Honda Odyssey (2019 year). Manual - part 18





272

uu

Audio System Basic Operation

u

Adjusting the Sound

Features

Adjusting the Sound

Press the

 (sound) button, and rotate



to scroll through the following choices:

Rotate

 to adjust the sound setting, then

press .

1

Adjusting the Sound

The SVC has four modes: OffLowMid, and High.
SVC adjusts the volume level based on the vehicle
speed. As you go faster, audio volume increases. As
you slow down, audio volume decreases.

Selector Knob

 (Sound) Button

TRE is selectable.

BAS

TRE

FAD

BAL

SVC

Bass

Treble

Fader

Balance

Speed-sensitive
Volume Compensation

SUBW

Subwoofer

273

uu

Audio System Basic Operation

u

Display Setup

Features

Display Setup

You can change the brightness or color theme of the audio/information screen.

1. Press the MENU/CLOCK button.
2. Rotate

 to select Settings, then press

.

3. Rotate

 to select Display Adjustment

then press

.

4. Rotate

 to select Brightness, then press

.

5. Rotate

 to adjust the setting, then press

.

1. Press the MENU/CLOCK button.
2. Rotate

 to select Settings, then press

.

3. Rotate

 to select Color Theme, then

press .

4. Rotate

 to select the setting you want,

then press

.

Changing the Screen Brightness

1

Changing the Screen Brightness

You can change the Contrast and Black Level
settings in the same manner.

Changing the Screen’s Color Theme

274

uu

Audio System Basic Operation

u

Playing AM/FM Radio

Features

Playing AM/FM Radio

RADIO Button
Press to select a band.

 (Back) Button

Press to go back to the previous
display or cancel a setting.

 /

 (Seek/Skip) Buttons

Press

 or

 to search up and down the

selected band for a station with a strong
signal.

VOL/

 (Volume/Power) Knob

Press to turn the audio system
on and off.
Turn to adjust the volume.

Preset Buttons (1-6)
To store a station:
1. Tune to the selected station.
2. Pick a preset button and hold it until you hear a beep.
To listen to a stored station, select a band, then press the preset button.

Selector Knob
Turn to tune the radio frequency.
Press and then turn to select an
item. After that, press again to
make your selection.

MENU/CLOCK Button
Press to display the menu items.

Audio/Information Screen

275

uu

Audio System Basic Operation

u

Playing AM/FM Radio

Features

Provides text data information related to your selected RDS capable FM station.

To find an RDS station from Station List

1. Press

 while listening to an FM station.

2. Rotate

 to select the station, then press

.

Update List

Updates your available station list at any time.
1. Press

 while listening to an FM station.

2. Rotate

 to select Update List, then press

.

Radio text

Displays the radio text information of the selected RDS station.
1. Press the MENU/CLOCK button.
2. Rotate

 to select Settings, then press

.

3. Rotate

 to select RDS Settings, then press

.

4. Rotate

 to select Radio Text, then press

.

Scan

Samples each of the strongest stations on the selected band for 10 seconds.
1. Press the MENU/CLOCK button.
2. Rotate

 to select Scan, then press

.

To turn off scan, press

.

Radio Data System (RDS)

1

Playing AM/FM Radio

The ST indicator appears on the display indicating
stereo FM broadcasts.
Stereo reproduction in AM is not available.

You can store 6 AM stations and 12 FM stations into
reset button memory. FM1 and FM2 let you store 6
stations each.

Switching the Audio Mode
Press the SOURCE button on the steering wheel.

Audio Remote Controls P. 264

1

Radio Data System (RDS)

When you select an RDS-capable FM station, the RDS
automatically turns on, and the frequency display
changes to the station name. However, when the
signals of that station become weak, the display
changes from the station name to the frequency.

276

uu

Audio System Basic Operation

u

Playing an iPod

Features

Playing an iPod

Connect the iPod using your USB connector to the USB port, then press the MEDIA
button.

USB Ports P. 261

USB Indicator
Appears when an iPod is connected.

MEDIA Button
Press to select iPod (if connected).

 (Back) Button

Press to go back to the previous
display or cancel a setting.

 /

 (Seek/Skip) Buttons

Press

 or

 to change songs.

Press and hold to move rapidly within a song.

VOL/

 (Volume/Power) Knob

Press to turn the audio system on and off.
Turn to adjust the volume.

Selector Knob
Turn to change songs.
Press and turn to select an item,
then press to set your selection.

MENU/CLOCK Button
Press to display the menu items.

Audio/Information Screen

Album Art

Play Mode Buttons
Press to select a play mode.

Continued

277

uu

Audio System Basic Operation

u

Playing an iPod

Features

1. Press

 to display the iPod music list.

2. Rotate

 to select a category.

3. Press

 to display a list of items in the

category.

4. Rotate

 to select an item, then press

.

u

Press

 and rotate

 repeatedly until a

desired item you want to listen to is
displayed.

How to Select a Song from the iPod Music List with the
Selector Knob

1

Playing an iPod

Available operating functions vary on models or
versions. Some functions may not be available on the
vehicle’s audio system.

If there is a problem, you may see an error message
on the audio/information screen.

iPod/USB Flash Drive P. 369

Item
Selection

Category
Selection

uu

Audio System Basic Operation

u

Playing an iPod

278

Features

You can select repeat and shuffle modes when playing a song.

Available mode icons appear above the play
mode buttons.
Press the button corresponding to the mode
you want to select.

To turn off a play mode

Press the selected button.

How to Select a Play Mode

1

How to Select a Play Mode

Play Mode Menu Items

 Shuffle Albums: Plays all available albums in

a selected category (playlists, artists, albums, songs,
genres, or composers) in random order.

 Shuffle: Plays all available songs in a selected

category (playlists, artists, albums, songs, genres, or
composers) in random order.

 Repeat One Track: Repeats the current song.

You can also select a play mode by pressing the
MENU/CLOCK button.
Rotate

 to select Play Mode, then press

Rotate

 to select a mode, then press

.

To turn it off, rotate

 to select Normal Play, then

press .

Play Mode Buttons

279

uu

Audio System Basic Operation

u

Playing a USB Flash Drive

Continued

Features

Playing a USB Flash Drive

Your audio system reads and plays audio files on a USB flash drive in either MP3,
WMA or AAC

*1

 format.

Connect your USB flash drive to the USB port, then press the MEDIA button.

USB Ports P. 261

*1:Only AAC format files recorded with iTunes are playable on this unit.

USB Indicator
Appears when a USB flash drive
is connected.

MEDIA Button
Press to select USB flash drive
(if connected).

 (Back) Button

Press to go back to the previous
display.

 /

 (Seek/Skip) Buttons

Press

 or

 to change tracks.

Press and hold to move rapidly within a track.

VOL/

 (Volume/Power) Knob

Press to turn the audio system on and off.
Turn to adjust the volume.

Selector Knob
Turn to change folders.
Press and turn to select an item,
then press to set your selection.

MENU/CLOCK Button
Press to display the menu items.

Audio/Information Screen

Play Mode Buttons (1-6)
Press to select a play mode.

uu

Audio System Basic Operation

u

Playing a USB Flash Drive

280

Features

1. Press

 to display a folder list.

2. Rotate

 to select a folder.

3. Press

 to display a list of tracks in that

folder.

4. Rotate

 to select a track, then press

.

How to Select a File from a Folder with the Selector Knob

1

Playing a USB Flash Drive

Use the recommended USB flash drives.

General Information on the Audio System

P. 372

Files in WMA format protected by digital rights
management (DRM) are not played.
The audio system displays Unplayable File, and then
skips to the next file.

If there is a problem, you may see an error message
on the audio/information screen.

iPod/USB Flash Drive P. 369

Track
Selection

Folder
Selection

281

uu

Audio System Basic Operation

u

Playing a USB Flash Drive

Features

You can select repeat, random, and scan modes when playing a file.

Available mode icons appear above the play
mode buttons.
Press the button corresponding to the mode
you want to select.

To turn off a play mode

Press the selected button.

How to Select a Play Mode

1

How to Select a Play Mode

Play Mode Menu Items
Repeat

 Repeat One Folder: Repeats all files in the

current folder.

 Repeat One Track: Repeats the current file.

Random

 Random in Folder: Plays all files in the

current folder in random order.

 Random All: Plays all files in random order.

Scan

 Scan Folders: Provides 10-second sampling

of the first file in each of the main folders.

 Scan Tracks: Provides 10-second sampling of

all files in the current folder.

You can also select a play mode by pressing the
MENU/CLOCK button.
Rotate

 to select Play Mode, then press

Rotate

 to select a mode, then press

.

To turn it off, rotate

 to select Normal Play, then

press .

Play Mode Buttons

282

uu

Audio System Basic Operation

u

Playing Bluetooth® Audio

Features

Playing Bluetooth® Audio

Your audio system allows you to listen to music from your Bluetooth-compatible
phone.
This function is available when the phone is paired and connected to the vehicle’s
Bluetooth® HandsFreeLink® (HFL) system.

Phone Setup P. 477

1

Playing Bluetooth® Audio

Not all Bluetooth-enabled phones with streaming
audio capabilities are compatible with the system.
For a list of compatible phones:

U.S.: Visit automobiles.honda.com/handsfreelink/
or call 1-888-528-7876.

Canada: For more information on smartphone
compatibility, call 1-888-528-7876.

In some states, it may be illegal to perform some data
device functions while driving.

Only one phone can be used with HFL at a time.
When there are more than two paired phones in the
vehicle, the first paired phone the system finds is
automatically connected.

If more than one phone is paired to the HFL system,
there may be a delay before the system begins to
play.

In some cases, the name of the artist, album, or track
may not appear correctly.

Some functions may not be available on some
devices.

MEDIA
Button
Press to select
the Bluetooth
Audio mode
(if
connected).

VOL/



(Volume/
Power) Knob
Press to turn
the audio
system on and
off.
Turn to adjust
the volume.

MENU/CLOCK
Button
Press to display
the menu items.

Audio/Information Screen

Bluetooth Indicator
Appears when your phone is connected to HFL.

 /

 (Seek/Skip) Buttons

Press

 or

 to change files.

Play Button (Preset 1)
Press to resume playing a file.

Pause Button (Preset 2)
Press to pause playing a file.

Selector Knob
Turn to change
groups.
Press to display
a music search
list. Turn to
select an item,
then press to
set your
selection.

Continued

283

uu

Audio System Basic Operation

u

Playing Bluetooth® Audio

Features

1. Make sure that your phone is paired and

connected to HFL.

2. Press the MEDIA button until the

Bluetooth® Audio mode is selected.

If the phone is not recognized, another HFL-
compatible phone, which is not compatible
for Bluetooth® Audio, may already be
connected.

To pause or resume a file

Press the play or pause button to select a mode.

To Play Bluetooth® Audio Files

1

To Play Bluetooth® Audio Files

To play the audio files, you may need to operate your
phone. If so, follow the phone maker’s operating
instructions.

The pause function may not be available on some
phones.

If any audio device is connected to the auxiliary input
jack or USB port, you may need to press the MEDIA
button repeatedly to select the Bluetooth® Audio
system.

Switching to another mode pauses the music playing
from your phone.

Play Button

Pause Button

MEDIA Button

uu

Audio System Basic Operation

u

Playing Bluetooth® Audio

284

Features

1. Press

 to display the music search list.

2. Rotate

 to select a category.

3. Press

 to display a list of items in the

category.

4. Rotate

 to select an item, then press

.

u

Press

 and rotate

 repeatedly until a

desired item you want to listen to is
displayed.

How to Select a Song from the Music Search List with the
Selector Knob

1

How to Select a Song from the Music Search List with the Selector
Knob

Depending on the Bluetooth® device you connect,
some or all of the categories may not be displayed.

Item
Selection

Category
Selection

285

Features

Audio System Basic Operation

To use the audio system function, the power mode must be in ACCESSORY or ON.

: Select to go to the home screen.

Switching the Display P. 286

: Select to go back to the previous display

when it is displayed.

: Select to change the audio/information

screen brightness.
Select

 once and select

 or

 to make

an adjustment.

u

Each time you select

, the mode

switches among the daytime mode,
nighttime mode and off mode.

Models with Display Audio

 (Day/Night) Icon

 (Home) Icon

 (Back) Icon

286

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

Audio/Information Screen

Displays the audio status and wallpaper. From this display, you can go to various
setup options.

Using the audio/information screen

Select

 to go to the home screen.

Select the following icons on the home screen or after selecting

 All Apps.

Switching the Display

1

Audio/Information Screen

Touchscreen Operation

Use simple gestures - including touching, swiping,
and scrolling - to operate certain audio functions.

Some items may be grayed out during driving to
reduce the potential for distraction.

You can select them when the vehicle is stopped or
use voice commands.

Wearing gloves may limit or prevent touchscreen
response.

You can change the touchscreen sensitivity setting.

Customized Features P. 443

Home Screen

Models without
navigation system

Models with
navigation system

 (Home) Icon

 All Apps

287

uu

Audio System Basic Operation

u

Audio/Information Screen

Continued

Features

Phone

Displays the HFL information.

Bluetooth® HandsFreeLink® P. 496

Trip Computer

Displays the trip computer information.
• Current Drive tab: Displays the current trip information.
• Trip A/Trip B tab: Displays information for the current and three previous drives.

The information is stored every time you reset Trip A/B.
To reset Trip A/B, select Reset.
To change the setting of how to reset Trip A/B, select Settings, then select Trip
A Reset Method
 or Trip B Reset Method.

Clock

Displays the clock.

System Updates

Updates the software version of the audio system.

System Updates P. 300

FM/AM/Sirius XM

*

/CD

*

/USB/Bluetooth Audio/AUX Input/My Honda

Music/Social Playlist

Displays the each audio information.

Settings

Enters the customizing menu screen.

Customized Features P. 449

* Not available on all models















Content   ..  16  17  18  19   ..
