PP0TB–01

PP–72

–

PREPARATION

BODY

LEXUS RX300   (RM785E)

LUBRICANT

Item

Capacity

Classification

MP grease

–

–

PP0TC–01

–

PREPARATION

BODY

PP–73

LEXUS RX300   (RM785E)

SSM (Special Service Materials)

08833–00070

Adhesive 1324,

THREE BOND 1324 or equivalent

08833–00030

Three cement black or equivalent

08850–00801

Windshield Glass Adhesive Set

or equivalent

PP1EH–02

PP–74

–

PREPARATION

AIR CONDITIONING

LEXUS RX300   (RM785E)

AIR CONDITIONING

SST (Special Service Tools)

07110–58060

Air Conditioner Service Tool Set

(07117–58060)

Refrigerant Drain Service Valve

(07117–58070)

T–Joint

(07117–58080)

Quick Disconnect Adapter

High pressure side

(07117–58090)

Quick Disconnect Adapter

Low pressure side

(07117–88060)

Refrigerant Charging Hose

High pressure side

(Color: Red)

(07117–88070)

Refrigerant Charging Hose

Low pressure side

(Color: Blue)

(07117–88080)

Refrigerant Charging Hose

Utility

(Color: Green)

07112–66040

Magnetic Clutch Remover

07112–76060

Magnetic Clutch Stopper

07116–38360

Gas Leak Detector Assembly

PP1AF–06

–

PREPARATION

AIR CONDITIONING

PP–75

LEXUS RX300   (RM785E)

RECOMMENDED TOOLS

09040–00011

Hexagon Wrench Set .

Expansion valve

(09043–20050)

Socket Hexagon Wrench 5.

5.0 mm (0.20 in.)

09082–00040

TOYOTA Electrical Tester.

09905–00013

Snap Ring Pliers .
