Honda Pilot (2019 year). Manual - part 8

111

uu

Gauges and Displays

u

Driver Information Interface

Continued

In

strum

e

nt Pa

nel

Driver Information Interface

The driver information interface displays the speedometer, tachometer, odometer,
trip computer, outside temperature

*

, and other gauges. It also displays important

messages such as warnings and other helpful information.

Displays your driving speed in mph or km/h.

Shows the number of engine revolutions per minute.

■

Speedometer

■

Tachometer

1

Speedometer

You can set the speedometer and the displayed
measurements to read in either mph and km/h.

2 Units P. 120

1

Tachometer

You can turn on or off the tachometer display.

2 Show Tachometer P. 124

* Not available on all models

uu

Gauges and Displays

u

Driver Information Interface

112

In

strum

e

nt Pa

nel

Shows the total number of miles or kilometers
that your vehicle has accumulated.

Shows the outside temperature in Fahrenheit
(U.S.) or Celsius (Canada).

Adjusting the outside temperature
display
Adjust the temperature reading by up to ±5°F
or ±3°C if the temperature reading seems
incorrect.
Use the driver information interface

*

 or audio/

information screen

*

 to correct the

temperature.

2 Vehicle Customization P. 125

2 Customized Features P. 432

■

Odometer

Odometer

■

Outside Temperature

*

1

Outside Temperature

*

The temperature sensor is in the front bumper.
Road heat and exhaust from another vehicle can
affect the temperature reading when your vehicle
speed is less than 19 mph (30 km/h).

It may take several minutes for the display to be
updated after the temperature reading has stabilized.

Outside Temperature

Models with color audio system

Models with Display Audio

* Not available on all models

Continued

113

uu

Gauges and Displays

u

Driver Information Interface

In

strum

e

nt Pa

nel

Press the

 (home) button, then press the

/

 button to scroll to the content

you want to see. Press the ENTER button to see detailed information.

*1: Models with color audio system
*2: Models with Display Audio

■

Accessing Content

1

Accessing Content

To go back to the previous screen, press the

*1

/

*2

 (back) button.

You can edit, add, or delete the meter contents using
the driver information interface.

2 Arrange Apps P. 123
2 Show/Hide Apps P. 122

3 4

114

uu

Gauges and Displays

u

Driver Information Interface

In

strum

e

nt Pa

nel

 (Home) Button

/

 Button

3 4

*

*

Press

or .

3

4

 P. 117

 P. 122

 P. 115

 P. 119

 P. 117

 P. 120

 P. 123

 P. 118

 P. 120

Models with color audio system

Models with Display Audio

 (Home) Button

/

 Button

3 4

 P. 121

*

*

 P. 119

*

* Not available on all models

115

uu

Gauges and Displays

u

Driver Information Interface

Continued

In

strum

e

nt Pa

nel

Press the ENTER button to switch between trip computer A and trip computer B.

■

Trip Computer

ENTER Button

ENTER

Trip Computer A

Trip Computer B

Distance

Range

Average Fuel
Economy

Instant Fuel
Economy

Models with color audio system

Models with Display Audio

ENTER Button

uu

Gauges and Displays

u

Driver Information Interface

116

In

strum

e

nt Pa

nel

■

Distance

Shows the total number of miles or kilometers driven since the last reset. Meters A
and B can be used to measure two separate trips.

Resetting distance
To reset the Distance, display it and then press and hold the ENTER button until the
Distance is reset to 0.0.

■

Average fuel economy (Avg. Fuel)

Shows the estimated average fuel economy of each Distance in mpg or l/100 km.
The display is updated at set intervals. When a Distance is reset, the average fuel
economy is also reset.

■

Instant fuel economy

Shows the instant fuel economy as a bar graph in mpg or l/100 km.

■

Range

Shows the estimated distance you can travel on the remaining fuel. This estimated
distance is based on the vehicle’s current fuel economy.

1

Distance

Switch between Distance A and Distance B by
pressing the ENTER button.

1

Average fuel economy (Avg. Fuel)

You can change when the average fuel economy is
reset.

2 Vehicle Customization P. 125

2 Customized Features P. 432

Models with color audio system

Models with Display Audio

Continued

117

uu

Gauges and Displays

u

Driver Information Interface

In

strum

e

nt Pa

nel

Display Audio shows you turn-by-turn
directions to your destination.

When the navigation system is not providing
driving guidance, an image of a compass
appears in the driver information interface.

2 Refer to the navigation system

2 Driver Information Interface Warning and

Information Messages P. 96

■

Navigation

1

Navigation

Turn-by-turn directions will be shown on the driver
information interface only when your android phone
is connected to Android Auto

TM

.

You can select whether to have the turn-by-turn
display come on or not during the route guidance.

2 Customized Features P. 432

Models with Display Audio

Compass

Turn-By-Turn Driving Directions

Models with Display Audio

Models with navigation system

■

Warnings

1

Warnings

The Warnings app is dynamic and will only appear
when there are active warnings. If there are no
Warnings, this app will not be shown.

(Example)

118

uu

Gauges and Displays

u

Driver Information Interface

In

strum

e

nt Pa

nel

Shows the current condition of the tire
pressure and the remaining oil life.

■

Tire Pressure

Shows the tire pressure of each tire.

2 Tire Pressure Monitoring System (TPMS)

with Tire Fill Assist P. 562

■

Oil Life

Shows the remaining oil life and Maintenance
Minder

TM

.

2 Maintenance Minder

TM

 P. 637

■

Maintenance

119

uu

Gauges and Displays

u

Driver Information Interface

Continued

In

strum

e

nt Pa

nel

The indicators on the display show the
amount of torque being transferred to the
right front, left front, right rear, and left rear
wheels.

2 Intelligent Variable Torque Management

(i-VTM4

TM

) AWD System

*

 P. 561

Shows the current phone information.

2 Bluetooth® HandsFreeLink® P. 454

■

AWD Torque

*

■

Phone

*

* Not available on all models

120

uu

Gauges and Displays

u

Driver Information Interface

In

strum

e

nt Pa

nel

Enables you to set the speedometer and the
displayed measurements to read in either mph
or km/h.

Press and hold the ENTER button. Each time
you do this, the unit will change from mph to
km/h or vice versa. After this, a confirmation
screen will appear for a few seconds.

Shows the current audio information.

2 Audio System Basic Operation P. 251

■

Units

■

Now Playing

*

* Not available on all models

121

uu

Gauges and Displays

u

Driver Information Interface

Continued

In

strum

e

nt Pa

nel

Shows the current audio source.

2 Audio System Basic Operation P. 251

■

Audio Source

*

(Example)

* Not available on all models

uu

Gauges and Displays

u

Driver Information Interface

122

In

strum

e

nt Pa

nel

You can show or hide the meter contents.

Select the content you wish to show or hide,
then press the ENTER button.

u

Repeat it if you want to show or hide
more than one app.

■

Show/Hide Apps

1

Show/Hide Apps

You cannot hide apps with the

 icon on the right

side.

Selecting Default All in Vehicle Customization
does not restore these settings to their original state.

You can also add the Android Auto, Apple
CarPlay, Sirius XM

*

, My Honda Music, USB, AM,

FM, Bluetooth Audio, Social Playlist, AUX Input,
CD

*

 and Rear Entertainment

*

 apps.

Models with Display Audio

Shown

Press ENTER

Hidden

* Not available on all models

Continued

123

uu

Gauges and Displays

u

Driver Information Interface

In

strum

e

nt Pa

nel

Change the settings to your liking.

■

Arrange Apps

You can change the order of the apps on the home screen.

1. Press the

/

 button to select Arrange

Apps, then press the ENTER button.

2. Press the

/

 button to select the icon

you want to move, then press the ENTER
button.

3. Press the

/

 button repeatedly to move

the icon to your desired position, then press
the ENTER button.

■

Settings

1

Arrange Apps

Selecting Default All in Vehicle Customization
does not restore these settings to their original state.

3 4

3 4

3 4

uu

Gauges and Displays

u

Driver Information Interface

124

In

strum

e

nt Pa

nel

■

Show Tachometer

You can show or hide the tachometer.

Press the

/

 button to select Show

Tachometer, then press the ENTER button.

u

The tachometer appears when the check
box is checked.

1

Show Tachometer

Selecting Default All in Vehicle Customization
does not restore these settings to their original state.

3 4

Continued

125

uu

Gauges and Displays

u

Driver Information Interface

In

strum

e

nt Pa

nel

■

Vehicle Customization

Use the driver information interface to customize certain vehicle features.

How to customize
First, make sure the vehicle is at a complete stop and that the power mode is set to
ON. Next, press the

 (home) button, then press the

/

 button to select

Settings. Finally, press the ENTER button.

Models with color audio system

1

Vehicle Customization

To customize other features, press the

/

 button.

2 List of customizable options P. 128
2 Example of how to customize a setting

P. 131

Change to

(

P before you attempt to change a

customized setting.

3 4

3 4

/

 Button

Scroll through the menu
or items.

3 4

 Button

Goes back to the previous
screen.

ENTER Button
Enters the selected
item.

 Button

Goes to home
screen.

Driver Information Interface:
Goes to Settings.

126

uu

Gauges and Displays

u

Driver Information Interface

In

strum

e

nt Pa

nel

■

Customization flow

Press the

 (home) button.

ENTER

“Trip B” Reset Timing

Fuel Efficiency Backlight

“Trip A” Reset Timing

Language Selection

Adjust Alarm Volume

Meter Setup

ENTER

Settings

Arrange Apps

Show Tachometer

3
4

3
4

3
4

3
4

3
4

Vehicle Customization

ENTER

 P. 123

 P. 124

Interior Light Dimming Time

Auto Headlight ON With Wiper ON

ENTER

Lighting Setup

3
4

ENTER

ENTER

Road Departure Mitigation Setting

Lane Keeping Assist Suspend Beep

ACC Forward Vehicle Detect Beep

Forward Collision Warning Distance

Driver Assist System

Setup

3
4

3
4

Auto Light Sensitivity

Headlight Auto OFF Timer

Auto Interior Illumination Sensitivity
