Honda Civic (2019 year). Manual - part 10

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

144

Co
ntrols

■

Unlocking the doors

Press the unlock button.
Once:

u

Some exterior lights flash twice, and the driver’s door and fuel fill door unlock.

Twice:

u

The remaining doors unlock.

If the lock or unlock button of the remote
does not work, use the key instead.
Fully insert the key and turn it.

■

Locking/Unlocking the Doors Using a Key

1

Using the Remote Transmitter

If the distance at which the remote transmitter works
varies, the battery is probably low.
If the LED does not come on when you press a
button, the battery is dead.

2 Replacing the Button Battery P. 596

You can customize the door unlock mode setting.

2 Customized Features P. 124, 337

1

Locking/Unlocking the Doors Using a Key

When you lock the driver’s door with a key, all the
other doors lock at the same time. When unlocking,
the driver’s door unlocks first. Turn the key a second
time within a few seconds to unlock the remaining
doors.

You can customize the door unlock mode setting.

2 Customized Features P. 124, 337

Lock

Unlock

145

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

Co
ntrols

If you do not have the key on you, or if for
some reason you cannot lock a door using the
key, you can lock the door without it.

■

Locking the driver’s door

Push the lock tab forward

a

 or push the

master door lock switch in the lock direction

b

, and close the door.

■

Locking the passenger’s doors

Push the lock tab forward and close the door.

■

Lockout prevention system

The doors cannot be locked when the key is in the ignition switch.

The doors cannot be locked when the smart entry remote is inside the vehicle.

■

Locking a Door Without Using a Key

1

Locking a Door Without Using a Key

When you lock the driver’s door, all the other doors
lock at the same time.
Before locking a door, make sure that the key is not
inside the vehicle.

Models without smart entry system

Models with smart entry system

146

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Inside

Co
ntrols

Locking/Unlocking the Doors from the Inside

■

Locking a door

Push the lock tab forward.

■

Unlocking a door

Pull the lock tab rearward.

■

Using the Lock Tab

1

Using the Lock Tab

When you lock the door using the lock tab on the
driver’s door, all of the other doors lock at the same
time.
When you unlock the door using the lock tab on the
driver’s door, only the driver’s door will unlock.

To Unlock

Lock Tab

To Lock

Continued

147

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Inside

Co
ntrols

Pull the front door inner handle.

u

The door unlocks and opens in one
motion.

Unlocking and opening the driver’s door from the inner handle unlocks all the other
doors.

To avoid all the doors to be unlocked, use the lock tab on the driver’s door to unlock,
then lock again before opening the door.

u

This setting works for one time only.
If you do not want all the doors to be unlocked all the time, customize the
Auto Door Unlock setting to Off using the driver information interface or
audio/information screen.

2 Customized Features P. 124, 337

■

Unlocking Using the Front Door Inner Handle

1

Unlocking Using the Front Door Inner Handle

The front door inner handles are designed to allow
front seat occupants to open the door in one motion.
However, this feature requires that front seat
occupants never pull a front door inner handle while
the vehicle is in motion.

Children should always ride in a rear seat where
childproof door locks are provided.

2 Childproof Door Locks P. 148

Inner
Handle

uu

Locking and Unlocking the Doors

u

Childproof Door Locks

148

Co
ntrols

Press the master door lock switch in as shown
to lock or unlock all doors.

Childproof Door Locks

The childproof door locks prevent the rear doors from being opened from the inside
regardless of the position of the lock tab.

Slide the lever in the rear door to the lock
position, and close the door.

■

When opening the door

Open the door using the outside door handle.

■

Using the Master Door Lock Switch

1

Using the Master Door Lock Switch

When you lock/unlock either of the front doors using
the master lock switch, all the other doors lock/
unlock at the same time.

To Unlock

Master Door
Lock Switch

To Lock

■

Setting the Childproof Door Locks

1

Childproof Door Locks

To open the door from the inside when the
childproof door lock is on, put the lock tab in the
unlock position, lower the rear window, put your
hand out of the window, and pull the outside door
handle.

Lock

Unlock

149

uu

Locking and Unlocking the Doors

u

Auto Door Locking/Unlocking

Co
ntrols

Auto Door Locking/Unlocking

Your vehicle locks or unlocks all doors automatically when a certain condition is met.

■

Drive lock mode

All doors lock when the vehicle’s speed reaches about 10 mph (15 km/h).

■

Driver’s door open mode

All doors unlock when the driver’s door is opened.

■

Auto Door Locking

■

Auto Door Unlocking

1

Auto Door Locking/Unlocking

You can turn off or change to another auto door
locking/unlocking setting using the driver
information interface or audio/information screen.

2 Customized Features P. 124, 337

150

Co
ntrols

Opening and Closing the Trunk

Precautions for Opening/Closing the Trunk

■

Opening the trunk

Open the trunk all the way.

u

If it is not fully opened, the trunk lid may begin to close under its own weight.

■

Closing the trunk

Keep the trunk lid closed while driving to:

u

Avoid possible damage.

u

Prevent exhaust gas from leaking into the vehicle.

2 Exhaust Gas Hazard P. 73

Using the Trunk Opener

Press and hold the trunk opener on the
driver’s door to unlock and open the trunk.

2 When You Cannot Open the Trunk P. 650

Trunk Opener

151

uu

Opening and Closing the Trunk

u

Using the Trunk Release Button

*

Co
ntrols

Using the Trunk Release Button

*

Push up the release button on the trunk lid
after the doors are unlocked.

2 When You Cannot Open the Trunk P. 650

Even if the trunk is locked, you can open the
trunk if you carry the smart entry remote.

u

Some exterior lights flash and the beeper
sounds.

Using the Remote Transmitter

Press the trunk release button for
approximately one second to unlock and open
the trunk.

1

Using the Trunk Release Button

*

•

If you forget the smart entry remote inside, the
beeper will sound and the trunk will not close.

•

A person who is not carrying the smart entry
remote can unlock the trunk if a person who is
carrying it is within range.

•

If the beeper sounds after you close the trunk,
move the smart entry remote away from the trunk
and close again.

•

The smart entry remote may not operate if it is too
close to the trunk.

Trunk Release Button

Trunk Release Button

* Not available on all models

152

uu

Opening and Closing the Trunk

u

Emergency Trunk Opener

Co
ntrols

Emergency Trunk Opener

The trunk release lever allows you to open the
trunk from inside for your safety.

Slide the release lever in the direction of the
arrow.

1

Emergency Trunk Opener

Parents should decide if their children should be
shown how to use this feature.

Lever

153

Continued

Co
ntrols

Security System

Immobilizer System

The immobilizer system prevents a key that has not been pre-registered from
starting the engine. Each key contains electronic transmitters that use electronic
signals to verify the key.

Pay attention to the following when inserting the key into the ignition switch or
pressing the ENGINE START/STOP button:
• Do not allow objects that emit strong radio waves near the ignition switch or the

ENGINE START/STOP button.

• Make sure the key is not covered by or touching a metal object.
• Do not bring a key from another vehicle’s immobilizer system near the ignition

switch or the ENGINE START/STOP button.

• Do not put the key near magnetic items. Electronic devices, such as televisions

and audio systems emit strong magnetic fields. Note that even a key chain can
become magnetic.

Security System Alarm

The security system alarm activates when the trunk, hood or doors are forcibly
opened. The alarm does not activate if the trunk or doors are opened with the key,
remote transmitter or smart entry system

*

.

However, the alarm activates if a door is opened with the key and then the
transmission is taken out of

(

P (continuously variable transmission models) or the

hood is opened before the ignition switch is turned to ON

(

w

*1

.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

1

Immobilizer System

NOTICE

Leaving the key in the vehicle can result in theft or
accidental movement of the vehicle.
Always take the key with you whenever you leave the
vehicle unattended.

Do not alter the system or add other devices to it.
Doing so may damage the system and make your
vehicle inoperable.

Canadian models only: Apply and hold the brake
pedal before turning the vehicle on the first time after
the battery has been disconnected.

1

Security System Alarm

Do not alter the system or add other devices to it.
Doing so may damage the system and make your
vehicle inoperable.

The security alarm continues for a maximum of two
minutes until the security system alarm deactivates.

* Not available on all models

uu

Security System

u

Security System Alarm

154

Co
ntrols

■

When the security system alarm activates

The horn sounds intermittently, and some exterior lights flash.

■

To deactivate the security system alarm

Unlock the vehicle using remote transmitter or smart entry system

*

, or turn the

ignition switch to ON

(

w

*1

. The system, along with the horn and flashing lights, is

deactivated.

■

Setting the security system alarm

The security system alarm automatically sets when the following conditions have
been met:
• The ignition switch is in LOCK

(

0

*1

, and the key has been removed from the

ignition switch.

• The hood and trunk are closed.
• All doors are locked with the key, the remote transmitter, or smart entry system

*

.

■

When the security system alarm sets

The security system alarm indicator in the instrument panel and the blinking interval
changes after about 15 seconds.

■

To cancel the security system alarm

The security system is canceled when the vehicle is unlocked using the remote
transmitter or smart entry system

*

, or when the ignition switch is turned to ON

(

w

*1

.

The security system indicator goes off at the same time.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

1

Security System Alarm

Do not set the security system alarm when someone
is in the vehicle or a window is open. The system can
accidentally activate when:

•

Unlocking the door with the lock tab.

•

Opening the trunk with the trunk opener on the
driver’s door or the emergency trunk opener.

•

Opening the hood with the hood release.

•

Taking the transmission out of

(

P.

If the battery goes dead after you have set the
security system alarm, the security alarm may activate
once the battery is recharged or replaced.
If this occurs, deactivate the security system alarm by
unlocking a door using the remote transmitter or
smart entry system

*

.

Continuously variable transmission models

* Not available on all models

155

uu

Security System

u

Security System Alarm

Co
ntrols

■

The panic button on the remote
transmitter

If you press the panic button for
approximately one second, the following will
occur for about 30 seconds:
• The horn sounds.
• Some exterior lights flash.

■

Canceling panic mode

Press any button on the remote transmitter, or turn the ignition switch to ON

(

w

*1

.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Panic Mode

Panic Button

156

Co
ntrols

Opening and Closing the Windows

Opening/Closing the Power Windows

The power windows can be opened and closed when the ignition switch is in ON

(

w

*1

, using the switches on the doors. The driver’s side switches can be used to

open and close all the windows.

The power window lock button on the driver’s side must be switched off (indicator
off) to open and close the windows from anywhere other than the driver’s seat.

When the power window lock button is pressed, the indicator comes on and you
can only operate the driver’s window. Turn the power window lock button on if a
child is in the vehicle.

■

Manual operation

To open: Push the switch down lightly, and
hold it until the desired position is reached.
To close: Pull the switch up lightly, and hold it
until the desired position is reached.

■

Automatic operation

To open: Push the switch down firmly.
To close: Pull the switch up firmly.

The window opens or closes completely. To
stop the window at any time, push or pull the
switch briefly.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Opening/Closing the Windows with Auto-Open/Close Function

1

Opening/Closing the Power Windows

The power windows can be operated for up to 10
minutes after you turn the ignition switch to LOCK

(

0

*1

.

Opening either front door cancels this function.

Auto Reverse
If a power window senses resistance when closing
automatically, it will stop closing and reverse
direction.

The driver’s window auto reverse function is disabled
when you continuously pull up the switch.

The auto reverse function stops sensing when the
window is almost closed to ensure that it fully closes.

3

WARNING

Closing a power window on someone’s
hands or fingers can cause serious injury.

Make sure your passengers are away from
the windows before closing them.

Power Window
Lock Button

Indicator

Driver’s
Window
Switch

Front Passenger’s
Window Switch

157

uu

Opening and Closing the Windows

u

Opening/Closing the Power Windows

Continued

Co
ntrols

To open: Push the switch down.
To close: Pull the switch up.

Release the switch when the window reaches
the desired position.

To open: Press the unlock button, and then
within 10 seconds, press it again and hold it. If
the windows and moonroof

*

 stop midway,

repeat the procedure.

■

Opening/Closing the Windows without Auto-Open/Close
Function

Close

Open

■

Opening the Windows and Moonroof

*

 with the Remote

Unlock Button

* Not available on all models

158

uu

Opening and Closing the Windows

u

Opening/Closing the Power Windows

Co
ntrols

To open: Unlock the driver’s door with the
key. Within 10 seconds of returning the key to
the central position, turn the key in the unlock
direction and hold it there.
To close: Lock the driver’s door with the key.
Within 10 seconds of returning the key to the
central position, turn the key in the lock
direction and hold it there.

Release the key to stop the windows and
moonroof at the desired position. If you want
further adjustment, repeat the same
operation.

■

Opening/Closing the Windows and Moonroof

*

 with the Key

Close

Open

* Not available on all models

159

Co
ntrols

Moonroof

*

You can only operate the moonroof when the power mode is in ON. Use the switch
in the front of the ceiling to open and close the moonroof.

■

Automatic operation

To open: Pull the switch back firmly.
To close: Push the switch forward firmly.

The moonroof will automatically open or close
all the way. To stop the moonroof midway,
touch the switch briefly.

■

Manual operation

To open: Pull the switch back lightly, and
hold it until the desired position is reached.
To close: Push the switch forward lightly, and
hold it until the desired position is reached.

■

Tilting the moonroof up

To tilt: Push on the center of the moonroof
switch.
To close: Push the switch forward firmly,
then release.

■

Opening/Closing the Moonroof

1

Opening/Closing the Moonroof

NOTICE

Opening the moonroof in below freezing
temperature or when it is covered with snow or ice
can damage the moonroof panel or motor.

The power moonroof can be operated for up to 10
minutes after you set the power mode to VEHICLE
OFF (LOCK).
Opening either front door cancels this function.

When resistance is detected, the auto reverse
function causes the moonroof to change directions,
then stop. Auto reverse stops sensing when the
moonroof is almost closed to ensure that it fully
closes.

You can use the remote transmitter or the key to
operate the moonroof.

2 Opening the Windows and Moonroof

*



with the Remote P. 157

2 Opening/Closing the Windows and

Moonroof

*

 with the Key P. 158

3

WARNING

Opening or closing the moonroof on
someone’s hands or fingers can cause
serious injury.

Make sure all hands and fingers are clear of
the moonroof before opening or closing it.

Open

Close

Tilt

* Not available on all models
