4C–8
DRIVE SHAFT SYSTEM
7. Apply Multipurpose grease NLGI No.2 in the hub and
bearing.
Hub
35 g (1.23 oz)
Outer bearing
10 g (0.35 oz)
Inner bearing
15 g (0.53 oz)
8. Install hub nut by using wrench J–36827.
Turn the place where there is a chamfer in the tapped
hole to the outer side, and attach the nut.
901RW054
Preload Adjustment
1. Tighten the hub nut to 29.4 N·m (21.7 lb ft), then
loosen the nut to the full.
2. Tighten the hub nut to the value given below,
using a spring scale on the wheel pin.
Bearing Preload
New bearing and New
oil seal
19.6 – 24.5 N
(4.4 – 5.5 lb)
Used bearing and New
oil seal
11.8 – 17.7 N
(2.6 – 4.0 lb)
If the measured bearing preload is outside the
specifications, adjust it by loosening or tightening
the bearing nut.
411RS011
9. Install lock washer.
D
Turn the side with larger diameter of the tapered
bore to the vehicle outer side, then attach the
washer.
If the bolt holes in the lock plate are not aligned with
the corresponding holes in the nut, reverse the lock
plate. If the bolt holes are still out of alignment, turn
in the nut just enough to obtain alignment. Screw is
to be fastened tightly so its head may come lower
than the surface of the washer.
411RS012
10. Install the paking.
11. Install cover and tighten the cover bolt.
12. Install brake caliper and tighten fixing bolt.
