Hyundai i30 / Elantra Neos. Body repair manual - part 14

BODY DIMENSIONS

BD-11

Trim mounting passage hole
                                                  (ø10)

Front seat belt retractor mounting
hole                                           (ø12)

Pillar trim mounting hole          (ø8.5)

Cowl cross bar mounting hole
                                                    (ø9)

Pillar trim mounting hole
                                                 (ø8.5)

Side trim mounting hole              (ø8)

Seat belt height adjust upper
mounting hole                              (ø9)

Wheel house trim mounting hole
                                                 (ø8.4)

BFDBD6118

A,A'

BFDBD6121

D,D'

E,E'

H,H'

I,I'

L,L'

BEDBD6305

BFDBD6123

BFDBD6124

BFDBD6127

M,M'

O,O'

BFDBD6128

BFDBD6129A

BD-12

BODY DIMENSIONS

REAR BODY

*  These dimensions indicated in this figure are actual-measurement dimensions.

Point symbol

Length(mm)

Point symbol

Length(mm)

A-A'

D-D'

B-B'

D-F

B-D

D-F'

B-D'

E-E'

B-E

E-F

B-G

E-F'

C-C'

F-F'

C-G

625

1529

961

428

742

1371

1421

972

790

314

1034

1085

1219

1110

964

BFDBD6401

A

B

C

D

E

F

G

A'

B'

C'

D'

E'

F'

G'

BODY DIMENSIONS

BD-13

Tail gate hinge mounting hole
                                                  (ø12)

Side outer rear corner

 Tail gate striker mounting hole
                                                  (ø11)

Roof rear corner

Rear bumper mounting hole
                                        (   7.5X7.5)

Gas lifter mounting passage hole
                                                  (ø11)

Rear bumper mounting hole
                                          (    18X20)

BFDBD6134

BFDBD6134B

BFDBD6134A

BFDBD6405

A,A'

B,B'

C,C'

BFDBD6135

BFDBD6135A

BFDBD6135B

D,D'

E,E'

F,F'

G'

G

BD-14

BODY DIMENSIONS

UNDER BODY (PROJECTED DIMENSIONS)

*  These dimensions indicated in this figure are projected dimensions.

Point symbol

Length(mm)

Point symbol

Length(mm)

Point symbol

Length(mm)

A-A'

I-I'

O-J

B-B'

J-J'

A-C

C-C'

O-A

C-E

D-D'

O-C

E-F

E-E'

O-E

F-G

F-F'

O-F

G-H

G-G'

O-G

H-J

H-H'

O-H

1004

1061

178

1000

998

295

1000

174

763

630

184

1312

832

-73

363

848

-81

420

1100

98

489

993

131

BFDBD6201A

A

C

E

F

H

G

J

0

I

A

B

C

D

E

F

H

G

J

I'

A'

B'

C'

D'

E'

F'

H'

G'

J'
