Honda CR-V (2018 year). Manual - part 19

288

Audio System Basic Operation

Voice Control Operation

Features

When On Screen Commands is selected,
the explanation screen is displayed.

The system accepts these commands on the
Music Search screen.

■

Using Song By Voice

Song By Voice

is a feature that allows you

to select music from your iPod or USB device
using Voice Commands. To activate this
mode, you must press the

(Talk) button

and say: “Music search”.

■

Song By Voice Commands

• What am I listening to?
• Who am I listening to?
• Who is this?
• What’s playing?
• Who’s playing?
• What album is this?

*1: Models with navigation system

■

On Screen Commands

■

Music Search Commands

■

Play Commands

• Play artist <Name>
• Play track/song <Name>
• Play album <Name>
• Play genre/category <Name>
• Play playlist <Name>
• Play composer <Name>

■

List Commands

• List artist <Name>
• List album <Name>
• List genre/category <Name>
• List playlist <Name>
• List composer <Name>

• What time is it?
• What is today’s date?

■

General Commands

• Climate Control On
• Climate Control Off
• Fan Speed <1-7>
• Temperature max heat
• Temperature max cool
• Temperature <57-87> degrees (U.S.)
• Temperature <18-32> degrees (Canada)
• Defrost On
• Defrost Off
• Air conditioner On
• Air conditioner Off
• More
• Vent
• Dash and floor
• Floor vents
• Floor and Defrost
• Climate Control Automatic
• Fan Speed up/down
• Temperature up
• Temperature down
NOTE:
These commands toggle the function on
and off, so the command may not match
your intended action.

■

Climate Control Commands

289

Audio System Basic Operation

Playing AM/FM Radio

Continued

Features

Playing AM/FM Radio

*1:Some or all of the lists may not be displayed.

VOL/

AUDIO (Volume/Power Audio)

Knob
Press to turn the audio system on and off.
Turn to adjust the volume.

(Back) Icon

Select to go back to the previous
display.

Seek Icons
Select

to search the

selected band up or down for a
station with a strong signal.

Open/Close Icon

Displays/hides the detailed
information.

(Audio) Icon

Select to display the audio screen.

Tune Icons
Select

to tune

the radio frequency.

Audio/Information Screen

Scan Icon
Select to scan each station with a
strong signal.

Preset Icons
Tune the preset radio frequency. Select and hold the
preset icon to store that station. Select

to display

preset 7 onwards.

Driver Information Interface

Audio System Basic Operation

Playing AM/FM Radio

290

Features

To store a station:
1. Tune to the selected station.
2. Select and hold the preset number for the station you want to store.

You can also store a preset station by the following procedure.
1. Tune to the selected station.
2. Select the open/close icon to display a list.
3. Select the Preset tab.
4. Select and hold the preset number for the station you want to store.

Lists the strongest stations on the selected band.
1. Select the open/close icon to display a list.
2. Select the Station List tab.
3. Select the station.

■

Manual update

Updates your available station list at any time.
1. Select the open/close icon to display a list.
2. Select the Station List tab.
3. Select Refresh.

■

Preset Memory

■

Station List

Preset Memory

The ST indicator appears on the display indicating
stereo FM broadcasts.
Stereo reproduction in AM is not available.

Switching the Audio Mode
Press the

button on the steering wheel or

select SOURCE on the screen.

2 Audio Remote Controls P. 235

You can store 6 AM stations and 12 FM stations into
preset memory.

HD Radio Technology manufactured under license
from iBiquity Digital Corporation. U.S. and Foreign
Patents. HD Radio

and the HD, HD Radio, and

“Arc” logos are proprietary trademarks of iBiquity
Digital Corp.

Continued

291

Audio System Basic Operation

Playing AM/FM Radio

Features

Samples each of the strongest stations on the selected band for 10 seconds. To turn
off scan, select Cancel or

Displays the subchannel list when an HD Radio

station is selected while listening to

an FM station.
1. Select MENU.
2. Select HD Radio Subchannel.
3. Select the channel number.

Provides text data information related to your selected RDS-capable FM station.

■

To find an RDS station from Station List

1. Select the open/close icon to display a list while listening to an FM station.
2. Select the Station List tab.
3. Select the station.

■

Manual update

Updates your available station list at any time.
1. Select the open/close icon to display a list while listening to an FM station.
2. Select the Station List tab.
3. Select Refresh.

■

Scan

■

HD Subchannel

■

Radio Data System (RDS)

Models with HD Radio

Radio Data System (RDS)

When you select an RDS-capable FM station, the RDS
automatically turns on, and the frequency display
changes to the station name. However, when the
signals of that station become weak, the display
changes from the station name to the frequency.

292

Audio System Basic Operation

Playing AM/FM Radio

Features

■

Radio text

Displays the radio text information of the selected RDS station.
1. Select MENU.
2. Select View Radio Text.

■

Scan

Samples each of the strongest stations on the selected band for 10 seconds.

To turn off scan, select Cancel or

293

Audio System Basic Operation

Playing SiriusXM® Radio

Continued

Features

Playing SiriusXM® Radio

*1:Some or all of the lists may not be displayed.

VOL/

AUDIO (Volume/Power Audio) Knob

Press to turn the audio system on and off.
Turn to adjust the volume.

(Back) Icon

Select to go back to the previous display.

Channel Icons
Select

to the previous

or next channel.
Select and hold to rapidly skip 10
channels at a time.

Open/Close Icon

Displays/hides the detailed
information.

(Audio) Icon

Select to display the audio screen.

Category Icons
Select

to display and select a

SiriusXM® Radio category.

Audio/Information Screen

Scan Icon
Select to scan each channel.

Preset Icons
Tune the preset radio station. Select
and hold the preset icon to store that
station. Select

to display preset 7

onwards.

Skip Icons
Select

to change

section in the channel. Select and
hold to move rapidly within the
section.

Driver Information Interface

Station Art

* Not available on all models

Audio System Basic Operation

Playing SiriusXM® Radio

294

Features

1. Select MENU.
2. Select Tune Mode.
3. Select Channel Mode or Category Mode.

■

To Change the Tune Mode

Playing SiriusXM® Radio

In the channel mode, all available channels are
selectable. In the category mode, you can select a
channel within a category (Jazz, Rock, Classical, etc.).

There may be instances when SiriusXM® Radio does
not broadcast all the data fields (artist name, title).
This does not indicate a problem with your audio
system.

SiriusXM® Radio stations load in ascending order,
which can take about a minute. Once they have
loaded you will be able to scroll up or down to make
your selections.

Switching the Audio Mode
Press the

button on the steering wheel or

select SOURCE on the screen.

2 Audio Remote Controls P. 235

Tune Start:
When you change to a preset channel, a song being
played on that channel restarts from the beginning
with this function. This can be turned on or off from
the Audio Settings screen.

2 Customized Features P. 351

* Not available on all models

Continued

295

Audio System Basic Operation

Playing SiriusXM® Radio

Features

To store a channel:
1. Tune to the selected channel.
2. Press and hold the preset number for the station you want to store.
3. Select OK.

You can also store a channel by the following procedure.
1. Tune to the selected channel.
2. Select the open/close icon to display a list.
3. Select the Preset tab.
4. Select and hold the preset number for the station you want to store.

■

Multi-channel preset (for music channels only)

You can store up to five of your preferred music channels in total.

1. Tune a station.
2. Select the open/close icon to display a list.
3. Select the Preset tab.
4. Select and hold the preset number you

want to add a music channel.

A message appears if there are no
available presets.

5. Select Combine.

■

Preset Memory

Playing SiriusXM® Radio

You can store 12 SiriusXM® channels into the preset
memory.

Multi-channel preset (for music channels only)

To store a multi-channel preset, you need to setup
the Multiple Channel Mix Preset setting to On.

2 Customized Features P. 351

* Not available on all models

Audio System Basic Operation

Playing SiriusXM® Radio

296

Features

Suggested channel listing received from SiriusXM® can be displayed and selected.
1. Select the open/close icon to display a channel list.
2. Select the Channel tab.
3. Select the featured channel list title you want to listen to.

The selected channel list of the title is displayed.

4. Select the channel.

■

Listening to Featured Channels

Listening to Featured Channels

Up to three featured channels by SiriusXM® can be
displayed.

Featured channel lists are at the top of the channel
list.

Continued

297

Audio System Basic Operation

Playing SiriusXM® Radio

Features

The system can record up to the last 60 minutes of your currently tuned channel’s
broadcast, as well as the last 30 minutes of your preset channel’s broadcast, starting
from the moment you turn the vehicle on. If you tuned to a preset channel, the
system records up to 60 minutes of a broadcast instead of up to 30 minutes. You
can rewind and replay the last 30 or 60 minutes of a broadcast.
1. Select MENU.
2. Select Playback.
3. Move the time marker to the position you want to replay.

The following items are available on the pop-up screen:

(Skip Down): Skips to the previously stored channel. Select and hold to fast-

rewind the current selection.

(Skip Up): Skips to the next channel. Select and hold to fast-forward the

current selection.

(15sec Back): Select to skip back 15 seconds in the current selection. Select and

hold to fast-rewind the current selection.

(15sec Skip): Select to skip forward 15 seconds in the current selection. Select

and hold to fast-forward the current selection.

Select OK to close the pop-up menu. Replay in playback mode continues.

To play or pause on playback mode:
1. Select MENU.
2. Select Play/Pause.

■

Returning to real-time broadcast

1. Select MENU.
2. Select Go to Live.

■

Replay Function

Replay Function

The system starts storing broadcast in memory when
the power mode is turned ON. You can go back to
the program from that point.

You can no longer replay any program once the
power mode is turned off as it erases memory.
You can check how long the program has been
stored in memory from the audio/information screen.

After 30 or 60 minutes of recording the system will
automatically start deleting the oldest data.

(A): Shows how much time the replayed segment is
behind the real-time broadcast
(B): Replayed segment
(C): Length stored in memory

Audio/Information Screen

(C)

(B)

(A)

Audio System Basic Operation

Playing SiriusXM® Radio

298

Features

While listening to other channels, you can receive sports alerts such as scores from
the games of your favorite teams.

■

To set up a favorite team

1. Select .
2. Select Settings.
3. Select Audio.
4. Select SportsFlash Setup.
5. Select Favorite Team.
6. Select a team.

■

To set up an alert message

1. Select .
2. Select Settings.
3. Select Audio.
4. Select SportsFlash Setup.
5. Select Interrupt.
6. Select On(One Time) or On(Continue).

■

Live Sports Alert

Live Sports Alert

The sports alert function is available in SiriusXM®
mode only.

To set up a favorite team

Sports alerts cut in only when SiriusXM® mode is on.
Selecting On(One Time) from the customize settings
disables the alert feature next time you turn the
power mode to ON.

2 Customized Features P. 351

You can also set up a favorite team by the following
procedure.
1. Select Audio.
2. Select MENU.
3. Select Setting.
4. Select SportsFlash Setup.

299

Audio System Basic Operation

Playing SiriusXM® Radio

Features

■

To set up an alert beep

1. Select .
2. Select Settings.
3. Select Audio.
4. Select SportsFlash Setup.
5. Select Interrupt Beep.
6. Select On.

■

Traffic and Weather Information

You can receive traffic and weather information.
1. Select .
2. Select Settings.
3. Select Audio.
4. Select Traffic & Weather Setup.
5. Select the region.

When you do not want to receive the information, select Unregistered.

Sample each channel on the selected mode for 10 seconds.
1. Select Scan.
2. Select Scan Channels.

You can select the desired channel by songs using Scan Song in Preset.

To turn off scan, select Cancel.

■

Scan

To set up an alert beep

You can also set up an alert beep by the following
procedure.
1. Select Audio.
2. Select MENU.
3. Select Setting.
4. Select SportsFlash Setup.

Traffic and Weather Information

The traffic and weather information function at
SiriusXM® mode only.

You can also set up the traffic and weather
information by the following procedure.
1. Select Audio.
2. Select MENU.
3. Select Setting.
4. Select Traffic & Weather Setup.

Scan

The “Scan Songs in Preset” function is based on
TuneScan

technology of SiriusXM®.

The “Featured Channels” function is based on
Featured Favorites

technology of SiriusXM®.

TuneScan

and Featured Favorites

are registered

trademarks of SiriusXM® Radio, Inc.

300

Audio System Basic Operation

Playing an iPod

Features

Playing an iPod

Connect the iPod using your dock connector to the USB port, then select the iPod
mode.

2 USB Port(s) P. 233

*1:Some or all of the lists may not be displayed.

VOL/

AUDIO (Volume/Power Audio) Knob

Press to turn the audio system on and off.
Turn to adjust the volume.

(Back) Icon

Select to go back to the previous
display.

Song Icons
Select

to change songs.

Select and hold to move rapidly
within a song.

Open/Close Icon

Displays/hides the detailed
information.

(Audio) Icon

Select to display the audio screen.

Cover Art

Audio/Information Screen

Play/Pause Icon

Driver Information Interface

Continued

301

Audio System Basic Operation

Playing an iPod

Features

1. Select MENU and select Music Search.

2. Select the items on that menu.

■

How to Select a Song from the Music Search List

Playing an iPod

Available operating functions vary on models or
versions. Some functions may not be available on the
vehicle’s audio system.

If there is a problem, you may see an error message
on the audio/information screen.

2 iPod/USB Flash Drive P. 329

If you operate any music app on your iPhone/iPod
while the phone is connected to the audio system,
you may no longer be able to operate the same app
on the audio/information screen.
Reconnect the device if necessary.

If an iPhone is connected via Apple CarPlay

, the

iPod/USB source is unavailable and audio files on the
phone can only be played within Apple CarPlay

Category
Selection

Item Selection

Audio System Basic Operation

Playing an iPod

302

Features

You can select shuffle and repeat modes when playing a file.

Select a play mode.

■

To turn off a play mode

Select the mode you want to turn off.

■

How to Select a Play Mode

How to Select a Play Mode

Play Mode Menu Items
Shuffle Albums: Plays all available albums in a
selected list (playlists, artists, albums, songs,
podcasts, genres, composers, or audiobooks) in
random order.
Shuffle All Songs: Plays all available files in a
selected list (playlists, artists, albums, songs,
podcasts, genres, composers, or audiobooks) in
random order.
Repeat: Repeats the current track.

303

Audio System Basic Operation

Song By Voice

(SBV)

Continued

Features

Song By Voice

(SBV)

Use SBV to search for and play music from your USB flash drive or iPod using voice
commands.

■

To enable SBV

1. Select .
2. Select Settings.
3. Select System.
4. Select the Voice Recog. tab.
5. Select Song by Voice.
6. Select Next, then select On or Off.

Song By Voice

(SBV)

Setting options:

•

On (factory default): Song By Voice

commands

are available.

•

Off: Disable the feature.

Content .. 17 18 19 20 ..
