Honda Odyssey (2019 year). Manual - part 7





96

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Lane Keeping
Assist System
(LKAS) Indicator
(Amber)

*

• Comes on for a few seconds when

you set the power mode to ON,
then goes off.

• Comes on if there is a problem

with the LKAS.

• Stays on constantly - Have your

vehicle checked by a dealer.

Lane Keeping
Assist System
(LKAS) Indicator
(Green)

*

• Comes on when you press the

MAIN button.

Lane Keeping Assist System (LKAS)

*



P. 583

• Comes on when the LKAS is in

operation, or the LKAS button is
pressed, but the temperature
inside the front sensor camera is
too high. The LKAS cancels
automatically. The beeper sounds
simultaneously.

• Use the climate control system to cool

down the camera.

• Goes off - The camera has cooled down

and the system is working normally.

Front Sensor Camera

*

 P. 564

• Comes on when the area around

the camera is blocked by dirt,
mud, etc. Stop your vehicle in a
safe place, and wipe it off with a
soft cloth.

• May come on when driving in bad

weather (rain, snow, fog, etc.)

• Have your vehicle checked by a dealer if

the indicator and message come back on
after you cleaned the area around the
camera.

* Not available on all models

97

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Road Departure
Mitigation
(RDM) Indicator

*

• Comes on for a few seconds when

you change the power mode to
ON, then goes off.

• Comes on if there is a problem

with the RDM system.

• Stays on constantly - Have your

vehicle checked by a dealer.

• Comes on when the RDM system

shuts itself off.

• Stays on - The temperature inside the

camera is too high.
Use the climate control system to cool
down the camera.
The system activates when the
temperature inside the camera cools
down.

Front Sensor Camera

*

 P. 564

• Stays on - The area around the camera

is blocked by dirt, mud, etc. Stop your
vehicle in a safe place, and wipe it off
with a soft cloth.

• Have your vehicle checked by a dealer if

the indicator and message come back on
after you cleaned the area around the
camera.

Front Sensor Camera

*

 P. 564

* Not available on all models

98

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Adaptive Cruise
Control (ACC
Indicator
(Amber)

*

• Comes on for a few seconds when

you set the power mode to ON,
then goes off.

• Comes on if there is a problem

with ACC.

• Comes on while driving - Have your

vehicle checked by a dealer.

• Comes on if anything covers the

radar sensor cover and prevents
the sensor from detecting a
vehicle in front.

• May come on when driving in bad

weather (rain, snow, fog, etc.)

• ACC has been automatically

canceled.

• When the radar sensor gets dirty, stop

your vehicle in a safe place, and wipe off
dirt using a soft cloth.

• Have your vehicle checked by a dealer if

the indicator does not go off even after
you clean the sensor cover.

Adaptive Cruise
Control (ACC
Indicator
(Green)

*

• Comes on when you press the

MAIN button.

Adaptive Cruise Control (ACC)

*



P. 566

• Comes on when ACC is in

operation, but the temperature
inside the front sensor camera is
too high. ACC cancels
automatically. The beeper sounds
simultaneously.

• Use the climate control system to cool

down the camera.

• Goes off - The camera has been cooled

down. Pressing the MAIN button can
resume the system.

Front Sensor Camera

*

 P. 564

Adaptive Cruise Control (ACC)

*



P. 566

* Not available on all models

99

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Adaptive Cruise
Control (ACC
Indicator
(Green)

*

• Comes on when the area around

the camera is blocked by dirt,
mud, etc. Stop your vehicle in a
safe place, and wipe it off with a
soft cloth.

• May come on when driving in bad

weather (rain, snow, fog, etc.)

• Have your vehicle checked by a dealer if

the indicator and message come back on
after you cleaned the area around the
camera.

Collision
Mitigation
Braking
System

TM



(CMBS

TM

Indicator

*

• Comes on for a few seconds when

you change the power mode to
ON, then goes off.

• Comes on when you deactivate

the CMBS

TM

. A driver information

interface message appears for five
seconds.

• Comes on if there is a problem

with the CMBS

TM

.

• Stays on constantly without the

CMBS

TM

 off - Have your vehicle checked

by a dealer.

Collision Mitigation Braking

System

TM

 (CMBS

TM

)

*

 P. 610

* Not available on all models

100

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Collision
Mitigation
Braking
System

TM



(CMBS

TM

Indicator

*

• Comes on when the CMBS

TM



system shuts itself off.

• Stays on - The area around the camera

is blocked by dirt, mud, etc. Stop your
vehicle in a safe place, and wipe it off
with a soft cloth.

Front Sensor Camera

*

 P. 564

• When the radar sensor gets dirty, stop

your vehicle in a safe place, and wipe off
dirt using a soft cloth.

• Have your vehicle checked by a dealer if

the indicator does not go off even after
you clean the sensor cover.

Collision Mitigation Braking

System

TM

 (CMBS

TM

)

*

 P. 610

• Stays on - The temperature inside the

camera is too high. Use the climate
control system to cool down the camera.
The system activates when the
temperature inside the camera cools
down.

Front Sensor Camera

*

 P. 564

* Not available on all models

101

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Blind spot
information
System Indicator

• Stays on while the blind spot

information system is turned off.

• Comes on when mud, snow, or ice

accumulates in the vicinity of
sensor.

• Comes on while driving - Remove the

obstacle in the vicinity of the sensor.

Blind spot information System

*



P. 598

• Comes on if there is a problem

with the system.

• Comes on while driving - Have your

vehicle checked by a dealer.

Models with Blind spot information System

* Not available on all models

102

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Driver Information Interface Warning and Information Messages

The following messages appear only on the driver information interface. Press the

 (home) button, select Warnings, then press the

ENTER button to see the message again with the system message indicator on.

Message

Condition

Explanation

• Appears if any door or the tailgate is not completely

closed.

• Goes off when all doors and the tailgate are closed.

• Appears when the hood is opened.

• Close the hood.

• Appears when the engine oil pressure is low.

• Appears while driving - Immediately stop in a safe

place.

If the Low Oil Pressure Symbol Appears P. 718

• Appears if there is a problem with the shutter grille,

and the radiator coolant temperature is too high.

• Power output will be reduced, so you may not be able

to accelerate or maintain your current speed. Have your
vehicle checked by a dealer.

103

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears when the washer fluid is low.

• Refill the washer fluid.

Refilling Window Washer Fluid  P. 659

• Appears while you are customizing the settings and

the transmission is in other than

(

P.

Vehicle Customization P. 133

• Appears when the temperature of the transmission

is starting to get too hot.

• The performance of the vehicle may be reduced.

• Until the message disappears, reduce your speed and

allow the system to cool down.

• Appears if the battery charge becomes low.

• Charge the battery.

• Appears when the fuel fill door is opened.

• Close the fuel fill door.

Canadian models

Models with color audio system

104

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears when there is a problem with the sensor on

the battery.

• Have your vehicle checked by a dealer.

Checking the Battery P. 684

• Appears along with the charging system indicator

when the battery is not charging.

• Turn off the climate control system and rear defogger

to reduce electricity consumption.

If the Charging System Indicator Comes On P. 718

• Appears when the scheduled maintenance is due

soon.

• Consequently, Maintenance Due Now and

Maintenance Past Due follow.

Maintenance Minder Messages on the Driver

Information Interface P. 643

• Appears if there is a problem with the power sliding

door system.

• Turn off the main switch and manually operate the

power sliding doors.

• Have your vehicle checked by a dealer.

Opening/Closing the Power Sliding Doors

*

  P. 172

U.S.

Canada

Models with power sliding doors

* Not available on all models

105

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears when the engine coolant temperature gets

abnormally high.

Overheating P. 715

• Appears when there is a problem with the power

tailgate system.

• Manually open or close the power tailgate.
• Have your vehicle checked by a dealer.

• Appears when the starter system has a problem.

• As a temporary measure, press and hold the ENGINE

START/STOP button for up to 15 seconds while
pressing the brake pedal and manually start the engine.

• Have your vehicle checked by a dealer.

U.S.

Canada

Models with power tailgate

U.S.

Canada

106

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears when you set the power mode to

ACCESSORY or ON.

Starting the Engine P. 538

• Appears when the engine does not restart

automatically due to the following reason:

• The hood is open.
• There is a problem in the system that disables Auto

Idle Stop.

• Follow the normal procedure to start the engine.

Starting the Engine P. 538

• Close the hood.

• Appears when the steering wheel is locked.

• Move the steering wheel left and right while pressing

the ENGINE START/STOP button.

• Appears when the power mode is in ACCESSORY.

• Appears after the driver’s door is opened when the

power mode is in ACCESSORY.

• Press the ENGINE START/STOP button twice with your

foot off the brake pedal to change the power mode to
VEHICLE OFF.

Models with Auto Idle Stop

Canadian models

107

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears when you close the door with the power

mode in ON without the remote inside the vehicle.

• Disappears when you bring the remote back inside the

vehicle and close the door.

Remote Reminder P. 188

• Appears when the remote battery becomes weak.

• Replace the battery as soon as possible.

Replacing the Button Battery P. 686

• Appears if the remote battery is too weak to start the

engine or the key is not within operating range to
start the engine.
A beeper sounds six times.

• Bring the remote in front of the ENGINE START/STOP

button to be touched with.

If the Remote Battery is Weak P. 711

• Appears if you press the ENGINE START/STOP

button while the vehicle is moving.

• The message will disappear after six seconds or when

the power mode is set to VEHICLE OFF.

• Appears after the driver’s door is opened when the

power mode is in ACCESSORY.

• Press and hold the ENGINE START/STOP button with

your foot off the brake pedal to change the power
mode to VEHICLE OFF.

• Appears when you attempt to change to another

gear position with the transmission in

(

P and the

engine OFF.

• To select another gear position while in

(

P, the engine

must be ON.

• Appears when you set the power mode to OFF while

driving.

• Immediately stop in a safe place, set the parking brake,

then restart the engine. If the message disappears,
continue driving.

ELITE and TOURING grade models

108

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears when the vehicle is stopped with the

driver’s seat belt unfastened and there is a chance
that the vehicle may roll unintentionally.

• Press the

(

P button before release the brake pedal

when idling, parking or exiting the vehicle.

Shift Operation P. 548

• Appears when the engine stops without the

transmission in

(

P, and does not restart

automatically.

• Appears if you open the hood while Auto Idle Stop

activates.

• If you want to set the power mode to ON, change the

gear position to

(

P.

• If you want to start the engine, follow the normal

procedure.

Starting the Engine P. 538

• Appears when you change to

(

N, then release the

(

N button.

If you want to keep the transmission in

(

N



position [car wash mode] P. 550

• Appears when car wash mode is not available due to

hot transmission.

• When transmission is too hot, car wash mode may not

be available. Let the engine idle and cool down
transmission.

If you want to keep the transmission in

(

N



position [car wash mode] P. 550

• Appears when you try to change the gear position

without depressing the brake pedal.

• Depress the brake pedal, then select a shift button.

Models with Auto Idle Stop

ELITE and TOURING grade models

109

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears when you try to change the gear position

without releasing your foot off the accelerator pedal.

• Release your foot off the accelerator pedal, then select

a shift button.

• Appears when the

(

P button is pressed while the

vehicle is moving.

• Appears if you change the gear position to

(

R while

the vehicle is moving forward, or to

(

D while the

vehicle is reversing.

• Make sure that the vehicle comes to a stop before

operating the select button.

• Appears when you set the power mode to ON

without fastening the driver’s seat belt.

• Appears when you change the gear position after

(

P has been automatically selected with the driver’s

door open, the driver’s seat belt unfastened, then
the brake pedal is released.

• Fasten the seat belt properly before you start to drive.

Shift Operation P. 548

• Appears when you press the

(

P button but it is not

engaged due to low ATF temperature.

• Depress the brake pedal until this message disappear.

• Appears when depressing the accelerator pedal

while the gear position is in

(

N.

• Remove your foot from the accelerator pedal. When

driving, depress the brake pedal and change the gear
position.

Except ELITE and TOURING grade models

110

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears when you press and hold

(

N button for

more than two seconds.

• Disappears when you set the gear position to other

than

(

N.

If you want to keep the transmission in

(

N



position [car wash mode] P. 550

• Appears if there is a problem with the cooling

system.

• Drive slowly to prevent overheating and have your

vehicle checked by a dealer as soon as possible.

• Appears if there is a problem with the automatic

lighting control system.

• Appears while driving - Manually turn the lights on,

and have your vehicle checked by a dealer.

• Appears if there is a problem with the headlights.

• Appears while driving - The headlights may not be

on. When conditions allow you to drive safety, have
your vehicle checked by a dealer as soon as possible.

• Appears if there is a problem with the parking sensor

system.

• Check if the area around the sensor(s) is covered with

mud, ice, snow, etc. If the indicator(s) stays on or the
beeper does not stop even after you clean the area,
have the system checked by a dealer.

• Appears if there are obstacles around the sensors.

• Check for obstacles near your vehicle to make sure it is

safe to park.

Models with LED headlights

Models with LED headlights

Models with parking sensor system

Models with parking sensor system

111

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears if the automatic brake hold is automatically

canceled while it is in operation.

• Immediately depress the brake pedal.

• Appears when the automatic brake hold system is

turned off.

Automatic Brake Hold P. 606

• Appears when the automatic brake hold button is

pressed without wearing the driver’s seat belt.

• Fasten the driver’s seat belt.

Automatic Brake Hold P. 606

• Appears when the automatic brake hold button is

pressed without depressing the brake pedal while
the automatic brake hold is in operation.

• Press the automatic brake hold button with the brake

pedal depressed.

Automatic Brake Hold P. 606

• Appears when the parking brake is applied

automatically while it is in operation.

Automatic Brake Hold P. 606
Parking Brake P. 602















Content   ..  5  6  7  8   ..
