• Next, choose the number designation (home, work,

mobile, or other) that you wish to edit.

• When prompted, recite the new phone number for the

phonebook entry that you are editing.

After you are finished editing an entry in the phonebook,
you will be given the opportunity to edit another entry in
the phonebook, call the number you just edited, or return
to the main menu.

NOTE:
• Editing names in the phonebook is recommended when

the vehicle is not in motion.

• Automatic downloaded phonebook entries cannot be

deleted or edited.

“Phonebook Edit” can be used to add another phone
number to a name entry that already exists in the phone-
book. For example, the entry John Doe may have a mobile
and a home number, but you can add “John Doe’s” work
number later using the “Phonebook Edit” feature.

Delete Uconnect Phonebook Entry

NOTE:

Editing phonebook entries is recommended when

the vehicle is not in motion.

To delete a Uconnect phonebook entry using Voice Com-
mands:

1. Push the Phone

button to begin.

2. After the “Ready” prompt and the following beep, say

“Phonebook Delete.”

3. After you enter the Phonebook Delete menu, you will

then be asked for the name of the entry that you wish to
delete. You can either say the name of a phonebook
entry that you wish to delete, or you can say “List
Names” to hear a list of the entries in the phonebook
from which you choose. To select one of the entries from
the list, push the Voice Command

button while the

Uconnect Phone is playing the desired entry and say
“Delete.”

4. After you enter the name, the Uconnect Phone will ask

you which designation you wish to delete: home, work,
mobile, other, or all. Say the designation you wish to
delete.

• Note that only the phonebook entry in the current

language is deleted.

NOTE:

Automatic downloaded phonebook entries cannot

be deleted or edited.

MULTIMEDIA

467

Delete/Erase “All” Uconnect Phonebook Entries

NOTE:
• ONLY the phonebook in the current language is deleted.
• Automatic downloaded phonebook entries cannot be

deleted or edited.

To delete or erase all Uconnect phonebook entries using
Voice Command:

1. Push the Phone

button to begin.

2. After the “Ready” prompt and the following beep, say

“Phonebook Erase All.”

• The Uconnect Phone will ask you to verify that you

wish to delete all the entries from the phonebook.

3. After confirmation, the phonebook entries will be de-

leted.

List All Names In The Uconnect Phonebook

• Push the Phone

button to begin.

• After the “Ready” prompt and the following beep, say

“Phonebook List Names.”

• The Uconnect Phone will play the names of all the

phonebook entries, including the downloaded phone-
book entries, if available.

• To call one of the names in the list, push the Voice

Command

button during the playing of the desired

name, and say “Call.”

NOTE:

The user can also exercise “Edit” or “Delete”

operations at this point.
• The Uconnect Phone will then prompt you as to the

number designation you wish to call.

• The selected number will be dialed.

Phone Call Features

The following features can be accessed through the
Uconnect Phone if the feature(s) are available on your
mobile service plan. For example, if your mobile service
plan provides three-way calling, this feature can be ac-
cessed through the Uconnect Phone. Check with your
mobile service provider for the features that you have.

Answer Or Reject An Incoming Call — No Call
Currently In Progress

When you receive a call on your mobile phone, the
Uconnect Phone will interrupt the vehicle audio system, if

468

MULTIMEDIA

on, and will ask if you would like to answer the call. Push
the Phone

button to accept the call. To reject the call,

push and hold the Phone

button until you hear a

single beep, indicating that the incoming call was re-
jected.

Answer Or Reject An Incoming Call — Call
Currently In Progress

If a call is currently in progress and you have another
incoming call, you will hear the same network tones for
call waiting that you normally hear when using your
mobile phone. Push the Phone

button to place the

current call on hold and answer the incoming call.

NOTE:

The Uconnect Phone compatible phones in the

market today do not support rejecting an incoming call
when another call is in progress. Therefore, the user can
only answer an incoming call or ignore it.

Making A Second Call While Current Call Is In
Progress

To make a second call while you are currently on a call,
push the Voice Command

button and say “Dial” or

“Call” followed by the phone number or phonebook
entry you wish to call. The first call will be on hold
while the second call is in progress. To go back to the

first call, refer to “Toggling Between Calls” in this
section. To combine two calls, refer to “Conference Call”
in this section.

Place/Retrieve A Call From Hold

To put a call on hold, push the Phone

button until you

hear a single beep. This indicates that the call is on hold.
To bring the call back from hold, push and hold the
Phone

button until you hear a single beep.

Toggling Between Calls

If two calls are in progress (one active and one on hold),
push the Phone

button until you hear a single beep,

indicating that the active and hold status of the two calls
have switched. Only one call can be placed on hold at a
time.

Conference Call

When two calls are in progress (one active and one on
hold):

1. Push and hold the Phone

button until you hear a

double beep, indicating that the two calls have been
joined into one conference call.

MULTIMEDIA

469

Three-Way Calling

To initiate three-way calling, push the Voice Command

button while a call is in progress, and make a second

phone call, as described under “Making a Second Call
While Current Call is in Progress.” After the second call
has established, push and hold the Phone

button

until you hear a double beep, indicating that the two
calls have been joined into one conference call.

Call Termination

To end a call in progress:

1. Momentarily push the Phone

button.

• Only the active call(s) will be terminated and if there is

a call on hold, it will become the new active call. If the
active call is terminated by the phone far end, a call on
hold may not become active automatically. This is cell
phone-dependent.

2. To bring the call back from hold, push and hold the

Phone

button until you hear a single beep.

Redial

To redial the last number called from your mobile phone
using Voice Command:

1. Push the Phone

button to begin.

2. After the “Ready” prompt and the following beep, say

“Redial.”

• The Uconnect Phone will call the last number that was

dialed from your mobile phone.

NOTE:

This may not be the last number dialed from the

Uconnect Phone.

Call Continuation

Call continuation is the progression of a phone call on the
Uconnect Phone after the vehicle ignition has been
switched to OFF. Call continuation functionality available
on the vehicle can be any one of three types:

1. After the ignition is switched to OFF, a call can continue

on the Uconnect Phone either until the call ends, or until
the vehicle battery condition dictates cessation of the
call on the Uconnect Phone and transfer of the call to the
mobile phone.

2. After the ignition is cycled to OFF, a call can continue on

the Uconnect Phone for a certain duration, after which
the call is automatically transferred from the Uconnect
Phone to the mobile phone.

3. An active call is automatically transferred to the mobile

phone after the ignition is cycled to OFF.

470

MULTIMEDIA

Uconnect Phone Features

Language Selection

To change the language that the Uconnect Phone is using:
• Push the Phone

button to begin.

• After the “Ready” prompt and the following beep, say

the name of the language you wish to switch to English,
Espanol, or Francais.

• Continue to follow the system prompts to complete the

language selection.

After selecting one of the languages, all prompts and voice
commands will be in that language.

NOTE:

After every Uconnect Phone language change

operation, only the language-specific 32-name phonebook
is usable. The paired phone name is not language-specific
and usable across all languages.

Emergency Assistance

If you are in an emergency and the mobile phone is
reachable:
• Pick up the phone and manually dial the emergency

number for your area.

If the phone is not reachable and the Uconnect Phone is
operational, you may reach the emergency number as
follows:
• Push the Phone

button to begin.

• After the “Ready” prompt and the following beep, say

“Emergency” and the Uconnect Phone will instruct the
paired mobile phone to call the emergency number.

NOTE:
• The emergency number dialed is based on the country

where the vehicle is purchased (911 for the U.S. and
Canada and 060 for Mexico). The number dialed may
not be applicable with the available mobile service and
area.

• If supported, this number may be programmable on

some systems. To do this, push the Phone

button and

say “Setup,” followed by “Emergency.”

• The Uconnect Phone does slightly lower your chances of

successfully making a phone call as to that for the
mobile phone directly.

MULTIMEDIA

471

WARNING!

To use your Uconnect Phone System in an emergency,
your mobile phone must be:
• Turned on.

• Paired to the Uconnect System.

• Have network coverage.

Roadside Assistance/Towing Assistance

If you need roadside assistance:
• Push the Phone

button to begin.

• After the “Ready” prompt and the following beep, say

“Towing Assistance.”

NOTE:

You should program the desired Towing Assistance

phone number using the Voice Command system. To do
this, push the Phone

button and say “Setup,” fol-

lowed by “Towing Assistance.” When prompted say
1-800-521-2779 for U.S., 1-800-363-4869 for Canada, 55-
14-3454 for Mexico City and 1-800-712-3040 for outside
Mexico City in Mexico.

Paging

To learn how to page, refer to “Working With Automated
Systems.” Paging works properly except for pagers of
certain companies, which time out a little too soon to work
properly with the Uconnect Phone.

Voice Mail Calling

To learn how to access your voice mail, refer to “Working
With Automated Systems.”

Working With Automated Systems

This method is used in instances where one generally has
to press numbers on the mobile phone keypad while
navigating through an automated telephone system.

You can use your Uconnect Phone to access a voice mail
system or an automated service, such as a paging service or
automated customer service line. Some services require
immediate response selection. In some instances, that may
be too quick for use of the Uconnect Phone.

When calling a number with your Uconnect Phone that
normally requires you to enter in a touch-tone sequence on
your mobile phone keypad, you can push the Voice Com-
mand

button and say the sequence you wish to enter,

followed by the word “Send.” For example, if required

472

MULTIMEDIA

to enter your PIN followed with a pound, (3 7 4 6 #), you
can push the Voice Command

button and say, “3 7 4

6 # Send.” Saying a number, or sequence of numbers,
followed by “Send,” is also to be used for navigating
through an automated customer service center menu
structure, and to leave a number on a pager.

You can also send stored Uconnect Phonebook entries as
tones for fast and easy access to voice mail and pager
entries. To use this feature, dial the number you wish to call
and then push the Voice Command

button and say,

“Send.” The system will prompt you to enter the name
or number and say the name of the phonebook entry
you wish to send. The Uconnect Phone will then send
the corresponding phone number associated with the
phonebook entry, as tones over the phone.

NOTE:
• You may not hear all of the tones due to mobile phone

network configurations. This is normal.

• Some paging and voice mail systems have system time

out settings that are too short and may not allow the use
of this feature.

Barge In – Overriding Prompts

The “Voice Command” button can be used when you wish
to skip part of a prompt and issue your voice command
immediately. For example, if a prompt is asking “Would
you like to pair a phone, clear a...,” you could push the
Voice Command

button and say, “Pair a Phone” to

select that option without having to listen to the rest of
the voice prompt.

Turning Confirmation Prompts On/Off

Turning confirmation prompts off will stop the system
from confirming your choices (e.g., the Uconnect Phone
will not repeat a phone number before you dial it).

To turn confirmation prompts on or off using Voice Com-
mand:

1. Push the Phone

button to begin.

2. After the “Ready” prompt and the following beep, say:

• “Setup Confirmations Prompts On”
• “Setup Confirmations Prompts Off”

MULTIMEDIA

473

Phone And Network Status Indicators

If available on the radio and/or on a premium display such
as the instrument panel cluster, and supported by your
mobile phone, the Uconnect Phone will provide notifica-
tion to inform you of your phone and network status when
you are attempting to make a phone call using Uconnect
Phone. The status is given for roaming, network signal
strength, phone battery strength, etc.

Dialing Using The Mobile Phone Keypad

You can dial a phone number with your mobile phone
keypad and still use the Uconnect Phone (while dialing via
the mobile phone keypad, the user must exercise caution
and take precautionary safety measures). By dialing a
number with your paired Bluetooth mobile phone, the
audio will be played through your vehicles audio system.
The Uconnect Phone will work the same as if you dial the
number using Voice Command.

NOTE:

Certain brands of mobile phones do not send the

dial ring to the Uconnect Phone to play it on the vehicle
audio system, so you will not hear it. Under this situation,
after successfully dialing a number the user may feel that
the call did not go through even though the call is in
progress. Once your call is answered, you will hear the
audio.

Mute/Un-Mute (Mute ON/OFF)

When you mute the Uconnect Phone, you will still be able
to hear the conversation coming from the other party, but
the other party will not be able to hear you. To mute the
Uconnect Phone:
• Push the Voice Command

button.

• Following the beep, say “Mute.”

To un-mute the Uconnect Phone:
• Push the Voice Command

button.

• Following the beep, say “Mute off.”

Advanced Phone Connectivity

Transfer Call To And From Mobile Phone

The Uconnect Phone allows ongoing calls to be transferred
from your mobile phone to the Uconnect Phone without
terminating the call. To transfer an ongoing call from your
Uconnect Phone paired mobile phone to the Uconnect
Phone or vice versa, push the Voice Command

button

and say “Transfer Call.”

474

MULTIMEDIA

Connect Or Disconnect Link Between The Uconnect
Phone And Mobile Phone

Your mobile phone can be paired with many different
electronic devices, but can only be actively

⬙connected⬙

with one electronic device at a time.

If you would like to connect or disconnect the Bluetooth
connection between a Uconnect Phone paired mobile
phone and the Uconnect Phone, follow the instructions
described in your mobile phone user manual.

List Paired Mobile Phone Names
• Push the Phone

button to begin.

• After the “Ready” prompt and the following beep, say

“Setup Phone Pairing.”

• When prompted, say “List Phones.”
• The Uconnect Phone will play the phone names of all

paired mobile phones in order from the highest to the
lowest priority. To “Select” or “Delete” a paired phone
being announced, push the Voice Command

button

and say “Select” or “Delete.” Also, see the next two
sections for an alternate way to “Select” or “Delete” a
paired phone.

Select Another Mobile Phone

This feature allows you to select and start using another
phone paired with the Uconnect Phone.
• Push the Phone

button to begin.

• After the “Ready” prompt and the following beep, say

“Setup Select Phone” and follow the prompts.

• You can also push the Voice Command

button at any

time while the list is being played, and then choose
the phone that you wish to select.

• The selected phone will be used for the next phone call.

If the selected phone is not available, the Uconnect
Phone will return to using the highest priority phone
present in or near (approximately within 30 ft (9 m) of
the vehicle.

Delete Uconnect Phone Paired Mobile Phones
• Push the Phone

button to begin.

• After the “Ready” prompt and the following beep, say

“Setup Phone Pairing.”

• At the next prompt, say “Delete” and follow the

prompts.

MULTIMEDIA

475

• You can also push the Voice Command

button at any

time while the list is being played, and then choose
the phone you wish to delete.

Things You Should Know About Your Uconnect
Phone

Uconnect Phone Tutorial

To hear a brief tutorial of the system features, push the
Phone

button and say “Uconnect Tutorial.”

Voice Training

For users experiencing difficulty with the system recogniz-
ing their voice commands or numbers, the Uconnect Phone
Voice Training feature may be used. To enter this training
mode, follow one of the two following procedures:
• From outside the Uconnect Phone mode (e.g., from radio

mode), push and hold the Voice Command

button

for five seconds until the session begins, or,

• Push the Voice Command

button and say the “Voice

Training,” “System Training,” or “Start Voice Train-
ing” command.

You can either push the Uconnect Phone button to restore
the factory setting or repeat the words and phrases when
prompted by the Uconnect Phone. For best results, the

Voice Training session should be completed when the
vehicle is parked with the engine running, all windows
closed, and the blower fan switched off.

This procedure may be repeated with a new user. The
system will adapt to the last trained voice only.

Reset

To Reset all settings using Voice Command:

1. Push the Phone

button.

2. After the “Ready” prompt and the following beep, say

“Setup,” then “Reset.”

• This will delete all phone pairing, phone book entries,

and other settings in all language modes. The System
will prompt you before resetting to factory settings.

Voice Command

For best performance:
• Adjust the rearview mirror to provide at least ½ inch (1

cm) gap between the overhead console (if equipped) and
the mirror.

• Always wait for the beep before speaking.

476

MULTIMEDIA

• Speak normally without pausing, just as you would

speak to a person sitting a few feet/meters away from
you.

• Make sure that no one other than you is speaking during

a Voice Command period.

Performance is maximized under:
• Low-to-medium blower setting
• Low-to-medium vehicle speed
• Low road noise
• Smooth road surface
• Fully closed windows
• Dry weather condition

NOTE:
• Even though the system is designed for users speaking

in North American English, French, and Spanish accents,
the system may not always work for some.

• When navigating through an automated system such as

voice mail, or when sending a page, at the end of
speaking the digit string, make sure to say “Send.”

• Storing names in the phonebook when the vehicle is not

in motion is recommended.

• It is not recommended to store similar sounding names

in the Uconnect Phonebook.

• Phonebook (Downloaded and Uconnect Phone Local)

name recognition rate is optimized when the entries are
not similar.

• Numbers must be spoken in single digits. “800” must be

spoken “eight-zero-zero” not “eight hundred.”

• You can say “O” (letter “O”) for “0” (zero).
• Even though international dialing for most number

combinations is supported, some shortcut dialing num-
ber combinations may not be supported.

Far End Audio Performance

Audio quality is maximized under:
• Low-to-medium blower setting
• Low-to-medium vehicle speed
• Low road noise
• Smooth road surface
• Fully closed windows

MULTIMEDIA

477

• Dry weather conditions
• Operation from the driver’s seat
• Performance, such as audio clarity, echo, and loudness

to a large degree rely on the phone and network, and not
the Uconnect Phone

• Echo at the phone far end can sometimes be reduced by

lowering the in-vehicle audio volume

Recent Calls

If your phone supports “Automatic Phonebook Down-
load,” Uconnect Phone can list your Outgoing, Incoming
and Missed Calls.

SMS

Uconnect Phone can read or send new messages on your
phone.

Read Messages:

If you receive a new text message while your phone is
connected to Uconnect Phone, an announcement will be
made to notify you that you have a new text message. If
you wish to hear the new message:

1. Push the Phone

button.

2. After the “Ready” prompt and the following beep, say

“SMS Read” or “Read Messages.”

• Uconnect Phone will play the new text message for

you.

After reading a message, you can “Reply” or “Forward”
the message using Uconnect Phone.

Send Messages:

You can send messages using Uconnect Phone. To send a
new message:

1. Push the Phone

button.

2. After the “Ready” prompt and the following beep, say

“SMS Send” or “Send Message.”

3. You can either say the message you wish to send or say

“List Messages.” There are 20 preset messages.

To send a message, push the Voice Command

button

while the system is listing the message and say “Send.”

Uconnect Phone will prompt you to say the name or
number of the person you wish to send the message to.

478

MULTIMEDIA

List of Preset Messages:
1. Yes

2. No

3. Where are you?

4. I need more direction

5. L O L

6. Why

7. I love you

8. Call me

9. Call me later

10. Thanks

11. See You in 15 minutes

12. I am on my way

13. I’ll be late

14. Are you there yet?

15. Where are we meeting?

16. Can this wait?

17. Bye for now

18. When can we meet?

19. Send number to call

20. Start without me

Turn SMS Incoming Announcement ON/OFF

Turning the SMS Incoming Announcement OFF will stop
the system from announcing the new incoming messages.

1. Push the Phone

button.

2. After the “Ready” prompt and the following beep, say

“Setup, SMS Incoming Message Announcement,” you
will then be given a choice to change it.

Bluetooth Communication Link

Mobile phones have been found to lose connection to the
Uconnect Phone. When this happens, the connection can
generally be reestablished by switching the phone off/on.
Your mobile phone is recommended to remain in Bluetooth
ON mode.

Power-Up

After switching the ignition key from OFF to either the ON
or ACC position, or after a language change, you must wait
at least 15 seconds prior to using the system.

MULTIMEDIA

479

Jeep Wrangler JK (2018 year). Manual - part 30
