Honda Ridgeline (2019 year). Manual - part 23





352

Features

Bluetooth® HandsFreeLink®

Bluetooth® HandsFreeLink® (HFL) allows you to place and receive phone calls using
your vehicle’s audio system, without handling your cell phone.

Using HFL

 (Pick-up) button: Press to go directly to the Phone screen or to answer an

incoming call.

 (Hang-up/Back) button: Press to end a call or to cancel a command.
 (Talk) button: Press to call a number with a stored voice tag.
 (Phone) button: Press to go directly to the Phone screen.

Selector knob: Rotate

 to select an item on the screen, then press

.

HFL Buttons

1

Using HFL

Place your phone where you can get good reception.

To use HFL, you need a Bluetooth-compatible cell
phone. For a list of compatible phones, pairing
procedures, and special feature capabilities:

U.S.: Visit automobiles.honda.com/handsfreelink/
or call 1-888-528-7876.

Canada: For more information on smartphone
compatibility, call 1-888-528-7876.

Voice control tips

Aim the vents away from the ceiling and close the
windows, as noise coming from them may interfere
with the microphone.

Press and release the

 button when you want to

call a number using a stored voice tag. Speak
clearly and naturally after a beep.

If the microphone picks up voices other than yours,
the command may be misinterpreted.

To change the volume level, use the audio system’s
volume knob or the remote audio controls on the
steering wheel.

State or local laws may prohibit the operation of
handheld electronic devices while operating a
vehicle.

Models with color audio system

Microphone

 (Talk) Button
 (Hang-up/Back) Button
 (Pick-up) Button

Selector Knob

 (Phone) Button

Volume up
Volume down

353

uu

Bluetooth® HandsFreeLink®

u

Using HFL

Features

The audio/information screen notifies you
when there is an incoming call.

Certain manual functions are disabled or inoperable while the vehicle is in motion.
You cannot select a grayed-out option until the vehicle is stopped.

Only previously stored speed dial entries can be called using voice commands while
the vehicle is in motion.

Speed Dial P. 367

HFL Status Display

1

Using HFL

If you receive a call while using the audio system, the
system resumes its operation after ending the call.

Up to 20 speed dial entries can be stored. If there is
no entry in the system, Speed Dial is disabled.

Speed Dial P. 367

Up to 20 call histories can be stored. If there is no call
history, Call History is disabled.

Bluetooth® Wireless Technology
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc., and any
use of such marks by Honda Motor Co., Ltd., is under
license. Other trademarks and trade names are those
of their respective owners.

HFL Limitations
An incoming call on HFL will interrupt the audio
system when it is playing. It will resume when the call
is ended.

HFL Mode

Battery Level Status

Signal Strength

Bluetooth Indicator
Appears when your
phone is connected
to HFL.

Roaming Status

Caller’s Name

Limitations for Manual Operation

1

HFL Status Display

The information that appears on the audio/
information screen varies between phone models.

You can change the system language.

Customized Features P. 318

354

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

HFL Menus

The power mode must be in ACCESSORY or ON to use the system.

1

HFL Menus

To use HFL, you must first pair your Bluetooth-
compatible cell phone to the system while the vehicle
is parked.

Some functions are limited while driving.

 or

Display the last 20 outgoing calls.

Display the last 20 incoming calls.

Display the last 20 missed calls.

*1 : Appears only when a phone is connected to HFL.

Phone

Speed Dial

*1

Add New

Select a phone number from the call history to
store as a speed dial number.

Call History

Phonebook

Select a phone number from the phonebook to
store as a speed dial number.

Phone Number

Enter a phone number to store as a speed dial
number.

Dialed Calls

Received Calls

Missed Calls

Phonebook

*1

Dial

*1

Call History

*1

Display the paired phone’s phonebook.

Enter a phone number to dial.

(Existing entry list)

355

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

*1 : Appears only when a phone is connected to HFL.

Redial the last number dialed in the phone’s history.

Add New Device

Connect a Phone

Connect an Audio Device

Bluetooth Setup

Phone Setup

Redial

*1

Pair a phone to the system.

Connect a phone to the system.

Change a pairing code.

Disconnect All Devices

Delete Device

Pass-key

Disconnect a paired device from the system.

Delete a previously paired device.

Connect a Bluetooth® Audio device to the
system.

356

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

*1 : Appears only when a phone is connected to HFL.

Call History

Phonebook

Phone Number

Speed Dial

*1

Select a phone number from the phonebook
to store as a speed dial number.

Select a phone number from the call history
to store as a speed dial number.

Create a voice tag for a speed dial number.

Change Speed Dial

Delete Speed Dial

Store Voice Tag

Enter a phone number to store as a speed dial
number.

Delete a previously stored speed dial number.

Change Voice Tag

Delete Voice Tag

Change a previously stored speed dial
number.

Change a voice tag for a speed dial number.

Delete a voice tag for a speed dial number.

Add New

Existing entry list

357

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

Fixed

Mobile Phone

System Clear

Ringtone

Select the ring tone stored in the connected
cell phone.

Name Priority

Number Priority

Caller ID Info

Prioritize the caller’s name as the caller ID.

Clear the system of all paired phones, phonebook entries,
and security codes.

Prioritize the caller’s phone number as the
caller ID.

Select the ring tone stored in HFL.

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

358

Features

To pair a cell phone (when there is no
phone paired to the system)

1. Press the

 button or the

 button.

2. Rotate

to

select

Yes, then press

.

3. Make sure your phone is in search or

discoverable mode, then press

.

u

HFL automatically searches for a
Bluetooth® device.

4. When your phone appears on the list, select

it by pressing

.

u

If your phone does not appear, select
Phone Not Found? and search for
Bluetooth® devices using your phone.
From your phone, select
HandsFreeLink.

5. The system gives you a pairing code on the

audio/information screen.

u

Confirm if the pairing code on the screen
and your phone match.
This may vary by phone.

6. A notification appears on the screen if

pairing is successful.

Phone Setup

1

Phone Setup

Your Bluetooth-compatible phone must be paired to
HFL before you can make and receive hands-free
calls.

Phone Pairing Tips:

You cannot pair your phone while the vehicle is
moving.

Up to six phones can be paired.

Your phone’s battery may drain faster when it is
connected to HFL.

If your phone is not ready for pairing or not found
by the system within three minutes, the system will
time out and return to idle.

Once you have paired a phone, you can see it
displayed on the screen with one or two icons on the
right side.
These icons indicate the following:

: The phone can be used with HFL.
: The phone is compatible with Bluetooth® Audio.

359

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

To pair a cell phone (when a phone has
already been paired to the system)

1. Press the

 button or the

 button.

u

If a prompt appears asking to connect to
a phone, select No and proceed with
step 2.

2. Rotate

 to select Phone Setup, then

press .

3. Rotate

 to select Bluetooth Setup

then press

.

4. Rotate

 to select Add New Device

then press

.

u

The screen changes to device list.

5. Rotate

 to select Add New, then press

.

360

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

6. Make sure your phone is in search or

discoverable mode, then press

.

u

HFL automatically searches for a
Bluetooth® device.

7. When your phone appears on the list, select

it by pressing

.

u

If your phone does not appear, select
Phone Not Found? and search for
Bluetooth® devices using your phone.
From your phone, select
HandsFreeLink.

8. The system gives you a pairing code on the

audio/information screen.

u

Confirm if the pairing code on the screen
and your phone match.
This may vary by a phone.

361

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

To change the currently paired phone

1. Press the

 button or the

 button.

2. Rotate

 to select Phone Setup, then

press .

3. Rotate

 to select Bluetooth Setup, then

press .

4. Rotate

 to select Connect a Phone

then press

.

u

The screen changes to a device list.

5. Rotate

 to select a desired device name,

then press

.

u

HFL disconnects the connected phone
and starts searching for another paired
phone.

362

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

To change the pairing code setting

1. Press the

 button or the

 button.

2. Rotate

to

select

Phone Setup, then

press .

3. Rotate

 to select Bluetooth Setup, then

press .

4. Rotate

to

select

Pass-Key, then press

.

5. Input a new pairing code, then press

.

363

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

To delete a paired phone

1. Press the

 button or the

 button.

2. Rotate

 to select Phone Setup, then

press .

3. Rotate

 to select Bluetooth Setup, then

press .

4. Rotate

 to select Delete Device, then

press .

u

The screen changes to a device list.

5. Rotate

 to select a phone you want to

delete, then press

.

6. A confirmation message appears on the

screen. Rotate

 to select Yes, then press

.

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

364

Features

You can change the ring tone setting.

1. Press the

 button or the

 button.

2. Rotate

to

select

Phone Setup, then

press .

3. Rotate

to

select

Ringtone, then press

.

4. Rotate

to

select

Mobile Phone or

Fixed, then press

.

You can select a caller’s information to be displayed when you have an incoming
call.

1. Press the

 button or the

 button.

2. Rotate

to

select

Phone Setup, then

press .

3. Rotate

to

select

Caller ID Info, then

press .

4. Rotate

 to select a mode you want, then

press .

Ring Tone

1

Ring Tone

Fixed: The fixed ring tone sounds from the speakers.
Mobile Phone: Depending on the make and model
of the mobile phone, the ring tone stored in the
phone will sound if the phone is connected.

Caller’s ID Information

1

Caller’s ID Information

Name Priority: A caller’s name is displayed if it is
stored in the phonebook.
Number Priority: A caller’s phone number is
displayed.

365

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

All speed dial entries, all imported phonebook data, all call history data, paired
phones, pairing codes, caller’s ID settings, and volume settings are reset as default.

1. Press the

 button or the

 button.

2. Rotate

 to select Phone Setup, then

press .

3. Rotate

 to select System Clear, then

press .

4. Rotate

 to select Yes, then press

.

5. A confirmation message appears on the

screen. Rotate

 to select Yes, then press

.

6. A notification appears on the screen. Press

.

To Clear the System

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

366

Features

When your phone is paired, the contents of its phonebook and call history are
automatically imported to HFL.

Automatic Import of Cellular Phonebook and Call History

1

Automatic Import of Cellular Phonebook and Call History

When you select a name from the list in the cellular
phonebook, you can see up to three category icons.
The icons indicate what types of numbers are stored
for that name.

If a name has four or more numbers, ... appears
instead of category icons.

On some phones, it may not be possible to import the
category icons to HFL.

The phonebook is updated after every connection.
Call history is updated after every connection or call.

Pref

Home

Mobile

Pager

Work

Fax

Car

Voice

Other

Continued

367

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

Up to 20 speed dial numbers can be stored per phone.

To store a speed dial number:
1. Press the

 button or the

 button.

2. Rotate

to

select

Speed Dial, then press

.

3. Rotate

 to select Add New, then press

.

4. Rotate

 to select a place to choose a

number from, then press

.

From Call History:

u

Select a number from the call history.

From Phonebook:

u

Select a number from the connected cell
phone’s imported phonebook.

From Phone Number:

u

Input the number manually.

5. When the speed dial is successfully stored,

you are asked to create a voice tag for the
number. Rotate

 to select Yes or No

then press

.

6. Using the

 button, follow the prompts to

say the name for the speed dial entry.

Speed Dial

1

Speed Dial

When a voice tag is stored, you can press the



button and call the number using voice commands.















Content   ..  21  22  23  24   ..
