Honda Odyssey (2019 year). Manual - part 12





uu

Opening and Closing the Sliding Doors

u

Opening/Closing the Power Sliding Doors

*

176

Co
ntrols

Outer handles

Pull up on the outer handle towards you. The
sliding door starts opening or closing.

When the power sliding door is locked, pulling
the outer handle unlocks all the doors and
tailgate while the remote is in your possession.
The power sliding door handle you pull
operates the door automatically.

While a power sliding door is in operation, if
you pull its handle, the beeper sounds and the
operation stops.
Pull the same handle again, the power sliding
door reverses direction.

Door Handles

1

Opening/Closing the Power Sliding Doors

*

The beeper will sound and the power sliding door will
not open if you pull the inner or outer handle under
the following conditions:

The power mode is in ON.

The transmission is not in

(

P.

The brake pedal is released.

The parking brake is released.

If you leave the power sliding door half open on a
steep hill with the engine off, the door starts to slide
down toward the hill bottom after 30 minutes. While
the door slides down, the beeper sounds.

Outer Handle

* Not available on all models

177

uu

Opening and Closing the Sliding Doors

u

Opening/Closing the Power Sliding Doors

*

Co
ntrols

Inner handles

Pull it rearward to automatically open the
sliding door, and pull it forward to
automatically close the door.

While a power sliding door is in operation, if
you pull its handle, the beeper sounds and the
operation stops.

To resume the power sliding door operation,
pull the same handle in the same direction
again.

Inner Handle

Close

Open

178

uu

Opening and Closing the Sliding Doors

u

Auto-Closer

*

Co
ntrols

Auto-Closer

*

If you manually close the power sliding door, it latches automatically.

The auto-closer feature activates with or without the main switch ON.

1

Auto-Closer

*

Keep your hands away from the power sliding door.
The manually closed door latches automatically when
it is half-shut.

The auto-closer feature does not activate if you keep
pulling the inner or outer handle while the sliding
door is closing.

Do not put any force on the power sliding door while
the door is latching.

* Not available on all models

179

Continued

Co
ntrols

Security System

Immobilizer System

The immobilizer system prevents a key that has not been pre-registered from
starting the engine. Each key contains electronic transmitters that use electronic
signals to verify the key.

Pay attention to the following when pressing the ENGINE START/STOP button:
• Do not allow objects that emit strong radio waves near the ENGINE START/

STOP button.

• Make sure the key is not covered by or touching a metal object.
• Do not bring a key from another vehicle’s immobilizer system near the ENGINE

START/STOP button.

• Do not put the key near magnetic items. Electronic devices, such as televisions

and audio systems emit strong magnetic fields. Note that even a key chain can
become magnetic.

Security System Alarm

The security system alarm activates when the tailgate, hood, or doors are forcibly
opened.
The alarm does not activate if the tailgate or doors are opened with the key, remote
transmitter or smart entry system

*

.

However, the alarm activates if a door is opened with the key, then the hood is
opened before the power mode is set to ON.

When the security system alarm activates

The horn sounds intermittently, and some exterior lights flash.

1

Immobilizer System

NOTICE

Leaving the key in the vehicle can result in theft or
accidental movement of the vehicle.
Always take the key with you whenever you leave the
vehicle unattended.

Do not alter the system or add other devices to it.
Doing so may damage the system and make your
vehicle inoperable.

Canadian models only: Apply and hold the brake
pedal before turning the vehicle on the first time after
the battery has been disconnected.

1

Security System Alarm

The security alarm continues for a maximum of two
minutes until the security system deactivates.

* Not available on all models

uu

Security System

u

Security System Alarm

180

Co
ntrols

To deactivate the security system alarm

Unlock the vehicle using remote transmitter or smart entry system

*

, or set the power

mode to ON. The system, along with the horn and flashing lights, is deactivated.

Setting the security system alarm

The security system alarm automatically sets when the following conditions have
been met:
• The power mode is set to VEHICLE OFF.
• The hood is closed.
• All doors and the tailgate are locked with the key, the remote transmitter or smart

entry system

*

.

When the security system alarm sets

The security system alarm indicator in the instrument panel blinks. When the
blinking interval changes after about 15 seconds, the security system alarm is set.

To cancel the security system alarm

The security system alarm is canceled when the vehicle is unlocked using the remote
transmitter, or smart entry system

*

, or the power mode is set to ON. The security

system alarm indicator goes off at the same time.

1

Security System Alarm

Do not set the security system alarm when someone
is in the vehicle or a window is open. The system can
accidentally activate when:

Unlocking the door with the lock tab.

Opening the hood with the hood release.

Opening the tailgate with the power tailgate
button on the dashboard.

If the battery goes dead after you have set the
security system alarm, the security alarm may activate
once the battery is recharged or replaced.
If this occurs, deactivate the security system alarm by
unlocking a door using the remote transmitter or
smart entry system

*

.

Do not alter the system or add other devices to it.
Doing so may damage the system and make your
vehicle inoperable.

Models with power tailgate

* Not available on all models

181

uu

Security System

u

Security System Alarm

Co
ntrols

The panic button on the remote
transmitter

If you press the panic button for
approximately one second, the following will
occur for about 30 seconds:
• The horn sounds.
• Some exterior lights flash.

Canceling panic mode

Press any button on the remote transmitter, or
set the power mode to ON.

Panic Mode

Panic
Button

182

Co
ntrols

Opening and Closing the Windows

Opening/Closing the Power Windows

The power windows can be opened and closed when the power mode is in ON,
using the switches on the doors. The driver side switches can be used to open and
close all of the windows.

The power window lock button on the driver side must be switched off (not pushed
in, indicator off) to open and close the windows from anywhere other than the
driver’s seat.

When the power window lock button is pushed in, the indicator comes on and you
can only operate the driver’s window. Turn the power window lock button on if a
child is in the vehicle.

Automatic operation

To open: Push the switch down firmly.
To close: Pull the switch up firmly.

The window opens or closes completely. To
stop the window at any time, push or pull the
switch briefly.

Manual operation

To open: Push the switch down lightly, and
hold it until the desired position is reached.
To close: Pull the switch up lightly, and hold it
until the desired position is reached.

Opening/Closing Windows with Auto-Open/Close Function

1

Opening/Closing the Power Windows

The power windows can be operated for up to 10
minutes after you set the power mode to VEHICLE
OFF.
Opening either front door cancels this function.

Auto Reverse
If a power window senses resistance when closing
automatically, it will stop closing and reverse
direction.

The driver’s window auto reverse function is disabled
when you continuously pull up the switch.

The auto reverse function stops sensing when the
window is almost closed to ensure that it fully closes.

3

WARNING

Closing a power window on someone’s
hands or fingers can cause serious injury.

Make sure your passengers are away from
the windows before closing them.

ON
OFF

Power Window
Lock Button

Indicator

Driver’s
Window
Switch

Front
Passenger’s
Window
Switch

Rear Passenger’s
Window Switch

*

* Not available on all models

183

uu

Opening and Closing the Windows

u

Opening/Closing the Power Windows

Continued

Co
ntrols

To open: Push the switch down.
To close: Pull the switch up.

Release the switch when the window reaches
the desired position.

To open: Press the unlock button, and then
within 10 seconds, press it again and hold it. If
the windows and moonroof

*

 stop midway,

repeat the procedure.

Opening/Closing Windows without Auto-Open/Close
Function

*

Close

Open

Second row seat

Opening the Windows and Moonroof

*

 with the Remote

Unlock
Button

* Not available on all models

184

uu

Opening and Closing the Windows

u

Opening/Closing the Power Windows

Co
ntrols

To open: Unlock the driver’s door with the
key. Within 10 seconds of returning the key to
the central position, turn the key in the unlock
direction and hold it there.

To close: Lock the driver’s door with the key.
Within 10 seconds of returning the key to the
central position, turn the key in the lock
direction and hold it there.

Release the key to stop the windows and
moonroof

*

 at the desired position. If you want

further adjustment, repeat the same
operation.

Opening/Closing the Windows and Moonroof

*

 with the Key

Close

Open

* Not available on all models

185

Co
ntrols

Opening and Closing the Moonroof

*

You can only operate the moonroof when the power mode is in ON. Use the switch
in the front of the ceiling to open and close the moonroof.

Automatic operation

To open: Pull the switch back firmly.
To close: Push the switch forward firmly.

The moonroof will automatically open or close
all the way. To stop the moonroof midway,
touch the switch briefly.

Manual operation

To open: Pull the switch back lightly, and
hold it until the desired position is reached.
To close: Push the switch forward lightly, and
hold it until the desired position is reached.

Tilting the moonroof up

To tilt: Push on the center of the moonroof
switch.
To close: Push the switch forward firmly,
then release.

Opening/Closing the Moonroof

1

Opening/Closing the Moonroof

NOTICE

Opening the moonroof in below freezing
temperature or when it is covered with snow or ice
can damage the moonroof panel or motor.

The power moonroof can be operated for up to 10
minutes after you set the power mode to VEHICLE
OFF.
Opening either front door cancels this function.

When resistance is detected, the auto reverse
function causes the moonroof to change directions,
then stop. Auto reverse stops sensing when the
moonroof is almost closed to ensure that it fully
closes. Make sure that all objects, including fingers,
are clear of the moonroof.

You can use the remote transmitter or the key to
operate the moonroof.

Opening the Windows and Moonroof

*



with the Remote P. 183

Opening/Closing the Windows and

Moonroof

*

 with the Key P. 184

3

WARNING

Opening or closing the moonroof on
someone’s hands or fingers can cause
serious injury.

Make sure all hands and fingers are clear of
the moonroof before opening or closing it.

Open

Close

Tilt

* Not available on all models

186

Co
ntrols

Operating the Switches Around the Steering Wheel

ENGINE START/STOP Button

*1:Canadian models

Changing the Power Mode

1

ENGINE START/STOP Button

ENGINE START/STOP Button Operating Range

You can start the engine when the remote is inside
the vehicle.
The engine may also run if the remote is close to the
door or window, even if it is outside the vehicle.

ON mode:
The ENGINE START/STOP button is red when the
engine is running.

If the battery of the remote is getting low, the engine
may not start when you press the ENGINE START/
STOP
 button. If the engine does not start, refer to
the following link.

If the Remote Battery is Weak P. 711

Operating Range

VEHICLE OFF (LOCK)
The button is off.
The steering wheel is locked

*1

The power to all electrical components is turned off.

ACCESSORY
The button blinks (in red).
Operate the audio system and other accessories
in this position.

ON
The button blinks (in red).
All electrical components can be used.

Press the button.

Without pressing the brake pedal

Change to

(

P.

U.S. models

Press the button without the
gear position in

(

P.

Change to

(

P then press the

button.

Continued

187

uu

Operating the Switches Around the Steering Wheel

u

ENGINE START/STOP Button

Co
ntrols

If you leave the vehicle for 30 to 60 minutes with the transmission in

(

P and the

power mode in ACCESSORY, the vehicle automatically goes into the mode similar to
VEHICLE OFF (LOCK) to avoid draining the battery.

When in this mode:
The steering wheel does not lock.
You cannot lock or unlock doors with the remote transmitter or the smart entry
system.

Press the ENGINE START/STOP button to switch the mode to VEHICLE OFF (LOCK).

Automatic Power Off

1

ENGINE START/STOP Button

If the power mode does not change from VEHICLE
OFF to ACCESSORY, press the ENGINE START/STOP
button while moving the steering wheel left and
right. The steering wheel will unlock, allowing the
mode to change.

Do not leave the power mode in ACCESSORY or ON
when you get out.

Canadian models

Canadian models

uu

Operating the Switches Around the Steering Wheel

u

ENGINE START/STOP Button

188

Co
ntrols

If you open the driver’s door when the power mode is set to ACCESSORY, a warning
beep sounds.

Warning buzzers may sound from inside and/
or outside the vehicle to remind you that the
remote is out of the vehicle. If the buzzer
continues even after the remote is put back
inside, place it to be within its operational
range.

When the power mode is in ON

If the remote is taken out of the vehicle, and
the driver’s door is closed, warning buzzers
sound from both inside and outside the
vehicle. A warning message on the driver
information interface notifies the driver inside
that the remote is outside of the vehicle.

When the power mode is in
ACCESSORY

If the remote is taken out of the vehicle, and
all the doors are closed, a warning buzzer
sounds from outside the vehicle.

Power Mode Reminder

Remote Reminder

1

Remote Reminder

When the remote is within the system’s operational
range, and the driver’s door is closed, the warning
function cancels.

If the remote is taken out of the vehicle after the
engine has been started, you can no longer change
the ENGINE START/STOP button mode or restart
the engine. Always make sure if the remote is in your
vehicle when you operate the ENGINE START/STOP
button.

Removing the remote from the vehicle through a
window does not activate the warning buzzer.

Do not put the remote on the dashboard or in the
glove box. It may cause the warning buzzer to
activate. Under some other conditions that can
prevent the vehicle from locating the remote, the
warning buzzer may also activate even if the remote
is within the system’s operational range.

189

uu

Operating the Switches Around the Steering Wheel

u

Turn Signals

Continued

Co
ntrols

Turn Signals

The turn signals can be used when the power
mode is in ON.

One-touch turn signal

When you lightly push up or down and release
the turn signal lever, the exterior turn signals
and turn signal indicator blink three times.

The feature can be used when signaling for a
lane change.

Light Switches

Rotating the light switch turns the lights on
and off, regardless of the power mode
setting.

High beams

Push the lever forward until you hear a click.

Low beams

When in high beams, pull the lever back to
return to low beams.

Flashing the high beams

Pull the lever back, and release it.

Right Turn

Left Turn

Manual Operation

1

Light Switches

If you leave the power mode in VEHICLE OFF with the
lights on, a chime sounds when the driver’s door is
opened.

When the lights are on, the lights on indicator in the
instrument panel will be on.

Lights On Indicator P. 93

Do not leave the lights on when the engine is off
because it will cause the battery to discharge.

If you sense that the level of the headlights is
abnormal, have the vehicle inspected by a dealer.

High Beams

Flashing the high beams

Low Beams

Turns on parking, side marker,
tail, and rear license plate lights

Turns on headlights, parking,
side marker, tail, and rear license
plate lights

uu

Operating the Switches Around the Steering Wheel

u

Light Switches

190

Co
ntrols

Automatic lighting control can be used when
the power mode is in ON.

When you turn the light switch to AUTO, the
headlights and other exterior lights will switch
on and off automatically depending on the
ambient brightness.

u

You can change the auto light sensitivity
setting.

Customized Features P. 443

Automatic Operation (automatic lighting control)

*

1

Automatic Operation (automatic lighting control)

*

We recommend that you turn on the lights manually
when driving at night, in a dense fog, or in dark areas
such as long tunnels or parking facilities.

The light sensor is in the location shown below.
Do not cover this light sensor with anything;
otherwise, the automatic lighting system may not
work properly.

Light
Sensor

Models without
automatic
intermittent wiper

Light Sensor

Models with automatic intermittent
wiper

* Not available on all models

191

uu

Operating the Switches Around the Steering Wheel

u

Light Switches

Co
ntrols

The headlights automatically come on when the wipers are used several times within
a certain number of intervals with the headlight switch in AUTO.
The headlights automatically go off a few minutes later if the wipers are stopped.

The headlights, all other exterior lights, and the instrument panel lights turn off 15
seconds after you set the power mode to VEHICLE OFF, take the remote with you,
and close the driver’s door.

u

You can change the headlight auto off timer setting.

Vehicle Customization P. 133

Customized Features P. 443

If you set the power mode to VEHICLE OFF with the headlight switch on, but do not
open the door, the lights turn off after 10 minutes (3 minutes, if the switch is in the
AUTO

*

 position).

The lights turn on again when you unlock or open the driver’s door. If you unlock
the door, but do not open it within 15 seconds, the lights go off. If you open the
driver’s door, you will hear a lights on reminder chime.

Headlight Integration with Wiper

*

Automatic Lighting Off Feature

1

Automatic Operation (automatic lighting control)

*

Adjust the auto light sensitivity as follows:

Setting

The exterior lights come on

when the ambient light is at

MAX

HIGH

MID

LOW

MIN

Bright

Dark

1

Headlight Integration with Wiper

*

This feature activates when AUTO mode is selected
and the headlights are off.
The instrument panel brightness does not change
when the headlights come on.

At dark ambient light levels, the automatic lighting
control feature turns on the headlights, regardless of
the number of wiper sweeps.

Models with color audio system

Models with Display Audio

* Not available on all models















Content   ..  10  11  12  13   ..
