Honda CR-V (2018 year). Manual - part 14

208

uu

Interior Lights/Interior Convenience Items

u

Interior Lights

Co
ntrols

Rear

Models without panoramic roof

Off

On

Door Activated
Position

Rear

Models with panoramic roof

Continued

209

uu

Interior Lights/Interior Convenience Items

u

Interior Lights

Co
ntrols

■

Front

The map lights can be turned on and off by
pressing the lens.

The map lights can be turned on and off by
pressing the button.

■

Map Lights

1

Map Lights

When the interior light switch is in the door activated
position and a door is opened or interior light switch
is in the ON position, the rear map light will not go
off when you press the button.

Models with panoramic roof

Models without panoramic roof

Models without panoramic roof

Models with panoramic roof

Models with panoramic roof

210

uu

Interior Lights/Interior Convenience Items

u

Interior Lights

Co
ntrols

■

Rear

The map lights can be turned on and off by
sliding the switch.

The map lights can be turned on and off by
pressing the button.

■

ON

The light comes on when you open the
tailgate, and goes off when closed.

■

OFF

The light stays off with or without opening the
tailgate.

Off

On

Models without panoramic roof

Models without panoramic roof

Models with panoramic roof

Models with panoramic roof

■

Cargo Area Lights

Off

On

211

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Continued

Co
ntrols

Interior Convenience Items

Pull the handle to open the glove box. You
can lock the glove box with the master key or
the built-in key.

■

Glove Box

1

Glove Box

3

WARNING

An open glove box can cause serious injury
to your passenger in a crash, even if the
passenger is wearing the seat belt.

Always keep the glove box closed while
driving.

Glove Box

212

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

To open, pull the knob. You can change the
position of the tray by sliding it forward or
back.

■

Removing the tray

1. Slide the tray back.

2. Lift the edge of the tray up slightly, then

pull it out.

■

Center Console Box

Knob

Tray

213

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Continued

Co
ntrols

Storing the tray:
Line the tray up with the slots located at the
rear section of the console box, and then push
it down all the way until it is in the locked
position.

Slot

214

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

Pull the strap to open the cargo floor lid.

■

Storing items on the lid at the bottom
position

This is convenient when storing a tall item.
1. Pull the strap upwards to lift the lid.
2. Pull the lid towards you until it disengages

from the support rods.

3. Push the far end of the lid down to the

bottom under the support rod, then lower
the other end.

■

Under-floor Storage Area

Support Rod

Continued

215

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

■

Front seat beverage holders

Are located in the console between the front
seats.

■

Rear seat beverage holders

Fold the armrest down to use the rear seat
beverage holders.

■

Beverage Holders

1

Beverage Holders

NOTICE

Spilled liquids can damage the upholstery, carpeting,
and electrical components in the interior.

Be careful when you are using the beverage holders.
Hot liquid can scald you.

216

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

■

Door side beverage holders

Are located on the both of front and rear door
side pockets.

Front

Rear

Continued

217

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

The accessory power sockets can be used when the ignition switch is in ACCESSORY

(

q or ON

(

w

*1

.

■

Accessory power socket on the console
panel

Open the cover to use it.

■

Accessory power socket in the console
compartment

Open the console lid and the cover to use it.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Accessory Power Sockets

1

Accessory Power Sockets

NOTICE

Do not insert an automotive type cigarette lighter
element.
This can overheat the power socket.

The accessory power socket is designed to supply
power for 12-volt DC accessories that are rated 180
watts or less (15 amps).

To prevent battery drain, only use the power socket
with the engine running.

218

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

■

Accessory power socket (cargo area)

*1

Open the cover to use it.

*1: Canadian models only, if equipped

Continued

219

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

There is a coat hook on the rear left grab
handle. Pull it down to use it.

The tie-down anchors on the cargo area floor
can be used to install a net for securing items.

■

Coat Hook

1

Coat Hook

The coat hook is not designed for large or heavy
items.

■

Tie-down Anchors

1

Tie-down Anchors

Do not let anyone access items in the cargo area
while driving. Loose items can cause injury if you have
to brake hard.

Hooks

Hooks

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

220

Co
ntrols

The cargo hooks on the driver's side of the
cargo area can be used to hang a light items.

■

Cargo Hooks

1

Cargo Hooks

NOTICE

Do not hang a large object or an object that weighs
more than 6 lbs (3 kg) on the side cargo hooks.
Hanging heavy or large objects may damage the
hooks.

Hook

Continued

221

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

To open the sunglasses holder, press and
release the indent. To close, press it again until
it latches.

You can store eyeglasses and other small
items in this holder.

■

Conversation mirror

The sunglasses holder comes with a mirror.
Open the sunglasses holder fully, then push it
back to the first detent.

You can use the mirror to view the rear seats.

■

Sunglasses Holder

1

Sunglasses Holder

Keep the holder closed while driving except when
accessing stored items.

Press

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

222

Co
ntrols

The power mode must be in ON to use the
heated steering wheel.

Press the button on the right side of the
steering wheel.

When a comfortable temperature is reached,
press the button again to turn it off.

The heated steering wheel is turned off every
time you start the engine, even if you turned it
on the last time you drove the vehicle.

*1: Canadian models only, if equipped

■

Heated Steering Wheel

*1

1

Heated Steering Wheel

*1

Do not use the heated steering wheel continuously
when the engine is off. Under such conditions, the
battery may be weakened, making the engine
difficult to start.

Continued

223

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

The power mode is in ON to use the seat
heaters. The HI setting heats the seats faster
than the LO setting.

Press the seat heater button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator on)
Four times - The OFF setting (no indicators on)

When the power mode is turn on after it is
turned off, the previous setting of seat heaters
is maintained.

■

Front Seat Heaters

*

1

Front Seat Heaters

*

Do not use the seat heaters even in LO when the
engine is off. Under such conditions, the battery may
be weakened, making the engine difficult to start.

After a certain period of time, the strength setting for
the seat heater as well as that for the seat ventilation
system will automatically be reduced by one level at a
time until the seat heater or ventilation system shuts
off. The elapsed time varies according to the interior
environment.

3

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models
