Honda Ridgeline (2019 year). Manual - part 12





176

uu

Interior Lights/Convenience Items

u

Interior Convenience Items

Co
ntrols

Rear seat beverage holders

Fold the armrest down to use the rear seat
beverage holders.

Continued

177

uu

Interior Lights/Convenience Items

u

Interior Convenience Items

Co
ntrols

The accessory power sockets can be used when the power mode is in ACCESSORY
or ON.

Accessory power socket (console panel)

Open the cover to use it.

Accessory power socket (console
compartment)

Pull the handle and open the cover to use it.

Accessory Power Sockets

1

Accessory Power Sockets

NOTICE

Do not insert an automotive type cigarette lighter
element: The power socket can overheat.

The accessory power socket is designed to supply
power for 12-volt DC accessories that are rated
180 watts (15 amps) or less.

To prevent battery drain, use the power socket only
when the engine is running.

When both sockets are being used, the combined
power rating of the accessories should not exceed
180 watts (15 amps).

uu

Interior Lights/Convenience Items

u

Interior Convenience Items

178

Co
ntrols

There is a coat hook on the rear grab handle
of both sides. Pull it down to use it.

Coat Hooks

1

Coat Hooks

The coat hooks are not designed for large or heavy
items.

Continued

179

uu

Interior Lights/Convenience Items

u

Interior Convenience Items

Co
ntrols

To open the sunglasses holder, push and
release the indent. To close, push it again until
it latches.

You can store eyeglasses and other small
items in this holder.

Conversation mirror

*

The sunglasses holder comes with a mirror.
Open the sunglasses holder fully, then push it
back to the first detent.

You can use the mirror to view the rear seats.

Sunglasses Holder

1

Sunglasses Holder

Keep the holder closed while driving except when
accessing stored items.

Push

* Not available on all models

uu

Interior Lights/Convenience Items

u

Interior Convenience Items

180

Co
ntrols

The power mode must be in ON to use the
heated steering wheel.

Press the button on the left side of the
steering wheel.

When a comfortable temperature is reached,
press the button again to turn it off.

The heated steering wheel is turned off every
time you start the engine, even if you turned it
on the last time you drove the vehicle.

Heated Steering Wheel

*

1

Heated Steering Wheel

*

Do not use the heated steering wheel continuously
when the engine is off. Under such conditions, the
battery may be weakened, making the engine
difficult to start.

Indicator

Heated Steering
Wheel Button

* Not available on all models

Continued

181

uu

Interior Lights/Convenience Items

u

Interior Convenience Items

Co
ntrols

The power mode is in ON to use the seat
heaters. The HI setting heats the seats faster
than the LO setting.

The appropriate indicator will be on while the
seat heater is on. For low heat and high heat,
press LO and HI respectively. Center the
rocker switch to turn the heater off.

Front Seat Heaters

*

1

Front Seat Heaters

*

Do not use the seat heaters even in LO when the
engine is off. Under such conditions, the battery may
be weakened, making the engine difficult to start.

In the LO setting, the heater runs continuously and
does not automatically turn off.

3

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

uu

Interior Lights/Convenience Items

u

Interior Convenience Items

182

Co
ntrols

If the power mode is in ON:
Seat heater - The HI setting heats the seats
faster than the LO setting.
Seat ventilation - The HI setting ventilates
the seats faster than the LO setting.

Press the seat heater or the seat ventilation
button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator on)
Four times - The OFF setting (no indicators on)

When a comfortable temperature is reached
while using the seat heaters in HI, select MID
or LO to keep the seat warm.

Front Seat Heaters and Seat Ventilation

*

1

Front Seat Heaters and Seat Ventilation

*

Do not use the seat heaters and the seat ventilation
even in LO when the engine is off. Under such
conditions, the battery may be weakened, making
the engine difficult to start.

3

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

183

uu

Interior Lights/Convenience Items

u

Interior Convenience Items

Co
ntrols

If the power mode is in ON: The HI setting
heats the seats faster than the LO setting.

There is no heater in the rear center seating
position.

Press the seat heater button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator on)
Four times - The OFF setting (no indicators on)

Once a comfortable temperature has been
reached using HI setting, select MID or LO to
keep the seat warm.

Rear Outer Seat Heaters

*

1

Rear Outer Seat Heaters

*

Do not use the seat heaters even in LO when the
engine is off. Under such conditions, the battery may
be weakened, making the engine difficult to start.

3

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

184

uu

Interior Lights/Convenience Items

u

In-Bed Convenience Items

Co
ntrols

In-Bed Convenience Items

Turn the knobs to the left to open the lid.

To use the AC power outlet, the power mode must be in ACCESSORY or ON.

1. Turn the knobs to the left to open the lid.

In-Bed Box P. 184

2. Open the cover and plug in the appliance

slightly. Turn the plug 90° clockwise, then
push it in all the way.

In-Bed Box

Knobs

AC Power Outlet

*

1

AC Power Outlet

*

Do not use the AC power outlet for electrical
appliances that require high initial peak wattage,
such as cathode-ray tube type televisions,
refrigerators, electric pumps, etc. It is not suitable for
devices that process precise data, such as medical
equipment, and that require an extremely stable
power supply, such as microcomputer-controlled
electric blankets, touch sensor lamps, etc.

The AC power outlet is designed to supply power for
up to 115 volt appliances that are rated 400 watts or
less.

Continued use of any electrical appliance/device
exceeding these ratings may result in damage to the
appliance/device.

* Not available on all models

Continued

185

uu

Interior Lights/Convenience Items

u

In-Bed Convenience Items

Co
ntrols

ON and OFF

Press the AC power outlet button to turn the
system on and off.

u

The indicator in the button comes on
when the system is on.

400W (Amber) mode is:
• When the engine running and the shift

lever in

(

P.

150W (Green) mode is:
• When the power mode is in ACCESSORY or

ON.

• When the engine running and the shift

lever out of

(

P.

• When the truck bed audio system is

activated.

1

AC Power Outlet

*

The protection circuit may be activated to cut the
power supply if any of the following conditions apply:

The engine is started when the power outlet switch
on.

An electrical appliance exceeding the maximum
capacity is used.

The total power consumed by the electrical
features (head lights, air conditioning, etc.),
including the truck bed audio

*

, has exceeded the

maximum vehicle wattage capacity for a prolonged
period of time.

Indicator

* Not available on all models

uu

Interior Lights/Convenience Items

u

In-Bed Convenience Items

186

Co
ntrols

The bed lights can be turned on or off by
pressing the button when the shift lever is in

(

P.

u

The indicator in the meter comes on
when the lights are on.

The tie-down anchors on the pickup bed can
be used to install a net for securing items.

Bed Lights

1

Bed Lights

The bed lights comes on when you swing open the
tailgate or open the trunk.

If you set the power mode to ACCESSORY or
VEHICLE OFF (LOCK) and leave the bed lights on, they
will shut off after 30 minutes.

Tie-down Anchors

Anchors

187

uu

Interior Lights/Convenience Items

u

In-Bed Convenience Items

Co
ntrols

There are three hooks for plastic grocery bags
at the back of the trunk. They are designed to
hold light items. Heavy objects may damage
the hooks.

Cargo Hooks

Hooks

188

Co
ntrols

Climate Control System

*

Using Automatic Climate Control

The automatic climate control system maintains the interior temperature you select.
The system also selects the proper mix of heated or cooled air that will as quickly as
possible, raise or lower the interior temperature to your preference.

Use the system when the engine is running.
1. Press the AUTO button.
2. Adjust the interior temperature using the driver’s side or passenger’s side

temperature control switch.

3. Press the

 ON/OFF button to cancel.

1

Using Automatic Climate Control

If any buttons are pressed while using the climate
control system in auto, the function of the button
that was pressed will take priority.
The AUTO indicator will go off, but functions
unrelated to the button that was pressed will be
controlled automatically.

If ECON mode is selected, the fan may turn off.
To prevent cold air from blowing in from outside, the
fan may operate at low speed for a while after the
AUTO button has been pressed.

Once you have set the desired temperature, do not
use the temperature control switches more than
necessary.
Doing so may delay the time it takes to reach the set
temperature.

If the interior is very warm, you can cool it down
more rapidly by partially opening the windows,
turning the system on auto, and setting the
temperature to low. Change the fresh mode to
recirculation mode until the temperature cools down.

When you set the temperature to the lower or upper
limit, Lo or Hi is displayed.

Pressing the

 ON/OFF button switches the

climate control system between on and off. When
turned on, the system returns to your last selection.

Floor and
defroster
vents

Floor vents

Dashboard and floor,
and back of the
center console vents

Dashboard and
back of the center
console vents

AUTO Button

Driver’s Side
Temperature
Control Switch

 (Recirculation) Button

Fan Control Button

A/C (Air Conditioning)
Button

Passenger’s Side
Temperature Control
Switch

 (Windshield Defroster)

Button

SYNC (Synchronized) Button

 (On/Off) Button

MODE Button

* Not available on all models

Continued

189

uu

Climate Control System

*

u

Using Automatic Climate Control

Co
ntrols

Switching between the recirculation and fresh air modes

Press the

 button and switch the mode depending on environmental conditions.

Recirculation Mode (indicator on): Recirculates air from the vehicle’s interior through
the system.
Fresh Air Mode (indicator off): Maintains outside ventilation. Keep the system in
fresh air mode in normal situations.

Pressing the

 button turns the air

conditioner system on and automatically
switches the system to fresh air mode.

Press the

 button again to turn off, the

system returns to the previous settings.

Defrosting the Windshield and Windows

1

Defrosting the Windshield and Windows

For your safety, make sure you have a clear view
through all the windows before driving.

Do not set the temperature near the upper or lower
limit.
When cold air hits the windshield, the outside of the
windshield may fog up.

If the side windows fog up, adjust the vents so that
the air hits the side windows.

uu

Climate Control System

*

u

Using Automatic Climate Control

190

Co
ntrols

To rapidly defrost the windows

1. Press the

 button.

2. Press the

 button.

1

To rapidly defrost the windows

After defrosting or defogging the windows, switch
over to fresh air mode. If you keep the system in
recirculation mode, the windows may fog up from
humidity. This impedes visibility.

191

uu

Climate Control System

*

u

Using Automatic Climate Control

Co
ntrols

You can set the temperature synchronously for the driver side, front passenger side
and rear seats in synchronized mode.

1. Press the SYNC button.

u

The system will switch to synchronized mode.

2. Adjust the temperature using driver’s side temperature control switch.

Press the SYNC button to return to synchronized mode off.

Synchronized Mode

1

Synchronized Mode

When you press the

 button, the system changes

to synchronized mode.

When the system is in synchronized mode off, the
temperature for the driver, front passenger, and rear
seats can be set separately.















Content   ..  10  11  12  13   ..
