D03683



 Non-reusable part

Cylindrical
Roller Bearing
Inner Race

Differential
Drive Pinion

Parking Lock Gear

Tapered Roller Bearing FR

U/D Planetary
Ring Gear

Snap Ring

Counter Driven Gear

U/D Planetary Gear

Tapered Roller Bearing RR



280 (2,855, 207)

N·m (kgf·cm, ft·lbf) : Specified torque

Lock Nut





-

AUTOMATIC TRANSMISSION / TRANS

AUTOMATIC TRANSMISSION / TRANSAXLE (U150E)

40-9

31

U150E A/T REPAIR MANUAL   (RM913U)

D03697

Snap Ring

Plate

Disc

Snap Ring

U/D Clutch Piston
Return Spring

U/D Clutch Piston Set

U/D Clutch Drum

Flange



 Non-reusable part



 O-ring

40-10

-

AUTOMATIC TRANSMISSION / TRANS

AUTOMATIC TRANSMISSION / TRANSAXLE (U150E)

32

U150E A/T REPAIR MANUAL   (RM913U)

D26459

N·m (kgf·cm, ft·lbf) : Specified torque

Shift Solenoid Valve SL2

Shift Solenoid Valve S4

Shift Solenoid Valve SR

Shift Solenoid Valve SL3

Line Pressure
Control Solenoid Assy

Shift Solenoid Valve SL1

Shift Solenoid Valve DSL

10.8 (110, 8)

6.6 (67, 58 in.

⋅

lbf)

10.8 (110, 8)

6.6 (67, 58 in.

⋅

lbf)

6.6 (67, 58 in.

⋅

lbf)

10.8 (110, 8)

-

AUTOMATIC TRANSMISSION / TRANS

AUTOMATIC TRANSMISSION / TRANSAXLE (U150E)

40-1 1

33

U150E A/T REPAIR MANUAL   (RM913U)

D03761



 Oil Seal

Transaxle Housing

Pin

Differential Pinion Thrust Washer

Differential Side Gear

Differential Pinion Shaft

Differential Side Gear
Thrust Washer

Differential Pinion

Differential Ring Gear

Differential Case



 Tapered Roller Bearing FR



Bearing Outer Race



 Oil Seal

Shim



Bearing Outer Race

N·m (kgf·cm, ft·lbf) : Specified torque



 Non-reusable part



Tapered Roller Bearing RR

95.1 (970, 70)

x14

40-12

-

AUTOMATIC TRANSMISSION / TRANS

AUTOMATIC TRANSMISSION / TRANSAXLE (U150E)

34
