Honda Crosstour (2015 year). Manual

546

Info

ation

Specifications

■

Vehicle Specifications

Model

Crosstour

No. of Passengers:
Front

Rear

Total

Weights:
Gross Vehicle Weight
Rating

U.S.: 4,784 lbs (2,170 kg)
Canada: 2,170 kg

Gross Axle Weight
Rating (Front)

U.S.: 2,469 lbs (1,120 kg)
Canada: 1,120 kg

Gross Axle Weight
Rating (Rear)

U.S.: 2,381 lbs (1,080 kg)
Canada: 1,080 kg

Air Conditioning:
Refrigerant Type

HFC-134a (R-134a)

Charge Quantity

14.1 – 15.9 oz (400 – 450 g)

Lubricant Type

ND-OIL 8

4-cylinder models

■

Engine Specifications

■

Fuel

■

Washer Fluid

Displacement

144 cu-in (2,354 cm

)

Spark Plugs

NGK

ILZKR7B11S

DENSO

SXU22HCR11S

Type

Unleaded gasoline, Pump octane number
of 87 or higher

Fuel Tank Capacity

18.5 US gal (70 ℓ)

Tank Capacity

5.3 US qt (5.0 ℓ)

■

Light Bulbs

Headlights (Low Beam)

55W (H11)

Headlights (High Beam)

60W (HB3)

Fog Lights

55W (H11)

Front Side Marker Lights

Front Turn Signal/Parking Lights

24/2.2CP (Amber)

Brake/Taillights

21/5W

Rear Side Marker Lights

3CP

Back-Up Lights

21W

Rear Turn Signal Lights

21W (Amber)

High-Mount Brake Light

LED

Rear License Plate Lights

Cargo Area Light

Interior Lights

Map Lights

Ceiling Light

Vanity Mirror Lights

1.4W

Glove Box Light

1.4W

Ambient Light

LED

Courtesy Lights

2CP

547

Specifications

Continued

Info

ation

■

Brake Fluid

■

Automatic Transmission Fluid

■

Power Steering Fluid

Specified

Honda Heavy Duty Brake Fluid DOT 3

Specified

Honda Automatic Transmission Fluid ATF
DW-1

Capacity

Change

2.6 US qt (2.5 ℓ)

Specified

Honda Power Steering Fluid

■

Engine Oil

■

Engine Coolant

Recommended

·Genuine Honda Motor Oil 0W-20
·API Premium-grade 0W-20 detergent oil

Capacity

Change

4.0 US qt (3.8 ℓ)

Change
including
filter

4.2 US qt (4.0 ℓ)

Specified

Honda Long Life Antifreeze/Coolant Type2

Ratio

50/50 with distilled water

Capacity

1.66 US gal (6.3 ℓ)
(change including the remaining 0.18 US gal
(0.68 ℓ) in the reserve tank)

■

Tire

Regular

Size

225/65R17 102T

Pressure
psi (kPa [kgf/cm

])

Front

32 (220 [2.2])

Rear

32 (220 [2.2])

Compact
Spare

Size

T155/90D16 110M

Pressure
psi (kPa [kgf/cm

])

60 (420 [4.2])

Wheel Size

Regular

17 x 6 1/2J

Compact Spare

16 x 4T

548

Specifications

Info

ation

■

Vehicle Specifications

*1: 2WD models
*2: 4WD models

Model

Crosstour

No. of Passengers:
Front

Rear

Total

Weights:
Gross Vehicle Weight
Rating

U.S.: 4,938 lbs (2,240 kg)

5,115 lbs (2,320 kg)

Canada: 2,240 kg

2,320 kg

Gross Axle Weight
Rating (Front)

U.S.: 2,623 lbs (1,190 kg)

2,668 lbs (1,210 kg)

Canada: 1,190 kg

1,210 kg

Gross Axle Weight
Rating (Rear)

U.S.: 2,381 lbs (1,080 kg)

2,513 lbs (1,140 kg)

Canada: 1,080 kg

1,140 kg

Air Conditioning:
Refrigerant Type

HFC-134a (R-134a)

Charge Quantity

14.1 – 15.9 oz (400 – 450 g)

Lubricant Type

ND-OIL 8

6-cylinder models

■

Engine Specifications

■

Fuel

■

Washer Fluid

Displacement

212 cu-in (3,471 cm

)

Spark Plugs

NGK

ILZKR7B11

DENSO

SXU22HCR11

Type

Unleaded gasoline, Pump octane number
of 87 or higher

Fuel Tank Capacity

18.5 US gal (70 ℓ)

Tank Capacity

5.3 US qt (5.0 ℓ)

■

Light Bulbs

Headlights (Low Beam)

55W (H11)

Headlights (High Beam)

60W (HB3)

Fog Lights

55W (H11)

Front Side Marker Lights

Front Turn Signal/Parking Lights

24/2.2CP (Amber)

Brake/Taillights

21/5W

Rear Side Marker Lights

3CP

Back-Up Lights

21W

Rear Turn Signal Lights

21W (Amber)

High-Mount Brake Light

LED

Rear License Plate Lights

Cargo Area Light

Interior Lights

Map Lights

Ceiling Light

Vanity Mirror Lights

1.4W

Glove Box Light

1.4W

Ambient Light

LED

Courtesy Lights

2CP

549

Specifications

Info

ation

■

Brake Fluid

■

Automatic Transmission Fluid

■

Rear Differential Fluid

■

Transfer Assembly Fluid

Specified

Honda Heavy Duty Brake Fluid DOT 3

Specified

Honda Automatic Transmission Fluid ATF
DW-1

Capacity

Change

3.28 US qt (3.1 ℓ)

Specified

Honda Dual Pump Fluid II

Capacity

Change

1.3 US qt (1.2 ℓ)

Specified

Honda Hypoid Gear Oil HGO-1

Capacity

Change

0.43 US qt (0.41 ℓ)

■

Engine Oil

■

Engine Coolant

Recommended

·Genuine Honda Motor Oil 0W-20
·API Premium-grade 0W-20 detergent oil

Capacity

Change

4.2 US qt (4.0 ℓ)

Change
including
filter

4.5 US qt (4.3 ℓ)

Specified

Honda Long Life Antifreeze/Coolant Type2

Ratio

50/50 with distilled water

Capacity

1.92 US gal (7.3 ℓ)
(change including the remaining 0.17 US gal
(0.64 ℓ) in the reserve tank)

■

Tire

*1: 2WD models
*2: 4WD models

Regular

Size

225/60R18 100H

Pressure
psi (kPa [kgf/cm

])

33 (230 [2.3])

Front
Rear

33 (230 [2.3])

Compact
Spare

Size

T155/90D16 110M

T155/90D17 101M

Pressure
psi (kPa [kgf/cm

])

60 (420 [4.2])

Wheel Size

Regular

18 x 7J

Compact Spare

16 x 4T

17 x 4T

550

Info

ation

Identification Numbers

Vehicle Identification Number (VIN), Engine Number
and Transmission Number

Your vehicle has a 17-digit vehicle identification number (VIN) used to register your
vehicle for warranty purposes, and for licensing and insuring your vehicle.
The locations of your vehicle’s VIN, engine number and transmission number are
shown as follows.

Vehicle
Identification
Number

Engine Number

Certification Label/
Vehicle Identification
Number

Automatic Transmission
Number

6-cylinder models

4-cylinder models

Engine Number

Automatic Transmission
Number

Vehicle Identification Number (VIN), Engine Number and
Transmission Number

The transmission number is located on the side of the
transmission.

551

Info

ation

Devices that Emit Radio Waves

The following products and systems on your vehicle emit radio waves when in operation.

Each of the above complies with the appropriate requirements or the required
standards of FCC (Federal Communications Commission) and Industry Canada
Standard, described below:

As required by the FCC:
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.

Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.

This device complies with Industry Canada Standard RSS-Gen/210/310. Operation is
subject to the following two conditions: (1) this device may not cause interference,
and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.

Audio System
Bluetooth® Audio
Bluetooth® HandsFreeLink®
HomeLink® Universal Transceiver
Immobilizer System
Smart Entry System
Remote Transmitter
Tire Pressure Monitoring System (TPMS)

552

Info

ation

Reporting Safety Defects

In the U.S.
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you
should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to
notifying American Honda Motor Co., Inc.

If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists
in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved
in individual problems between you, your dealer, or American Honda Motor Co., Inc.

To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1-888-327-4236 (TTY: 1-800-424-
9153); go to http://www.safercar.gov; or write to: Administrator, NHTSA, 1200 New Jersey Avenue, SE.,
Washington, DC 20590. You can also obtain other information about motor vehicle safety from http://
www.safercar.gov.

In Canada
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you
should immediately inform Honda Canada Inc. and you may also inform Transport Canada.

If Transport Canada receives similar complaints, it may open an investigation, and if it finds that a safety
defect exists in a group of vehicles, it may lead to a recall and remedy campaign. However, Transport Canada
cannot become involved in individual problems between you, your dealer, or Honda Canada Inc.

To contact Transport Canada’s Defect Investigations and Recalls Division, you may call 1-800-333-0510. For
more information on reporting safety defects or about motor vehicle safety, go to http://www.tc.gc.ca/
roadsafety.

553

Continued

Info

ation

Emissions Testing

Testing of Readiness Codes

Your vehicle has “Readiness Codes,” as part of the onboard self diagnostic system.
Some States use these codes as a test to see if your vehicle’s emissions components
are working properly.
The codes may not be read properly if testing is performed just after the battery has
gone dead or been disconnected.

To check if they are set, turn the ignition switch to ON

(

, without starting the

engine. The malfunction indicator lamp will come on for several seconds. If it then
goes off, the readiness codes are set. If it blinks five times, the readiness codes are
not set.

If you are required to have your vehicle tested before the readiness codes are ready,
prepare the vehicle for retesting by doing the following:

1. Fill the gas tank to approximately 3/4 full.
2. Park the vehicle and leave the engine off for 6 hours or more.
3. Make sure the ambient temperature is between 40°F and 95°F (4°C and 35°C).
4. Start the engine without touching the accelerator pedal, and let it idle for 20

seconds.

5. Keep the vehicle in

(

P. Increase the engine speed to 2,000 rpm, and hold it there

for about 3 minutes.

6. Let the engine idle with your foot off the accelerator for 20 seconds.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

Testing of Readiness Codes

The readiness codes are erased when the battery is
disconnected, and set again only after several days of
driving under a variety of conditions.

If a testing facility determines that the readiness
codes are not set, you may be requested to return at
a later date to complete the test.

If the testing facility determines the readiness codes
are still not set, see a dealer.

554

Emissions Testing

Testing of Readiness Codes

Info

ation

7. Select a nearby, lightly traveled major highway where you can maintain a speed

of 50 to 60 mph (80 to 97 km/h) for at least 20 minutes. Drive on the highway in

(

D. Do not use cruise control. When traffic allows, drive for 90 seconds without

moving the accelerator pedal. (Vehicle speed may vary slightly; this is okay.) If you
cannot do this for a continuous 90 seconds because of traffic conditions, drive for
at least 30 seconds, then repeat it two more times (for a total of 90 seconds).

8. Drive in city/suburban traffic for at least 10 minutes. When traffic conditions

allow, let the vehicle coast for several seconds without using the accelerator pedal
or the brake pedal.

9. Park the vehicle and leave the engine off for 30 minutes.

555

Continued

Info

ation

Warranty Coverages

■

U.S. Owners

Your new vehicle is covered by these warranties:

New Vehicle Limited Warranty – covers your new vehicle, except for the
emissions control systems and accessories, against defects in materials and
workmanship.

Emissions Control Systems Defects Warranty and Emissions Performance
Warranty – these two warranties cover your vehicle’s emissions control systems.
Time, mileage, and coverage are conditional. Please read your warranty booklet for
exact information.

Seat Belt Limited Warranty – a seat belt that fails to function properly is covered
by a limited warranty. Please read your warranty booklet for details.

Rust Perforation Limited Warranty – all exterior body panels are covered for
rust-through from the inside for the specified time period with no mileage limit.

Accessory Limited Warranty – Honda accessories are covered under this
warranty. Time and mileage limits depend on the type of accessory and other
factors. Please read your warranty booklet for details.

Replacement Parts Limited Warranty – covers all Honda replacement parts
against defects in materials and workmanship.

558

Info

ation

Customer Service Information

Honda dealership personnel are trained professionals.

They should be able to answer all your questions. If you encounter a problem that
your dealership does not solve to your satisfaction, please discuss it with the
dealership's service manager or general manager. If you are dissatisfied with the
decision made by the dealership’s management, contact Honda Customer Services.

U.S. Owners:
American Honda Motor Co., Inc.
Honda Automobile Customer Services
Mail Stop 500-2N-7A
1919 Torrance Blvd.
Torrance, CA 90501-2746
Tel: (800) 999-1009

Canadian Owners:
Honda Canada Inc.
Customer Relations
180 Honda Boulevard
Markham, ON
L6C 0H9
Tel: 1-888-9-HONDA-9
Fax: 1-877-939-0909
E-mail: Honda_cr@ch.honda.com

In Puerto Rico and the U.S. Virgin
Islands:
Bella International
P.O. Box 190816
San Juan, PR 00919-0816
Tel: (787) 620-7546

Customer Service Information

When you call or write, please give us the following
information:

•

Vehicle Identification Number

2 Vehicle Identification Number (VIN),

Engine Number and Transmission
Number P. 550

•

Date of purchase

•

Odometer reading of your vehicle

•

Your name, address, and telephone number

•

A detailed description of the problem

•

Name of the dealer who sold the vehicle to you

559

Customer Service Information

Continued

Info

ation

Music recognition technology and related
data are provided by Gracenote®.
Gracenote is the industry standard in music
recognition technology and related content
delivery.
For more information, visit
www.gracenote.com.
When music is recorded to the HDD from a
CD, information such as the recording artist
and track name are retrieved from the
Gracenote Database and displayed (when
available).
Gracenote may not contain information for
all albums.
Gracenote is an internet-based music
recognition service that allows artist, album,
and track information from CDs to display
on the HDD.
Gracenote users are allowed 4 free updates
a year. More information about Gracenote,
its features, and downloads are available at

■

Gracenote Music Recognition
Service (CDDB)

www.honda.com (in U.S.) or
www.honda.ca (in Canada).
CD and music-related data from Gracenote,
Inc., copyright © 2000 to present
Gracenote. Gracenote Software, copyright
© 2000 to present Gracenote.
One or more patents owned by Gracenote
apply to this product and service. See the
Gracenote website for a non-exhaustive list
of applicable Gracenote patents.
Gracenote, CDDB, MusicID, MediaVOCS,
the Gracenote logo and logotype, and the
“Powered by Gracenote” logo are either
registered trademarks or trademarks of
Gracenote in the United States and/or other
countries.

This application or device contains software
from Gracenote, Inc. of Emeryville,
California (“Gracenote”). The software
from Gracenote (the “Gracenote
Software”) enables this application to
perform disc and/or file identification and
obtain music- related information, including
name, artist, track, and title information
(“Gracenote Data”) from online servers or

■

Gracenote® END USER LICENSE
AGREEMENT

embedded databases (collectively,
“Gracenote Servers”) and to perform other
functions. You may use Gracenote Data
only by means of the intended End-User
functions or this application or device.

You agree that you will use Gracenote Data,
the Gracenote Software, and Gracenote
Servers for your own personal non-
commercial use only.

You agree not to assign, copy, transfer, or
transmit the Gracenote Software or any
Gracenote Data to any third party.

YOU AGREE NOT TO USE OR EXPLOIT
GRACENOTE DATA, THE GRACENOTE
SOFTWARE, OR GRACENOTE SERVERS,
EXCEPT AS EXPRESSLY PERMITTED HEREIN.

You agree that your non-exclusive license to
use the Gracenote Data, the Gracenote
Software, and Gracenote Servers will
terminate if you violate these restrictions. If
your license terminates, you agree to cease
any and all use of the Gracenote Data, the
Gracenote Software, and Gracenote
Servers.

560

Customer Service Information

Info

ation

Gracenote reserves all rights in Gracenote
Data, the Gracenote Software, and the
Gracenote Servers, including all ownership
rights. Under no circumstances will
Gracenote become liable for any payment
to you for any information that you provide.
You agree that Gracenote, Inc. may enforce
its rights under this Agreement against you
directly in its own name.

The Gracenote service uses a unique
identifier to track queries for statistical
purposes. The purpose of a randomly
assigned numeric identifier is to allow the
Gracenote service to count queries without
knowing anything about who you are. For
more information, see the web page for the
Gracenote Privacy Policy for the Gracenote
service.

The Gracenote Software and each item of
Gracenote Data are licensed to you “AS IS.”

Gracenote makes no representations or
warranties, express or implied, regarding
the accuracy of any Gracenote Data from in
the Gracenote Servers. Gracenote reserves
the right to delete data from the Gracenote
Servers or to change data categories for any

cause that Gracenote deems sufficient. No
warranty is made that the Gracenote
Software or Gracenote Servers are error-
free or that functioning of Gracenote
Software or Gracenote Servers will be
uninterrupted.

Gracenote is not obligated to provide you
with new enhanced or additional data types
or categories that Gracenote may provide in
the future and is free to discontinue its
services at any time.

GRACENOTE DISCLAIMS ALL WARRANTIES
EXPRESS OR IMPLIED, INCLUDING, BUT
NOT LIMITED TO, IMPLIED WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE, TITLE, AND
NONINFRINGEMENT. GRACENOTE DOES
NOT WARRANT THE RESULTS THAT WILL BE
OBTAINED BY YOUR USE OF THE
GRACENOTE SOFTWARE OR ANY
GRACENOTE SERVER. IN NO CASE WILL
GRACENOTE BE LIABLE FOR ANY
CONSEQUENTIAL OR INCIDENTAL
DAMAGES OR FOR ANY LOST PROFITS OR
LOST REVENUES.
copyright © 2000 to present Gracenote

Requirements to access Pandora®
• Latest version of the Pandora application

installed on your mobile device. (Visit the
Apple iTunes store or Google Play
Marketplace to download the latest
version.)

• Registered Pandora account (you can

create a free account at
www.pandora.com <http://
www.pandora.com/> or on your
smartphone)

• Connection to the internet via WiFi or

cellular data network.

• Android devices must be connected to

the vehicle via Bluetooth, iPhone devices
may be connected via Bluetooth or USB.

■

Disclaimer of Pandora®

561

Customer Service Information

Info

ation

Limitations
• Access to Pandora requires an active

internet connection

• Ability to access Pandora through this

system is subject to change without
notice

• Certain functionality of Pandora service is

not available when accessing the service
through this system including, but not
limited to, creating new stations, deleting
stations, emailing current stations,
buying songs, viewing additional text
information, logging in to Pandora, and
adjusting Cell Network Audio Quality.
Pandora internet radio is a music service
not affiliated with HONDA. More
information is available at http://
www.pandora.com <http://
www.pandora.com/>. Pandora, the
Pandora logo, and the Pandora trade
dress are trademarks or registered
trademarks of Pandora Media, Inc., used
with permission.

• Mobile access requires a smartphone

with an active data plan. Standard data
rates may apply.

• Pandora is only available in the United

States.

Honda Crosstour (2015 year). Manual - part 35
