PP–2

–

PREPARATION

AUTOMATIC TRANSAXLE

U140F AX   (RM848E)

(09351–32111)

Side Bearing Race Replacer

09387–00010

Transfer Oil Seal Replacer

09387–00020

Direct Clutch Wrench

09387–00030

Counter Drive Gear Holding Tool

09387–00040

Bearing Puller Assembly

(09387–01010)

Claw No.1

(09387–01020)

Claw No.2

(09387–01030)

Pin

(09387–01040)

Bearing Puller Body

09387–00050

Under Drive Gear Puller

09387–00060

Second Brake Wrench

09387–00070

First & Reverse Brake Wrench

09387–00080

Counter Drive Gear Nut Wrench

–

PREPARATION

AUTOMATIC TRANSAXLE

PP–3

U140F AX   (RM848E)

09506–35010

Differential Drive Pinion Rear

Bearing Replacer

09514–35011

Rear Wheel Bearing Puller

09556–16030

Differential Drive Pinion

Holding Tool 28

09564–16020

Drive Pinion Lock Nut Wrench

09564–32011

Differential Preload Adaptor

09608–10010

Steering Knuckle Oil Seal

Replacer

09608–32010

Steering Knuckle Oil Seal

Replacer

09649–17010

Steering Knuckle Tool

09930–00010

Drive Shaft Nut Chisel

(09931–00010)

Handle

(09931–00020)

Nut Chisel

09950–00020

Bearing Remover

09950–00030

Bearing Remover Attachment

PP–4

–

PREPARATION

AUTOMATIC TRANSAXLE

U140F AX   (RM848E)

09950–60010

Replacer Set

(09951–00230)

Replacer 23

(09951–00320)

Replacer 32

(09951–00340)

Replacer 34

(09951–00350)

Replacer 35

(09951–00360)

Replacer 36

(09951–00370)

Replacer 37

(09951–00380)

Replacer 38

(09951–00400)

Replacer 40

(09951–00420)

Replacer 42

(09951–00450)

Replacer 45

(09951–00540)

Replacer 54

(09951–00590)

Replacer 59

–

PREPARATION

AUTOMATIC TRANSAXLE

PP–5

U140F AX   (RM848E)

(09951–00600)

Replacer 60

(09951–00610)

Replacer 61

(09951–00620)

Replacer 62

(09951–00640)

Replacer 64

(09952–06010)

Adapter

09950–60020

Replacer Set No.2

(09951–00710)

Replacer 71

(09951–00730)

Replacer 73

(09951–00790)

Replacer 79

(09951–00810)

Replacer 81

(09951–00890)

Replacer 89

09950–70010

Handle Set

(09951–07100)

Handle 100
