LEXUS CT200H (2017 year). Manual - part 12

187

4-4. Refueling

iving

Press the opener to open the fuel
filler door.

Turn the fuel tank cap slowly to open
and hang it on the back of the fuel
filler door.

WARNING

■

When refueling
Observe the following precautions to prevent fuel overflowing from the fuel tank:

●

Securely insert the fuel nozzle into the fuel filler neck.

●

Stop filling the tank after the fuel nozzle automatically clicks off.

●

Do not top off the fuel tank.

NOTICE

■

Refueling
Do not spill fuel during refueling.

Doing so may damage the vehicle, such as causing the emission control system to

operate abnormally or damaging fuel system components or the vehicle’s painted sur-

face.

Opening the fuel tank cap

188

4-4. Refueling

■

When the fuel filler door cannot be opened by pressing the inside switch

After refueling, turn the fuel tank cap
until you hear a click. Once the cap is
released, it will turn slightly in the oppo-
site direction.

Remove the cover inside the luggage compart-

ment and pull the lever.

Closing the fuel tank cap

WARNING

■

When replacing the fuel tank cap
Do not use anything but a genuine Lexus fuel tank cap designed for your vehicle. Doing

so may cause a fire or other incident which may result in death or serious injury.

189

4-5. Using the driving support systems

iving

Cruise control



Use the cruise control to maintain a set speed without depressing the accelera-
tor pedal.

Indicator
Display
Cruise control switch

Press the “ON-OFF” button to acti-
vate the cruise control.

Cruise control indicator will come on.
Press the button again to deactivate the

cruise control.

Accelerate or decelerate the vehicle
to the desired speed, and push the
lever down to set the speed.

“SET” will be displayed.
The vehicle speed at the moment the

lever is released becomes the set speed.



: If equipped

Summary of functions

2
3

Setting the vehicle speed

190

4-5. Using the driving support systems

To change the set speed, operate the lever until the desired set speed is obtained.

Increases the speed
Decreases the speed

Fine adjustment: Momentarily move the

lever in the desired direction.
Large adjustment: Hold the lever in the

desired direction.

The set speed will be increased or decreased as follows:
Fine adjustment: By approximately 1 mph (1.6 km/h) each time the lever is operated.
Large adjustment: The set speed can be increased or decreased continually until the

lever is released.

Pulling the lever toward you cancels
the constant speed control.

The speed setting is also canceled when

the brakes are applied.

Pushing the lever up resumes the
constant speed control.

Resuming is available when the vehicle

speed is more than approximately 25

mph (40 km/h).

Adjusting the set speed

Canceling and resuming the constant speed control

191

4-5. Using the driving support systems

iving

■

Cruise control can be set when

●

The shift position is in D.

●

Vehicle speed is above approximately 25 mph (40 km/h).

■

Accelerating after setting the vehicle speed

●

The vehicle can be accelerated normally. After acceleration, the set speed resumes.

●

Even without canceling the cruise control, the set speed can be increased by first accel-

erating the vehicle to the desired speed and then pushing the lever down to set the new

speed.

■

Automatic cruise control cancelation
Cruise control will stop maintaining the vehicle speed in any of the following situations.

●

Actual vehicle speed falls more than approximately 10 mph (16 km/h) below the preset

vehicle speed.

At this time, the memorized set speed is not retained.

●

Actual vehicle speed is below approximately 25 mph (40km/h).

●

Enhanced VSC is activated.

■

If the warning message for the cruise control is shown on the multi-information display
Press the “ON-OFF” button once to deactivate the system, and then press the button

again to reactivate the system.

If the cruise control speed cannot be set or if the cruise control cancels immediately after

being activated, there may be a malfunction in the cruise control system. Have the vehi-

cle inspected by your Lexus dealer.

WARNING

■

To avoid operating the cruise control by mistake
Switch the cruise control off using the “ON-OFF” button when not in use.

■

Situations unsuitable for cruise control
Do not use cruise control in any of the following situations.

Doing so may result in loss of control and could cause an accident resulting in death or

serious injury.

●

In heavy traffic

●

On roads with sharp bends

●

On winding roads

●

On slippery roads, such as those covered with rain, ice or snow

●

On steep hills

Vehicle speed may exceed the set speed when driving down a steep hill.

●

During emergency towing

192

4-5. Using the driving support systems

Dynamic radar cruise control



Dynamic radar cruise control supplements conventional cruise control with a
vehicle-to-vehicle distance control. In vehicle-to-vehicle distance control mode,
the vehicle automatically accelerates or decelerates in order to maintain a set
following distance from vehicles ahead.

Indicators
Display
Set speed
Vehicle-to-vehicle distance button
Cruise control switch

Press the “ON-OFF” button to acti-
vate the Dynamic radar cruise con-
trol.

Radar cruise control indicator will come

on.
Press the button again to deactivate the

cruise control.



: If equipped

Summary of functions

2
3
4
5

Setting the vehicle speed (vehicle-to-vehicle distance control mode)

193

4-5. Using the driving support systems

iving

Accelerate or decelerate the vehicle
to the desired speed, and push the
lever down to set the speed.

“SET” and set speed will be displayed.
The vehicle speed at the moment the

lever is released becomes the set speed.

To change the set speed, operate the lever until the desired set speed is dis-
played.

Increases the speed
Decreases the speed

Fine adjustment: Momentarily move the

lever in the desired direction.
Large adjustment: Hold the lever in the

desired direction.

In the vehicle-to-vehicle distance control mode, the set speed will be increased or

decreased as follows:



When the set speed is shown in “MPH”

Fine adjustment: By approximately 1 mph (1.6 km/h) each time the lever is operated
Large adjustment: By approximately 5 mph (8 km/h) for each 0.75 seconds the lever

is held



When the set speed is shown in “km/h”

Fine adjustment: By approximately 0.6 mph (1 km/h) each time the lever is operated
Large adjustment: By approximately 3.1 mph (5 km/h) for each 0.75 seconds the

lever is held
In the constant speed control mode (

P. 196), the set speed will be increased or

decreased as follows:
Fine adjustment: By approximately 1 mph (1.6 km/h) each time the lever is operated
Large adjustment: The set speed can be increased or decreased continually until the

lever is released.

Adjusting the set speed

194

4-5. Using the driving support systems

Pressing the button changes the vehi-
cle-to-vehicle distance as follows:

Long
Medium
Short

The vehicle-to-vehicle distance is set

automatically to long mode when the

power switch is turned to ON mode.
If a vehicle is running ahead of you, the preceding vehicle mark will also be displayed.

Select a distance from the table below. Note that the distances shown corre-
spond to a vehicle speed of 50 mph (80 km/h). Vehicle-to-vehicle distance
increases/decreases in accordance with vehicle speed.

Pulling the lever toward you cancels
the Dynamic radar cruise control.

The speed setting is also canceled when

the brakes are applied.

Pushing the lever up resumes the
Dynamic radar cruise control and
returns vehicle speed to the set
speed.

Resuming is available when the vehicle

speed is more than approximately 25

mph (40 km/h).

Changing the vehicle-to-vehicle distance

Preceding vehicle mark

2
3

Vehicle-to-vehicle distance settings

Distance options

Vehicle-to-vehicle distance

Long

Approximately 160 ft. (50 m)

Medium

Approximately 130 ft. (40 m)

Short

Approximately 100 ft. (30 m)

Canceling and resuming the speed control

195

4-5. Using the driving support systems

iving

This mode employs a radar sensor to detect the presence of vehicles up to
approximately 400 ft. (120 m) ahead, determines the current vehicle-to-vehicle
following distance, and operates to maintain a suitable following distance from
the vehicle ahead.

Note that vehicle-to-vehicle distance will close in when traveling on long downhill

slopes.

Example of constant speed cruising
When there are no vehicles ahead

The vehicle travels at the speed set by the driver. The desired vehicle-to-vehicle dis-

tance can also be set by operating the vehicle-to-vehicle distance control.

Example of deceleration cruising
When the vehicle ahead is driving slower than the set speed

When a vehicle is detected running ahead of you, the system automatically deceler-

ates your vehicle. When a greater reduction in vehicle speed is necessary, the system

applies the brakes. A warning tone warns you when the system cannot decelerate suf-

ficiently to prevent your vehicle from closing in on the vehicle ahead.

Example of follow-up cruising
When following a vehicle driving slower than the set speed

The system continues follow-up cruising while adjusting for changes in the speed of

the vehicle ahead in order to maintain the vehicle-to-vehicle distance set by the driver.

Example of acceleration
When there are no longer any vehicles ahead driving slower than the set
speed

The system accelerates until the set speed is reached. The system then returns to con-

stant speed cruising.

Driving in vehicle-to-vehicle distance control mode

196

4-5. Using the driving support systems

When your vehicle is too close to a vehicle ahead, and sufficient automatic
deceleration via the Dynamic radar cruise control is not possible, the display will
flash and the buzzer will sound to alert the driver. An example of this would be if
another driver cuts in front of you while you are following a vehicle. Apply the
brakes to ensure an appropriate vehicle-to-vehicle distance.

■

Warnings may not occur when
In the following instances, there is a possibility that the warnings will not occur:

●

When the speed of the vehicle ahead matches or exceeds your vehicle
speed

●

When the vehicle ahead is traveling at an extremely slow speed

●

Immediately after the cruise control speed was set

●

At the instant the accelerator is applied

Constant speed control mode differs from vehicle-to-vehicle distance control
mode. When constant speed control mode is selected, your vehicle will maintain
a set speed regardless of whether or not there are other vehicles in the lane
ahead.

Press the “ON-OFF” button to acti-
vate the cruise control.

Press the button again to deactivate the

cruise control.

Switch to constant speed control
mode.
(Push the lever forward and hold for
approximately one second.)

Cruise control indicator will come on.
When in constant speed control mode, to return to vehicle-to-vehicle distance con-

trol mode, push the lever forward again and hold for approximately 1 second.

After the desired speed has been set, it is not possible to return to vehicle-to-vehicle

distance control mode.

If the power switch is turned off and then turned to ON mode again, the vehicle will

automatically return to vehicle-to-vehicle distance control mode.
Adjusting the speed setting:

P. 193

Canceling and resuming the speed setting:

P. 194

Approach warning

Selecting conventional constant speed control mode

197

4-5. Using the driving support systems

iving

■

Dynamic radar cruise control can be set when

●

The shift position is in D.

●

Vehicle speed is above approximately 30 mph (50 km/h).

■

Accelerating after setting the vehicle speed
The vehicle can accelerate normally. After acceleration, the set speed resumes. How-

ever, during vehicle-to-vehicle distance control mode, the vehicle speed may decrease

below the set speed in order to maintain the distance to the vehicle ahead.

■

Set speed
The set speed may be unsustainable depending on driving circumstances.

■

Automatic cancelation of vehicle-to-vehicle distance control
Vehicle-to-vehicle distance control driving is automatically canceled in the following situ-

ations:

●

Actual vehicle speed falls below approximately 25 mph (40 km/h).

●

Enhanced VSC is activated.

●

The sensor cannot operate correctly because it is covered in some way.

●

The windshield wipers are operating at high speed. (when the wiper switch is set to the

“AUTO” mode or the high speed wiper operation position).

If vehicle-to-vehicle distance control driving is automatically canceled for any other rea-

son, there may be a malfunction in the system. Contact your Lexus dealer.

■

Automatic cancelation of constant speed control
The cruise control will stop maintaining the vehicle speed in the following situations:

●

Actual vehicle speed is more than approximately 10 mph (16 km/h) below the set vehi-

cle speed.

At this time, the memorized set speed is not retained.

●

Vehicle speed falls below approximately 25 mph (40 km/h).

●

Enhanced VSC is activated.

■

Radar sensor and grille cover
Always keep the sensor and grille cover clean to ensure that the vehicle-to-vehicle dis-

tance control operates properly. (Some obstructions, such as snow, ice and plastic

objects, cannot be detected by the obstruction sensor.)

Dynamic radar cruise control is canceled if an obstruction is detected.

■

Warning messages and buzzers for dynamic radar cruise control
Warning messages and buzzers are used to indicate a system malfunction or to inform

the driver of the need for caution while driving. (

P. 542)

Grille cover
Radar sensor

198

4-5. Using the driving support systems

■

Certification



For vehicles sold in the U.S.A.

FCC ID: HYQDNMWR004
This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation.
FCC WARNING

Changes or modifications not expressly approved by the party responsible for compli-

ance could void the user’s authority to operate the equipment.
Radiofrequency radiation exposure Information:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled

environment.

This equipment should be installed and operated with minimum distance of 20 cm

between the radiator (antenna) and your body.

This transmitter must not be co-located or operating in conjunction with any other

antenna or transmitter.



For vehicles sold in Canada

This device complies with Industry Canada licence-exempt RSS standard(s).

Operation is subject to the following two conditions: (1) this device may not cause inter-

ference, and (2) this device must accept any interference, including interference that

may cause undesired operation of the device.

199

4-5. Using the driving support systems

iving

WARNING

■

Before using dynamic radar cruise control
Do not overly rely on vehicle-to-vehicle distance control.

Be aware of the set speed. If automatic deceleration/acceleration is not appropriate,

adjust the vehicle speed, as well as the distance between your vehicle and vehicles

ahead by applying the brakes etc.

■

Cautions regarding the driving assist systems
Observe the following precautions.

Failure to do so may cause an accident resulting in death or serious injury.

●

Assisting the driver to measure following distance

The dynamic radar cruise control is only intended to help the driver in determining

the following distance between the driver’s own vehicle and a designated vehicle

traveling ahead. It is not a mechanism that allows careless or inattentive driving, and it

is not a system that can assist the driver in low-visibility conditions. It is still necessary

for driver to pay close attention to the vehicle’s surroundings.

●

Assisting the driver to judge proper following distance

The dynamic radar cruise control determines whether the following distance

between the driver’s own vehicle and a designated vehicle traveling ahead is appro-

priate or not. It is not capable of making any other type of judgement. Therefore, it is

absolutely necessary for the driver to remain vigilant and to determine whether or not

there is a possibility of danger in any given situation.

●

Assisting the driver to operate the vehicle

The dynamic radar cruise control has no capability to prevent or avoid a collision with

a vehicle traveling ahead. Therefore, if there is ever any danger, the driver must take

immediate and direct control of the vehicle and act appropriately in order to ensure

the safety of all involved.

200

4-5. Using the driving support systems

WARNING

■

To avoid inadvertent cruise control activation
Switch the cruise control off using the “ON-OFF” button when not in use.

■

Situations unsuitable for dynamic radar cruise control
Do not use dynamic radar cruise control in any of the following situations.

Doing so may result in inappropriate speed control and could cause an accident result-

ing in death or serious injury.

●

Roads where there are pedestrians, cyclers, etc.

●

In heavy traffic

●

On roads with sharp bends

●

On winding roads

●

On slippery roads, such as those covered with rain, ice or snow

●

On steep downhills, or where there are sudden changes between sharp up and down

gradients

Vehicle speed may exceed the set speed when driving down a steep hill.

●

At entrances to expressways

●

When weather conditions are bad enough that they may prevent the sensors from

detecting correctly (fog, snow, sandstorm, heavy rain, etc.)

●

When an approach warning buzzer is heard often

●

During emergency towing

201

4-5. Using the driving support systems

iving

WARNING

■

When the sensor may not be correctly detecting the vehicle ahead
In the case of the following and depending on the conditions, operate the brake pedal

when deceleration of the system is insufficient or operate the accelerator pedal when

acceleration is required.

As the sensor may not be able to correctly detect these types of vehicles, the approach

warning (

P. 196) will not be activated, which may lead to an accident resulting in

death or serious injury.

●

Vehicles with small rear ends (trailers with no load on board etc.)

●

Vehicles that cut in suddenly

●

Vehicles traveling at low speeds

●

Vehicles that are not moving in the same lane

202

4-5. Using the driving support systems

WARNING

●

When water or snow thrown up by the surrounding vehicles hinders the detecting of

the sensor

●

Motorcycles traveling in the same lane

●

When your vehicle is pointing upwards

(caused by a heavy load in the luggage com-

partment etc.)

Content .. 10 11 12 13 ..
