Jeep Patriot (2017 year). Manual

Operation Instructions — CD MODE For CD And
MP3 Audio Play

NOTE:

• The ignition switch must be in the ON/RUN or ACC

position to operate the radio.

• This radio is capable of playing compact discs (CD),

recordable compact discs (CD-R), rewritable compact
discs (CD-RW), compact discs with MP3 tracks and
multisession compact discs with CD and MP3 tracks.

Inserting Compact Disc(s)

Gently insert one CD into the CD player with the CD label
facing up. The CD will automatically be pulled into the CD
player and the CD icon will illuminate on the radio display.
If a CD does not go into the slot more than 1.0 inch (2.5 cm),
a disc may already be loaded and must be ejected before a
new disc can be loaded.

If you insert a disc with the ignition ON/RUN and the
radio ON, the unit will switch from radio to CD mode and
begin to play when you insert the disc. The display will
show the track number, and index time in minutes and
seconds. Play will begin at the start of track 1.

CAUTION!

• This CD player will accept 4–3/4 inch (12 cm) discs

only. The use of other sized discs may damage the
CD player mechanism.

• Do not use adhesive labels. These labels can peel

away and jam the player mechanism.

• The Radio 130 is a single CD player. Do not attempt

to insert a second CD if one is already loaded.

• Dual-media disc types (one side is a DVD, the other

side is a CD) should not be used, and they can cause
damage to the player.

EJECT Button — Ejecting A CD

Push the EJECT button to eject the CD.

If you have ejected a disc and have not removed it within
10 seconds, it will be reloaded. If the CD is not removed,
the radio will reinsert the CD but will not play it.

A disc can be ejected with the radio and ignition OFF.

NOTE:

Ejecting with the ignition OFF is not allowed on

convertible or soft-top models (if equipped.)

352

MULTIMEDIA

SEEK Button

Push the right SEEK button for the next selection on the
CD. Push the left SEEK button to return to the beginning of
the current selection, or return to the beginning of the
previous selection if the CD is within the first second of the
current selection. Pushing and holding the SEEK button
will allow faster scrolling through the tracks in CD and
MP3 modes.

TIME Button

Push this button to change the display from a large CD
playing time display to a small CD playing time display.

RW/FF

Push and hold the FF (Fast Forward) button and the CD
player will begin to fast forward until FF is released, or RW
or another CD button is pushed. The RW (Reverse) button
operates in a similar manner.

AM/FM Button

Push the button to select either AM or FM mode.

SET/RND Button (Random Play Button)

Push this button while the CD is playing to activate
Random Play. This feature plays the selections on the
compact disc in random order to provide an interesting
change of pace.

Push the right SEEK button to move to the next randomly
selected track.

Push the RND button a second time to stop Random Play.

Notes On Playing MP3 Files

The radio can play MP3 files; however, acceptable MP3 file
recording media and formats are limited. When writing
MP3 files, pay attention to the following restrictions.

Supported Media (Disc Types)

The MP3 file recording media supported by the radio are
CDDA, CD-R, CD-RW, MP3, and CDDA+MP3.

Supported Medium Formats (File Systems)

The medium formats supported by the radio are ISO 9660
Level 1 and Level 2 and includes the Joliet extension. When
reading discs recorded using formats other than ISO 9660

MULTIMEDIA

353

Level 1 and Level 2, the radio may fail to read files properly
and may be unable to play the file normally. UDF and
Apple HFS formats are not supported.

The radio uses the following limits for file systems:

• Maximum number of folder levels: 8
• Maximum number of files: 255
• Maximum number of folders. (The radio display of file

names and folder names is limited. For large numbers of
files and/or folders, the radio may be unable to display
the file name and folder name, and will assign a number
instead. With a maximum number of files, exceeding 20
folders will result in this display. With 200 files, exceed-
ing 50 folders will result in this display.)

Maximum number of characters in file/folder names:

• Level 1: 12 (including a separator ⬙.⬙ and a three-

character extension)

• Level 2: 31 (including a separator ⬙.⬙ and a three-

character extension)

Multi-session disc formats are supported by the radio.
Multi-session discs may contain combinations of normal
CD audio tracks and computer files (including MP3 files).

Discs created with an option such as

⬙keep disc open after

writing

⬙ are most likely multi-session discs. The use of

multi-session for CD audio or MP3 playback may result in
longer disc loading times.

Supported MP3 File Formats

The radio will recognize only files with the *.MP3 exten-
sion as MP3 files. Non-MP3 files named with the *.MP3
extension may cause playback problems. The radio is
designed to recognize the file as an invalid MP3 and will
not play the file.

When using the MP3 encoder to compress audio data to an
MP3 file, the bit rate and sampling frequencies in the
following table are supported. In addition, variable bit
rates (VBR) are also supported. The majority of MP3 files
use a 44.1 kHz sampling rate and a 192, 160, 128, 96 or VBR
bit rate.

MPEG Specifi-

cation

Sampling Fre-

quency (kHz)

Bit Rate (kbps)

MPEG-1 Audio

Layer 3

48, 44.1, 32

320, 256, 224,
192, 160, 128,

112, 96, 80, 64,

56, 48, 40, 32

354

MULTIMEDIA

MPEG Specifi-

cation

Sampling Fre-

quency (kHz)

Bit Rate (kbps)

MPEG-2 Audio

Layer 3

24, 22.05, 16

160, 128, 144,

112, 96, 80, 64,

56, 48, 40, 32, 24,

16, 8

ID3 Tag information for artist, song title, and album title
are supported for version 1 ID3 tags. ID3 version 2 is not
supported by the radios.

Playlist files are not supported. MP3 Pro files are not
supported.

Playback Of MP3 Files

When a medium containing MP3 data is loaded, the radio
checks all files on the medium. If the medium contains a lot
of folders or files, the radio will take more time to start
playing the MP3 files.

Loading times for playback of MP3 files may be affected by
the following:

• Media - CD-RW media may take longer to load than

CD-R media

• Medium formats - Multisession discs may take longer to

load than non-multisession discs

• Number of files and folders - Loading times will increase

with more files and folders

To increase the speed of disc loading, it is recommended to
use CD-R media and single-session discs. To create a
single-session disc, enable the “Disc at Once” option before
writing to the disc.

LIST Button — CD Mode For MP3 Play

Pushing the LIST button will bring up a list of all folders on
the disc. Scrolling up or down the list is done by turning
the TUNE/SCROLL control knob. Selecting a folder by
pushing the TUNE/SCROLL control knob will begin play-
ing the files contained in that folder (or the next folder in
sequence if the selection does not contain playable files).

The folder list will time out after five seconds.

INFO Button — CD Mode For MP3 Play

Pushing the INFO button repeatedly will scroll through the
following TAG information: Song Title, Artist, File Name,
and Folder Name (if available).

Push the INFO button once more to return to

⬙elapsed

time

⬙ priority mode.

MULTIMEDIA

355

Push and hold the INFO button for three seconds or more
and the radio will display song titles for each file.

Push and hold the INFO button again for three seconds to
return to

⬙elapsed time⬙ display.

Operation Instructions — Auxiliary Mode

The auxiliary (AUX) jack is an audio input jack which
allows the user to plug in a portable device such as an MP3
player and utilize the vehicle’s audio system to amplify the
source and play through the vehicle speakers.

Pushing the AUX button will change the mode to auxiliary
device if the AUX jack is connected.

NOTE:

The AUX device must be turned on and the

device’s volume set to the proper level. If the AUX audio is
not loud enough, turn the device’s volume up. If the AUX
audio sounds distorted, turn the device’s volume down.

TIME Button (Auxiliary Mode)

Push this button to change the display to time of day. The
time of day will display for five seconds (when the ignition
is OFF).

Uconnect (Satellite Radio) — If Equipped

Satellite radio uses direct satellite-to-receiver broadcasting
technology to provide clear digital sound, coast to coast.
The subscription service provider is Sirius Satellite Radio.
This service offers over 130 channels of music, sports,
news, entertainment, and programming for children, di-
rectly from its satellites and broadcasting studios.

NOTE:

Sirius service is not available in Hawaii and has

limited coverage in Alaska.

System Activation

Sirius Satellite Radio service is pre-activated, and you may
begin listening immediately to the one year of audio
service that is included with the factory-installed satellite
radio system in your vehicle. Sirius will supply a welcome
kit that contains general information, including how to
setup your online listening account. For further informa-
tion, call the toll-free number 888-539-7474, or visit the
Sirius

web

site

www.siriusxm.com,

www.siriusxm.ca for Canadian residents.

356

MULTIMEDIA

Electronic Serial Number/Sirius Identification
Number (ESN/SID)

Please have the following information available when
calling:

1. The Electronic Serial Number/Sirius Identification

Number (ESN/SID).

2. Your Vehicle Identification Number.

To access the ESN/SID, refer to the following steps:

ESN/SID Access

With the ignition switch in the ON/RUN or ACC position
and the radio on, push the SETUP button and scroll using
the TUNE/SCROLL control knob until Sirius ID is selected.
Push the TUNE/SCROLL control knob and the Sirius ID
number will display. The Sirius ID number display will
time out in two minutes. Push any button on the radio to
exit this screen.

Selecting Uconnect (Satellite) Mode

Push the SAT button until

⬙SAT⬙ appears in the display. A

CD may remain in the radio while in the Satellite radio
mode.

Satellite Antenna

To ensure optimum reception, do not place items on the
roof around the rooftop antenna location. Metal objects
placed within the line of sight of the antenna will cause
decreased performance. Larger luggage items such as bikes
should be placed as far rearward as possible, within the
loading design of the rack. Do not place items directly on
or above the antenna.

Reception Quality

Satellite reception may be interrupted due to one of the
following reasons:

• The vehicle is parked in an underground parking struc-

ture or under a physical obstacle.

• Dense tree coverage may interrupt reception in the form

of short audio mutes.

• Driving under wide bridges or along tall buildings can

cause intermittent reception.

• Placing objects over or too close to the antenna can cause

signal blockage.

MULTIMEDIA

357

Operating Instructions — Uconnect (Satellite)
Mode

NOTE:

The ignition switch must be in the ON/RUN or

ACC position to operate the radio.

SEEK Buttons

Push and release the SEEK buttons to search for the next
listenable station in AM/FM mode. Push the right switch
to seek up and the left switch to seek down. The radio will
remain tuned to the new station until you make another
selection. Holding either button will bypass stations with-
out stopping, until you release it.

SCAN Button

Pushing the SCAN button causes the tuner to search for the
next channel, pausing for eight seconds before continuing
to the next. To stop the search, push the SCAN button a
second time.

INFO Button

Pushing the INFO button will cycle the display informa-
tion between Artist, Song Title, and Composer (if avail-
able). Also, pushing and holding the INFO button for an

additional three seconds will make the radio display the
Song Title all of the time (push and hold again to return to
normal display).

RW/FF

Pushing the RW (Rewind) or FF (Fast Forward) buttons
causes the tuner to search for the next channel in the
direction of the arrows.

TUNE Control

Turn the rotary TUNE/SCROLL control knob clockwise to
increase or counterclockwise to decrease the frequency.

MUSIC TYPE Button

Pushing this button once will turn on the Music Type mode
for five seconds. Pushing the MUSIC TYPE button or
turning the TUNE/SCROLL control knob within five sec-
onds will allow the program format type to be selected.

Toggle the MUSIC TYPE button again to select the music
type.

By pushing the SEEK button when the Music Type function
is active, the radio will be tuned to the next channel with
the same selected Music Type name.

358

MULTIMEDIA

If a preset button is activated while in the Music Type
(Program Type) mode, the Music Type mode will be exited
and the radio will tune to the preset channel.

SETUP Button

Pushing the SETUP button allows you to select the follow-
ing items:

• Display Sirius ID number — Push the AUDIO/SELECT

button to display the Sirius ID number. This number is
used to activate, deactivate, or change the Sirius sub-
scription.

SET Button — To Set The Pushbutton Memory

When you are receiving a channel that you wish to commit
to push button memory, push the SET button. The symbol
SET 1 will now show in the display window. Select the
button (1-6) you wish to lock onto this channel and push
and release that button. If a button is not selected within
five seconds after pushing the SET button, the channel will
continue to play but will not be stored into push button
memory.

You may add a second channel to each push button by
repeating the above procedure with this exception: Push
the SET button twice and SET 2 will show in the display
window. Each button can be set for SET 1 and SET 2. This

allows a total of 12 Satellite channels to be stored into push
button memory. The channels stored in SET 2 memory can
be selected by pushing the push button twice.

Every time a preset button is used, a corresponding button
number will display.

Buttons 1 - 6

These buttons tune the radio to the channels that you
commit to pushbutton memory (12 Satellite stations).

Operating Instructions (Uconnect Phone) — If
Equipped

Refer to “Uconnect Phone” in “Multimedia”.

RADIO 430/430N CD/DVD/HDD/NAV — IF
EQUIPPED

Refer to your Uconnect Owner’s Manual Supplement for
detailed operating instructions.

Operating Instructions (Voice Command System) —
If Equipped

Refer to “Voice Command” in “Multimedia” for further
details.

MULTIMEDIA

359

Operating Instructions (Uconnect Phone) — If
Equipped

Refer to “Uconnect Phone” in “Multimedia” for further
details.

CYBERSECURITY

Your vehicle may be a connected vehicle and may be
equipped with both wired and wireless networks. These
networks allow your vehicle to send and receive informa-
tion. This information allows systems and features in your
vehicle to function properly.

Your vehicle may be equipped with certain security fea-
tures to reduce the risk of unauthorized and unlawful
access to vehicle systems and wireless communications.
Vehicle software technology continues to evolve over time
and FCA US LLC, working with its suppliers, evaluates
and takes appropriate steps as needed. Similar to a com-
puter or other devices, your vehicle may require software
updates to improve the usability and performance of your
systems or to reduce the potential risk of unauthorized and
unlawful access to your vehicle systems.

The risk of unauthorized and unlawful access to your
vehicle systems may still exist, even if the most recent
version of vehicle software (such as Uconnect software) is
installed.

WARNING!

• It is not possible to know or to predict all of the

possible outcomes if your vehicle’s systems are
breached. It may be possible that vehicle systems,
including safety related systems, could be impaired
or a loss of vehicle control could occur that may
result in an accident involving serious injury or
death.

• ONLY insert media (e.g., USB, SD card, or CD) into

your vehicle if it came from a trusted source. Media
of unknown origin could possibly contain malicious
software, and if installed in your vehicle, it may
increase the possibility for vehicle systems to be
breached.

• As always, if you experience unusual vehicle behav-

ior, take your vehicle to your nearest authorized
dealer immediately.

360

MULTIMEDIA

NOTE:

• FCA or your dealer may contact you directly regarding

software updates.

• To help further improve vehicle security and minimize

the potential risk of a security breach, vehicle owners
should:

• Routinely

check

www.driveuconnect.com/

software-update to learn about available Uconnect
software updates.

• Only connect and use trusted media devices (e.g.

personal mobile phones, USBs, CDs).

Privacy of any wireless and wired communications cannot
be assured. Third parties may unlawfully intercept infor-
mation and private communications without your consent.
For further information, refer to “Onboard Diagnostic
System (OBD II) Cybersecurity” in “Getting To Know Your
Instrument Panel”.

STEERING WHEEL AUDIO CONTROLS

The remote sound system controls are located on the rear
surface of the steering wheel. Reach behind the wheel to
access the switches.

The right-hand control is a rocker-type switch with a
pushbutton in the center and controls the volume and
mode of the sound system. Pushing the top of the rocker
switch will increase the volume, and pushing the bottom of
the rocker switch will decrease the volume.

Pushing the center button will make the radio switch
between the various modes available (AM/FM/SAT/CD/
HDD/AUX/VES, etc.).

Remote Sound System Controls (Back View Of Steering

Wheel)

MULTIMEDIA

361

The left-hand control is a rocker-type switch with a push-
button in the center. The function of the left-hand control is
different depending on which mode you are in.

The following describes the left-hand control operation in
each mode.

Radio Operation

Pushing the top of the switch will “Seek” up for the next
listenable station and pushing the bottom of the switch will
“Seek” down for the next listenable station.

The button located in the center of the left-hand control
will tune to the next preset station that you have pro-
grammed in the radio preset button.

CD Player

Pushing the top of the switch once will go to the next track
on the CD. Pushing the bottom of the switch once will go
to the beginning of the current track, or to the beginning of
the previous track if it is within eight seconds after the
current track begins to play.

If you push the switch up or down twice, it plays the
second track; three times, it will play the third, etc.

The center button on the left side rocker switch has no
function for a single-disc CD player. However, when a
multiple-disc CD player is equipped on the vehicle, the
center button will select the next available CD in the player.

AUX/USB/MP3 CONTROL — IF EQUIPPED

This feature allows an iPod or external USB device to be
plugged into the USB port, located in the center console or
glove compartment.

iPod control supports Mini, 4G, Photo, Nano, 5G iPod and
iPhone devices. Some iPod software versions may not fully
support the iPod control features. Please visit Apple’s
website for software updates.

NOTE:

• If the radio has a USB port, refer to the appropriate

Uconnect Owner’s Manual Supplement for iPod or
external USB device support capability.

• Connecting an iPod or consumer electronic audio device

to the AUX port located in the radio faceplate, plays
media, but does not use the iPod/MP3 control feature to
control the connected device.

362

MULTIMEDIA

WARNING!

Do not plug in or remove the iPod or external device
while driving. Failure to follow this warning could
result in a collision.

Connecting The iPod Or External USB Device

Use the connection cable to connect an iPod or external
USB device to the vehicle’s USB/AUX connector port
which is located in the center console or glove compart-
ment.

Once the audio device is connected and synchronized to
the vehicle’s AUX/USB/MP3 control system (iPod or
external USB device may take a few minutes to connect),
the audio device starts charging and is ready for use by
pushing radio switches, as described below.

NOTE:

If the audio device battery is completely dis-

charged, it may not communicate with the AUX/USB/
MP3 control system until a minimum charge is attained.
Leaving the audio device connected to the AUX/USB/MP3
control system may charge it to the required level.

Using This Feature

By using an external USB device to connect to the USB port:

• The audio device can be played on the vehicle’s sound

system, providing metadata (artist, track title, album,
etc.) information on the radio display.

• The audio device can be controlled using the radio

buttons to Play, Browse, and List the iPod contents.

• The audio device battery charges when plugged into the

USB connector (if supported by the specific audio de-
vice).

AUX/USB Connector Ports

MULTIMEDIA

363

Controlling The iPod Or External USB Device
Using Radio Buttons

To enter the AUX/USB/MP3 control mode and access a
connected audio device, either push the “AUX” button on
the radio faceplate or push the VR button and say

⬙USB⬙ or

⬙Switch to USB.⬙ Once in the AUX/USB/MP3 control
mode, audio tracks (if available from audio device) start
playing over the vehicle’s audio system.

Play Mode

When switched to AUX/USB/MP3 control mode, the iPod
or external USB device automatically starts Play mode. In
Play mode, the following buttons on the radio faceplate
may be used to control the iPod or external USB device and
display data:

• Use the TUNE control knob to select the next or previ-

ous track.

• Turning it clockwise (forward) by one click, while play-

ing a track, skips to the next track or push the VR button
and say

⬙Next Track.⬙

• Turning it counterclockwise (backward) by one click,

will jump to the previous track in the list or push the VR
button and say

⬙Previous Track.⬙

• Jump backward in the current track by pushing and

holding the << RW button. Holding the << RW button
long enough will jump to the beginning of the current
track.

• Jump forward in the current track by pushing and

holding the FF >> button.

• A single push backward << RW or forward FF >> will

jump backward or forward respectively, for five seconds.

• Use the << SEEK and SEEK >> buttons to jump to the

previous or next track. Pushing the SEEK >> button
during play mode will jump to the next track in the list,
or push the VR button and say

⬙Next or Previous Track.⬙

• While a track is playing, push the INFO button to see the

associated metadata (artist, track title, album, etc.) for
that track. Pushing the INFO button again jumps to the
next screen of data for that track. Once all screens have
been viewed, the last INFO button push will go back to
the play mode screen on the radio.

• Pushing the REPEAT button will change the audio

device mode to repeat the current playing track or push
the VR button and say

⬙Repeat ON⬙ or ⬙Repeat Off.⬙

364

MULTIMEDIA

• Push the SCAN button to use AUX/USB/MP3 device

scan mode, which will play the first ten seconds of each
track in the current list and then forward to the next
song. To stop SCAN mode and start playing the desired
track, when it is playing the track, push the SCAN
button again. During Scan mode, pushing the << SEEK
and SEEK >> buttons will select the previous and next
tracks.

• RND button (available on sales code RES radio only):

Pushing this button toggles between Shuffle ON and
Shuffle OFF modes for the iPod or external USB device,
or push the VR button and say

⬙Shuffle ON⬙ or ⬙Shuffle

Off.

⬙ If the RND icon is showing on the radio display,

then the shuffle mode is ON.

List Or Browse Mode

During Play mode, pushing any of the buttons described
below, will bring up List mode. List mode enables scrolling
through the list of menus and tracks on the audio device.

TUNE

control knob: The TUNE control knob functions in

a similar manner as the scroll wheel on the audio device or
external USB device.

• Turning it clockwise (forward) and counterclockwise

(backward) scrolls through the lists, displaying the track

detail on the radio display. Once the track to be played
is highlighted on the radio display, push the TUNE
control knob to select and start playing the track. Turn-
ing the TUNE control knob fast will scroll through the
list faster. During fast scroll, a slight delay in updating
the information on the radio display may be noticeable.

During all List modes, the iPod displays all lists in “wrap-
around” mode. So if the track is at the bottom of the list,
just turn the wheel backward (counterclockwise) to get to
the track faster.

In List mode, the radio PRESET buttons are used as
shortcuts to the following lists on the iPod or external USB
device:

• Preset 1 – Playlists
• Preset 2 – Artists
• Preset 3 – Albums
• Preset 4 – Genres
• Preset 5 – Audiobooks
• Preset 6 – Podcasts

MULTIMEDIA

365

Pushing a PRESET button will display the current list on
the top line and the first item in that list on the second line.

To exit List mode without selecting a track, push the same
PRESET

button again to go back to Play mode.

LIST

button: The LIST button will display the top level

menu of the iPod or external USB device.

• Turn the TUNE control knob to list the top-menu item to

be selected and push the TUNE control knob. This will
display the next sub-menu list item on the audio device,
then follow the same steps to go to the desired track in
that list. Not all iPod or external USB device sub-menu
levels are available on this system.

MUSIC TYPE

button: The MUSIC TYPE button is another

shortcut button to the genre listing on your audio device.

WARNING!

Do not plug in or remove the iPod or external USB
device while driving. Failure to follow this warning
could result in an accident.

CAUTION!

• Leaving the iPod or external USB device (or any

supported device) anywhere in the vehicle in ex-
treme heat or cold can alter the operation or damage
the device. Follow the device manufacturer’s guide-
lines.

• Placing items on the iPod or external USB device, or

connections to the iPod or external USB device in the
vehicle, can cause damage to the device and/or to the
connectors.

Bluetooth Streaming Audio (BTSA)

Music can be streamed from your cellular phone to the
Uconnect phone system.

Refer to the Uconnect Owner’s Manual Supplement for
further information on Bluetooth connectivity.

Controlling BTSA Using Radio Buttons

To enter BTSA mode, push either “AUX” button on the
radio or push the VR

button and say “Bluetooth

Streaming Audio.”

366

MULTIMEDIA

Play Mode

When switched to BTSA mode, some audio devices can
start playing music over the vehicle’s audio system, but
some devices require the music to be initiated on the device
first, then it will get streamed to the Uconnect phone
system. Seven devices can be paired to the Uconnect phone
system, but just one can be selected and played.

Selecting A Different Audio Device

1. Push the Phone

button to begin.

2. After the

⬙Ready⬙ prompt and following the beep, say

⬙Setup⬙, then say ⬙Select Audio Devices.⬙

3. Say the name of the audio device or ask the Uconnect

phone system to list the audio devices.

Next Track

Use the SEEK UP button, or push the VR

button on the

radio and say “Next Track,” to jump to the next music
track on your cellular phone.

Previous Track

Use the SEEK DOWN button, or push the VR

button on

the radio and say “Previous Track,” to jump to the
previous music track on your cellular phone.

Browse

Browsing is not available on a Bluetooth Streaming Audio
(BTSA) device. Only the current song that is playing will
display info.

UCONNECT PHONE — IF EQUIPPED

Uconnect Phone is a voice-activated, hands-free, in-vehicle
communications system. Uconnect Phone allows you to dial
a phone number with your mobile phone using simple voice
commands (e.g., “Call”

ѧ “Mike” ѧ “Work” or “Dial” ѧ

“248-555-1212”). Your mobile phone’s audio is transmitted
through your vehicle’s audio system; the system will auto-
matically mute your radio when using the Uconnect Phone.

MULTIMEDIA

367

Jeep Patriot (2017 year). Manual - part 23
