Honda Fit (2019 year). Manual - part 24





367

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

The following options are available during a call.
Swap Call: Put the current call on hold to answer the incoming call.
Mute: Mute your voice.
Transfer Call: Transfer a call from HFL to your phone.
Dial Tones: Send numbers during a call. This is useful when you call a menu-driven
phone system.

1. To view the available options, press the



button.

2. Rotate

 to select the option, then press

.

u

The check box is checked when Mute is
selected. Select Mute again to turn it off.

Options During a Call

1

Options During a Call

Dial Tones: Available on some phones.

368

Features

Bluetooth® HandsFreeLink®

The Bluetooth® HandsFreeLink® (HFL) allows you to place and receive phone calls
using your vehicle’s audio system, without handling your mobile phone.

Using HFL

HFL Buttons

1

Bluetooth® HandsFreeLink®

Place your phone where you can get good reception.
To use HFL, you need a Bluetooth-compatible mobile
phone. For a list of compatible phones, pairing
procedures, and special feature capabilities:

U.S.: Visit automobiles.honda.com/handsfreelink/
or call 1-888-528-7876.

Canada: For more information on smartphone
compatibility, call 1-888-528-7876.

To use the system, the Bluetooth On/Off Status
setting must be On. If there is an active connection to
Apple CarPlay

TM

, HFL is unavailable.

Customized Features P. 328

Voice control tips

Aim the vents away from the ceiling and close the
windows, as noise coming from them may interfere
with the microphones.

Press the

 button when you want to call a

number using a stored voice tag. Speak clearly and
naturally after a beep.

If the microphones pick up voices other than yours,
the command may be misinterpreted.

To change the volume level, use the audio system's
volume knob or the remote audio controls on the
steering wheel.

Up to five speed dial entries can be displayed among
a total of 20 that can be entered. If there is no entry
in the system, Speed Dial is disabled.

Speed Dial P. 381

Up to five call histories can be displayed among a
total of 20 that can be entered. If there is no call
history, Call History is disabled.

Models with display audio system

Microphone

 (Pick-up) Button

 (Hang-up/Back) Button

Volume up

 (Talk) Button

 (Menu) Button

Volume down

SOURCE Button



Button

Continued

369

uu

Bluetooth® HandsFreeLink®

u

Using HFL

Features

 (Pick-up) button: Press to go directly to the phone screen, or to answer an

incoming call.

 (Hang-up/back) button: Press to end a call, go back to the previous

command, or cancel a command.

 (Talk) button: Press to call a number with a stored voice tag.

 (Menu) button: Press and hold to display Speed DialCall History, or Redial

on the phone screen.



button:

Press to select an item displayed on the phone screen.

SOURCE button: Press to call a number listed in the selected item on the phone
screen.
To go to the Phone Menu screen:
1. Select .
2. Select Phone to switch the display to the phone screen.
3. Select .

1

Bluetooth® HandsFreeLink®

Bluetooth® Wireless Technology
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc., and any
use of such marks by Honda Motor Co., Ltd., is under
license. Other trademarks and trade names are those
of their respective owners.

HFL Limitations
An incoming call on HFL will interrupt the audio
system when it is playing. It will resume when the call
is ended.

uu

Bluetooth® HandsFreeLink®

u

Using HFL

370

Features

The audio/information screen notifies you when there is an incoming call.

Certain manual functions are disabled or inoperable while the vehicle is in motion.
You cannot select a grayed-out option until the vehicle is stopped.

Only previously stored speed dial entries with voice tags, phonebook names, or
numbers can be called using voice commands while the vehicle is in motion.

Speed Dial P. 381

HFL Status Display

1

HFL Status Display

The information that appears on the audio/
information screen varies between phone models.

You can change the system language.

Customized Features P. 328

HFL Mode

Battery Level Status

Signal Strength

Bluetooth Indicator
Appears when your phone
is connected to HFL.

Caller’s Name

Caller’s Number

Roaming Status

Limitations for Manual Operation

371

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

HFL Menus

The ignition switch must be in ACCESSORY

(

q or ON

(

w

*1

 to use the system.

Phone settings screen

1. Select .
2. Select Settings.
3. Select Phone.

1

HFL Menus

To use HFL, you must first pair your Bluetooth-
compatible mobile phone to the system while the
vehicle is parked.

Some functions are limited while driving.

*1 : Models with the keyless access system have an ENGINE START/STOP button instead of an ignition switch.

Disconnect a paired phone
from the system.

Bluetooth Device List

(Existing entry list)

Disconnect

Delete

Delete a previously paired
phone.

Add Bluetooth Device

Pair a new phone to the system.

Phone

Connect a paired device to
the system.

Connect:

Connect
Connect

372

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

Automatic Phone Sync

Ring Tone

Select the fixed or mobile phone.

Turn HondaLink® Assist on and off.

HondaLink Assist

Set phonebook and call history data to be automatically imported when a phone is paired to HFL.

Auto Phone Call Transfer

When vehicle is turned on, automatically transfer an active call from device to vehicle speakers.

Enable Text Messages

Text Messages

New Message Notification

Select whether a pop-up alert comes on the screen when HFL
receives a new text message.

Turn the text message function on and off.

Default

Cancel/Reset all customized items in the Phone settings group as default.

373

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

Phone Menu screen

1. Select .
2. Select Phone.
3. Select .

Select a phone number from the call history to
store as a speed dial number.

Speed Dial

Manual Input

New Entry

Import from Call History

Import from Phonebook

Select a phone number from the phonebook
to store as a speed dial number.

Enter a phone number to store as a speed
dial number.

(Existing entry list)

Dial the selected number in the speed dial list.

Select a phone number from the call history to
store as a speed dial number.

Manual Input

New Entry

Import from Call History

Import from Phonebook

Select a phone number from the phonebook
to store as a speed dial number.

Enter a phone number to store as a speed
dial number.

(Existing entry list)

Dial the selected number in the speed dial list.

Edit Speed Dial

Delete All

Delete all of the previously stored speed dial number.

374

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

See the previous message.

Text Messages

Read/Stop

(Existing message list)

See the next message.

System reads received message aloud, or
stop message from being read.

Reply to a received message using one of six
fixed phrases.

Dial

Make a call to the sender.

Reply

Display the last outgoing, incoming and missed calls.

Call History

All

Dialed

Received

Display the last outgoing calls.

Display the last incoming calls.

Missed

Display the last missed calls.

Dial

Redial

Enter a phone number to dial.

Redial the last number dialed.

Phonebook

Display the paired phone’s phonebook.

Continued

375

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

To pair a mobile phone (when there is
no phone paired to the system)

1. Select Phone.
2. Select Yes.
3. Make sure your phone is search or

discoverable mode, then select OK.

u

HFL automatically searches for a
Bluetooth® device.

4. Select your phone when it appears on the

list.

u

If your phone does not appear, you can
select Refresh to search again.

u

If your phone still does not appear, select
Phone Not Found and search for
Bluetooth® devices using your phone.
From your phone, search for
HandsFreeLink.

5. The system gives you a pairing code on the

audio/information screen.

u

Confirm if the pairing code on the screen
and your phone match.
This may vary by phone.

Phone Setup

1

Phone Setup

Your Bluetooth-compatible phone must be paired to
the system before you can make and receive hands-
free calls.

Phone Pairing Tips:

You cannot pair your phone while the vehicle is
moving.

Up to six phones can be paired.

Your phone’s battery may drain faster when it is
paired to the system.

If your phone is not ready for pairing or not found
by the system within three minutes, the system will
time out and returns to idle.

Once you have paired a phone, you can see it
displayed on the screen with one or two icons on the
right side.
These icons indicate the following:

: The phone can be used with HFL.

: The phone is compatible with Bluetooth® Audio.

If there is an active connection to Apple CarPlay

TM

pairing of additional Bluetooth-compatible devices is
unavailable and Add Bluetooth Device is grayed
out from the Bluetooth Device List screen.

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

376

Features

To change the currently paired phone

1. Go to the phone settings screen.

Phone settings screen P. 371

2. Select Bluetooth Device List.
3. Select a phone to connect.

u

HFL disconnects the connected phone
and starts searching for another paired
phone.

4. Select Connect



Connect ,

or

Connect

.

To change the pairing code setting

1. Select .
2. Select Settings.
3. Select Bluetooth / Wi-Fi.
4. Select the Bluetooth tab.
5. Select Edit Pairing Code.

6. Select Random or Fixed.

1

To change the currently paired phone

If no other phones are found or paired when trying to
switch to another phone, HFL will inform you that the
original phone is connected again.

To pair other phones, select Add Bluetooth Device
from the Bluetooth Device List screen.

1

To change the pairing code setting

The default pairing code is 0000 until you change the
setting.
To create your own, select Fixed, and delete the
current code, then enter a new one.

For a randomly generated pairing code each time you
pair a phone, select Random.

377

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

To delete a paired phone

1. Go to the phone settings screen.

Phone settings screen P. 371

2. Select Bluetooth Device List.
3. Select a phone you want to delete.

4. Select Delete.
5. A confirmation message appears on the

screen. Select Yes.

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

378

Features

To turn on or off the text message
function

1. Go to the phone settings screen.

Phone settings screen P. 371

2. Select Enable Text Messages.

u

A pop-up menu appears on the screen.

3. Select On or Off.

To turn on or off the text message
notice

1. Go to the phone settings screen.

Phone settings screen P. 371

2. Select New Message Notification.

u

A pop-up menu appears on the screen.

3. Select On or Off.

To Set Up Text Message Options

1

To Set Up Text Message Options

To use the text message function, it may be necessary
to set up on your phone.

1

To turn on or off the text message notice

On: A pop-up notification comes on every time you
receive a new message.
Off: The message you receive is stored in the system
without notification.

Continued

379

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

When Automatic Phone Sync is set to
On:

When your phone is paired, the contents of its
phonebook and call history are automatically
imported to the system.

Changing the Automatic Phone Sync
setting

1. Go to the phone settings screen.

Phone settings screen P. 371

2. Select Automatic Phone Sync.

3. Select On or Off.

Automatic Import of Cellular Phonebook and Call History

1

Automatic Import of Cellular Phonebook and Call History

When you select a name from the list in the cellular
phonebook, you can see up to three category icons.
The icons indicate what types of numbers are stored
for that name.

On some phones, it may not be possible to import the
category icons to the system.

The phonebook is updated after every connection.
Call history is updated after every connection or call.

Pref

Home

Mobile

Work

Pager

Fax

Car

Other

Voice

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

380

Features

You can change the ring tone setting.

1. Go to the phone settings screen.

Phone settings screen P. 371

2. Select Ring Tone.
3. Select Fixed or Mobile Phone.

If you get into the vehicle while you are on the phone, the call can be automatically
transferred to HFL.

1. Go to the phone setting screen.

Phone settings screen P. 371

2. Select Auto Phone Call Transfer.
3. Select On or Off.

Ring Tone

1

Ring Tone

Fixed: The fixed ring tone sounds from the speakers.
Mobile Phone: For certain connected phones, the
ring tone stored in the phone sounds from the
speakers.

Automatic Transferring

Continued

381

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

Up to 20 speed dial numbers can be stored per phone.

To store a speed dial number:
1. Go to the phone menu screen.

Phone Menu screen P. 373

2. Select Speed Dial.
3. Select New Entry.
4. Select a place to choose a number.

From Import from Call History:

u

Select a number from the call history.

From Manual Input:

u

Input the number manually.

From Import from Phonebook:

u

Select a number from the connected
mobile phone’s imported phonebook.

5. When the speed dial is successfully stored,

you are asked to create a voice tag for the
number. Select Yes or No.

6. Select Record to store a voice tag for the

speed dial entry.

u

Using the

 button, follow the prompts

to store a voice tag for the speed dial
entry.

Speed Dial

1

Speed Dial

When a voice tag is stored, press the

 button to

call the number using the voice tag. Say the voice tag
name.

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

382

Features

To add a voice tag to a stored speed
dial number

1. Go to the phone menu screen.

Phone Menu screen P. 373

2. Select Edit Speed Dial.
3. Select an existing speed dial entry.

u

From the pop-up menu, select Edit.

4. Select Voice Tag.

u

From the pop-up menu, select Record.

5. Select Record, or use the

 button,

follow the prompts to complete the voice
tag.

To delete a voice tag

1. Go to the phone menu screen.

Phone Menu screen P. 373

2. Select Edit Speed Dial.
3. Select an existing speed dial entry.

u

From the pop-up menu, select Edit.

4. Select Voice Tag.

u

From the pop-up menu, select Clear.

5. A confirmation message appears on the

screen. Select Yes.

1

Speed Dial

Avoid using duplicate voice tags.
Avoid using “home” as a voice tag.
It is easier for the system to recognise a longer name.
For example, use “John Smith” instead of “John.”















Content   ..  22  23  24  25   ..
