MO-34

NEW MODEL OUTLINE

EQUIPMENT LIST

: Standard OP: Option

Exterior

UV (Ultraviolet) Cut & Water-Repellent Coating Glass

Chassis

Tire (P 215/60 R 16)

Disc Wheel

Aluminum and Silver Painted

Disc Wheel
(16

×

 6 1/2JJ-50)

Aluminum and Chrome Plated

OP

ABS (Anti-lock Brake System) with EBD (Electronic Brake force Distribution)

Brake Assist & TRAC (Traction Control) & VSC (Vehicle Skid Control)

OP

Power Steering System (Engine Revolution Sensing type)

Steering

Manual Tilt Steering

Steering

3-Spoke Steering Wheel (Leather)

3-Spoke Steering Wheel (Combination of Wood & Leather)

OP

Electric Modulated Suspension

OP

Body

Seat Covers

Fabric

Seat Covers

Leather (Manufactured by Garden State Tanning)

OP

Front Seat Belt

Pretensioner & Forcelimiter & Tension Reducer

Front Seat Belt

Driver seat: ELR

*

1

, Passenger Seat: ELR

*

1

/ALR

*

2

Rear Seat Belt

3-point ELR

*

1

/ALR

*

2

 Seat Belt

CRS (Child Restraint System) Anchor System

Body Electrical

Headlight

Halogen

Headlight

HID (High Intensity Discharge)

OP

Daytime Running Light System

Headlight Beam Level Control System

OP

Front Fog Light

Automatic Light
Control System

Light Auto Turn-OFF & Auto Position Function

Illuminated Entry System

Wiper System

Washer-Linked Wiper Function

Wiper System

Washer-Linked Wiper with Raindrop Sensing Function

OP

Air Conditioning
System

Right/Left Independent Temperature Control Automatic Air
Conditioning

System

Clean Air Filter

*

1

: Emergency Locking Retractor *

2

: Automatic Locking Retractor

MO-35

NEW MODEL OUTLINE

: Standard OP: Option

Body Electrical

LEXUS Navigation System

OP

Compass

Multi-Information Display

Power Window System

All-Door One-Motion Auto Up-and-Down,
Jam Protection Function

Power Door Lock /
Wireless Door Lock

Front Door Key-Linked Lock Function

Wireless Door Lock
Remote Control System

Shift-Linked Automatic Door Lock Function

Engine Immobiliser System

Theft Deterrent System

SRS

*

3

 Airbag System

Driver & Passenger & Side & Curtain Shield Airbags

Cruise Control System

Power Front Seats

Both Driver & Front Passenger Seats

Memory System (Driver’s Seat, Outside Rear View Mirrors)

OP

Seat Heater

For Driver & Front Passenger

OP

Outside Rear View

Electrical Remote Control Mirrors with Heater

Outside Rear View
Mirror

Automatic Glare-Resistant EC (Electrochromic) Mirror

Inside Rear View Mirror

Automatic Glare-Resistant EC (Electrochromic) Mirror
with Compass

Standard (Manufactured by Pioneer)

Radio with AM/FM/

Standard (Manufactured by Pioneer)

*

4

OP

Cassette/CD/7-Speakers

LEXUS Premium Sound System
(Manufactured by Mark Levinson)

*

4

OP

Radio with AM/FM/
Cassette/In-dash 6-CD

LEXUS Premium Sound System
(Manufactured by Mark Levinson)

OP

Cassette/In dash 6 CD
Changer/7-Speakers

Standard (Manufactured by Pioneer)

OP

Rear Electrical Sunshade

OP

Moon Roof

OP

*

3

: Supplemental Restraint System *

4

: With LEXUS Navigation System

MO-15

211MO23

211MO75

Open

Tilt Switch

Open Switch

Tilted

CD

Cassett

211MO76

211MO77

NEW MODEL OUTLINE

EQUIPMENT

The joy of cruising has been heightened with delightful features
installed at every turn.

LEXUS Navigation System

The LEXUS navigation system, with
the latest functions and high-speed
hardware built in, can pinpoint your
destination by accessing a large
bank of map data, calculate the rec-
ommended route and provide on-
screen guidance in one simple and
quick process.

The 6.5-inch wide LCD (Liquid Crystal Display) screen
responds quickly and is easy to use.

The navigation ECU that reads the map data on the
DVD (Digital Versatile Disc) is located in the luggage
room. The GPS (Global Positioning System) antenna
is located under the package tray.

DVD has been selected as the medium for storing
the map data enabling a large volume of data to
be utilized.

With the adoption of a touch panel, multiple functions
can be handled with a simple configuration of
switches. The audio system is also operated through
the touch panel.

The easy-to-see guidance display includes a three-
position tilt display function to suit the tastes of the
occupants. The tilt angle is controlled by a switch
on the panel surrounding the screen.

To insert or eject CDs and cassettes, press the “Open”
switch on the panel surrounding the screen. The dis-
play will slide open.

MO-2

NEW MODEL OUTLINE

EXTERIOR APPEARANCE

Front View

211IN01
