PP1AI–01

PP–8

–

PREPARATION

ENGINE MECHANICAL

LEXUS RX300   (RM785E)

SSM (Special Service Materials)

08826–00080

Seal Packing Black or equivalent

(FIPG)

Camshaft bearing cap

Semi–circular plug

Cylinder head cover

Rear oil seal retainer

08826–00100

Seal Packing 1282B,

THREE BOND 1282B or equivalent

(FIPG)

Engine coolant drain union

Water seal plate

Water inlet housing

08833–00070

Adhesive 1324,

THREE BOND 1324 or equivalent

Spark plug tube

Drive plate bolt

08833–00080

Adhesive 1344

THREE BOND 1344

LOCTITE 242 or equivalent

No.1 idler pulley pivot bolt

PP06S–03

–

PREPARATION

EMISSION CONTROL

PP–9

LEXUS RX300   (RM785E)

EMISSION CONTROL

EQUIPMENT

Torque wrench

MITYVAC (Hand–held vacuum pump)

PP3DM–01

PP–10

–

PREPARATION

ELECTRONIC FUEL INJECTION

LEXUS RX300   (RM785E)

 ELECTRONIC FUEL INJECTION

SST (Special Service Tools)

09268–41047

Injection Measuring Tool Set

INJECTOR

FUEL PUMP

(09268–41100)

Clamp

INJECTOR

(09268–41300)

Clamp

INJECTOR

(09268–41250)

T Joint

FUEL PUMP

09268–45012

EFI Fuel Pressure Gauge

FUEL PUMP

09817–16011

Back–up Light Switch Tool

KNOCK SENSOR

09842–30070

Wiring ”F” EFI Inspection

INJECTOR

EFI SYSTEM

09843–18020

Diagnosis Check Wire

IDLE SPEED CONTROL (ISC) VALVE

PP06U–11

–

PREPARATION

ELECTRONIC FUEL INJECTION

PP–11

LEXUS RX300   (RM785E)

RECOMMENDED TOOLS

09040–00011

Hexagon Wrench Set .

09082–00040

TOYOTA Electrical Tester.

09200–00010

Engine Adjust Kit .

09258–00030

Hose Plug Set .

Plug for the vacuum hose, fuel

hose etc.
