V08418
Turn ignition Key from LOCK position to ACC position.
Troubleshooting for ANTI–THEFT SYSTEM
Display A:
ID Number is set.
Display E:
ANTI–THEFT SYSTEM opera-
tion condition. (ID number input
error 10 times or more.)
Display B
”SEC display disappears after 1
second.
Radio switch ON.
Take to designated radio
service station.
Display B
Display D
Refer to each
malfunction item.
Normal
operation.
Radio switch ON.
Normal operation.
Cancel ID number, refer to each malfunction item.
Yes
No
OK
NG
ANTI–THEFT SYSTEM operation condition. (ID number input error 9 times or less.)
Input ID number to cancel ANTI–THEFT SYSTEM, and check display.
Display A
→
B
Display B
Display E
Display C
→
A
Radio switch ON.
Refer to each
malfunction item.
Take to designated
radio service station.
ANTI–THEFT SYSTEM not can-
celled. (ID number input error 10
times or less.)
Display D
ANTI–THEFT SYSTEM cancelled.
Check audio system again.
Normal operation.
OK
NG
Cancel ID number, refer to each malfunction item.
Liquid Crystal Display (LCD) or VFD for Audio System
Display ”A”
Display ”B”
Display ”C”
Display ”D” Example:
Display ”E”
2 DIN Type
1 DIN Type
Blank
No Illumination
2 DIN Type
1 DIN Type
2 DIN Type
1 DIN Type
Error Times
2 DIN Type
1 DIN Type
Radio Display
1 DIN Type
2 DIN Type
HINT:
Refer to Owner’s Manual for operation details of ANTI–THEFT SYSTEM.
When the ID number has been cancelled, reset the same number after completing the operation, or
inform the customer that it has been cancelled.
BE–148
–
BODY ELECTRICAL
AUDIO SYSTEM
1532
1997 LEXUS ES300 (RM511U)
