Lexus RX300 (MCU15). Service manual - part 607
SS–10
–
SERVICE SPECIFICATIONS
AUTOMATIC TRANSAXLE
U140F AX (RM848E)
Center differential side gear thrust washer No.1 thickness
Mark
0
1
2
3
4
5
6
7
8
9
A
B
C
0.80 mm (0.0315 in.)
0.85 mm (0.0335 in.)
0.90 mm (0.0354 in.)
0.95 mm (0.0374 in.)
1.00 mm (0.0394 in.)
1.05 mm (0.0413 in.)
1.10 mm (0.0433 in.)
1.15 mm (0.0453 in.)
1.20 mm (0.0472 in.)
1.25 mm (0.0492 in.)
1.30 mm (0.0512 in.)
1.35 mm (0.0531 in.)
1.40 mm (0.0551 in.)
Center differential side gear thrust washer No.2 thickness
Mark
MA
MB
MC
MD
ME
MF
MG
MH
MJ
MK
MM
MN
ML
0.80 mm (0.0315 in.)
0.85 mm (0.0335 in.)
0.90 mm (0.0354 in.)
0.95 mm (0.0374 in.)
1.00 mm (0.0394 in.)
1.05 mm (0.0413 in.)
1.10 mm (0.0433 in.)
1.15 mm (0.0453 in.)
1.20 mm (0.0472 in.)
1.25 mm (0.0492 in.)
1.30 mm (0.0512 in.)
1.35 mm (0.0531 in.)
1.40 mm (0.0551 in.)
Preload (at starting)
New bearing
Reused bearing
0.8 – 1.3 N·m (8.0 – 13.4 kgf·cm, 7.1 – 11.5 in.·lbf)
0.4 – 0.6 N·m (4.1 – 6.7 kgf·cm, 3.5 – 5.3 in.·lbf)
Plate washer thickness
Mark
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
G
H
2.00 mm (0.0787 in.)
2.05 mm (0.0807 in.)
2.10 mm (0.0827 in.)
2.15 mm (0.0846 in.)
2.20 mm (0.0866 in.)
2.25 mm (0.0886 in.)
2.30 mm (0.0906 in.)
2.35 mm (0.0925 in.)
2.40 mm (0.0945 in.)
2.45 mm (0.0965 in.)
2.50 mm (0.0984 in.)
2.55 mm (0.1004 in.)
2.60 mm (0.1024 in.)
2.65 mm (0.1043 in.)
2.70 mm (0.1063 in.)
2.75 mm (0.1083 in.)
2.80 mm (0.1102 in.)
2.85 mm (0.1122 in.)
