Lexus RX300 (MCU15). Service manual - part 25

QUARTER WHEEL HOUSING OUTER PANEL
(ASSY): Left Side

REMOVAL (With the quarter panel removed.)

1.

Cut the roof side outer panel at the location
shown in the above figure and remove the
quarter wheel housing outer panel.

Cut and Join Location

130 mm

Roof Side
Outer Panel

— 1

— 4

— 2

— 4

— 2

— 6

— 7

— 3

— 2

— 2

— 18

— 1

— 1

— 12

— 5

— 5

— 8

BODY PANEL REPLACEMENT

RE-46

mm

in.

130

5.12

1.

Determine the position of the new parts by the
assembly marks of the inner and outer panels.

2.

Before welding the new parts, temporarily
install the quearter panel and check the fit.

3.

After installing the new parts, apply foamed
materials.

Butt Weld

A –  A
[Foamed Material
Application Areas]

A

A

Assembly
Mark

— 4

— 2

— 1

— 4

— 5

— 2

— 6

— 4

— 4

— 3

— 8

— 16

— 24

— 2

— 2

— 1

— 5

— 1

BODY PANEL REPLACEMENT

RE-47

INSTALLATION

BODY LOWER BACK PANEL (ASSY)

REMOVAL

— 2

— 1

— 2

— 5

— 19

— 3

— 5

— 2

— 3

— 10

— 2

BODY PANEL REPLACEMENT

RE-48

1.

Temporarily install the new parts and check
the fit of the back door.

— 2

— 1

— 2

— 2

— 5

— 5

— 10

— 25

— 4

— 4

— 3

BODY PANEL REPLACEMENT

RE-49

INSTALLATION
