PP0N5–02

PP–60

–

PREPARATION

AUTOMATIC TRANSMISSION

112

RECOMMENDED TOOLS

09017–12301

Deep Socket Wrench 30 mm .

09082–00040

TOYOTA Electrical Tester.

PP0N6–01

–

PREPARATION

AUTOMATIC TRANSMISSION

PP–61

113

EQUIPMENT

OBD II scan tool

Dial indicator or dial indicator with magnetic base

Output shaft, Major bushing

Straight edge

Torque wrench

PP0N7–06

PP–62

–

PREPARATION

AUTOMATIC TRANSMISSION

114

LUBRICANT

Item

Capacity

Classification

Automatic transmission fluid

 Dry fill

 Drain and refill

8.4 liters (8.9 US qts, 7.4 Imp. qts)

1.9 liters (2.0 US qts, 1.7 Imp. qts)

ATF TYPE T–IV

PP0SU–01

–

PREPARATION

AUTOMATIC TRANSMISSION

PP–63

115

SSM (Special Service Materials)

08826–00090

Seal Packing 1281,

THREE BOND 1281 or equivalent

(FIPG)

Transmission case x Oil pan
