Jaguar XK. Service manual - part 7

31

Introduction

R

Introduction

SYMBOLS GLOSSARY

Warnings

Cautions

Symbols

This recycling symbol
identifies those items that must
be disposed of safely in order

to prevent unnecessary damage to the
environment.

This symbol identifies those
features that can be adjusted,
disabled or enabled by a

Jaguar Dealer.

LABEL LOCATIONS

Warning labels attached to
your vehicle bearing this
symbol mean: Do not touch or
adjust components until you

have read the relevant instructions in the
handbook.

Labels showing this symbol
indicate that the ignition
system utilises very high
voltages. Do not touch any

ignition components while the starter
switch is turned on.

Warning labels

Labels are attached to your vehicle at
several positions. These are applied to
draw your attention to important
subjects, e.g. tire pressures, air bags,
engine compartment hazards, etc.

1. Vehicle certification, Air bag, Child

restraint, Tire placard.

2. Air conditioning, Emissions.

3. Under hood warnings.

4. Coolant warnings.

5. Fuel warnings.

WARNING

Safety warnings are included in
this handbook. These indicate
either a procedure which must be

followed precisely, or information that
should be considered with great care in
order to avoid the possibility of personal
injury.

CAUTION

Cautions are included in this
handbook. These indicate either a
procedure which must be followed

precisely, or information that should be
considered with great care in order to
avoid the possibility of damage to your
vehicle.

E83651

E83652

1

2

6

1

2

3

5

4

E90641

Introduction

32

L

6. Battery.

It is important that you are familiar with
these subjects to ensure that your vehicle
and its features are used safely. Using the
index at the back of this handbook, refer
to the relevant topic for more information.

HEALTH AND SAFETY

DATA RECORDING

Service data recording

Service data recorders in your vehicle are
capable of collecting and storing
diagnostic information about your
vehicle. This potentially includes
information about the performance or
status of various systems and modules in
the vehicle such as engine, throttle,
steering or brakes.

In order to properly diagnose and service
your vehicle, Jaguar Cars Limited and
service and repair facilities may access
vehicle diagnostic information through a
direct connection to your vehicle.

Event data recording

Event data recorders are capable of
collecting and storing data during a crash
or near-crash event. The recorded
information may assist in the
investigation of such an event. The
modules may record information about
both the vehicle and the occupants,
potentially including information such as:
• How various systems in your vehicle

were operating.

• Whether or not the driver and

passenger seat belts were buckled.

• How far, if at all, the driver was

depressing the accelerator and/or the
brake pedal.

• How fast the vehicle was travelling.
• Where the driver was positioning the

steering wheel.

WARNINGS

The vehicle should not be parked
over long dry grass or other
combustible material, particularly

during dry weather. As the heat
generated by the exhaust and emission
control systems may be sufficient to start
a fire.

Before exiting the vehicle, ensure
the P park is selected and the
parking brake is applied. When

exiting the vehicle make sure that the
Jaguar Smart Key is removed from the
vehicle.

Many liquids and other
substances used in vehicles are
poisonous and should never be

consumed and must be kept away from
open wounds. These substances include
anti-freeze, brake fluid, fuel, windshield
washer additives, lubricants and various
adhesives.

33

Introduction

R

To access this information special
equipment must be connected directly to
the recording modules. Jaguar Cars
Limited do not access event data
recorder information without obtaining
consent, unless pursuant to court order
or where required by law enforcement,
other government authorities or third
parties acting with lawful authority.

Other parties may seek to access the
information independently of Jaguar Cars
Limited.

DISABILITY MODIFICATIONS

CALIFORNIA PROPOSITION 65

REPORTING SAFETY DEFECTS

Vehicle defects (U.S. only)

If you believe that your vehicle has a
defect which could cause a crash or
could cause injury or death, you should
immediately inform the National Highway
Traffic Safety Administration (NHTSA) in
addition to notifying Jaguar Cars.

If NHTSA receives similar complaints,
it may open an investigation, and if it
finds that a safety defect exists in a group
of vehicles, it may order a recall and
remedy campaign.

WARNING

Occupants with disabilities that
may require the vehicle to be
modified must contact a Jaguar

Dealer before any modifications are
made.

(USA only) If you are considering
modifying your vehicle in any way to
accommodate a disability, for example
by altering or adapting the driver’s or
passenger’s seat(s) or air bag system,
please contact Jaguar Cars at:

Jaguar Cars

Customer Relations Center

555 MacArthur Blvd

Mahwah

New Jersey 07430-2327

1-800-4JAGUAR OPTIONS 9.

WARNINGS

California Proposition 65: Engine
exhaust, some of its constituents
and certain vehicle components,

contain or emit chemicals known to the
State of California to cause cancer and
birth defects or other reproductive harm.
In addition, certain fluids contained in
vehicles and certain products of
component wear contain or emit
chemicals known to the State of
California to cause cancer and birth
defects or other reproductive harm.

battery posts, terminals and
related accessories contain lead
and lead compounds. Wash

hands after handling.

Certain copmonents of this
vehicle such as air bag modules
and seat belt pretensioners may

contain Perchlorate Material -- Special
handling may apply for service or vehicle
end of life disposal. See
www.dtsc.ca.gov/hazardouswaste/pe
rchlorate.

Introduction

34

L

However, NHTSA cannot become
involved in individual problems between
you, your Dealer, or Jaguar Cars.

To contact NHTSA, you may call the
Vehicle Safety Hotline toll-free
at 1-888-327-4236 (TTY:
1-800-424-9153); go to
http://www.safercar.gov; or write to:

Administrator, NHTSA, 400 Seventh
Street SW., Washington, DC. 20590.

To contact Jaguar Cars, call 1-800 4
Jaguar.

You can also obtain other information
about motor safety from
http://www.safercar.gov.

Vehicle defects (Canada only)

If you believe that your vehicle has a
defect which could cause a crash or
could cause injury or death, you should
immediately inform Transport Canada in
addition to notifying Jaguar Cars.

To contact Transport Canada, call their
toll-free number 1-800-333-0510.

PARTS AND ACCESSORIES

The vehicle has been designed, built and
tested to cope with a variety of driving
conditions, some of which can place the
severest possible demands on control
systems and components. As such,
fitting replacement parts and accessories
that have been developed and tested to
the same stringent standards as the
original components will safeguard the
continued reliability, safety and
performance of your vehicle.

To augment the vehicle's already
impressive performance, a
comprehensive range of Jaguar
approved spare parts and accessories is
available.

Jaguar parts are the only parts built to
original equipment specifications and
approved by Jaguar designers; this
means that every single part and
accessory has been rigorously tested by
the same engineering team that designed
and built the vehicle.

A full list and description of all
accessories is available from your Jaguar
Dealer.

WARNINGS

The fitting of non-approved parts
and accessories, or the carrying
out of non-approved alterations or

conversions, may be dangerous and
could affect the safety of the vehicle and
occupants and also invalidate the terms
and conditions of the vehicle warranty.

Jaguar will not accept any liability
for death, personal injury or
damage to property which may

occur as a direct result of fitment of
non-approved accessories or the
carrying out of non-approved
conversions to Jaguar vehicles.

Jaguar strongly advise against
making any modifications to the
suspension or steering system.

This could seriously affect the handling
and stability of the vehicle leading to loss
of control or rollover.

WARNINGS
