Operating door locks from

• If the inner door handle of the dri-

With the central door lock switch:

inside the vehicle

ver’s (or front passenger’s) door is

■ Driver’s door

pulled when the door lock button is

With the door lock button:

in the lock position, the button is

unlocked and the door will open.

• The front doors cannot be locked if

the key is in the vehicle and any

front door is open.

3

• The doors cannot be locked if the

Lock

smart key is in the vehicle and any

Unlock

door is open.

OLMB043207

■ Passenger’s door

✽ NOTICE

If a power door lock ever fails to

function while you are in the vehicle

OLMB043206

try one or more of the following

•

To unlock a door, push the door

techniques to exit:

lock button (1) to the “Unlock” posi-

Operate the door unlock feature

tion. The red mark (2) on the door

repeatedly

(both electronic and

lock button will be visible.

manual) while simultaneously

•

To lock a door, push the door lock

pulling on the door handle.

button (1) to the “Lock” position. If

Operate the other door locks and

OLM049209N

the door is locked properly, the red

handles, front and rear.

When pressing the front portion (1) of

mark (2) on the door lock button

Lower a front window and use the

the switch, all vehicle doors will lock.

will not be visible.

mechanical key to unlock the door

When pressing the rear portion (2) of

•

To open a door, pull the door han-

from outside.

the switch, all vehicle doors will

dle (3) outward.

unlock.

3-11

Convenient features of your vehicle

• If the key is in the vehicle and any

WARNING

WARNING

door is opened, the doors will not

lock even though the lock button

Do not leave children or animals

Always secure your vehicle.

(1) of the central door lock switch is

unattended in your vehicle. An

pressed.

Leaving your vehicle unlocked

enclosed vehicle can become

increases the potential risk to

• If the smart key is in the vehicle

extremely hot, causing death or

you or others from someone hid-

and any door is opened, the doors

serious injury to unattended

ing in your vehicle.

will not lock even though the lock

children or animals who cannot

button (1) of the central door lock

To secure your vehicle, while

escape the vehicle. Children

switch is pressed.

depressing the brake, move the

might operate features of the

shift lever to the P (Park) posi-

vehicle that could injure them,

tion, engage the parking brake,

WARNING

or they could encounter other

and place the POWER button in

harm, possibly from someone

the LOCK/OFF position, close

The doors should always be

gaining entry to the vehicle.

all windows, lock all doors, and

fully closed and locked while

always take the key with you.

the vehicle is in motion. If the

doors are unlocked, the risk of

being thrown from the vehicle in

WARNING

a crash is increased.

Opening a door when something

is approaching may cause dam-

age or injury. Be careful when

opening doors and watch for

vehicles, motorcycles, bicycles

or pedestrians approaching the

vehicle in the path of the door.

3-12

Auto door lock/unlock features

Child-protector rear door locks

To allow a rear door to be opened

from inside the vehicle, unlock the

• All doors will be automatically

child safety lock.

locked when moving the shift lever

out of P (Park) when the vehicle is

in READY mode.

WARNING

• All doors will be automatically

If children accidently open the

unlocked when shifting the gear

rear doors while the vehicle is

3

shift lever shift lever into P (Park)

in motion, they could fall out of

with the vehicle is running.

the vehicle. The rear door safety

locks should always be used

✽ NOTICE

whenever children are in the

vehicle.

An authorized HYUNDAI Tucson

OLMB043208

Fuel Cell dealer can activate or

deactivate

some auto door

The child safety lock is provided to

lock/unlock features as follows:

help prevent children seated in the

• Auto door unlock by using the dri-

rear from accidentally opening the

ver's door lock button

rear doors. The rear door safety locks

• Auto door unlock when the power

should be used whenever children

cell module is off.

are in the vehicle.

• Auto door lock/unlock by shifting

The child safety lock is located on

the shift lever out of P (Park) or

the edge of each rear door. When the

into P (Park)

child safety lock is in the lock position

If you want to activate or deactivate

(

), the rear door will not open if

some door lock/unlock feature, con-

the inner door handle (1) is pulled.

sult an authorized HYUNDAI

Tucson Fuel Cell dealer.

3-13

STEERING WHEEL

Electric Power Steering (EPS)

✽ NOTICE

Tilt steering/Telescope steering

This system assists you with steering

•

The steering effort may be high

the vehicle.

immediately after placing the

POWER button in the ON posi-

If the power cell module is turned off

tion. This happens as the system

or if the EPS becomes inoperative,

performs the EPS system diagnos-

you may still steer the vehicle, but it

tics. When the diagnostics are

will require increased steering effort.

completed, the steering effort will

3

Should you notice any change in the

return to its normal condition.

effort required to steer during normal

•

A click noise may be heard from

vehicle operation, have the EPS

the EPS relay after the POWER

checked by an authorized HYUNDAI

button is placed in the ON or

Tucson Fuel Cell dealer.

LOCK/OFF position.

OLMB043225

•

A motor noise may be heard when

CAUTION

the vehicle is at a stop or at a low

Pull down the lock-release lever (1)

driving speed.

on the steering wheel column and

If the Electric Power Steering

•

When you operate the vehicle in

adjust the steering wheel angle (2)

System does not operate nor-

cold weather conditions, a noise

and position (3, if equipped). Move

mally, the warning light (

) will

may be heard when you operate

the steering wheel, so it points

illuminate on the instrument

the steering wheel. This is a nor-

toward your chest, not toward your

cluster. The steering wheel may

mal condition. When the ambient

face. Make sure you can see the

become difficult to control or

temperature increases, the noise

instrument panel warning lights and

operate. Take your vehicle to an

will disappear.

gauges. After adjusting, pull up the

authorized HYUNDAI Tucson

lock-release lever

(1) to lock the

Fuel Cell dealer and have the

steering wheel in place. Push the

steering wheel both up and down to

system checked as soon as

possible.

be certain it is locked in position.

Always adjust the position of the

steering wheel before driving.

3-15

Convenient features of your vehicle

Horn

WARNING

NEVER adjust the steering

wheel while driving. This may

cause loss of vehicle control

resulting in an accident.

OLMB043227

To sound the horn, press the area

indicated by the horn symbol on your

steering wheel (see illustration). The

horn will operate only when this area

is pressed.

CAUTION

Do not strike the horn severely

to operate it, or hit it with your

fist. Do not press on the horn

with a sharp-pointed object.

3-16

MIRRORS

Interior rearview mirrors

Electric chromic mirror (ECM)

WARNING

(if equipped)

Before you start driving, adjust the

rearview mirror to center the view

The electric rearview mirror automat-

To prevent serious injury during

through the rear window.

ically controls the glare from the

an accident or deployment of

headlights of the car behind you in

the air bag, do not modify the

nighttime or low light driving condi-

rearview mirror and do not

WARNING

tions.

install a wide mirror.

When the power cell module is run-

3

Make sure your line of sight is

ning, the glare is automatically con-

not obstructed. Do not place

trolled by the sensor mounted in the

objects in the rear seat, cargo

WARNING

rearview mirror. The sensor detects

area, or behind the rear head-

the light level around the vehicle, and

rests which could interfere with

NEVER adjust the mirror while

automatically adjusts to control the

your vision through the rear

driving. This may cause loss of

headlight glare from vehicles behind

window.

vehicle control resulting in an

you.

accident.

Whenever the shift lever is placed in

R (Reverse), the mirror will automat-

ically go to the brightest setting to

improve the driver’s view behind the

vehicle.

3-17

Convenient features of your vehicle

Electric chromic mirror (ECM)

CAUTION

with compass

Your vehicle may be equipped with a

When cleaning the mirror, use a

Rearview display

Gentex Automatic-Dimming Mirror

paper towel or similar material

with a Z-Nav™ Electronic Compass

dampened with glass cleaner.

Display.

Do not spray glass cleaner

directly on the mirror as that

During nighttime driving, this feature

may cause the liquid cleaner to

will automatically detect and reduce

Indicator

Sensor

enter the mirror housing and

rearview mirror glare while the com-

damage the rearview mirror.

pass indicates the direction the vehi-

cle is pointed.

OLMFC043301

To operate the electric rearview

mirror:

• Press the ON/OFF button (1) to

turn the automatic dimming func-

tion on. The mirror indicator light

will illuminate.

Press the ON/OFF button to turn

the automatic dimming function off.

The mirror indicator light will turn

off.

• The mirror defaults to the ON posi-

tion whenever the POWER button

is turned on.

3-18

Convenient features of your vehicle

Compass function

The Compass can be turned ON and

OFF and will remember the last state

when the POWER button is cycled.

To turn the display feature ON/OFF:

1. Press and release the button to

turn the display feature OFF.

2. Press and release the

button

again to turn the display back ON.

Additional options can be set with

press and hold sequences of the but-

ton and are detailed below.

There is a difference between mag-

netic north and true north. To com-

pensate for this difference you will

need to adjust the Zone setting

based on where you live.

B520C05NF

3-20

To adjust the Zone setting:

There are some conditions that can

If you need to recalibrate the com-

cause changes to the vehicle mag-

pass:

1. Determine the desired Zone

nets, such as installing a ski rack or

Number based upon your current

1. Press and hold the

button for

a CB antenna. Body repair work on

location on the Zone Map.

more than 6 seconds. When the

the vehicle can also cause changes

compass memory is cleared a "C"

2. Press and hold the

button for

to the vehicle's magnetic field. In

will appear in the display.

more than 3 but less than 6 sec-

these situations, the compass will

onds, the current Zone Number

2. Drive the vehicle in 2 complete cir-

need to be re-calibrated to quickly

will appear on the display.

cles at less than 5 mph (8 km/h).

3

correct these changes.

3. Pressing and holding the button

again will cause the numbers to

increment (Note: they will repeat

…13, 14, 15, 1, 2, …). Releasing

the button when the desired Zone

Number appears on the display

will set the new Zone.

4. Within about 5 seconds the com-

pass will start displaying a com-

pass heading again.

3-21

Convenient features of your vehicle

Outside rearview mirrors

WARNING

WARNING

•

The right outside rearview

Do not adjust or fold the outside

mirror is convex. Objects seen

rearview mirrors while driving.

in the mirror are closer than

This may cause loss of vehicle

they appear.

control resulting in an accident.

•

Use your interior rearview

mirror or turn your head and

look to determine the actual

CAUTION

distance of following vehicles

when changing lanes.

•

Do not scrape ice off the mir-

ror face; this may damage the

OLMB073045

surface of the glass.

Your vehicle is equipped with both left-

•

If the mirror is jammed with

hand and right-hand outside mirrors.

ice, do not adjust the mirror by

force. Use an approved de-icer

(not radiator antifreeze) spray,

or a sponge or soft cloth with

very warm water, or move the

vehicle to a warm place and

allow the ice to melt.

3-22

Folding the outside rearview

CAUTION

mirrors

•

The mirrors stop moving

when they reach the maxi-

mum adjusting angles, but the

motor continues to operate

while the switch is pressed.

3

Do not press the switch

longer than necessary; the

motor may be damaged.

•

Do not attempt to adjust the

OLMB043236/Q

outside rearview mirror by

Adjusting the rearview mirrors:

hand or the motor may be

Press either the L (driver’s side) or R

damaged.

OLMB043237

(passenger’s side) button

(1) to

To fold outside rearview mirror, grasp

select the rearview mirror you would

the housing of mirror and then fold it

like to adjust.

toward the rear of the vehicle.

Use the mirror adjustment control (2)

to position the selected mirror up,

down, left or right.

After adjustment, press the L or R

button (1) again to prevent inadver-

tent adjustment.

3-23

Convenient features of your vehicle

WINDOWS

(1) Driver’s door power window

switch

(2) Front passenger’s door power

window switch

(3) Rear door (left) power window

switch

(4) Rear door (right) power window

switch

(5) Window opening and closing

(6) Automatic power window

up*/down

(7) Power window lock switch

*: if equipped

OLMFC043007N

3-24

Power windows

Window opening and closing

Auto up/down window

The POWER button must be in the

Pressing or pulling up the power win-

ON position to be able to raise or

dow switch momentarily to the second

lower the windows.

detent position (6) completely lowers

or raises the window even when the

Each door has a Power Window

switch is released. To stop the window

switch to control that door's window.

at the desired position while the win-

The driver has a Power Window Lock

dow is in operation, pull up or press

3

switch which can block the operation

down and release the switch.

of passenger windows. The power

windows will operate for approxi-

mately 30 seconds after the POWER

To reset the power windows

button is placed in the ACC or

If the power windows do not operate

LOCK/OFF position. However, if the

OLMB043213

normally, the automatic power win-

front doors are opened, the Power

To open:

dow system must be reset as follows:

Windows cannot be operated even

Press the window switch down to the

1. Place the POWER button to the

within the 30 second period.

first detent position (5). Release the

ON position.

switch when you want the window to

2. Close the windows and continue

WARNING

stop.

pulling up on the power window

switch for at least one second.

To avoid serious injury or death,

do not extend your head, arms

To close:

If the power windows do not operate

or body outside the windows

properly after resetting, have the

Pull the window switch up to the first

while driving.

system checked by an authorized

detent position (5). Release the win-

HYUNDAI Tucson Fuel Cell dealer.

dow switch when you want the win-

dow to stop.

3-25

Convenient features of your vehicle

Automatic reverse

✽ NOTICE

Power window lock button

The automatic reverse feature is

only active when the “auto up” fea-

ture is used by fully pulling up the

switch to the second detent.

WARNING

Make sure heads, other body

parts or other objects are safely

out of the way before closing

the windows to avoid injuries or

OLMB043214

vehicle damage.

OLMB043215

Objects less than 0.16 inch (4

If a window senses any obstacle while

The driver can disable the power

mm) in diameter caught

it is closing automatically, it will stop

window switches on the passengers’

between the window glass and

and lower approximately 12 inches

doors by pressing the power window

the upper window channel may

(30 cm) to allow the object to be

lock switch.

not be detected by the automat-

cleared.

• The driver’s control can operate

ic reverse window and the win-

If the window detects the resistance

the driver’s power window.

dow will not stop and reverse

while the power window switch is

direction.

• The front passenger’s control can-

pulled up continuously, the window will

not operate the front passenger’s

stop upward movement then lower

power window.

approximately 1 inches (2.5 cm).

• The rear passenger’s control can-

If the power window switch is pulled

not operate the rear passenger’s

up continuously again within five

power window.

seconds after the window is lowered

by the automatic window reversal

feature, the automatic window rever-

sal will not operate.

3-26

WARNING

CAUTION

Do not allow children to play

• To prevent possible damage

with the power windows. Keep

to the power window system,

the driver’s door power window

do not open or close two win-

lock switch in the LOCK position

dows or more at the same

(indicator illuminated). Serious

time. This will also ensure the

3

injury or death can result from

longevity of the fuse.

unintentional window operation

• Never try to operate the main

by a child.

switch on the driver's door and

the individual door window

switch in opposing directions

at the same time. If this is

done, the window will stop and

cannot be opened or closed.

3-27

Content   ..  4  5  6  7   ..
