate the

wipers in any mode other than AUTO mode.

Switching between the intermittent windshield wipers and rain-sensing
windshield wipers (vehicles with rain-sensing windshield wipers)

●

The raindrop sensor judges the amount of

raindrops.
An optical sensor is adopted. It may not oper-

ate properly when sunlight from the rising or

setting of the sun intermittently strikes the

windshield, or if bugs etc. are present on the

windshield.

227

4-3. Operating the lights and wipers

iving

■

When the windshield wipers are in temporary operation

AUTO mode cannot be activated even if

is pressed.

■

If no windshield washer fluid sprays
Check that the washer nozzles are not blocked if there is washer fluid in the windshield

washer fluid reservoir.

WARNING

■

Caution regarding the use of windshield wipers in AUTO mode
The windshield wipers may operate unexpectedly if the sensor is touched or the wind-

shield is subject to vibration in AUTO mode. Take care that your fingers or anything

else do not become caught in the windshield wipers.

■

Caution regarding the use of washer fluid
When it is cold, do not use the washer fluid until the windshield becomes warm. The

fluid may freeze on the windshield and cause low visibility. This may lead to an accident,

resulting in death or serious injury.

NOTICE

■

When the windshield is dry
Do not use the wipers, as they may damage the windshield.

■

When there is no washer fluid spray from the nozzle
Damage to the washer fluid pump may be caused if the lever is pulled toward you and

held continually.

■

When a nozzle becomes blocked
In this case, contact your Lexus dealer.

Do not try to clear it with a pin or other object. The nozzle will be damaged.

■

When standing the windshield wipers up
Raise the wipers in line with the windshield. (

→P. 299)

Failure to do so may result in damage to the wipers and/or the hood.

228

4-4. Refueling

Opening the fuel tank cap

●

Turn the engine switch off and ensure that all the doors and windows are
closed.

●

Confirm the type of fuel.

■

Fuel types
→P. 532

■

Fuel tank opening for unleaded gasoline
To help prevent incorrect fueling, your vehicle has a fuel tank opening that only accom-

modates the special nozzle on unleaded fuel pumps.

Perform the following steps to open the fuel tank cap:

Before refueling the vehicle

WARNING

■

When refueling the vehicle
Observe the following precautions while refueling the vehicle. Failure to do so may

result in death or serious injury.

●

After exiting the vehicle and before opening the fuel door, touch an unpainted metal

surface to discharge any static electricity. It is important to discharge static electricity

before refueling because sparks resulting from static electricity can cause fuel vapors

to ignite while refueling.

●

Always hold the grips on the fuel tank cap and turn it slowly to remove it.

A whooshing sound may be heard when the fuel tank cap is loosened. Wait until the

sound cannot be heard before fully removing the cap. In hot weather, pressurized fuel

may spray out the filler neck and cause injury.

●

Do not allow anyone that has not discharged static electricity from their body to come

close to an open fuel tank.

●

Do not inhale vaporized fuel.

Fuel contains substances that are harmful if inhaled.

●

Do not smoke while refueling the vehicle.

Doing so may cause the fuel to ignite and cause a fire.

●

Do not return to the vehicle or touch any person or object that is statically charged.

This may cause static electricity to build up, resulting in a possible ignition hazard.

■

When refueling
Observe the following precautions to prevent fuel overflowing from the fuel tank:

●

Securely insert the fuel nozzle into the fuel filler neck.

●

Stop filling the tank after the fuel nozzle automatically clicks off.

●

Do not top off the fuel tank.

229

4-4. Refueling

iving

With the doors unlocked, press the
center of the rear edge of the fuel
filler door.

Push until you hear a click and take your

hand away to slightly open the fuel filler

door. Then open the door fully by hand.

Turn the fuel tank cap slowly to
remove it and put it into the holder
on the fuel filler door.

NOTICE

■

Refueling
Do not spill fuel during refueling.

Doing so may damage the vehicle, such as causing the emission control system to

operate abnormally or damaging fuel system components or the vehicle’s painted sur-

face.

Opening the fuel tank cap

Content .. 12 13 14 15 ..
