uu

When Driving

u

Shifting

448

Driving

Use the paddle shifters to change between 1st and 7th speeds without releasing
your hands from the steering wheel. The transmission switches to the 7-speed
manual shift mode when you pull a paddle shifter while driving. This mode is useful
when engine braking is needed.

When the shift lever is in

(

D:

The shift mode goes into the 7-speed manual shift mode temporarily, and the
number is displayed in the shift indicator.
The 7-speed manual shift mode is canceled automatically if you drive at constant
speed or accelerate, and the number in the shift indicator goes off.
You can cancel this mode by pulling the

(

+ paddle shifter for a few seconds.

The 7-speed manual shift mode is especially useful when reducing the vehicle speed
temporarily before making a turn.

When the shift lever is in

(

S:

The shift mode goes into the 7-speed manual shift mode. The M indicator and the
speed number are displayed in the shift indicator. As the vehicle speed slows down,
the transmission automatically shifts down accordingly. When the vehicle comes to
a stop, it automatically shifts down into 1st.

If the vehicle speed increases and the engine speed reaches near the tachometer’s
red zone, the transmission automatically shifts up.

You can only pull away in 1st speed.

When canceling the 7-speed manual shift mode, move the shift lever from

(

S to

(

D. When the 7-speed manual shift mode is canceled, the M indicator and shift

indicator will turn off.

7-Speed Manual Shift Mode

1

7-Speed Manual Shift Mode

In the 7-speed manual shift mode, the transmission
shifts up or down by operating either paddle shifter
under the following conditions:
Shift Up: The engine speed reaches the lowest
threshold of the higher speed position.
Shift Down: The engine speed reaches the highest
threshold of the lower speed position.

When the engine speed reaches near the
tachometer’s red zone, the transmission shifts up
automatically.
When the engine speed reaches the lowest threshold
of the selected speed position, the transmission shifts
down automatically.

Operating the paddle shifters on slippery surfaces
may cause the tires to lock up. In this case, the 7-
speed manual shift mode is canceled and goes back
to the normal

(

D driving mode.

449

uu

When Driving

u

Shifting

Driving

7-Speed Manual Shift Mode Operation

1

7-Speed Manual Shift Mode Operation

Each paddle shift operation makes a single speed
change.
To change continuously, release the paddle shifter
before pulling it again for the next speed.

The shift indicator blinks when you cannot shift up or
down. It indicates that your vehicle speed is not in its
allowable shifting range.
Slightly accelerate to shift up and decelerate to shift
down while the indicator is blinking.

(

- Paddle Shifter

(Shift down)

(

+ Paddle Shifter

(Shift up)

Downshifting when pulling
the

(

- paddle shifter

(Changes to lower speed
number)

Upshifting when pulling
the

(

+ paddle shifter

(Changes to higher speed
number)

450

uu

When Driving

u

Shifting

Driving

Shifting

Fully depress the clutch pedal to operate the shift lever and change gears, then
slowly release the pedal.

Depress the clutch pedal, and pause for a few seconds before shifting into

(

R, or

shift into one of the forward gears for a moment. This stops the gears so they do not
“grind.”

When you are not shifting, do not rest your
foot on the clutch pedal. This can cause your
clutch to wear out faster.

Shift Lever Operation

Manual transmission models

1

Shifting

NOTICE

Do not shift to

(

R before the vehicle comes to a

complete stop.
Shifting to

(

R before stopping can damage the

transmission.

NOTICE

Before downshifting, make sure the engine will not
go into the tachometer's red zone. Should this occur,
it can severely damage your engine.

There is a metallic part on the shift lever. If you leave
the vehicle parked outside for a long time on a hot
day, be careful before moving the shift lever. Because
of heat, the shift lever may be extremely hot. If the
outside temperature is low, the shift lever may feel
cold.

If you exceed the maximum speed for the gear you
are in, the engine speed will enter into the
tachometer’s red zone. When this happens, you may
experience a slight jolt.

Continued

451

uu

When Driving

u

Shifting

Driving

Come on to inform you that upshifting or
downshifting is necessary to prevent the
engine from over revving or stalling.

The shift up indicator: Comes on when
upshifting is recommended.

The shift down indicator: Comes on when
downshifting is recommended.

Shift Up/Down Indicators

*

1

Shift Up/Down Indicators

*

This indicator will not prompt you to downshift to
increase engine braking. It is up to you to downshift
to increase engine braking when driving downhill.

Always shift down at the appropriate vehicle speed.

The shift down indicator does not come on when
downshifting from

(

2 to

(

1.

Ambient meter color may change if you do not
change gears when a shift indicator illuminates. This
can result in a change in fuel economy.

Road and traffic conditions may require you to shift
at times other than those indicated.

* Not available on all models

452

uu

When Driving

u

Shifting

Driving

The manual transmission has a lockout mechanism that stops you from accidentally
shifting into

(

R from a forward gear while the vehicle is moving above a certain

speed.

If you cannot shift to

(

R when the vehicle is stopped, do the following:

1. Depress the clutch pedal, move the shift

lever all the way to the left, and shift to

(

R.

2. If you still cannot shift into

(

R, apply the

parking brake, and turn the ignition switch
to ACCESSORY

(

q or LOCK

(

0

*1

.

3. Depress the clutch pedal and shift into

(

R.

4. Keep depressing the clutch pedal and start

the engine.

Have the vehicle checked by a dealer if you
have to go through this procedure repeatedly.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

Reverse Lockout

453

uu

When Driving

u

SPORT Mode

*

Driving

SPORT Mode

*

To turn the SPORT mode on and off, press the SPORT button.

With SPORT mode activated, the driver can enjoy enhanced engine response, and
greater stability and handling.

The SPORT mode is turned off every time you start the engine, even if you turned it
on the last time you drove the vehicle.

1

SPORT Mode

*

The mode may not be able to be changed under
some driving conditions. If mode change is necessary,
reduce speed or cornering speed.
This message will also appear if you try to change
mode when there is a vehicle system failure.

SPORT Button

SPORT Mode Indicator

* Not available on all models

454

uu

When Driving

u

ECON Mode

*

Driving

ECON Mode

*

The ECON button turns the ECON mode on and off.
The ECON mode helps you improve your fuel economy by adjusting the
performance of the engine, transmission, heating system

*

/climate control system

*

and cruise control

*

.

1

ECON Mode

*

While in the ECON mode, the climate control system
has greater temperature fluctuations.

* Not available on all models

455

uu

When Driving

u

Adaptive Damper System

*

Driving

Adaptive Damper System

*

Constantly controls your vehicle’s front and rear dampers according to current road
conditions, vehicle speed and steering operation.

You can change handling response by turning the SPORT mode on.

SPORT Mode

*

 P. 453

* Not available on all models

456

uu

When Driving

u

Cruise Control

*

Driving

Cruise Control

*

Maintains a constant vehicle speed without having to keep your foot on the
accelerator. Use cruise control on freeways or open roads where you can travel at a
constant speed with little acceleration or deceleration.

1

Cruise Control

*

It may not be possible to maintain a constant speed
when driving uphill or downhill.

When not using cruise control:
Turn off cruise control by pressing the CRUISE
button.

When the engine speed slows down, try to
downshift.
You can maintain the set speed if you change gear
within five seconds.

3

WARNING

Improper use of the cruise control can lead
to a crash.

Use the cruise control only when traveling
on open highways in good weather.

Gear positions for cruise control:
In

(

2 or higher position

Always keep sufficient distance
between you and the vehicle in
front of you.

Vehicle speed for cruise control:
Desired speed in a range above
roughly 25 mph (40 km/h) ~

When to use

CRUISE MAIN is on in the
instrument panel.
Cruise control is ready to use.

Press the CRUISE button on the
steering wheel.

How to use

* Not available on all models

457

uu

When Driving

u

Cruise Control

*

Continued

Driving

Take your foot off the pedal and press the –/SET button when you reach the desired
speed.

The moment you release the –/SET button, the set speed is fixed, and cruise control
begins. The CRUISE CONTROL indicator comes on.

When you use cruise control, Straight Driving Assist (a feature of the Electric Power
Steering system) is activated.
By enabling the steering system to automatically compensate for natural steering
pull, Straight Driving Assist makes it easier for you to keep your vehicle in a straight
line.

To Set the Vehicle Speed

–/SET Button

On when cruise
control begins

Press and release

uu

When Driving

u

Cruise Control

*

458

Driving

Increase or decrease the vehicle speed using the RES/+ or –/SET buttons on the
steering wheel.

• Each time you press the button, the vehicle speed is increased or decreased by

about 1 mph (1.6 km/h).

• If you keep the button pressed, the vehicle speed increases or decreases until you

release it. This speed is then set.

To cancel cruise control, do any of the
following:
• Press the CANCEL button.
• Press the CRUISE button.
• Depress the brake pedal.
• Depress the clutch pedal for five seconds or

more.

The CRUISE CONTROL indicator goes off.

To Adjust the Vehicle Speed

1

To Adjust the Vehicle Speed

You can set the vehicle speed using the –/SET button
on the steering wheel when adjusting the speed with
the accelerator and brake pedals.

To Cancel

To decrease speed

To increase speed

1

To Cancel

Resuming the prior set speed:
After cruise control has been canceled, you can still
resume the prior set speed by pressing the RES/+
button while driving at a speed of at least 25 mph (40
km/h) or more.

You cannot set or resume in the following situations:

When vehicle speed is less than 25 mph (40 km/h)

When the CRUISE button is turned off.

At vehicle speeds of 22 mph (35 km/h) or less, cruise
control is canceled automatically.

CRUISE
Button

CANCEL
Button

459

uu

When Driving

u

Vehicle Stability Assist® (VSA®), aka Electronic Stability Control (ESC), System

Continued

Driving

Vehicle Stability Assist® (VSA®), aka Electronic
Stability Control (ESC), System

VSA® helps to stabilize the vehicle during cornering if the vehicle turns more or less
than what was intended. It also assists in maintaining traction on slippery surfaces.
It does so by regulating engine output and selectively applying the brakes.

When VSA® activates, you may notice that the
engine does not respond to the accelerator.
You may also notice some noise from the
hydraulic system. You will also see the
indicator blink.

VSA® Operation

1

Vehicle Stability Assist® (VSA®), aka Electronic Stability Control
(ESC), System

VSA® may not function properly if tire types and sizes
are mixed. Make sure to use the same size and type
of tire, and the air pressures are as specified.

When the VSA® system indicator comes on and stays
on while driving, there may be a problem with the
system. While this may not interfere with normal
driving, have your vehicle checked by a dealer
immediately.

The indicators for the Adaptive Cruise Control (ACC)

*

Adaptive Cruise Control (ACC) with Low Speed Follow
(LSF)

*

, Road Departure Mitigation (RDM)

*

, Vehicle

Stability Assist® (VSA®) system, Vehicle Stability Assist®
(VSA®) OFF, Low Tire Pressure/TPMS

*

 and Collision

Mitigation Braking System

TM

 (CMBS

TM

)

*

 may come on

after re-connecting the battery. Drive a short distance
at more than 12 mph (20 km/h). The indicators should
go off. If they do not, have your vehicle checked by a
dealer.

VSA® cannot enhance stability in all driving situations
and does not control the entire braking system. You
still need to drive and corner at speeds appropriate
for the conditions and always leave a sufficient
margin of safety.

The main function of the VSA® system is generally
known as Electronic Stability Control (ESC). The
system also includes a traction control function.

VSA® System
Indicator

* Not available on all models

uu

When Driving

u

Vehicle Stability Assist® (VSA®), aka Electronic Stability Control (ESC), System

460

Driving

This button is on the driver side control panel.
To partially disable VSA® functionality/
features, press and hold it until you hear a
beep.

Your vehicle will have normal braking and
cornering ability, but traction control function
will be less effective.

To restore VSA® functionality/features, press
the

(VSA® OFF) button until you hear a

beep.

VSA® is turned on every time you start the
engine, even if you turned it off the last time
you drove the vehicle.

VSA® On and Off

1

Vehicle Stability Assist® (VSA®), aka Electronic Stability Control
(ESC), System

In certain unusual conditions when your vehicle gets
stuck in shallow mud or fresh snow, it may be easier
to free it with the VSA® temporarily switched off.

When the

 button is pressed, the traction control

function becomes less effective. This allows for the
wheels to spin more freely at low speed. You should
only attempt to free your vehicle with the VSA® off if
you are not able to free it when the VSA® is on.

Immediately after freeing your vehicle, be sure to
switch VSA® on again. We do not recommend driving
your vehicle with the VSA® system switched off.

You may hear a motor sound coming from the
engine compartment while system checks are being
performed immediately after starting the engine or
while driving. This is normal.

VSA® OFF

Indicator

461

uu

When Driving

u

Agile Handling Assist

Driving

Agile Handling Assist

Lightly brakes selective wheels, as needed, when you turn the steering wheel, and
helps support the vehicle’s stability and performance during cornering.

1

Agile Handling Assist

The agile handling assist cannot enhance stability in
all driving situations. You still need to drive and
corner at speeds appropriate for the conditions and
always leave a sufficient margin of safety.

When the VSA® system indicator comes on and stays
on while driving, the agile handling assist does not
activate.

You may hear a sound coming from the engine
compartment while the agile handling assist is
activated. This is normal.

462

uu

When Driving

u

Limited Slip Differential (LSD)

Driving

Limited Slip Differential (LSD)

LSD (limited slip differential) is a type of differential that delivers extra torque to the
wheel or the wheels with the most traction to minimize wheel slip and maintain
control of the vehicle.

Models with SPORT mode

1

Limited Slip Differential (LSD)

NOTICE

Make sure both front tires of your vehicle are of the
same brand and specified size, and have equal wear.
Otherwise, the LSD may not function properly.

463

uu

When Driving

u

Tire Pressure Monitoring System (TPMS)

Continued

Driving

Tire Pressure Monitoring System (TPMS)

Instead of directly measuring the pressure in each tire, the TPMS on this vehicle
monitors and compares the rolling radius and rotational characteristics of each
wheel and tire while you are driving to determine if one or more tires are
significantly under-inflated. This will cause the low tire pressure/TPMS indicator to
come on and a message to appear on the driver information interface.

You must start TPMS calibration every time you:
• Adjust the pressure in one or more tires.
• Rotate the tires.
• Replace one or more tires.

Before calibrating the TPMS:
• Set the cold tire pressure in all four tires.

Checking Tires P. 584

Make sure:
• The vehicle is at a complete stop.

• The shift lever is in

(

N.

• The shift lever is in

(

P.

• The ignition switch is in ON

(

w

*1

.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

TPMS Calibration

U.S. models

1

Tire Pressure Monitoring System (TPMS)

The system does not monitor the tires when driving
at low speed.

Conditions such as low ambient temperature and
altitude change directly affect tire pressure and can
trigger the low tire pressure/TPMS indicator to come on.

Tire pressure checked and inflated in:

Warm weather can become under-inflated in
colder weather.

Cold weather can become over-inflated in warmer
weather.

The low tire pressure indicator will not come on as a
result of over inflation.

The TPMS may not function properly if tire type and
size are mixed. Make sure to use the same size and
type of tire.

Checking and Maintaining Tires P. 584

The low tire pressure/TPMS indicator may come on
with a delay or may not come on at all when:

You rapidly accelerate, decelerate, or turn the
steering wheel.

You drive on snowy or slippery roads.

Snow chains

*

 are used.

The low tire pressure/TPMS indicator may come on
under the following conditions:

A compact spare tire

*

 is used.

There is a heavier and uneven load on the tires than
the condition at calibration.

Snow chains

*

 are used.

Manual transmission models

Continuously variable transmission models

All models

* Not available on all models















Content   ..  27  28  29  30   ..
