PP1XM–01

–

PREPARATION

ENGINE MECHANICAL (2JZ–GE)

PP–7

59

SSM (Special Service Materials)

08826–00080

Seal Packing Black or equivalent

(FIPG)

No.1, No.3 camshaft bearing cap

Cylinder head cover

Rear oil seal retainer

08833–00070

Adhesive 1324,

THREE BOND 1324 or equivalent

Drive plate bolt

Heater union

Torque converter clutch bolt

08833–00080

Adhesive 1344

THREE BOND 1344

LOCTITE 242 or equivalent

Idler pulley povot bolt

PP0T2–03

PP–72

–

PREPARATION

SUSPENSION AND AXLE

124

RECOMMENDED TOOLS

09025–00010

Torque Wrench (30 kgf–cm)

09031–00030

Pin Punch .

09040–00011

Hexagon Wrench Set .

09905–00012

Snap Ring No.1 Expander .

09905–00013

Snap Ring Pliers .

PP0T3–01

–

PREPARATION

SUSPENSION AND AXLE

PP–73

125

EQUIPMENT

Dial indicator with magnetic base

Torque wrench

Micrometer

PP0T4–01

PP–74

–

PREPARATION

SUSPENSION AND AXLE

126

LUBRICANT

Item

Capacity

Classification

Outboard joint

100 – 105 g

(0.22 – 0.23 lb, 3.5 – 3.7 oz.)

Inboard joint

100 – 105 g

(0.22 – 0.23 lb, 3.5 – 3.7 oz.)

End cover

50 – 55 g

(0.11 – 0.12 lb, 1.8 – 1.9 oz.)

Differential oil

1.35 liters (1.43 US qts, 1.19 lmp qts)

Hypoid gear oil API GL–5

Above –18

°

C (0

°

F)

SAE 90

Below  –18

°

C (0

°

F)

SAE 80W–90 or 80W
